Apex Dynamics ADS Shaft-Input Precision Planetary Gearboxes (047-255)

Apex Dynamics ADS Shaft-Input Precision Planetary Gearboxes (047-255)

APEX Dynamics ADS series high-precision planetary gearboxes with a solid input shaft and ISO 9409 flange output, in seven frame sizes from 047 to 255 and ratios 4 to 91.

Key features

  • Input shaft version of the AD series with straddle-mounted oversized input bearings for high radial and axial input loads
  • Input shaft options S1 smooth and S2 with key; frame sizes ADS047 to ADS255
  • 1-stage ratios 4, 5, 7, 10; 2-stage ratios 16, 21, 31, 61, 91
  • Backlash classes P0 micro (<=1/<=3 arcmin, ADS090 1-stage and ADS110-ADS255), P1 reduced (<=3/<=5), P2 standard (<=5/<=7)
  • Nominal output torque 14 to 2,000 Nm; input radial load up to 12,500 N, input axial load up to 8,000 N
  • Example order code ADS047-010-S1-P1 / SIEMENS 1FT5 034-OAK71

Specifications

Type Inline planetary gearbox, shaft input, flange output
Code format ADS<size>-<ratio>-<shaft>-<backlash>
Torsional rigidity 3 to 225 Nm/arcmin (047-255)
Max. tilting moment M2K 55 to 5,500 Nm
Max. input speed 3,800 to 10,000 rpm
Weight 0.8 to 74.7 kg
Noise <=56 to <=70 dB(A)
Lubrication Synthetic lubrication oil, lubricated for life
Protection / mounting IP65, any mounting position
Operating temperature -10 to +90 C
Source APEX Dynamics AD catalog, p. 3, 11-16
ADS047-004-S1-P1 Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-004-S1-P2 Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-004-S2-P1 Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-004-S2-P2 Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-005-S1-P1 Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-005-S1-P2 Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-005-S2-P1 Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-005-S2-P2 Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-007-S1-P1 Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-007-S1-P2 Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-007-S2-P1 Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-007-S2-P2 Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-010-S1-P1 Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-010-S1-P2 Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-010-S2-P1 Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS047-010-S2-P2 Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS047-016-S1-P1 Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-016-S1-P2 Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-016-S2-P1 Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-016-S2-P2 Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-021-S1-P1 Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-021-S1-P2 Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-021-S2-P1 Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-021-S2-P2 Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-031-S1-P1 Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-031-S1-P2 Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-031-S2-P1 Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-031-S2-P2 Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-061-S1-P1 Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-061-S1-P2 Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-061-S2-P1 Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-061-S2-P2 Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-091-S1-P1 Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-091-S1-P2 Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-091-S2-P1 Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS047-091-S2-P2 Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS064-004-S1-P1 Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-004-S1-P2 Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-004-S2-P1 Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-004-S2-P2 Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-005-S1-P1 Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-005-S1-P2 Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-005-S2-P1 Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-005-S2-P2 Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-007-S1-P1 Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-007-S1-P2 Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-007-S2-P1 Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-007-S2-P2 Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-010-S1-P1 Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-010-S1-P2 Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-010-S2-P1 Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS064-010-S2-P2 Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS064-016-S1-P1 Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-016-S1-P2 Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-016-S2-P1 Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-016-S2-P2 Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-021-S1-P1 Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-021-S1-P2 Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-021-S2-P1 Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-021-S2-P2 Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-031-S1-P1 Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-031-S1-P2 Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-031-S2-P1 Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-031-S2-P2 Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-061-S1-P1 Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-061-S1-P2 Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-061-S2-P1 Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-061-S2-P2 Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-091-S1-P1 Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-091-S1-P2 Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-091-S2-P1 Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS064-091-S2-P2 Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS090-004-S1-P0 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-004-S1-P1 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-004-S1-P2 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-004-S2-P0 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-004-S2-P1 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-004-S2-P2 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-005-S1-P0 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-005-S1-P1 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-005-S1-P2 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-005-S2-P0 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-005-S2-P1 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-005-S2-P2 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-007-S1-P0 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-007-S1-P1 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-007-S1-P2 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-007-S2-P0 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-007-S2-P1 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-007-S2-P2 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-010-S1-P0 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-010-S1-P1 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-010-S1-P2 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-010-S2-P0 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-010-S2-P1 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-010-S2-P2 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-016-S1-P1 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-016-S1-P2 