Apex Dynamics Lubrication Tubes, Connectors and Fixing Sockets

Apex Dynamics Lubrication Tubes, Connectors and Fixing Sockets

Apex Dynamics tubing and fittings for the smart lubrication system: spring-protected flexible main tubes, PA12 tubes empty or pre-filled with grease, in-line, right-angle and tube connectors, non-return valves, oil filling connectors and LUG 400 fixing sockets.

Key features

  • Flexible tube set FTS08 (approx. 10/15 m, max. 100 bar) recommended for main lines over 5 m
  • PA12 tubes 4/6/8 mm: empty (T04/T06/T08) or pre-filled with G02, G03 or G04 grease (T0x-02/-03/-04)
  • In-line (TB), right-angle (R-TB) and tube connectors (C-TB) in copper; TBS / R-TBS / C-TBS in stainless steel
  • Connector threads M3 to M10, G 1/8", G 1/4" and R 1/8"; max. 80 bar, -30 to +100 C
  • RV right-angle non-return valves prevent backflow; TB-x-22 oil filling connectors (M22 x 2.0) for cartridge refilling
  • BK-01 to BK-05 fixing sockets (SPCC, black paint) for mounting the LUG 400

Specifications

Connector operating pressure Max. 80 bar
Connector temperature -30 to +100 C
Flexible tube set Max. 100 bar, -30 to +80 C, nickel-plated spring
PA tube pressure 25 kg/cm2 (4 mm), 28 kg/cm2 (6/8 mm) at 20 C
PA tube temperature -40 to +80 C
Tube selection PA tube < 1 m: 4 mm; > 1 m: 6 mm
Source APEX Dynamics Smart Lubrication System catalog, p. 12-18
FTS08-1000 Item: Flexible tube set | Tube OD: 8 mm | Connection: M10 x 1.0 both ends | Material: Spring-protected | Variant: Approx. 10 m
FTS08-1500 Item: Flexible tube set | Tube OD: 8 mm | Connection: M10 x 1.0 both ends | Material: Spring-protected | Variant: Approx. 15 m
FTC08-01 Item: Flexible tube in-line connector | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: For 10 m set
FTC08-02 Item: Flexible tube in-line connector | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: For 15 m set
R-FTC08-01 Item: Flexible tube right-angle conn. | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Use with in-line conn.
PTS08-1000 Item: Protective tube spring | Tube OD: 8 mm | Connection: - | Material: Nickel-plated spring steel | Variant: L1 10 m
PTS08-1500 Item: Protective tube spring | Tube OD: 8 mm | Connection: - | Material: Nickel-plated spring steel | Variant: L1 15 m
TB-401 Item: In-line connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Carbon steel | Variant: Fig D
TBS-401 Item: In-line connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Stainless steel | Variant: Fig D
TB-402 Item: In-line connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
TBS-402 Item: In-line connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
TB-403 Item: In-line connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
TBS-403 Item: In-line connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
TB-404 Item: In-line connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
TBS-404 Item: In-line connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
TB-405 Item: In-line connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
TBS-405 Item: In-line connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
TB-406 Item: In-line connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
TBS-406 Item: In-line connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
TB-407 Item: In-line connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
TBS-407 Item: In-line connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
TB-601 Item: In-line connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
TBS-601 Item: In-line connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
TB-602 Item: In-line connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
TBS-602 Item: In-line connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
TB-603 Item: In-line connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
TBS-603 Item: In-line connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
TB-604 Item: In-line connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
TBS-604 Item: In-line connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
TB-605 Item: In-line connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
TBS-605 Item: In-line connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
TB-606 Item: In-line connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
TBS-606 Item: In-line connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
TB-607 Item: In-line connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
TBS-607 Item: In-line connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
TB-608 Item: In-line connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Copper | Variant: Fig C
TBS-608 Item: In-line connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig C
TB-801 Item: In-line connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
TBS-801 Item: In-line connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
TB-802 Item: In-line connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
TBS-802 Item: In-line connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
TB-803 Item: In-line connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
TBS-803 Item: In-line connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
R-TB-401 Item: Right-angle connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Carbon steel | Variant: Fig A
R-TBS-401 Item: Right-angle connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Stainless steel | Variant: Fig A
R-TB-402 Item: Right-angle connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
R-TBS-402 Item: Right-angle connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
R-TB-403 Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
R-TBS-403 Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
R-TB-404 Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
R-TBS-404 Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-405 Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
R-TBS-405 Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-406 Item: Right-angle connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
R-TBS-406 Item: Right-angle connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-407 Item: Right-angle connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
R-TBS-407 Item: Right-angle connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
R-TB-408 Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig D
R-TBS-408 Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-409 Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig D
R-TBS-409 Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-410 Item: Right-angle connector | Tube OD: 4 mm | Connection: R 1/8" | Material: Copper | Variant: Fig D
R-TBS-410 Item: Right-angle connector | Tube OD: 4 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig D
R-TB-601 Item: Right-angle connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
R-TBS-601 Item: Right-angle connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
R-TB-602 Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
R-TBS-602 Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
R-TB-603 Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
R-TBS-603 Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-604 Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
R-TBS-604 Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-605 Item: Right-angle connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
R-TBS-605 Item: Right-angle connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-606 Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
R-TBS-606 Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
R-TB-607 Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
R-TBS-607 Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
R-TB-608 Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Copper | Variant: Fig C
R-TBS-608 Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig C
R-TB-609 Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig D
R-TBS-609 Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-610 Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig D
R-TBS-610 Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-611 Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Copper | Variant: Fig D
R-TBS-611 Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig D
R-TB-801 Item: Right-angle connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
R-TBS-801 Item: Right-angle connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-802 Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
R-TBS-802 Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
R-TB-803 Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
R-TBS-803 Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
C-TB-401 Item: Tube connector | Tube OD: 4 mm | Connection: Straight union | Material: Copper | Variant: Fig A
C-TBS-401 Item: Tube connector | Tube OD: 4 mm | Connection: Straight union | Material: Stainless steel | Variant: Fig A
C-TB-402 Item: Tube connector | Tube OD: 4 mm | Connection: Elbow union | Material: Copper | Variant: Fig C
C-TBS-402 Item: Tube connector | Tube OD: 4 mm | Connection: Elbow union | Material: Stainless steel | Variant: Fig C
C-TB-403 Item: Tube connector | Tube OD: 4 mm | Connection: Plug-in stem 6 mm | Material: Copper | Variant: Fig D
C-TBS-403 Item: Tube connector | Tube OD: 4 mm | Connection: Plug-in stem 6 mm | Material: Stainless steel | Variant: Fig D
C-TB-601 Item: Tube connector | Tube OD: 6 mm | Connection: Straight union | Material: Copper | Variant: Fig A
C-TBS-601 Item: Tube connector | Tube OD: 6 mm | Connection: Straight union | Material: Stainless steel | Variant: Fig A
C-TB-602 Item: Tube connector | Tube OD: 6 mm | Connection: Reducing union to 4 mm | Material: Copper | Variant: Fig B
C-TBS-602 Item: Tube connector | Tube OD: 6 mm | Connection: Reducing union to 4 mm | Material: Stainless steel | Variant: Fig B
C-TB-603 Item: Tube connector | Tube OD: 6 mm | Connection: Elbow union | Material: Copper | Variant: Fig C
C-TBS-603 Item: Tube connector | Tube OD: 6 mm | Connection: Elbow union | Material: Stainless steel | Variant: Fig C
C-TB-604 Item: Tube connector | Tube OD: 6 mm | Connection: Plug-in stem 4 mm | Material: Copper | Variant: Fig D
C-TBS-604 Item: Tube connector | Tube OD: 6 mm | Connection: Plug-in stem 4 mm | Material: Stainless steel | Variant: Fig D
C-TB-801 Item: Tube connector | Tube OD: 8 mm | Connection: Reducing union to 6 mm | Material: Copper | Variant: Fig B
C-TBS-801 Item: Tube connector | Tube OD: 8 mm | Connection: Reducing union to 6 mm | Material: Stainless steel | Variant: Fig B
C-TB-802 Item: Tube connector | Tube OD: 8 mm | Connection: Plug-in stem 6 mm | Material: Copper | Variant: Fig D
C-TBS-802 Item: Tube connector | Tube OD: 8 mm | Connection: Plug-in stem 6 mm | Material: Stainless steel | Variant: Fig D
RV-TB-401 Item: Right-angle non-return valve | Tube OD: 4 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Anti-backflow
RV-TBS-401 Item: Right-angle non-return valve | Tube OD: 4 mm | Connection: M10 x 1.0 | Material: Stainless steel | Variant: Anti-backflow
RV-TB-601 Item: Right-angle non-return valve | Tube OD: 6 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Anti-backflow
RV-TBS-601 Item: Right-angle non-return valve | Tube OD: 6 mm | Connection: M10 x 1.0 | Material: Stainless steel | Variant: Anti-backflow
RV-TB-801 Item: Right-angle non-return valve | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Anti-backflow
RV-TBS-801 Item: Right-angle non-return valve | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Stainless steel | Variant: Anti-backflow
TB-4-22 Item: Oil filling connector | Tube OD: 4 mm | Connection: M22 x 2.0 | Material: - | Variant: Cartridge refilling
TB-6-22 Item: Oil filling connector | Tube OD: 6 mm | Connection: M22 x 2.0 | Material: - | Variant: Cartridge refilling
TB-8-22 Item: Oil filling connector | Tube OD: 8 mm | Connection: M22 x 2.0 | Material: - | Variant: Cartridge refilling
T04 Item: PA12 tube, empty | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: 200 m package
T06 Item: PA12 tube, empty | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: 200 m package
T08 Item: PA12 tube, empty | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: 100 m package
T04-02 Item: PA12 tube, pre-filled | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: Food grade grease G02, 5 m
T06-02 Item: PA12 tube, pre-filled | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: Food grade grease G02, 5 m
T08-02 Item: PA12 tube, pre-filled | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: Food grade grease G02, 5 m
T04-03 Item: PA12 tube, pre-filled | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: Low temp. grease G03, 5 m
T06-03 Item: PA12 tube, pre-filled | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: Low temp. grease G03, 10 m
T08-03 Item: PA12 tube, pre-filled | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: Low temp. grease G03, 10 m
T04-04 Item: PA12 tube, pre-filled | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: Standard grease G04, 5 m
T06-04 Item: PA12 tube, pre-filled | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: Standard grease G04, 10 m
T08-04 Item: PA12 tube, pre-filled | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: Standard grease G04, 10 m
BK-01 Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 1
BK-02 Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 2
BK-03 Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 3
BK-04 Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 4
BK-05 Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 5
Lubrication SystemsApex Dynamics
135 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics Lubrication Tubes, Connectors and Fixing Sockets

Brand Apex Dynamics·Lubrication Systems

Available part numbers (135)

FTS08-1000, FTS08-1500, FTC08-01, FTC08-02, R-FTC08-01, PTS08-1000, PTS08-1500, TB-401, TBS-401, TB-402 + 125 more — see full table ↓

How to order

Send the Apex Dynamics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FTS08-1000Item: Flexible tube set | Tube OD: 8 mm | Connection: M10 x 1.0 both ends | Material: Spring-protected | Variant: Approx. 10 m
FTS08-1500Item: Flexible tube set | Tube OD: 8 mm | Connection: M10 x 1.0 both ends | Material: Spring-protected | Variant: Approx. 15 m
FTC08-01Item: Flexible tube in-line connector | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: For 10 m set
FTC08-02Item: Flexible tube in-line connector | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: For 15 m set
R-FTC08-01Item: Flexible tube right-angle conn. | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Use with in-line conn.
PTS08-1000Item: Protective tube spring | Tube OD: 8 mm | Connection: - | Material: Nickel-plated spring steel | Variant: L1 10 m
PTS08-1500Item: Protective tube spring | Tube OD: 8 mm | Connection: - | Material: Nickel-plated spring steel | Variant: L1 15 m
TB-401Item: In-line connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Carbon steel | Variant: Fig D
TBS-401Item: In-line connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Stainless steel | Variant: Fig D
TB-402Item: In-line connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
TBS-402Item: In-line connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
TB-403Item: In-line connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
TBS-403Item: In-line connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
TB-404Item: In-line connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
TBS-404Item: In-line connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
TB-405Item: In-line connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
TBS-405Item: In-line connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
TB-406Item: In-line connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
TBS-406Item: In-line connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
TB-407Item: In-line connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
TBS-407Item: In-line connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
TB-601Item: In-line connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
TBS-601Item: In-line connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
TB-602Item: In-line connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
TBS-602Item: In-line connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
TB-603Item: In-line connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
TBS-603Item: In-line connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
TB-604Item: In-line connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
TBS-604Item: In-line connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
TB-605Item: In-line connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
TBS-605Item: In-line connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
TB-606Item: In-line connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
TBS-606Item: In-line connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
TB-607Item: In-line connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
TBS-607Item: In-line connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
TB-608Item: In-line connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Copper | Variant: Fig C
TBS-608Item: In-line connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig C
TB-801Item: In-line connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
TBS-801Item: In-line connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
TB-802Item: In-line connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
TBS-802Item: In-line connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
TB-803Item: In-line connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
TBS-803Item: In-line connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
R-TB-401Item: Right-angle connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Carbon steel | Variant: Fig A
R-TBS-401Item: Right-angle connector | Tube OD: 4 mm | Connection: M3x0.5 | Material: Stainless steel | Variant: Fig A
R-TB-402Item: Right-angle connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
R-TBS-402Item: Right-angle connector | Tube OD: 4 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
