Rotary Encoder Omron

[OMRON] — E6H-C Hollow-shaft Rotary Encoder (Line-driver output, 5~12 VDC, 300~3600P/R)

Family ID: OMRON-E6H-LD

OMRON E6H-C Series 40mm hollow-shaft incremental rotary encoder. Line-driver output. 5~12 VDC. 300~3,600 P/R (15 resolutions). A/B/Z phases. Cable 0.5m.

15 product codes available in this family

Product Codes & Specifications

	Product Code	Description	Brand	Spec
	E6H-CWZ3X 300P/R 0.5M	E6H-C Line-driver output 300P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 300P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 360P/R 0.5M	E6H-C Line-driver output 360P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 360P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 500P/R 0.5M	E6H-C Line-driver output 500P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 500P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 600P/R 0.5M	E6H-C Line-driver output 600P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 600P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 720P/R 0.5M	E6H-C Line-driver output 720P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 720P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 800P/R 0.5M	E6H-C Line-driver output 800P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 800P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 1,000P/R 0.5M	E6H-C Line-driver output 1,000P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,000P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 1,024P/R 0.5M	E6H-C Line-driver output 1,024P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,024P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 1,200P/R 0.5M	E6H-C Line-driver output 1,200P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,200P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 1,500P/R 0.5M	E6H-C Line-driver output 1,500P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,500P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 1,800P/R 0.5M	E6H-C Line-driver output 1,800P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,800P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 2,000P/R 0.5M	E6H-C Line-driver output 2,000P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 2,000P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 2,048P/R 0.5M	E6H-C Line-driver output 2,048P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 2,048P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 2,500P/R 0.5M	E6H-C Line-driver output 2,500P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 2,500P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
	E6H-CWZ3X 3,600P/R 0.5M	E6H-C Line-driver output 3,600P/R 0.5m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 3,600P/R \| Output Phases: A, B, Z \| Cable: 0.5 m \| Encoder Type: Incremental Hollow-shaft \| Diameter: 40 mm
