Yuken — L-DSG-01 Energy-Saving Solenoid Operated Directional Valve
Family ID: YUK-LDSG01
1/8 Solenoid Operated Directional Valves, DSG-01 Series — Energy-saving type. Max. operating pressure 16 MPa, max. flow 40 L/min, tank back pressure 16 MPa, max. switching frequency 300 min-1 (R solenoid) / 120 min-1. Detailed specifications by inquiry. Subplate mounting.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| L-DSG-01-3C*-*-70 | L-DSG-01 solenoid directional valve, spool group 3C (3-position, spring centered) | Yuken | Type: Energy-saving (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 16 MPa | Max Flow: 40 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 300 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 3Cx (spool no. per base table) | Spring: 3-position, spring centered | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 70 | Note: Energy-saving type — detailed spec by separate inquiry | ||
| L-DSG-01-2D2-*-70 | L-DSG-01 solenoid directional valve, spool group 2D2 (2-position, no-spring detented) | Yuken | Type: Energy-saving (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 16 MPa | Max Flow: 40 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 300 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2D2 | Spring: 2-position, no-spring detented | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 70 | Note: Energy-saving type — detailed spec by separate inquiry | ||
| L-DSG-01-2N*-*-70 | L-DSG-01 solenoid directional valve, spool group 2N (2-position, no-spring) | Yuken | Type: Energy-saving (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 16 MPa | Max Flow: 40 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 300 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2Nx (spool no. per base table) | Spring: 2-position, no-spring | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 70 | Note: Energy-saving type — detailed spec by separate inquiry | ||
| L-DSG-01-2B*-*-70 | L-DSG-01 solenoid directional valve, spool group 2B (2-position, spring offset) | Yuken | Type: Energy-saving (Solenoid Operated) | Valve Size: 01 (Rc 1/8) | Max Pressure: 16 MPa | Max Flow: 40 L/min | Tank Back Pressure: 16 MPa | Max Switching Freq: 300 (R) / 120 min-1 | Mounting: Subplate (ISO 4401) | Spool Group: 2Bx (spool no. per base table) | Spring: 2-position, spring offset | Spool Selection: Per base DSG model table (specify at RFQ) | Coil: AC/DC/R (RFQ) | Wiring: Per base series (RFQ) | Design No.: 70 | Note: Energy-saving type — detailed spec by separate inquiry |