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-016-S2-P1 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-016-S2-P2 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-021-S1-P1 Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-021-S1-P2 Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-021-S2-P1 Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-021-S2-P2 Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-031-S1-P1 Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-031-S1-P2 Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-031-S2-P1 Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-031-S2-P2 Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-061-S1-P1 Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-061-S1-P2 Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-061-S2-P1 Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-061-S2-P2 Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-091-S1-P1 Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-091-S1-P2 Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-091-S2-P1 Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-091-S2-P2 Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS110-004-S1-P0 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-004-S1-P1 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-004-S1-P2 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-004-S2-P0 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-004-S2-P1 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-004-S2-P2 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-005-S1-P0 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-005-S1-P1 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-005-S1-P2 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-005-S2-P0 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-005-S2-P1 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-005-S2-P2 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-007-S1-P0 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-007-S1-P1 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-007-S1-P2 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-007-S2-P0 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-007-S2-P1 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-007-S2-P2 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-010-S1-P0 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-010-S1-P1 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-010-S1-P2 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-010-S2-P0 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-010-S2-P1 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-010-S2-P2 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-016-S1-P0 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-016-S1-P1 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-016-S1-P2 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-016-S2-P0 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-016-S2-P1 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-016-S2-P2 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-021-S1-P0 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-021-S1-P1 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-021-S1-P2 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-021-S2-P0 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-021-S2-P1 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-021-S2-P2 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-031-S1-P0 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-031-S1-P1 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-031-S1-P2 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-031-S2-P0 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-031-S2-P1 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-031-S2-P2 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-061-S1-P0 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-061-S1-P1 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-061-S1-P2 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-061-S2-P0 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-061-S2-P1 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-061-S2-P2 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-091-S1-P0 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-091-S1-P1 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-091-S1-P2 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-091-S2-P0 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-091-S2-P1 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-091-S2-P2 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS140-004-S1-P0 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-004-S1-P1 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-004-S1-P2 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-004-S2-P0 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-004-S2-P1 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-004-S2-P2 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-005-S1-P0 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-005-S1-P1 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-005-S1-P2 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-005-S2-P0 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-005-S2-P1 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-005-S2-P2 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-007-S1-P0 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-007-S1-P1 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-007-S1-P2 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-007-S2-P0 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-007-S2-P1 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-007-S2-P2 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-010-S1-P0 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-010-S1-P1 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-010-S1-P2 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-010-S2-P0 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-010-S2-P1 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-010-S2-P2 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-016-S1-P0 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-016-S1-P1 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-016-S1-P2 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-016-S2-P0 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-016-S2-P1 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-016-S2-P2 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-021-S1-P0 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-021-S1-P1 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-021-S1-P2 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-021-S2-P0 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-021-S2-P1 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-021-S2-P2 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-031-S1-P0 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-031-S1-P1 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-031-S1-P2 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-031-S2-P0 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-031-S2-P1 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-031-S2-P2 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-061-S1-P0 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-061-S1-P1 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-061-S1-P2 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-061-S2-P0 