GGM KGE-3429-T2 R-Type Offset Geared DC Motor (DC 24V, 7500rpm base, 18 ratios 1/22-1/687)

GGM KGE-3429-T2 r-type offset parallel-shaft geared DC motor, DC 24V (7500 rpm base motor). 18 gear ratios 1/22-1/687, output torque up to 18 kgf·cm, ø8 output shaft, 8-M4 mounting on 56x100.5 housing.

Key features

R-Type shaft orientation (F-Type is standard)

Specifications

Shaft Type	R-Type

KGE-0022-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/22, 295rpm, 0.6kgf·cm \| Gear Ratio: 1/22 \| Output Speed: 295 rpm \| Output Torque: 0.6 kgf·cm \| Shaft Type: R-Type
KGE-0034-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/34, 191rpm, 1kgf·cm \| Gear Ratio: 1/34 \| Output Speed: 191 rpm \| Output Torque: 1 kgf·cm \| Shaft Type: R-Type
KGE-0043-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/43, 151rpm, 1.3kgf·cm \| Gear Ratio: 1/43 \| Output Speed: 151 rpm \| Output Torque: 1.3 kgf·cm \| Shaft Type: R-Type
KGE-0050-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/50, 130rpm, 1.5kgf·cm \| Gear Ratio: 1/50 \| Output Speed: 130 rpm \| Output Torque: 1.5 kgf·cm \| Shaft Type: R-Type
KGE-0062-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/62, 105rpm, 1.8kgf·cm \| Gear Ratio: 1/62 \| Output Speed: 105 rpm \| Output Torque: 1.8 kgf·cm \| Shaft Type: R-Type
KGE-0068-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/68, 95.5rpm, 2kgf·cm \| Gear Ratio: 1/68 \| Output Speed: 95.5 rpm \| Output Torque: 2 kgf·cm \| Shaft Type: R-Type
KGE-0083-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/83, 78.3rpm, 2.4kgf·cm \| Gear Ratio: 1/83 \| Output Speed: 78.3 rpm \| Output Torque: 2.4 kgf·cm \| Shaft Type: R-Type
KGE-0105-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/105, 62rpm, 3kgf·cm \| Gear Ratio: 1/105 \| Output Speed: 62 rpm \| Output Torque: 3 kgf·cm \| Shaft Type: R-Type
KGE-0116-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/116, 56rpm, 3.4kgf·cm \| Gear Ratio: 1/116 \| Output Speed: 56 rpm \| Output Torque: 3.4 kgf·cm \| Shaft Type: R-Type
KGE-0162-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/162, 40rpm, 4.3kgf·cm \| Gear Ratio: 1/162 \| Output Speed: 40 rpm \| Output Torque: 4.3 kgf·cm \| Shaft Type: R-Type
KGE-0182-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/182, 35.7rpm, 4.8kgf·cm \| Gear Ratio: 1/182 \| Output Speed: 35.7 rpm \| Output Torque: 4.8 kgf·cm \| Shaft Type: R-Type
KGE-0204-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/204, 31.8rpm, 5.4kgf·cm \| Gear Ratio: 1/204 \| Output Speed: 31.8 rpm \| Output Torque: 5.4 kgf·cm \| Shaft Type: R-Type
KGE-0240-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/240, 27.1rpm, 6.3kgf·cm \| Gear Ratio: 1/240 \| Output Speed: 27.1 rpm \| Output Torque: 6.3 kgf·cm \| Shaft Type: R-Type
KGE-0308-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/308, 21.1rpm, 8.1kgf·cm \| Gear Ratio: 1/308 \| Output Speed: 21.1 rpm \| Output Torque: 8.1 kgf·cm \| Shaft Type: R-Type
KGE-0350-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/350, 18.6rpm, 9.2kgf·cm \| Gear Ratio: 1/350 \| Output Speed: 18.6 rpm \| Output Torque: 9.2 kgf·cm \| Shaft Type: R-Type
KGE-0452-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/452, 14.4rpm, 11.9kgf·cm \| Gear Ratio: 1/452 \| Output Speed: 14.4 rpm \| Output Torque: 11.9 kgf·cm \| Shaft Type: R-Type
KGE-0615-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/615, 10.5rpm, 16.1kgf·cm \| Gear Ratio: 1/615 \| Output Speed: 10.5 rpm \| Output Torque: 16.1 kgf·cm \| Shaft Type: R-Type
KGE-0687-KD3429T2-R		KGE-3429-T2 R-Type offset geared, 1/687, 9.5rpm, 18kgf·cm \| Gear Ratio: 1/687 \| Output Speed: 9.5 rpm \| Output Torque: 18 kgf·cm \| Shaft Type: R-Type

DCGGM

18 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KGE-3429-T2 R-Type Offset Geared DC Motor (DC 24V, 7500rpm base, 18 ratios 1/22-1/687)

Brand GGM·DC

Available part numbers (18)

KGE-0022-KD3429T2-R, KGE-0034-KD3429T2-R, KGE-0043-KD3429T2-R, KGE-0050-KD3429T2-R, KGE-0062-KD3429T2-R, KGE-0068-KD3429T2-R, KGE-0083-KD3429T2-R, KGE-0105-KD3429T2-R, KGE-0116-KD3429T2-R, KGE-0162-KD3429T2-R + 8 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	KGE-0022-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/22, 295rpm, 0.6kgf·cm \| Gear Ratio: 1/22 \| Output Speed: 295 rpm \| Output Torque: 0.6 kgf·cm \| Shaft Type: R-Type
	KGE-0034-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/34, 191rpm, 1kgf·cm \| Gear Ratio: 1/34 \| Output Speed: 191 rpm \| Output Torque: 1 kgf·cm \| Shaft Type: R-Type
	KGE-0043-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/43, 151rpm, 1.3kgf·cm \| Gear Ratio: 1/43 \| Output Speed: 151 rpm \| Output Torque: 1.3 kgf·cm \| Shaft Type: R-Type
	KGE-0050-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/50, 130rpm, 1.5kgf·cm \| Gear Ratio: 1/50 \| Output Speed: 130 rpm \| Output Torque: 1.5 kgf·cm \| Shaft Type: R-Type
	KGE-0062-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/62, 105rpm, 1.8kgf·cm \| Gear Ratio: 1/62 \| Output Speed: 105 rpm \| Output Torque: 1.8 kgf·cm \| Shaft Type: R-Type
	KGE-0068-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/68, 95.5rpm, 2kgf·cm \| Gear Ratio: 1/68 \| Output Speed: 95.5 rpm \| Output Torque: 2 kgf·cm \| Shaft Type: R-Type
	KGE-0083-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/83, 78.3rpm, 2.4kgf·cm \| Gear Ratio: 1/83 \| Output Speed: 78.3 rpm \| Output Torque: 2.4 kgf·cm \| Shaft Type: R-Type
	KGE-0105-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/105, 62rpm, 3kgf·cm \| Gear Ratio: 1/105 \| Output Speed: 62 rpm \| Output Torque: 3 kgf·cm \| Shaft Type: R-Type
	KGE-0116-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/116, 56rpm, 3.4kgf·cm \| Gear Ratio: 1/116 \| Output Speed: 56 rpm \| Output Torque: 3.4 kgf·cm \| Shaft Type: R-Type
	KGE-0162-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/162, 40rpm, 4.3kgf·cm \| Gear Ratio: 1/162 \| Output Speed: 40 rpm \| Output Torque: 4.3 kgf·cm \| Shaft Type: R-Type
	KGE-0182-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/182, 35.7rpm, 4.8kgf·cm \| Gear Ratio: 1/182 \| Output Speed: 35.7 rpm \| Output Torque: 4.8 kgf·cm \| Shaft Type: R-Type
	KGE-0204-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/204, 31.8rpm, 5.4kgf·cm \| Gear Ratio: 1/204 \| Output Speed: 31.8 rpm \| Output Torque: 5.4 kgf·cm \| Shaft Type: R-Type
	KGE-0240-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/240, 27.1rpm, 6.3kgf·cm \| Gear Ratio: 1/240 \| Output Speed: 27.1 rpm \| Output Torque: 6.3 kgf·cm \| Shaft Type: R-Type
	KGE-0308-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/308, 21.1rpm, 8.1kgf·cm \| Gear Ratio: 1/308 \| Output Speed: 21.1 rpm \| Output Torque: 8.1 kgf·cm \| Shaft Type: R-Type
	KGE-0350-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/350, 18.6rpm, 9.2kgf·cm \| Gear Ratio: 1/350 \| Output Speed: 18.6 rpm \| Output Torque: 9.2 kgf·cm \| Shaft Type: R-Type
	KGE-0452-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/452, 14.4rpm, 11.9kgf·cm \| Gear Ratio: 1/452 \| Output Speed: 14.4 rpm \| Output Torque: 11.9 kgf·cm \| Shaft Type: R-Type
	KGE-0615-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/615, 10.5rpm, 16.1kgf·cm \| Gear Ratio: 1/615 \| Output Speed: 10.5 rpm \| Output Torque: 16.1 kgf·cm \| Shaft Type: R-Type
	KGE-0687-KD3429T2-R	KGE-3429-T2 R-Type offset geared, 1/687, 9.5rpm, 18kgf·cm \| Gear Ratio: 1/687 \| Output Speed: 9.5 rpm \| Output Torque: 18 kgf·cm \| Shaft Type: R-Type
