FAG ARCALUB Hose Connectors, Fittings, Y Pieces and Check Valve

FAG ARCALUB Hose Connectors, Fittings, Y Pieces and Check Valve

FAG ARCALUB hose connectors, push-fit connector parts, Y pieces and check valves build the lubrication lines between CONCEPT lubricators and lubrication points.

Key features

  • Push-fit connector parts for 4, 6 and 8 mm hoses
  • Straight and angled versions with metric and G threads
  • Y pieces for splitting a line
  • Check valve for oil lubrication

Specifications

System ARCALUB lubrication lines
Source Schaeffler Lubricators TPI 252, p. 44-49
ARCALUB-X.CONNECT-6-4 Order no.: 093040717-0000-10 | Type: Hose connector | Hose: 6 / 4 mm
ARCALUB-X.CONNECT-6-6 Order no.: 083867112-0000-10 | Type: Hose connector | Hose: 6 / 6 mm
ARCALUB-X.CONNECT-8-6 Order no.: 083867279-0000-10 | Type: Hose connector | Hose: 8 / 6 mm
ARCALUB-X.CONNECT-8-8 Order no.: 083867309-0000-10 | Type: Hose connector | Hose: 8 / 8 mm
ARCALUB-X.CONNECT-6-6-W Order no.: 088902250-0000-10 | Type: Hose connector, angled | Hose: 6 / 6 mm
ARCALUB-X.TUBEFIT-Y-D6 Order no.: 076693180-0000-10 | Type: Y piece | Hose: 6 mm
ARCALUB-X.TUBEFIT-Y-D8 Order no.: 083654640-0000-10 | Type: Y piece | Hose: 8 mm
ARCALUB-X.OIL-VALVE-SAT106G Order no.: 092927122-0000-10 | Type: Check valve (oil only) | Hose: 6 mm | Thread: M10x1
ARCALUB-X.TUBEFIT-M3-SAT034G-S Order no.: 093041390-0000-10 | Type: Hose connector part, straight push fit | Hose: 4 mm | Thread: M3
ARCALUB-X.TUBEFIT-M5-SAT056G Order no.: 077937490-0000-10 | Type: Hose connector part, straight push fit | Hose: 6 mm | Thread: M5
ARCALUB-X.TUBEFIT-M5-SAT056W Order no.: 079567401-0000-10 | Type: Hose connector part, angled push fit | Hose: 6 mm | Thread: M5
ARCALUB-X.TUBEFIT-M6-SAT066G Order no.: 075527472-0000-10 | Type: Hose connector part, straight push fit | Hose: 6 mm | Thread: M6
ARCALUB-X.TUBEFIT-M6-SAT066W Order no.: 075676621-0000-10 | Type: Hose connector part, angled push fit | Hose: 6 mm | Thread: M6
ARCALUB-X.TUBEFIT-M8X1-SAT086G Order no.: 079567428-0000-10 | Type: Hose connector part, straight push fit | Hose: 6 mm | Thread: M8x1
ARCALUB-X.TUBEFIT-M8X1-SAT086W Order no.: 079567584-0000-10 | Type: Hose connector part, angled push fit | Hose: 6 mm | Thread: M8x1
ARCALUB-X.TUBEFIT-M10X1-SAT106G Order no.: 075527626-0000-10 | Type: Hose connector part, straight push fit | Hose: 6 mm | Thread: M10x1
ARCALUB-X.TUBEFIT-M10X1-SAT106W Order no.: 076968553-0000-10 | Type: Hose connector part, angled push fit | Hose: 6 mm | Thread: M10x1
ARCALUB-X.TUBEFIT-G1/8-SAT186G Order no.: 084465905-0000-10 | Type: Hose connector part, straight push fit | Hose: 6 mm | Thread: G1/8
ARCALUB-X.TUBEFIT-G1/8-SAT186W Order no.: 084465964-0000-10 | Type: Hose connector part, angled push fit | Hose: 6 mm | Thread: G1/8
ARCALUB-X.TUBEFIT-G1/4-SAT146G Order no.: 079567606-0000-10 | Type: Hose connector part, straight push fit | Hose: 6 mm | Thread: G1/4
ARCALUB-X.TUBEFIT-G1/4-SAT146W Order no.: 079567622-0000-10 | Type: Hose connector part, angled push fit | Hose: 6 mm | Thread: G1/4
ARCALUB-X.TUBEFIT-M8X1-SAT088G Order no.: 083654216-0000-10 | Type: Hose connector part, straight push fit | Hose: 8 mm | Thread: M8x1
ARCALUB-X.TUBEFIT-M8X1-SAT088W Order no.: 083654275-0000-10 | Type: Hose connector part, angled push fit | Hose: 8 mm | Thread: M8x1
ARCALUB-X.TUBEFIT-M10X1-SAT108G Order no.: 083654356-0000-10 | Type: Hose connector part, straight push fit | Hose: 8 mm | Thread: M10x1
ARCALUB-X.TUBEFIT-M10X1-SAT108W Order no.: 083654402-0000-10 | Type: Hose connector part, angled push fit | Hose: 8 mm | Thread: M10x1
ARCALUB-X.TUBEFIT-G1/8-SAT188G Order no.: 083654534-0000-10 | Type: Hose connector part, straight push fit | Hose: 8 mm | Thread: G1/8
ARCALUB-X.TUBEFIT-G1/8-SAT188W Order no.: 083654577-0000-10 | Type: Hose connector part, angled push fit | Hose: 8 mm | Thread: G1/8
ARCALUB-X.TUBEFIT-G1/4-SAT148G Order no.: 083654607-0000-10 | Type: Hose connector part, straight push fit | Hose: 8 mm | Thread: G1/4
ARCALUB-X.TUBEFIT-G1/4-SAT148W Order no.: 083654623-0000-10 | Type: Hose connector part, angled push fit | Hose: 8 mm | Thread: G1/4
LubricatorsFAG
29 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

FAG ARCALUB Hose Connectors, Fittings, Y Pieces and Check Valve

Brand FAG·Lubricators

Available part numbers (29)

ARCALUB-X.CONNECT-6-4, ARCALUB-X.CONNECT-6-6, ARCALUB-X.CONNECT-8-6, ARCALUB-X.CONNECT-8-8, ARCALUB-X.CONNECT-6-6-W, ARCALUB-X.TUBEFIT-Y-D6, ARCALUB-X.TUBEFIT-Y-D8, ARCALUB-X.OIL-VALVE-SAT106G, ARCALUB-X.TUBEFIT-M3-SAT034G-S, ARCALUB-X.TUBEFIT-M5-SAT056G + 19 more — see full table ↓