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-061-S2-P1 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-061-S2-P2 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-091-S1-P0 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-091-S1-P1 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-091-S1-P2 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-091-S2-P0 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-091-S2-P1 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-091-S2-P2 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS200-004-S1-P0 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-004-S1-P1 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-004-S1-P2 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-004-S2-P0 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-004-S2-P1 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-004-S2-P2 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-005-S1-P0 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-005-S1-P1 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-005-S1-P2 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-005-S2-P0 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-005-S2-P1 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-005-S2-P2 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-007-S1-P0 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-007-S1-P1 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-007-S1-P2 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-007-S2-P0 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-007-S2-P1 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-007-S2-P2 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-010-S1-P0 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-010-S1-P1 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-010-S1-P2 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-010-S2-P0 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-010-S2-P1 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-010-S2-P2 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-016-S1-P0 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-016-S1-P1 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-016-S1-P2 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-016-S2-P0 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-016-S2-P1 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-016-S2-P2 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-021-S1-P0 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-021-S1-P1 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-021-S1-P2 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-021-S2-P0 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-021-S2-P1 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-021-S2-P2 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-031-S1-P0 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-031-S1-P1 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-031-S1-P2 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-031-S2-P0 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-031-S2-P1 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-031-S2-P2 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-061-S1-P0 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-061-S1-P1 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-061-S1-P2 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-061-S2-P0 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-061-S2-P1 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-061-S2-P2 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-091-S1-P0 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-091-S1-P1 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-091-S1-P2 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-091-S2-P0 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-091-S2-P1 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-091-S2-P2 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS255-004-S1-P0 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-004-S1-P1 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-004-S1-P2 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-004-S2-P0 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-004-S2-P1 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-004-S2-P2 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-005-S1-P0 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-005-S1-P1 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-005-S1-P2 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-005-S2-P0 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-005-S2-P1 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-005-S2-P2 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-007-S1-P0 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-007-S1-P1 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-007-S1-P2 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-007-S2-P0 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-007-S2-P1 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-007-S2-P2 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-010-S1-P0 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-010-S1-P1 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-010-S1-P2 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-010-S2-P0 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-010-S2-P1 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-010-S2-P2 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-016-S1-P0 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-016-S1-P1 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-016-S1-P2 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-016-S2-P0 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-016-S2-P1 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-016-S2-P2 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-021-S1-P0 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-021-S1-P1 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-021-S1-P2 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-021-S2-P0 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-021-S2-P1 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-021-S2-P2 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-031-S1-P0 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-031-S1-P1 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-031-S1-P2 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-031-S2-P0 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-031-S2-P1 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-031-S2-P2 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-061-S1-P0 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-061-S1-P1 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-061-S1-P2 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-061-S2-P0 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-061-S2-P1 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-061-S2-P2 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-091-S1-P0 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-091-S1-P1 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-091-S1-P2 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-091-S2-P0 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-091-S2-P1 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-091-S2-P2 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
Planetary GearboxesApex Dynamics
332 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics ADS Shaft-Input Precision Planetary Gearboxes (047-255)

