Additional catalogue order codes for Apex Dynamics rack pinions: curvic-plate pinion sets in Fig. A mounting, a teeth-plate pinion with FB050 flange and a keyway pinion with 40 mm bore.

Key features

  • Pinions for direct mounting on Apex Dynamics planetary gearbox output flanges
  • Curvic and teeth plate versions for backlash-free, high-torque connection
  • Alloy steel, case-hardened, teeth ground
  • Helical (left-hand) and straight tooth versions
  • Matching racks available in qualities Q4 to Q10

Specifications

Material Alloy steel, case-hardened
Finish Teeth ground
Curvic/teeth plate quality DIN 4, tolerance e24
Keyway pinion quality DIN 5, tolerance e25
Helical pinions Left-hand helical teeth
Source Apex Dynamics Apex Dynamics High Precision Rack and Pinion catalogue, p. 35, 47, 82, 96
A02L17A031 Type: Helical, curvic plate | Module: 2 | Teeth z: 17 | Mounting: Fig. A, BC 31.5 mm
A02L20A050 Type: Helical, curvic plate | Module: 2 | Teeth z: 20 | Mounting: Fig. A, BC 50 mm
A03L17A050 Type: Helical, curvic plate | Module: 3 | Teeth z: 17 | Mounting: Fig. A, BC 50 mm
C02L29B040 Type: Helical, teeth plate | Module: 2 | Teeth z: 29 | Mounting: BC 50 mm, flange FB050
A02121A050 Type: Straight, curvic plate | Module: 2 | Teeth z: 21 | Mounting: Fig. A, BC 50 mm
F04120A40 Type: Straight, keyway bore | Module: 4 | Teeth z: 20 | Mounting: Fig. A, bore 40 mm H6
