APEX Dynamics straight-teeth pinions with long shaft with keyway for hollow shaft interface for high-precision rack-and-pinion drives, module 2 to 6.

Key features

  • Straight teeth matched to APEX straight racks; straight-cut for straight racks
  • Interface: Long shaft with keyway for hollow shaft
  • Carburized alloy steel, case hardened to about 60 HRC, teeth ground to reduce noise and wear
  • Max. permitted torque and feed force per rack quality given in the catalog torque tables
  • Backlash depends on center height; contact APEX for adjustment guidance

Specifications

Teeth Straight
Interface Long shaft with keyway for hollow shaft
Quality DIN 5
Tooth thickness tolerance e25
Heat treatment Case hardened (carburized), approx. 60 HRC, teeth ground
Module range 2-6
Pinion series code G
Order code Series-Module-Teeth angle-Teeth no.-Fig-Size field, e.g. G02115D20
Source APEX Dynamics High Precision Rack and Pinion catalog, p. 100-100
G02115D20 Module: 2 | Teeth z: 15 | Shaft d1 h6: 20 mm
G02121D25 Module: 2 | Teeth z: 21 | Shaft d1 h6: 25 mm
G02132D25 Module: 2 | Teeth z: 32 | Shaft d1 h6: 25 mm
G02132D28 Module: 2 | Teeth z: 32 | Shaft d1 h6: 28 mm
G02132D36 Module: 2 | Teeth z: 32 | Shaft d1 h6: 36 mm
G03121D25 Module: 3 | Teeth z: 21 | Shaft d1 h6: 25 mm
G03121D28 Module: 3 | Teeth z: 21 | Shaft d1 h6: 28 mm
G03121D36 Module: 3 | Teeth z: 21 | Shaft d1 h6: 36 mm
G04117D28 Module: 4 | Teeth z: 17 | Shaft d1 h6: 28 mm
G04117D36 Module: 4 | Teeth z: 17 | Shaft d1 h6: 36 mm
G04117D48 Module: 4 | Teeth z: 17 | Shaft d1 h6: 48 mm
G04130D48 Module: 4 | Teeth z: 30 | Shaft d1 h6: 48 mm
G05113D48 Module: 5 | Teeth z: 13 | Shaft d1 h6: 48 mm
G05115D60 Module: 5 | Teeth z: 15 | Shaft d1 h6: 60 mm
G06113D60 Module: 6 | Teeth z: 13 | Shaft d1 h6: 60 mm
