![[OMRON] — E6A2-C Incremental Rotary Encoder (A/B Phases, Open-collector NPN (5~12 VDC), 5~12 VDC)](https://prosourcemro.com/wp-content/uploads/2026/05/001-407-1024x683.png)
Rotary Encoder
Omron
[OMRON] — E6A2-C Incremental Rotary Encoder (A/B Phases, Open-collector NPN (5~12 VDC), 5~12 VDC)
Family ID: OMRON-E6A2-AB-C3
OMRON E6A2-C Series 25mm incremental rotary encoder. Output phases A, B. Open-collector NPN (5~12 VDC). 5~12 VDC. 100, 200, 360, 500 pulses/rotation. Cable 0.5m.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6A2-CW3C 100P/R 0.5M | E6A2-C AB 100P/R Open-collector NPN (5~12 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (5~12 VDC) | Power Supply: 5~12 VDC | Resolution: 100P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm | ||
| E6A2-CW3C 200P/R 0.5M | E6A2-C AB 200P/R Open-collector NPN (5~12 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (5~12 VDC) | Power Supply: 5~12 VDC | Resolution: 200P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm | ||
| E6A2-CW3C 360P/R 0.5M | E6A2-C AB 360P/R Open-collector NPN (5~12 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (5~12 VDC) | Power Supply: 5~12 VDC | Resolution: 360P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm | ||
| E6A2-CW3C 500P/R 0.5M | E6A2-C AB 500P/R Open-collector NPN (5~12 VDC) 0.5m | OMRON | Output Phases: A, B | Output Type: Open-collector NPN (5~12 VDC) | Power Supply: 5~12 VDC | Resolution: 500P/R | Cable: 0.5 m | Encoder Type: Incremental | Diameter: 25 mm |
