Apex Dynamics Helical Pinions - Keyway for AF/KF/AE/PII (Series E)

Apex Dynamics Helical Pinions - Keyway for AF/KF/AE/PII (Series E)

APEX Dynamics helical-teeth pinions with keyway for apex af / kf / ae / pii gearboxes interface for high-precision rack-and-pinion drives, module 2 to 3.

Key features

  • Helical teeth matched to APEX helical racks; left-hand helix pairs with right-hand helical racks
  • Interface: Keyway for APEX AF / KF / AE / PII gearboxes
  • Carburized alloy steel, case hardened to about 60 HRC, teeth ground to reduce noise and wear
  • Max. permitted torque and feed force per rack quality given in the catalog torque tables
  • Backlash depends on center height; contact APEX for adjustment guidance
  • Direct fit on APEX AF/AFR, KF, AE/AER and PEII gearbox output shafts

Specifications

Teeth Left-hand helical 19°31'42"
Interface Keyway for APEX AF / KF / AE / PII gearboxes
Quality DIN 5, Alloy Steel
Tooth thickness tolerance e25
Heat treatment Case hardened (carburized), approx. 60 HRC, teeth ground
Module range 2-3
Pinion series code E
Order code Series-Module-Teeth angle-Teeth no.-Fig-Size field, e.g. E02L18
Source APEX Dynamics High Precision Rack and Pinion catalog, p. 52-52
E02L18 Module: 2 | Teeth z: 18 | Gearbox: AF/AFR060, KF060, AE/AER070, PEII070
E02L22 Module: 2 | Teeth z: 22 | Gearbox: AF/AFR075, KF075, AE/AER090, PEII090
E02L26 Module: 2 | Teeth z: 26 | Gearbox: AF/AFR100, KF100, AE/AER120, PEII120
E03L24 Module: 3 | Teeth z: 24 | Gearbox: AF/AFR140, KF140, AE/AER155, PEII155
Racks & PinionsApex Dynamics
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics Helical Pinions - Keyway for AF/KF/AE/PII (Series E)

Brand Apex Dynamics·Racks & Pinions

Available part numbers (4)

E02L18, E02L22, E02L26, E03L24

How to order

Send the Apex Dynamics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
E02L18Module: 2 | Teeth z: 18 | Gearbox: AF/AFR060, KF060, AE/AER070, PEII070
E02L22Module: 2 | Teeth z: 22 | Gearbox: AF/AFR075, KF075, AE/AER090, PEII090
E02L26Module: 2 | Teeth z: 26 | Gearbox: AF/AFR100, KF100, AE/AER120, PEII120
E03L24Module: 3 | Teeth z: 24 | Gearbox: AF/AFR140, KF140, AE/AER155, PEII155
