[Yuken] — A3HG Series High Pressure Variable Displacement Piston Pump (External Pilot Constant Power Control, 37.1-180.7 cm3/rev)
Piston Pumps Yuken

[Yuken] — A3HG Series High Pressure Variable Displacement Piston Pump (External Pilot Constant Power Control, 37.1-180.7 cm3/rev)

Family ID: YUKEN-A3HG-09V

"A3HG" Series High Pressure Variable Displacement Piston Pump - Constant Power Control Type With External Pilot.

12 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
A3HG37-FR09V-10 Yuken A3HG37 (37.1 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Flange mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG37-LR09V-10 Yuken A3HG37 (37.1 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Foot mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG37 | Geometric Displacement: 37.1 cm3/rev | Min. Adjustment Flow: 16 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2700 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG56-FR09V-10 Yuken A3HG56 (56.3 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Flange mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG56-LR09V-10 Yuken A3HG56 (56.3 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Foot mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG56 | Geometric Displacement: 56.3 cm3/rev | Min. Adjustment Flow: 35 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2500 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG71-FR09V-10 Yuken A3HG71 (70.7 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Flange mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG71-LR09V-10 Yuken A3HG71 (70.7 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Foot mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG71 | Geometric Displacement: 70.7 cm3/rev | Min. Adjustment Flow: 45 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2300 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG100-FR09V-10 Yuken A3HG100 (100.5 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Flange mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG100-LR09V-10 Yuken A3HG100 (100.5 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Foot mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG100 | Geometric Displacement: 100.5 cm3/rev | Min. Adjustment Flow: 63 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-2100 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG145-FR09V-10 Yuken A3HG145 (145.2 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Flange mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG145-LR09V-10 Yuken A3HG145 (145.2 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Foot mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG145 | Geometric Displacement: 145.2 cm3/rev | Min. Adjustment Flow: 95 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG180-FR09V-10 Yuken A3HG180 (180.7 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Flange mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
A3HG180-LR09V-10 Yuken A3HG180 (180.7 cm3/rev) ISO high-pressure External Pilot Constant Power Control, Foot mount; shaft/port/bolt specified at order Yuken Series: A3HG | Frame: A3HG180 | Geometric Displacement: 180.7 cm3/rev | Min. Adjustment Flow: 130 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: External Pilot Constant Power Control (09V) | Shaft Power Setting: Specify at order (7.5-110 kW range, per frame) (RFQ) | Min. Adjustment Pressure: 5 MPa | Rated Pressure: 31.5 MPa | Max. Working Pressure: 35 MPa | Allowable Speed: 600-1800 r/min | Shaft End: K (parallel key) / SP (high-torque spline) / SP1 (ISO 3019-1 spline) - specify at order (RFQ) | Port / Thread Standard: E1 (ISO 3019-2, metric) / E2 (ISO 3019-1, metric) / U1 (UNF) / U2 (BSPP) / J1 (Rc) - specify at order (RFQ) | Mounting Bolts: 2 (C) or 4 (D) - specify at order (RFQ) | Thru-Drive: 2nd pump mounting (thru-drive) available - RFQ | Design Number: 10 | Mass: Varies by configuration
