Rotary Encoder
Omron
[OMRON] — E6A2-C Incremental Rotary Encoder (A/B Phases, Open-collector NPN (12~24 VDC), 12~24 VDC)
Family ID: OMRON-E6A2-AB-C5
OMRON E6A2-C Series 25mm incremental rotary encoder. Output phases A, B. Open-collector NPN (12~24 VDC). 12~24 VDC. 100, 200, 360, 500 pulses/rotation. Cable 0.5m.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6A2-CW5C 100P/R 0.5M | E6A2-C AB 100P/R Open-collector NPN (12~24 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (12~24 VDC) | Power Supply: 12~24 VDC | Resolution: 100P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm | ||
| E6A2-CW5C 200P/R 0.5M | E6A2-C AB 200P/R Open-collector NPN (12~24 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (12~24 VDC) | Power Supply: 12~24 VDC | Resolution: 200P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm | ||
| E6A2-CW5C 360P/R 0.5M | E6A2-C AB 360P/R Open-collector NPN (12~24 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (12~24 VDC) | Power Supply: 12~24 VDC | Resolution: 360P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm | ||
| E6A2-CW5C 500P/R 0.5M | E6A2-C AB 500P/R Open-collector NPN (12~24 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (12~24 VDC) | Power Supply: 12~24 VDC | Resolution: 500P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm |
