Fuji Electric AH164/AH165 Series Pushbutton Switches (16 mm)

Fuji Electric AH164/AH165 Series Pushbutton Switches (16 mm)

AH164, AH165 and AH165-2 series non-illuminated pushbutton switches with flush, extended, guarded, large, push-lock, ring-select and lever operators.

Key features

  • Momentary, alternate and push-lock actions
  • Round, square and rectangular operators
  • Guarded and large (mushroom) heads
  • Button colours G, R, B, Y, W, S, O per type designation
  • Contacts 1b, 2b, 1a1b, 2a2b, 3a3b

Specifications

Mounting 16 mm class panel cut-out
Terminals Solder tab (#110) or wrapping (W suffix)
Ordering Base type + colour + contacts + terminal
Example AH165-2ER11-W
Series AH164 / AH165 / AH165-2
Button colours G, R, B, Y, W, S, O
Source Fuji Electric AH164/AH165 command switch catalogue, p. 4-6, 8
AH164-E Series: AH164 (dust-tight) | Operator: Round extended | Action: Momentary
AH165-E Series: AH165 (oil-tight) | Operator: Round extended | Action: Momentary
AH164-E5 Series: AH164 (dust-tight) | Operator: Round extended | Action: Alternate
AH165-E5 Series: AH165 (oil-tight) | Operator: Round extended | Action: Alternate
AH164-SF Series: AH164 (dust-tight) | Operator: Square flush | Action: Momentary
AH165-SF Series: AH165 (oil-tight) | Operator: Square flush | Action: Momentary
AH164-SF5 Series: AH164 (dust-tight) | Operator: Square flush | Action: Alternate
AH165-SF5 Series: AH165 (oil-tight) | Operator: Square flush | Action: Alternate
AH164-TF Series: AH164 (dust-tight) | Operator: Rectangular flush | Action: Momentary
AH165-TF Series: AH165 (oil-tight) | Operator: Rectangular flush | Action: Momentary
AH164-TF5 Series: AH164 (dust-tight) | Operator: Rectangular flush | Action: Alternate
AH165-TF5 Series: AH165 (oil-tight) | Operator: Rectangular flush | Action: Alternate
AH164-TGF Series: AH164 (dust-tight) | Operator: Guarded rectangular flush | Action: Momentary
AH165-TGF Series: AH165 (oil-tight) | Operator: Guarded rectangular flush | Action: Momentary
AH164-TGF5 Series: AH164 (dust-tight) | Operator: Guarded rectangular flush | Action: Alternate
AH165-TGF5 Series: AH165 (oil-tight) | Operator: Guarded rectangular flush | Action: Alternate
AH164-SGF Series: AH164 (dust-tight) | Operator: Guarded square flush | Action: Momentary
AH165-SGF Series: AH165 (oil-tight) | Operator: Guarded square flush | Action: Momentary
AH164-SGF5 Series: AH164 (dust-tight) | Operator: Guarded square flush | Action: Alternate
AH165-SGF5 Series: AH165 (oil-tight) | Operator: Guarded square flush | Action: Alternate
AH164-M Series: AH164 (dust-tight) | Operator: Large round | Action: Momentary
AH165-M Series: AH165 (oil-tight) | Operator: Large round | Action: Momentary
AH164-M5 Series: AH164 (dust-tight) | Operator: Large round | Action: Alternate
AH165-M5 Series: AH165 (oil-tight) | Operator: Large round | Action: Alternate
AH164-SM Series: AH164 (dust-tight) | Operator: Large square | Action: Momentary
AH165-SM Series: AH165 (oil-tight) | Operator: Large square | Action: Momentary
AH164-SM5 Series: AH164 (dust-tight) | Operator: Large square | Action: Alternate
AH165-SM5 Series: AH165 (oil-tight) | Operator: Large square | Action: Alternate
AH164-TM Series: AH164 (dust-tight) | Operator: Large rectangular | Action: Momentary
AH165-TM Series: AH165 (oil-tight) | Operator: Large rectangular | Action: Momentary
AH164-TM5 Series: AH164 (dust-tight) | Operator: Large rectangular | Action: Alternate
AH165-TM5 Series: AH165 (oil-tight) | Operator: Large rectangular | Action: Alternate
AH165-V Series: AH165 (oil-tight) | Operator: Push-lock 32 mm | Action: Push-lock
AH165-V1 Series: AH165 (oil-tight) | Operator: Push-lock 40 mm | Action: Push-lock
AH165-2F Series: AH165-2 (oil-tight) | Operator: Round flush | Action: Momentary
AH165-2F5 Series: AH165-2 (oil-tight) | Operator: Round flush | Action: Alternate
AH165-2SF Series: AH165-2 (oil-tight) | Operator: Square flush | Action: Momentary
AH165-2SF5 Series: AH165-2 (oil-tight) | Operator: Square flush | Action: Alternate
AH165-2E Series: AH165-2 (oil-tight) | Operator: Round extended | Action: Momentary
AH165-2E5 Series: AH165-2 (oil-tight) | Operator: Round extended | Action: Alternate
AH165-2SE Series: AH165-2 (oil-tight) | Operator: Square extended | Action: Momentary
AH165-2SE5 Series: AH165-2 (oil-tight) | Operator: Square extended | Action: Alternate
AH165-2SCE Series: AH165-2 (oil-tight) | Operator: Square extended recessed | Action: Momentary
AH165-2SCE5 Series: AH165-2 (oil-tight) | Operator: Square extended recessed | Action: Alternate
AH165-2M Series: AH165-2 (oil-tight) | Operator: Mushroom, round bezel | Action: Momentary
AH165-2YM Series: AH165-2 (oil-tight) | Operator: Mushroom, square bezel | Action: Momentary
AH165-2V Series: AH165-2 (oil-tight) | Operator: Push-lock, round bezel | Action: Push-lock
AH165-2YV Series: AH165-2 (oil-tight) | Operator: Push-lock, square bezel | Action: Push-lock
AH165-2S2 Series: AH165-2 (oil-tight) | Operator: Ring select, round bezel | Action: Momentary
AH165-2YS2 Series: AH165-2 (oil-tight) | Operator: Ring select, square bezel | Action: Momentary
AH165-2H2 Series: AH165-2 (oil-tight) | Operator: Lever, round bezel | Action: Momentary
AH165-2SH2 Series: AH165-2 (oil-tight) | Operator: Lever, square bezel | Action: Momentary
