Rotary Encoder Omron

[OMRON] — E6C3-C Rugged Incremental Rotary Encoder (Line-driver Output, 5~12VDC, 100~3600P/R)

Family ID: OMRON-E6C3-LD

OMRON E6C3-C Series 50mm rugged incremental rotary encoder. Line-driver output. 5~12 VDC. 100~3600 P/R (17 resolutions). A/B/Z phases. Pre-wired 1m.

17 product codes available in this family

Product Codes & Specifications

	Product Code	Description	Brand	Spec
	E6C3-CWZ3XH 100P/R 1M	E6C3-C Line-driver 100P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 100P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 200P/R 1M	E6C3-C Line-driver 200P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 200P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 300P/R 1M	E6C3-C Line-driver 300P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 300P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 360P/R 1M	E6C3-C Line-driver 360P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 360P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 500P/R 1M	E6C3-C Line-driver 500P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 500P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 600P/R 1M	E6C3-C Line-driver 600P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 600P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 720P/R 1M	E6C3-C Line-driver 720P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 720P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 800P/R 1M	E6C3-C Line-driver 800P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 800P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 1,000P/R 1M	E6C3-C Line-driver 1,000P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,000P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 1,024P/R 1M	E6C3-C Line-driver 1,024P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,024P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 1,200P/R 1M	E6C3-C Line-driver 1,200P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,200P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 1,500P/R 1M	E6C3-C Line-driver 1,500P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,500P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 1,800P/R 1M	E6C3-C Line-driver 1,800P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 1,800P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 2,000P/R 1M	E6C3-C Line-driver 2,000P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 2,000P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 2,048P/R 1M	E6C3-C Line-driver 2,048P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 2,048P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 2,500P/R 1M	E6C3-C Line-driver 2,500P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 2,500P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
	E6C3-CWZ3XH 3,600P/R 1M	E6C3-C Line-driver 3,600P/R 1m	OMRON	Output Type: Line-driver output \| Power Supply: 5~12 VDC \| Resolution: 3,600P/R \| Output Phases: A, B, Z \| Cable: 1 m \| Encoder Type: Incremental \| Diameter: 50 mm \| Type: Rugged