Brand Apex Dynamics·Planetary Gearboxes

Available part numbers (332)

ADS047-004-S1-P1, ADS047-004-S1-P2, ADS047-004-S2-P1, ADS047-004-S2-P2, ADS047-005-S1-P1, ADS047-005-S1-P2, ADS047-005-S2-P1, ADS047-005-S2-P2, ADS047-007-S1-P1, ADS047-007-S1-P2 + 322 more — see full table ↓

How to order

Send the Apex Dynamics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ADS047-004-S1-P1Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-004-S1-P2Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-004-S2-P1Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-004-S2-P2Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-005-S1-P1Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-005-S1-P2Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-005-S2-P1Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-005-S2-P2Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-007-S1-P1Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-007-S1-P2Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-007-S2-P1Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-007-S2-P2Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-010-S1-P1Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-010-S1-P2Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-010-S2-P1Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS047-010-S2-P2Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS047-016-S1-P1Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-016-S1-P2Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-016-S2-P1Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-016-S2-P2Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-021-S1-P1Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-021-S1-P2Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 22 Nm
ADS047-021-S2-P1Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-021-S2-P2Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 22 Nm
ADS047-031-S1-P1Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-031-S1-P2Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-031-S2-P1Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-031-S2-P2Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-061-S1-P1Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-061-S1-P2Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 19 Nm
ADS047-061-S2-P1Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-061-S2-P2Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 19 Nm
ADS047-091-S1-P1Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-091-S1-P2Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 14 Nm
ADS047-091-S2-P1Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS047-091-S2-P2Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 14 Nm
ADS064-004-S1-P1Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-004-S1-P2Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-004-S2-P1Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-004-S2-P2Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-005-S1-P1Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-005-S1-P2Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-005-S2-P1Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-005-S2-P2Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-007-S1-P1Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-007-S1-P2Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-007-S2-P1Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-007-S2-P2Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-010-S1-P1Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-010-S1-P2Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-010-S2-P1Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS064-010-S2-P2Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS064-016-S1-P1Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-016-S1-P2Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 48 Nm
ADS064-016-S2-P1Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-016-S2-P2Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 48 Nm
ADS064-021-S1-P1Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-021-S1-P2Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 60 Nm
ADS064-021-S2-P1Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-021-S2-P2Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 60 Nm
ADS064-031-S1-P1Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-031-S1-P2Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-031-S2-P1Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-031-S2-P2Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-061-S1-P1Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-061-S1-P2Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 50 Nm
ADS064-061-S2-P1Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-061-S2-P2Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 50 Nm
ADS064-091-S1-P1Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-091-S1-P2Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 40 Nm
ADS064-091-S2-P1Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS064-091-S2-P2Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 40 Nm
ADS090-004-S1-P0Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-004-S1-P1Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-004-S1-P2Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-004-S2-P0Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-004-S2-P1Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-004-S2-P2Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-005-S1-P0Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-005-S1-P1Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-005-S1-P2Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-005-S2-P0Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-005-S2-P1Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-005-S2-P2Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-007-S1-P0Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-007-S1-P1Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-007-S1-P2Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-007-S2-P0Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-007-S2-P1Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-007-S2-P2Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-010-S1-P0Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-010-S1-P1Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-010-S1-P2Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-010-S2-P0Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-010-S2-P1Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-010-S2-P2Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-016-S1-P1Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-016-S1-P2Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 130 Nm
ADS090-016-S2-P1Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-016-S2-P2Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 130 Nm
ADS090-021-S1-P1Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-021-S1-P2Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 160 Nm
ADS090-021-S2-P1Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-021-S2-P2Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 160 Nm
ADS090-031-S1-P1Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-031-S1-P2Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-031-S2-P1Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-031-S2-P2Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-061-S1-P1Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-061-S1-P2Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 140 Nm
ADS090-061-S2-P1Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-061-S2-P2Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 140 Nm
ADS090-091-S1-P1Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-091-S1-P2Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 100 Nm
ADS090-091-S2-P1Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS090-091-S2-P2Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 100 Nm
ADS110-004-S1-P0Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-004-S1-P1Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-004-S1-P2Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-004-S2-P0Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-004-S2-P1Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-004-S2-P2Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-005-S1-P0Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-005-S1-P1Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-005-S1-P2Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-005-S2-P0Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-005-S2-P1Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-005-S2-P2Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-007-S1-P0Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-007-S1-P1Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-007-S1-P2Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-007-S2-P0Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-007-S2-P1Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-007-S2-P2Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-010-S1-P0Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-010-S1-P1Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-010-S1-P2Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-010-S2-P0Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-010-S2-P1Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-010-S2-P2Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-016-S1-P0Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-016-S1-P1Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-016-S1-P2Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 270 Nm
ADS110-016-S2-P0Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-016-S2-P1Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-016-S2-P2Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 270 Nm
ADS110-021-S1-P0Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-021-S1-P1Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-021-S1-P2Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 330 Nm
ADS110-021-S2-P0Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-021-S2-P1Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-021-S2-P2Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 330 Nm
ADS110-031-S1-P0Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-031-S1-P1Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-031-S1-P2Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-031-S2-P0Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-031-S2-P1Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-031-S2-P2Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-061-S1-P0Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-061-S1-P1Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-061-S1-P2Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 300 Nm
ADS110-061-S2-P0Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-061-S2-P1Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-061-S2-P2Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 300 Nm
