[WIDIN] — EB302140W Carbide Ball End Mill

Family ID: 386-6373

WIDIN EB302140W Carbide Ball End Mill is a solid carbide cutting tool designed for precision milling of contoured and 3D surfaces, sourced direct from Korea. Ball end mills of this type are widely used in mold and die machining, aerospace component finishing, and general CNC profiling where curved geometries and smooth surface finishes are required. Request a quote today for export-ready supply through a KITA-registered Korean exporter, with competitive pricing available for both sample orders and high-volume procurement.

15 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code	Description	Brand	Spec
386-6373	EB302140W	WIDIN	2F*14MM(EB302140) \| Spec: 14 \| Cutting Length: 28 \| Number of Flutes: 2 \| Overall Length: 98 \| Shank Length: 60 \| Shank Diameter: 16
386-6391	EB302150W	WIDIN	2F*15MM(EB302150) \| Spec: 15 \| Cutting Length: 28 \| Number of Flutes: 2날 \| Overall Length: 98 \| 생크길이: 60 \| Shank Diameter: 16
386-6407	EB302160W	WIDIN	2F*16MM(EB302160) \| Spec: 16 \| Cutting Length: 28 \| Number of Flutes: 2날 \| Overall Length: 98 \| 생크길이: 60 \| Shank Diameter: 16
386-6425	EB302170W	WIDIN	2F*17MM(EB302170) \| Spec: 17 \| Cutting Length: 32 \| Number of Flutes: 2날 \| Overall Length: 115 \| 생크길이: 70 \| Shank Diameter: 20
386-6434	EB302180W	WIDIN	2F*18MM(EB302180) \| Spec: 18 \| Cutting Length: 32 \| Number of Flutes: 2날 \| Overall Length: 115 \| 생크길이: 70 \| Shank Diameter: 20
386-6461	EB302200W	WIDIN	2F*20MM(EB302200) \| Spec: 20 \| Cutting Length: 32 \| Number of Flutes: 2날 \| Overall Length: 115 \| 생크길이: 70 \| Shank Diameter: 20
386-6522	EB302240W	WIDIN	2F*24MM(EB302240) \| Spec: 24 \| Cutting Length: 40 \| Number of Flutes: 2날 \| Overall Length: 140 \| 생크길이: 85 \| Shank Diameter: 25
386-6540	EB302250W	WIDIN	2F*25MM(EB302250) \| Spec: 25 \| Cutting Length: 40 \| Number of Flutes: 2날 \| Overall Length: 140 \| 생크길이: 85 \| Shank Diameter: 25
386-6559	EB302260W	WIDIN	2F*26MM(EB302260) \| Spec: 26 \| Cutting Length: 40 \| Number of Flutes: 2날 \| Overall Length: 140 \| 생크길이: 85 \| Shank Diameter: 25
386-6577	EB302280W	WIDIN	2F*28MM(EB302280) \| Spec: 28 \| Cutting Length: 40 \| Number of Flutes: 2날 \| Overall Length: 140 \| 생크길이: 85 \| Shank Diameter: 25
386-6586	EB302300W	WIDIN	2F*30MM(EB302300) \| Spec: 30 \| Cutting Length: 50 \| Number of Flutes: 2날 \| Overall Length: 150 \| 생크길이: 85 \| Shank Diameter: 32
386-6601	EB302320W	WIDIN	2F*32MM(EB302320) \| Spec: 32 \| Cutting Length: 50 \| Number of Flutes: 2 \| Overall Length: 150 \| Shank Length: 85 \| Shank Diameter: 32
386-6610	EB302350W	WIDIN	2F*35MM(EB302350) \| Spec: 35 \| Cutting Length: 50 \| Number of Flutes: 2 \| Overall Length: 150 \| Shank Length: 85 \| Shank Diameter: 32
386-6629	EB302400W	WIDIN	2F*40MM(EB302400W) \| Spec: 40 \| Cutting Length: 55 \| Number of Flutes: 2날 \| Overall Length: 155 \| 생크길이: 85 \| Shank Diameter: 32
386-6638	EB302450W	WIDIN	2F*45MM(EB302450) \| Spec: 45 \| Cutting Length: 63 \| Number of Flutes: 2날 \| Overall Length: 160 \| 생크길이: 85 \| Shank Diameter: 32
