FAG ARCA-PUMP-BARREL Drum Pumps and Accessories (25/50/180 kg)

FAG ARCA-PUMP-BARREL Drum Pumps and Accessories (25/50/180 kg)

FAG ARCA-PUMP-BARREL-..-S pneumatic drum pumps deliver grease from 25 kg and 50 kg hobbocks and 180 kg drums for filling bearings and gearboxes, with dust covers, follower pistons and hoses.

Key features

  • Pneumatic pump, pressure ratio 70:1
  • Delivery rate 1 100 cm3/min, up to NLGI 2
  • Dust covers and zinc-coated follower pistons per container size
  • High pressure hoses 400 bar in 2-10 m lengths
  • Use with hand valve or metering pistol grease gun

Specifications

Pressure ratio 70:1
Air supply 3.5-8.5 bar
Connections G1/4
Source Schaeffler Lubricators TPI 252, p. 76-79
ARCA-PUMP-BARREL-25-S Order no.: 065139470-0000-10 | Type: Drum pump | Container: 25 kg | Size: Suction pipe 480 mm
ARCA-PUMP-BARREL-50-S Order no.: 065139542-0000-10 | Type: Drum pump | Container: 50 kg | Size: Suction pipe 750 mm
ARCA-PUMP-BARREL-180-S Order no.: 065139550-0000-10 | Type: Drum pump | Container: 180 kg | Size: Suction pipe 950 mm
ARCA-PUMP-BARREL-25-S.LID Order no.: 065348524-0000-10 | Type: Dust cover | Container: 25 kg | Size: dia. 350 mm
ARCA-PUMP-BARREL-50-S.LID Order no.: 065349849-0000-10 | Type: Dust cover | Container: 50 kg | Size: dia. 420 mm
ARCA-PUMP-BARREL-180-S.LID Order no.: 065350863-0000-10 | Type: Dust cover | Container: 180 kg | Size: dia. 600 mm
ARCA-PUMP-BARREL-25-S.FP Order no.: 065349687-0000-10 | Type: Follower piston | Container: 25 kg | Size: dia. 340 mm
ARCA-PUMP-BARREL-50-S.FP Order no.: 065350685-0000-10 | Type: Follower piston | Container: 50 kg | Size: dia. 400 mm
ARCA-PUMP-BARREL-180-S.FP Order no.: 065351592-0000-10 | Type: Follower piston | Container: 180 kg | Size: dia. 590 mm
ARCA-PUMP-BARREL.HOSE-2M Order no.: 065352270-0000-10 | Type: High pressure hose 400 bar | Size: 2 m
ARCA-PUMP-BARREL.HOSE-3M Order no.: 065352432-0000-10 | Type: High pressure hose 400 bar | Size: 3 m
ARCA-PUMP-BARREL.HOSE-5M Order no.: 065352866-0000-10 | Type: High pressure hose 400 bar | Size: 5 m
ARCA-PUMP-BARREL.HOSE-10M Order no.: 065353153-0000-10 | Type: High pressure hose 400 bar | Size: 10 m
LubricatorsFAG
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

FAG ARCA-PUMP-BARREL Drum Pumps and Accessories (25/50/180 kg)

Brand FAG·Lubricators

Available part numbers (13)

ARCA-PUMP-BARREL-25-S, ARCA-PUMP-BARREL-50-S, ARCA-PUMP-BARREL-180-S, ARCA-PUMP-BARREL-25-S.LID, ARCA-PUMP-BARREL-50-S.LID, ARCA-PUMP-BARREL-180-S.LID, ARCA-PUMP-BARREL-25-S.FP, ARCA-PUMP-BARREL-50-S.FP, ARCA-PUMP-BARREL-180-S.FP, ARCA-PUMP-BARREL.HOSE-2M + 3 more — see full table ↓

How to order

Send the FAG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ARCA-PUMP-BARREL-25-SOrder no.: 065139470-0000-10 | Type: Drum pump | Container: 25 kg | Size: Suction pipe 480 mm
ARCA-PUMP-BARREL-50-SOrder no.: 065139542-0000-10 | Type: Drum pump | Container: 50 kg | Size: Suction pipe 750 mm
ARCA-PUMP-BARREL-180-SOrder no.: 065139550-0000-10 | Type: Drum pump | Container: 180 kg | Size: Suction pipe 950 mm
ARCA-PUMP-BARREL-25-S.LIDOrder no.: 065348524-0000-10 | Type: Dust cover | Container: 25 kg | Size: dia. 350 mm
ARCA-PUMP-BARREL-50-S.LIDOrder no.: 065349849-0000-10 | Type: Dust cover | Container: 50 kg | Size: dia. 420 mm
ARCA-PUMP-BARREL-180-S.LIDOrder no.: 065350863-0000-10 | Type: Dust cover | Container: 180 kg | Size: dia. 600 mm
ARCA-PUMP-BARREL-25-S.FPOrder no.: 065349687-0000-10 | Type: Follower piston | Container: 25 kg | Size: dia. 340 mm
ARCA-PUMP-BARREL-50-S.FPOrder no.: 065350685-0000-10 | Type: Follower piston | Container: 50 kg | Size: dia. 400 mm
ARCA-PUMP-BARREL-180-S.FPOrder no.: 065351592-0000-10 | Type: Follower piston | Container: 180 kg | Size: dia. 590 mm
ARCA-PUMP-BARREL.HOSE-2MOrder no.: 065352270-0000-10 | Type: High pressure hose 400 bar | Size: 2 m
ARCA-PUMP-BARREL.HOSE-3MOrder no.: 065352432-0000-10 | Type: High pressure hose 400 bar | Size: 3 m
ARCA-PUMP-BARREL.HOSE-5MOrder no.: 065352866-0000-10 | Type: High pressure hose 400 bar | Size: 5 m
ARCA-PUMP-BARREL.HOSE-10MOrder no.: 065353153-0000-10 | Type: High pressure hose 400 bar | Size: 10 m
