Yuken — DSG-03 Explosion Proof (Increased Safety) Solenoid Operated Directional Valve
Family ID: YUK-DSG03-IS
Explosion Proof (Increased Safety) Type Solenoid Operated Directional Valves, DSG-03 (eG3). Increased-safety construction (recommended for class 2 areas): max. operating pressure 31.5 MPa (spool 5,60) / 25 MPa, max. flow 120 L/min, tank back pressure 16 MPa. Subplate mounting.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| DSG-03-3C*-eG3-50 | DSG-03 explosion-proof (Increased Safety) solenoid directional valve, spool group 3C (3-position, spring centered) | Yuken | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 31.5 MPa (spool 5,60) / 25 MPa | Max Flow: 120 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 3Cx (per base DSG-03 table) | Spring: 3-position, spring centered | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 50 | ||
| DSG-03-2D2-eG3-50 | DSG-03 explosion-proof (Increased Safety) solenoid directional valve, spool group 2D2 (2-position, no-spring detented) | Yuken | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 31.5 MPa (spool 5,60) / 25 MPa | Max Flow: 120 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 2D2 | Spring: 2-position, no-spring detented | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 50 | ||
| DSG-03-2B*-eG3-50 | DSG-03 explosion-proof (Increased Safety) solenoid directional valve, spool group 2B (2-position, spring offset) | Yuken | Type: Explosion-proof Increased Safety (Solenoid Operated) | Valve Size: 03 (Rc 3/8) | Max Pressure: 31.5 MPa (spool 5,60) / 25 MPa | Max Flow: 120 L/min | Explosion-proof Class: eG3 | Mounting: Subplate (ISO 4401) | Spool Group: 2Bx (per base DSG-03 table) | Spring: 2-position, spring offset | Spool Selection: Per base DSG model table (RFQ) | Coil: DC / rectified R type (RFQ) | Design No.: 50 |