R-TB-403Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
R-TBS-403Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
R-TB-404Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
R-TBS-404Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-405Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
R-TBS-405Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-406Item: Right-angle connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
R-TBS-406Item: Right-angle connector | Tube OD: 4 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-407Item: Right-angle connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
R-TBS-407Item: Right-angle connector | Tube OD: 4 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
R-TB-408Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig D
R-TBS-408Item: Right-angle connector | Tube OD: 4 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-409Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig D
R-TBS-409Item: Right-angle connector | Tube OD: 4 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-410Item: Right-angle connector | Tube OD: 4 mm | Connection: R 1/8" | Material: Copper | Variant: Fig D
R-TBS-410Item: Right-angle connector | Tube OD: 4 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig D
R-TB-601Item: Right-angle connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Carbon steel | Variant: Fig A
R-TBS-601Item: Right-angle connector | Tube OD: 6 mm | Connection: M5x0.8 | Material: Stainless steel | Variant: Fig A
R-TB-602Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Copper | Variant: Fig A
R-TBS-602Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x0.75 | Material: Stainless steel | Variant: Fig A
R-TB-603Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig A
R-TBS-603Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-604Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig A
R-TBS-604Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-605Item: Right-angle connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
R-TBS-605Item: Right-angle connector | Tube OD: 6 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-606Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
R-TBS-606Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
R-TB-607Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
R-TBS-607Item: Right-angle connector | Tube OD: 6 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
R-TB-608Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Copper | Variant: Fig C
R-TBS-608Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig C
R-TB-609Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Copper | Variant: Fig D
R-TBS-609Item: Right-angle connector | Tube OD: 6 mm | Connection: M6x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-610Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Copper | Variant: Fig D
R-TBS-610Item: Right-angle connector | Tube OD: 6 mm | Connection: M8x1.0 | Material: Stainless steel | Variant: Fig D
R-TB-611Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Copper | Variant: Fig D
R-TBS-611Item: Right-angle connector | Tube OD: 6 mm | Connection: R 1/8" | Material: Stainless steel | Variant: Fig D
R-TB-801Item: Right-angle connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Copper | Variant: Fig A
R-TBS-801Item: Right-angle connector | Tube OD: 8 mm | Connection: M10x1.0 | Material: Stainless steel | Variant: Fig A
R-TB-802Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Copper | Variant: Fig A
R-TBS-802Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/8" | Material: Stainless steel | Variant: Fig A
R-TB-803Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Copper | Variant: Fig B
R-TBS-803Item: Right-angle connector | Tube OD: 8 mm | Connection: G 1/4" | Material: Stainless steel | Variant: Fig B
C-TB-401Item: Tube connector | Tube OD: 4 mm | Connection: Straight union | Material: Copper | Variant: Fig A
C-TBS-401Item: Tube connector | Tube OD: 4 mm | Connection: Straight union | Material: Stainless steel | Variant: Fig A
C-TB-402Item: Tube connector | Tube OD: 4 mm | Connection: Elbow union | Material: Copper | Variant: Fig C
C-TBS-402Item: Tube connector | Tube OD: 4 mm | Connection: Elbow union | Material: Stainless steel | Variant: Fig C
C-TB-403Item: Tube connector | Tube OD: 4 mm | Connection: Plug-in stem 6 mm | Material: Copper | Variant: Fig D
