FAG CONCEPT8 Automatic Lubricators (ARCALUB-C8, up to 8 Outlets)

FAG CONCEPT8 Automatic Lubricators (ARCALUB-C8, up to 8 Outlets)

The FAG CONCEPT8 is a DC 24 V automatic, pulse-controlled lubricator with two or four piston pumps supplying up to 8 outlets (16 with splitters) with grease or oil at 70 bar.

Key features

  • 2 or 4 independently operating piston pumps, each with 2 outlets
  • Variable metering 0.15-7.2 cm3 per outlet
  • Pause times 1-240 h internal or external PLC control
  • 800 cm3 grease cartridge or 1 000 cm3 oil container
  • Integrated pressure and fill level monitoring

Specifications

Supply DC 24 V
Pressure 70 bar
Operating temperature -20 to +70 C
Protection class IP65
Mass 3 kg
Source Schaeffler Lubricators TPI 252, p. 20-25
ARCALUB-C8-2P Order no.: 082249156-0000-10 | Pump bodies: 2 | Outlets: 4 | Lubricant: Grease, hose 8 mm
ARCALUB-C8-4P Order no.: 082266646-0000-10 | Pump bodies: 4 | Outlets: 8 | Lubricant: Grease, hose 8 mm
ARCALUB-C8-2P-OIL Order no.: 083786910-0000-10 | Pump bodies: 2 | Outlets: 4 | Lubricant: Oil, hose 6 mm
ARCALUB-C8-4P-OIL Order no.: 083787062-0000-10 | Pump bodies: 4 | Outlets: 8 | Lubricant: Oil, hose 6 mm
DEMO-ARCALUB-C8-SET Order no.: 084224878-0000-10 | Content: Demo case with CONCEPT8-4P
LubricatorsFAG
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

FAG CONCEPT8 Automatic Lubricators (ARCALUB-C8, up to 8 Outlets)

Brand FAG·Lubricators

Available part numbers (5)

ARCALUB-C8-2P, ARCALUB-C8-4P, ARCALUB-C8-2P-OIL, ARCALUB-C8-4P-OIL, DEMO-ARCALUB-C8-SET

How to order

Send the FAG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ARCALUB-C8-2POrder no.: 082249156-0000-10 | Pump bodies: 2 | Outlets: 4 | Lubricant: Grease, hose 8 mm
ARCALUB-C8-4POrder no.: 082266646-0000-10 | Pump bodies: 4 | Outlets: 8 | Lubricant: Grease, hose 8 mm
ARCALUB-C8-2P-OILOrder no.: 083786910-0000-10 | Pump bodies: 2 | Outlets: 4 | Lubricant: Oil, hose 6 mm
ARCALUB-C8-4P-OILOrder no.: 083787062-0000-10 | Pump bodies: 4 | Outlets: 8 | Lubricant: Oil, hose 6 mm
DEMO-ARCALUB-C8-SETOrder no.: 084224878-0000-10 | Content: Demo case with CONCEPT8-4P