ADS110-091-S1-P0Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-091-S1-P1Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-091-S1-P2Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 230 Nm
ADS110-091-S2-P0Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-091-S2-P1Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS110-091-S2-P2Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 230 Nm
ADS140-004-S1-P0Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-004-S1-P1Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-004-S1-P2Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-004-S2-P0Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-004-S2-P1Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-004-S2-P2Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-005-S1-P0Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-005-S1-P1Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-005-S1-P2Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-005-S2-P0Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-005-S2-P1Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-005-S2-P2Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-007-S1-P0Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-007-S1-P1Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-007-S1-P2Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-007-S2-P0Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-007-S2-P1Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-007-S2-P2Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-010-S1-P0Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-010-S1-P1Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-010-S1-P2Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-010-S2-P0Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-010-S2-P1Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-010-S2-P2Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-016-S1-P0Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-016-S1-P1Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-016-S1-P2Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 560 Nm
ADS140-016-S2-P0Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-016-S2-P1Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-016-S2-P2Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 560 Nm
ADS140-021-S1-P0Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-021-S1-P1Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-021-S1-P2Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 650 Nm
ADS140-021-S2-P0Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-021-S2-P1Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-021-S2-P2Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 650 Nm
ADS140-031-S1-P0Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-031-S1-P1Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-031-S1-P2Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-031-S2-P0Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-031-S2-P1Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-031-S2-P2Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-061-S1-P0Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-061-S1-P1Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-061-S1-P2Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 550 Nm
ADS140-061-S2-P0Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-061-S2-P1Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-061-S2-P2Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 550 Nm
ADS140-091-S1-P0Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-091-S1-P1Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-091-S1-P2Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 450 Nm
ADS140-091-S2-P0Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-091-S2-P1Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS140-091-S2-P2Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 450 Nm
ADS200-004-S1-P0Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-004-S1-P1Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-004-S1-P2Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-004-S2-P0Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-004-S2-P1Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-004-S2-P2Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-005-S1-P0Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-005-S1-P1Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-005-S1-P2Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-005-S2-P0Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-005-S2-P1Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-005-S2-P2Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-007-S1-P0Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-007-S1-P1Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-007-S1-P2Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-007-S2-P0Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-007-S2-P1Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-007-S2-P2Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-010-S1-P0Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-010-S1-P1Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-010-S1-P2Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-010-S2-P0Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-010-S2-P1Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-010-S2-P2Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-016-S1-P0Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-016-S1-P1Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-016-S1-P2Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-016-S2-P0Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-016-S2-P1Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-016-S2-P2Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-021-S1-P0Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-021-S1-P1Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-021-S1-P2Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,200 Nm
ADS200-021-S2-P0Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-021-S2-P1Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-021-S2-P2Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,200 Nm
ADS200-031-S1-P0Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-031-S1-P1Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-031-S1-P2Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-031-S2-P0Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-031-S2-P1Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-031-S2-P2Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-061-S1-P0Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-061-S1-P1Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-061-S1-P2Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,100 Nm
ADS200-061-S2-P0Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-061-S2-P1Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-061-S2-P2Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,100 Nm
ADS200-091-S1-P0Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-091-S1-P1Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-091-S1-P2Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 900 Nm
ADS200-091-S2-P0Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-091-S2-P1Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS200-091-S2-P2Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 900 Nm
ADS255-004-S1-P0Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-004-S1-P1Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-004-S1-P2Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-004-S2-P0Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-004-S2-P1Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-004-S2-P2Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-005-S1-P0Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-005-S1-P1Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-005-S1-P2Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-005-S2-P0Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-005-S2-P1Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-005-S2-P2Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-007-S1-P0Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-007-S1-P1Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-007-S1-P2Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-007-S2-P0Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-007-S2-P1Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-007-S2-P2Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-010-S1-P0Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-010-S1-P1Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-010-S1-P2Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-010-S2-P0Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-010-S2-P1Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-010-S2-P2Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-016-S1-P0Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-016-S1-P1Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-016-S1-P2Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,700 Nm
ADS255-016-S2-P0Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-016-S2-P1Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-016-S2-P2Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,700 Nm
ADS255-021-S1-P0Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-021-S1-P1Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-021-S1-P2Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 2,000 Nm
ADS255-021-S2-P0Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-021-S2-P1Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-021-S2-P2Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 2,000 Nm
ADS255-031-S1-P0Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-031-S1-P1Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-031-S1-P2Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-031-S2-P0Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-031-S2-P1Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-031-S2-P2Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-061-S1-P0Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-061-S1-P1Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-061-S1-P2Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,800 Nm
ADS255-061-S2-P0Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-061-S2-P1Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-061-S2-P2Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,800 Nm
ADS255-091-S1-P0Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-091-S1-P1Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-091-S1-P2Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S1 smooth | Nominal torque T2N: 1,500 Nm
ADS255-091-S2-P0Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-091-S2-P1Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm
ADS255-091-S2-P2Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Input shaft: S2 keyed | Nominal torque T2N: 1,500 Nm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →
