Fuji Electric MONITOUCH V806 HMI Touch Panels (5.7 in, DC24V)

Fuji Electric MONITOUCH V806 HMI Touch Panels (5.7 in, DC24V)

5.7-inch QVGA MONITOUCH V8 programmable displays in colour (T, C) and monochrome (M) versions for DC24V supply, with optional DU-10/DUN-10 unit adding a D-sub9 port and CF card slot.

Key features

  • QVGA 320 x 240 dot display, colour or monochrome
  • 4.5 MB FROM screen memory, SRAM 512 KB (i models) / 128 KB
  • Ethernet built in on 'i' models
  • USB-A and USB-B interfaces
  • Two modular serial ports MJ1/MJ2
  • Communication units CU/CUN-00 to -08 supported

Specifications

Series MONITOUCH V8
Screen size 5.7 in
Resolution 320 x 240 (QVGA)
Power supply DC24V
Screen memory FROM 4.5 MB
Panel cutout 174 x 131 mm
Standards CE (EN61000-6-2/6-4), UL508
Screen 5.7 in
Touch switch Analog
Power DC24V
Source Fuji Electric MONITOUCH V8 Series catalogue (KR ed.) / MONITOUCH V9 Series catalogue (KR ed., 2016), p. 5, 14 (V8); 14-15 (V9 cat.)
V806iTD Display: TFT colour QVGA 320x240 | Ethernet: Built-in | Version: Original (2008)
V806TD Display: TFT colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: Original (2008)
V806iCD Display: STN colour QVGA 320x240 | Ethernet: Built-in | Version: Original (2008)
V806CD Display: STN colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: Original (2008)
V806iMD Display: STN mono QVGA 320x240 | Ethernet: Built-in | Version: Original (2008)
V806MD Display: STN mono QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: Original (2008)
V806iTDN Display: TFT colour QVGA 320x240 | Ethernet: Built-in | Version: N model (CN5 revised)
V806TDN Display: TFT colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: N model (CN5 revised)
V806iCDN Display: TFT colour QVGA 320x240 | Ethernet: Built-in | Version: N model (CN5 revised)
V806CDN Display: TFT colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: N model (CN5 revised)
V806iMDN Display: TFT mono QVGA 320x240 | Ethernet: Built-in | Version: N model (CN5 revised)
V806MDN Display: TFT mono QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: N model (CN5 revised)
HMI Touch PanelsFuji Electric
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Fuji Electric MONITOUCH V806 HMI Touch Panels (5.7 in, DC24V)

Brand Fuji Electric·HMI Touch Panels

Available part numbers (12)

V806iTD, V806TD, V806iCD, V806CD, V806iMD, V806MD, V806iTDN, V806TDN, V806iCDN, V806CDN + 2 more — see full table ↓

How to order

Send the Fuji Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
V806iTDDisplay: TFT colour QVGA 320x240 | Ethernet: Built-in | Version: Original (2008)
V806TDDisplay: TFT colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: Original (2008)
V806iCDDisplay: STN colour QVGA 320x240 | Ethernet: Built-in | Version: Original (2008)
V806CDDisplay: STN colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: Original (2008)
V806iMDDisplay: STN mono QVGA 320x240 | Ethernet: Built-in | Version: Original (2008)
V806MDDisplay: STN mono QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: Original (2008)
V806iTDNDisplay: TFT colour QVGA 320x240 | Ethernet: Built-in | Version: N model (CN5 revised)
V806TDNDisplay: TFT colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: N model (CN5 revised)
V806iCDNDisplay: TFT colour QVGA 320x240 | Ethernet: Built-in | Version: N model (CN5 revised)
V806CDNDisplay: TFT colour QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: N model (CN5 revised)
V806iMDNDisplay: TFT mono QVGA 320x240 | Ethernet: Built-in | Version: N model (CN5 revised)
V806MDNDisplay: TFT mono QVGA 320x240 | Ethernet: Option (CU/CUN-03-3) | Version: N model (CN5 revised)
