Rotary Encoder
Omron
[OMRON] — E6F-A Absolute Rotary Encoder (Gray, NPN, Pre-wired, 12~24VDC, 60mm)
Family ID: OMRON-E6FA-GRAY-NPN
OMRON E6F-A 60mm rugged absolute encoder. Gray code, NPN. 256/360/720/1,024 P/R. Pre-wired 2m.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6F-AG5C 256P/R 2M | Gray NPN pre-wired 256P/R 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: Gray | Output: NPN open-collector | Power Supply: 12~24 VDC | Resolution: 256P/R | Connection: Pre-wired 2 m | ||
| E6F-AG5C 360P/R 2M | Gray NPN pre-wired 360P/R 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: Gray | Output: NPN open-collector | Power Supply: 12~24 VDC | Resolution: 360P/R | Connection: Pre-wired 2 m | ||
| E6F-AG5C 720P/R 2M | Gray NPN pre-wired 720P/R 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: Gray | Output: NPN open-collector | Power Supply: 12~24 VDC | Resolution: 720P/R | Connection: Pre-wired 2 m | ||
| E6F-AG5C 1,024P/R 2M | Gray NPN pre-wired 1,024P/R 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: Gray | Output: NPN open-collector | Power Supply: 12~24 VDC | Resolution: 1,024P/R | Connection: Pre-wired 2 m |
