• GGM KGQ Gearhead for KA61 Shaded-Pole Motors (□60, 1/96–1/532)
1 1

GGM KGQ Gearhead for KA61 Shaded-Pole Motors (□60, 1/96–1/532)

GGM KGQ Gearhead for KA61 Shaded-Pole Motors (□60, 1/96–1/532)

GGM KGQ gearhead for □60 KA61 shaded-pole general-type motors, 3 gear ratios (1/96, 1/380, 1/532).

Key features

  • Max permissible output torque 20 kgf·cm, body 60×76mm, Ø8 shaft, M4 tapped mounting

Specifications

Max Permissible Output Torque 20 kgf·cm
KGQ-0096 KGQ gearhead, 1/96, output 25/30.2 rpm (50/60Hz) | Gear Ratio: 1/96 | Output Speed: 25 rpm (50Hz) / 30.2 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGQ-0380 KGQ gearhead, 1/380, output 6.3/7.6 rpm (50/60Hz) | Gear Ratio: 1/380 | Output Speed: 6.3 rpm (50Hz) / 7.6 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGQ-0532 KGQ gearhead, 1/532, output 4.5/5.4 rpm (50/60Hz) | Gear Ratio: 1/532 | Output Speed: 4.5 rpm (50Hz) / 5.4 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
Shaded-Pole MotorsGGM
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KGQ Gearhead for KA61 Shaded-Pole Motors (□60, 1/96–1/532)

Brand GGM·Shaded-Pole Motors

Available part numbers (3)

KGQ-0096, KGQ-0380, KGQ-0532

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KGQ-0096KGQ gearhead, 1/96, output 25/30.2 rpm (50/60Hz) | Gear Ratio: 1/96 | Output Speed: 25 rpm (50Hz) / 30.2 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGQ-0380KGQ gearhead, 1/380, output 6.3/7.6 rpm (50/60Hz) | Gear Ratio: 1/380 | Output Speed: 6.3 rpm (50Hz) / 7.6 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
KGQ-0532KGQ gearhead, 1/532, output 4.5/5.4 rpm (50/60Hz) | Gear Ratio: 1/532 | Output Speed: 4.5 rpm (50Hz) / 5.4 rpm (60Hz) | Max Permissible Output Torque: 20 kgf·cm
