GGM KME-3429-S1 DC Geared Motor (DC 12V, F/R output, 1/22–1/67)

GGM KME-3429 S1 right-angle DC geared motor, KD3429S1 base, DC 12V.

Key features

Gear ratios 1/22 to 1/67, output torque 0.6–1.8 kgf·cm; F-TYPE (standard) and R-TYPE output shaft

KME-0022-KD3429S1		KME-3429 KD3429S1, 1/22, F-TYPE, DC 12V \| Gear Ratio: 1/22 \| Output Speed: 205 rpm \| Output Torque: 0.6 kgf·cm \| Output Shaft: F-TYPE
KME-0034-KD3429S1		KME-3429 KD3429S1, 1/34, F-TYPE, DC 12V \| Gear Ratio: 1/34 \| Output Speed: 132 rpm \| Output Torque: 1 kgf·cm \| Output Shaft: F-TYPE
KME-0043-KD3429S1		KME-3429 KD3429S1, 1/43, F-TYPE, DC 12V \| Gear Ratio: 1/43 \| Output Speed: 104.7 rpm \| Output Torque: 1.1 kgf·cm \| Output Shaft: F-TYPE
KME-0053-KD3429S1		KME-3429 KD3429S1, 1/53, F-TYPE, DC 12V \| Gear Ratio: 1/53 \| Output Speed: 84 rpm \| Output Torque: 1.3 kgf·cm \| Output Shaft: F-TYPE
KME-0060-KD3429S1		KME-3429 KD3429S1, 1/60, F-TYPE, DC 12V \| Gear Ratio: 1/60 \| Output Speed: 75 rpm \| Output Torque: 1.6 kgf·cm \| Output Shaft: F-TYPE
KME-0067-KD3429S1		KME-3429 KD3429S1, 1/67, F-TYPE, DC 12V \| Gear Ratio: 1/67 \| Output Speed: 67.2 rpm \| Output Torque: 1.8 kgf·cm \| Output Shaft: F-TYPE
KME-0022-KD3429S1-R		KME-3429 KD3429S1, 1/22, R-TYPE, DC 12V \| Gear Ratio: 1/22 \| Output Speed: 205 rpm \| Output Torque: 0.6 kgf·cm \| Output Shaft: R-TYPE
KME-0034-KD3429S1-R		KME-3429 KD3429S1, 1/34, R-TYPE, DC 12V \| Gear Ratio: 1/34 \| Output Speed: 132 rpm \| Output Torque: 1 kgf·cm \| Output Shaft: R-TYPE
KME-0043-KD3429S1-R		KME-3429 KD3429S1, 1/43, R-TYPE, DC 12V \| Gear Ratio: 1/43 \| Output Speed: 104.7 rpm \| Output Torque: 1.1 kgf·cm \| Output Shaft: R-TYPE
KME-0053-KD3429S1-R		KME-3429 KD3429S1, 1/53, R-TYPE, DC 12V \| Gear Ratio: 1/53 \| Output Speed: 84 rpm \| Output Torque: 1.3 kgf·cm \| Output Shaft: R-TYPE
KME-0060-KD3429S1-R		KME-3429 KD3429S1, 1/60, R-TYPE, DC 12V \| Gear Ratio: 1/60 \| Output Speed: 75 rpm \| Output Torque: 1.6 kgf·cm \| Output Shaft: R-TYPE
KME-0067-KD3429S1-R		KME-3429 KD3429S1, 1/67, R-TYPE, DC 12V \| Gear Ratio: 1/67 \| Output Speed: 67.2 rpm \| Output Torque: 1.8 kgf·cm \| Output Shaft: R-TYPE

DCGGM

12 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KME-3429-S1 DC Geared Motor (DC 12V, F/R output, 1/22–1/67)

Brand GGM·DC

Available part numbers (12)

KME-0022-KD3429S1, KME-0034-KD3429S1, KME-0043-KD3429S1, KME-0053-KD3429S1, KME-0060-KD3429S1, KME-0067-KD3429S1, KME-0022-KD3429S1-R, KME-0034-KD3429S1-R, KME-0043-KD3429S1-R, KME-0053-KD3429S1-R + 2 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

	Product code	Spec
	KME-0022-KD3429S1	KME-3429 KD3429S1, 1/22, F-TYPE, DC 12V \| Gear Ratio: 1/22 \| Output Speed: 205 rpm \| Output Torque: 0.6 kgf·cm \| Output Shaft: F-TYPE
	KME-0034-KD3429S1	KME-3429 KD3429S1, 1/34, F-TYPE, DC 12V \| Gear Ratio: 1/34 \| Output Speed: 132 rpm \| Output Torque: 1 kgf·cm \| Output Shaft: F-TYPE
	KME-0043-KD3429S1	KME-3429 KD3429S1, 1/43, F-TYPE, DC 12V \| Gear Ratio: 1/43 \| Output Speed: 104.7 rpm \| Output Torque: 1.1 kgf·cm \| Output Shaft: F-TYPE
	KME-0053-KD3429S1	KME-3429 KD3429S1, 1/53, F-TYPE, DC 12V \| Gear Ratio: 1/53 \| Output Speed: 84 rpm \| Output Torque: 1.3 kgf·cm \| Output Shaft: F-TYPE
	KME-0060-KD3429S1	KME-3429 KD3429S1, 1/60, F-TYPE, DC 12V \| Gear Ratio: 1/60 \| Output Speed: 75 rpm \| Output Torque: 1.6 kgf·cm \| Output Shaft: F-TYPE
	KME-0067-KD3429S1	KME-3429 KD3429S1, 1/67, F-TYPE, DC 12V \| Gear Ratio: 1/67 \| Output Speed: 67.2 rpm \| Output Torque: 1.8 kgf·cm \| Output Shaft: F-TYPE
	KME-0022-KD3429S1-R	KME-3429 KD3429S1, 1/22, R-TYPE, DC 12V \| Gear Ratio: 1/22 \| Output Speed: 205 rpm \| Output Torque: 0.6 kgf·cm \| Output Shaft: R-TYPE
	KME-0034-KD3429S1-R	KME-3429 KD3429S1, 1/34, R-TYPE, DC 12V \| Gear Ratio: 1/34 \| Output Speed: 132 rpm \| Output Torque: 1 kgf·cm \| Output Shaft: R-TYPE
	KME-0043-KD3429S1-R	KME-3429 KD3429S1, 1/43, R-TYPE, DC 12V \| Gear Ratio: 1/43 \| Output Speed: 104.7 rpm \| Output Torque: 1.1 kgf·cm \| Output Shaft: R-TYPE
	KME-0053-KD3429S1-R	KME-3429 KD3429S1, 1/53, R-TYPE, DC 12V \| Gear Ratio: 1/53 \| Output Speed: 84 rpm \| Output Torque: 1.3 kgf·cm \| Output Shaft: R-TYPE
	KME-0060-KD3429S1-R	KME-3429 KD3429S1, 1/60, R-TYPE, DC 12V \| Gear Ratio: 1/60 \| Output Speed: 75 rpm \| Output Torque: 1.6 kgf·cm \| Output Shaft: R-TYPE
	KME-0067-KD3429S1-R	KME-3429 KD3429S1, 1/67, R-TYPE, DC 12V \| Gear Ratio: 1/67 \| Output Speed: 67.2 rpm \| Output Torque: 1.8 kgf·cm \| Output Shaft: R-TYPE
