Rotary Encoder
Omron
[OMRON] — E6F-A Absolute Rotary Encoder (BCD, NPN/PNP, 360P/R, 60mm Rugged)
Family ID: OMRON-E6FA-BCD
OMRON E6F-A 60mm rugged absolute encoder. BCD code. 360 P/R. NPN: 5~12V pre-wired+conn, 12~24V pre-wired+conn. PNP: 12~24V pre-wired. Cable 2m.
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E6F-AB3C 360P/R 2M | BCD NPN 5~12V pre-wired 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: BCD | Output: NPN open-collector | Power Supply: 5~12 VDC | Resolution: 360 P/R | Connection: Pre-wired 2 m | Note: 5m cable model also available | ||
| E6F-AB3C-C 360P/R 2M | BCD NPN 5~12V conn 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: BCD | Output: NPN open-collector | Power Supply: 5~12 VDC | Resolution: 360 P/R | Connection: Pre-wired Connector 2 m | Note: 5m cable model also available | ||
| E6F-AB5C 360P/R 2M | BCD NPN 12~24V pre-wired 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: BCD | Output: NPN open-collector | Power Supply: 12~24 VDC | Resolution: 360 P/R | Connection: Pre-wired 2 m | ||
| E6F-AB5C-C 360P/R 2M | BCD NPN 12~24V conn 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: BCD | Output: NPN open-collector | Power Supply: 12~24 VDC | Resolution: 360 P/R | Connection: Pre-wired Connector 2 m | ||
| E6F-AB5B 360P/R 2M | BCD PNP 12~24V pre-wired 2m | OMRON | Encoder Type: Absolute | Diameter: 60 mm | Code: BCD | Output: PNP open-collector | Power Supply: 12~24 VDC | Resolution: 360 P/R | Connection: Pre-wired 2 m |
