EAO Series 14 Terminal & PCB Accessories (22.5 mm compact)

EAO Series 14 Terminal & PCB Accessories (22.5 mm compact)

Terminal & PCB Accessories for the EAO Series 14 (compact 22.5 mm) HMI component range, listed by part number from the accessories section of the catalogue.

Key features

  • Compact 22.5 mm EAO Series 14 system enabling space-saving installations
  • Item options: PCB plug-in base, Flat receptacle, Insulation sleeve
  • Product attribute options: for low level sw. element, for snap-action sw. element 2.8 mm, 2.0x0.5 mm plug-in terminal, 2.8x0.5 mm plug-in terminal, Cover
  • Terminal options: PCB
  • Pins options: axial, right-angled
  • 8 part numbers exactly as printed in the ordering tables

Specifications

Brand EAO
Product family Terminal & PCB Accessories
Series EAO Series 14 (compact 22.5 mm)
Mounting cut-out Ø 22.5 mm
Catalogue EAO Series 14 catalogue (Edition 11/2013)
Part numbers 8 printed codes
Source EAO Series 14 catalogue (Edition 11/2013), p. 46-47
31-940 Item: PCB plug-in base | Product attribute: for low level switching element | Terminal: PCB | Pins: axial
31-941 Item: PCB plug-in base | Product attribute: for low level switching element | Terminal: PCB | Pins: right-angled
31-942 Item: PCB plug-in base | Product attribute: for snap-action switching element 2.8 mm | Terminal: PCB | Pins: axial
31-945 Item: Flat receptacle | Product attribute: 2.0 x 0.5 mm plug-in terminal | Terminal: - | Pins: -
31-946 Item: Flat receptacle | Product attribute: 2.8 x 0.5 mm plug-in terminal | Terminal: - | Pins: -
01-928 Item: Insulation sleeve | Product attribute: Cover plug-in terminals for snap-action | Terminal: - | Pins: -
31-928 Item: Insulation sleeve | Product attribute: for flat receptacle 2.0 mm | Terminal: - | Pins: -
31-929 Item: Insulation sleeve | Product attribute: for flat receptacle 2.8 mm | Terminal: - | Pins: -
Pushbutton AccessoriesEAO
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

EAO Series 14 Terminal & PCB Accessories (22.5 mm compact)

Brand EAO·Pushbutton Accessories

Available part numbers (8)

31-940, 31-941, 31-942, 31-945, 31-946, 01-928, 31-928, 31-929

How to order

Send the EAO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
