![[OMRON] — E6CP-A General-purpose Absolute Rotary Encoder (50mm, 256 divisions, Open-collector)](https://img.prosourcemro.com/2026/05/001-414-1024x683.png)
Rotary Encoder
Omron
[OMRON] — E6CP-A General-purpose Absolute Rotary Encoder (50mm, 256 divisions, Open-collector)
Family ID: OMRON-E6CP
OMRON E6CP-A Series 50mm low-cost general-purpose absolute rotary encoder. 256 divisions (8-bit). Open-collector output. Cable 2m. E6CP-AG3C: 5~12 VDC. E6CP-AG5C: 12~24 VDC. E6CP-AG5C-C: 12~24 VDC with H8PS Cam Positioner connector.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6CP-AG3C 256P/R 2M | E6CP-A Absolute 256div OC 5~12V 2m | OMRON | Encoder Type: Absolute | Diameter: 50 mm | Resolution: 256 divisions (8-bit) | Output Type: Open-collector | Power Supply: 5~12 VDC | Cable: 2 m | H8PS Connector: None | ||
| E6CP-AG5C 256P/R 2M | E6CP-A Absolute 256div OC 12~24V 2m | OMRON | Encoder Type: Absolute | Diameter: 50 mm | Resolution: 256 divisions (8-bit) | Output Type: Open-collector | Power Supply: 12~24 VDC | Cable: 2 m | H8PS Connector: None | ||
| E6CP-AG5C-C 256P/R 2M | E6CP-A Absolute 256div OC 12~24V 2m H8PS connector | OMRON | Encoder Type: Absolute | Diameter: 50 mm | Resolution: 256 divisions (8-bit) | Output Type: Open-collector | Power Supply: 12~24 VDC | Cable: 2 m | H8PS Connector: Supported (for H8PS Cam Positioner only) | Note: Cannot be used with other models |