C-TBS-403Item: Tube connector | Tube OD: 4 mm | Connection: Plug-in stem 6 mm | Material: Stainless steel | Variant: Fig D
C-TB-601Item: Tube connector | Tube OD: 6 mm | Connection: Straight union | Material: Copper | Variant: Fig A
C-TBS-601Item: Tube connector | Tube OD: 6 mm | Connection: Straight union | Material: Stainless steel | Variant: Fig A
C-TB-602Item: Tube connector | Tube OD: 6 mm | Connection: Reducing union to 4 mm | Material: Copper | Variant: Fig B
C-TBS-602Item: Tube connector | Tube OD: 6 mm | Connection: Reducing union to 4 mm | Material: Stainless steel | Variant: Fig B
C-TB-603Item: Tube connector | Tube OD: 6 mm | Connection: Elbow union | Material: Copper | Variant: Fig C
C-TBS-603Item: Tube connector | Tube OD: 6 mm | Connection: Elbow union | Material: Stainless steel | Variant: Fig C
C-TB-604Item: Tube connector | Tube OD: 6 mm | Connection: Plug-in stem 4 mm | Material: Copper | Variant: Fig D
C-TBS-604Item: Tube connector | Tube OD: 6 mm | Connection: Plug-in stem 4 mm | Material: Stainless steel | Variant: Fig D
C-TB-801Item: Tube connector | Tube OD: 8 mm | Connection: Reducing union to 6 mm | Material: Copper | Variant: Fig B
C-TBS-801Item: Tube connector | Tube OD: 8 mm | Connection: Reducing union to 6 mm | Material: Stainless steel | Variant: Fig B
C-TB-802Item: Tube connector | Tube OD: 8 mm | Connection: Plug-in stem 6 mm | Material: Copper | Variant: Fig D
C-TBS-802Item: Tube connector | Tube OD: 8 mm | Connection: Plug-in stem 6 mm | Material: Stainless steel | Variant: Fig D
RV-TB-401Item: Right-angle non-return valve | Tube OD: 4 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Anti-backflow
RV-TBS-401Item: Right-angle non-return valve | Tube OD: 4 mm | Connection: M10 x 1.0 | Material: Stainless steel | Variant: Anti-backflow
RV-TB-601Item: Right-angle non-return valve | Tube OD: 6 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Anti-backflow
RV-TBS-601Item: Right-angle non-return valve | Tube OD: 6 mm | Connection: M10 x 1.0 | Material: Stainless steel | Variant: Anti-backflow
RV-TB-801Item: Right-angle non-return valve | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Copper | Variant: Anti-backflow
RV-TBS-801Item: Right-angle non-return valve | Tube OD: 8 mm | Connection: M10 x 1.0 | Material: Stainless steel | Variant: Anti-backflow
TB-4-22Item: Oil filling connector | Tube OD: 4 mm | Connection: M22 x 2.0 | Material: - | Variant: Cartridge refilling
TB-6-22Item: Oil filling connector | Tube OD: 6 mm | Connection: M22 x 2.0 | Material: - | Variant: Cartridge refilling
TB-8-22Item: Oil filling connector | Tube OD: 8 mm | Connection: M22 x 2.0 | Material: - | Variant: Cartridge refilling
T04Item: PA12 tube, empty | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: 200 m package
T06Item: PA12 tube, empty | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: 200 m package
T08Item: PA12 tube, empty | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: 100 m package
T04-02Item: PA12 tube, pre-filled | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: Food grade grease G02, 5 m
T06-02Item: PA12 tube, pre-filled | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: Food grade grease G02, 5 m
T08-02Item: PA12 tube, pre-filled | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: Food grade grease G02, 5 m
T04-03Item: PA12 tube, pre-filled | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: Low temp. grease G03, 5 m
T06-03Item: PA12 tube, pre-filled | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: Low temp. grease G03, 10 m
T08-03Item: PA12 tube, pre-filled | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: Low temp. grease G03, 10 m
T04-04Item: PA12 tube, pre-filled | Tube OD: 4 mm | Connection: ID 2.5 mm | Material: PA12 | Variant: Standard grease G04, 5 m
T06-04Item: PA12 tube, pre-filled | Tube OD: 6 mm | Connection: ID 4 mm | Material: PA12 | Variant: Standard grease G04, 10 m
T08-04Item: PA12 tube, pre-filled | Tube OD: 8 mm | Connection: ID 5 mm | Material: PA12 | Variant: Standard grease G04, 10 m
BK-01Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 1
BK-02Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 2
BK-03Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 3
BK-04Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 4
BK-05Item: LUG 400 fixing socket | Tube OD: - | Connection: - | Material: SPCC, black paint | Variant: Type 5

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Power Transmission →
