• GGM KWC-3640-S1 BLDC Worm Geared Motor (DC 12V, 1/25–1/1500)
1 1

GGM KWC-3640-S1 BLDC Worm Geared Motor (DC 12V, 1/25–1/1500)

GGM KWC-3640-S1 BLDC Worm Geared Motor (DC 12V, 1/25–1/1500)

GGM KWC-3640 BLDC round-flange worm geared motor, KB3640S1 base, DC 12V, 6-lead PWM speed control with CW/CCW and brake; GUN-type speed controller. 19 gear ratios 1/25 to 1/1500, output torque to 6 kgf·cm.

KWC-0025-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/25, DC 12V | Gear Ratio: 1/25 | Output Speed: 180 rpm | Output Torque: 0.8 kgf·cm
KWC-0030-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/30, DC 12V | Gear Ratio: 1/30 | Output Speed: 150 rpm | Output Torque: 1.0 kgf·cm
KWC-0050-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/50, DC 12V | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 1.6 kgf·cm
KWC-0060-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/60, DC 12V | Gear Ratio: 1/60 | Output Speed: 75 rpm | Output Torque: 1.7 kgf·cm
KWC-0075-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/75, DC 12V | Gear Ratio: 1/75 | Output Speed: 60 rpm | Output Torque: 2.2 kgf·cm
KWC-0100-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/100, DC 12V | Gear Ratio: 1/100 | Output Speed: 45 rpm | Output Torque: 2.9 kgf·cm
KWC-0125-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/125, DC 12V | Gear Ratio: 1/125 | Output Speed: 36 rpm | Output Torque: 3.6 kgf·cm
KWC-0150-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/150, DC 12V | Gear Ratio: 1/150 | Output Speed: 30 rpm | Output Torque: 4.4 kgf·cm
KWC-0200-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/200, DC 12V | Gear Ratio: 1/200 | Output Speed: 22.5 rpm | Output Torque: 5.2 kgf·cm
KWC-0250-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/250, DC 12V | Gear Ratio: 1/250 | Output Speed: 18 rpm | Output Torque: 6 kgf·cm
KWC-0300-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/300, DC 12V | Gear Ratio: 1/300 | Output Speed: 15 rpm | Output Torque: 6 kgf·cm
KWC-0375-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/375, DC 12V | Gear Ratio: 1/375 | Output Speed: 12 rpm | Output Torque: 6 kgf·cm
KWC-0500-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/500, DC 12V | Gear Ratio: 1/500 | Output Speed: 9 rpm | Output Torque: 6 kgf·cm
KWC-0600-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/600, DC 12V | Gear Ratio: 1/600 | Output Speed: 7.5 rpm | Output Torque: 6 kgf·cm
KWC-0750-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/750, DC 12V | Gear Ratio: 1/750 | Output Speed: 6 rpm | Output Torque: 6 kgf·cm
KWC-0900-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/900, DC 12V | Gear Ratio: 1/900 | Output Speed: 5 rpm | Output Torque: 6 kgf·cm
KWC-1050-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/1050, DC 12V | Gear Ratio: 1/1050 | Output Speed: 4.2 rpm | Output Torque: 6 kgf·cm
KWC-1350-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/1350, DC 12V | Gear Ratio: 1/1350 | Output Speed: 3.3 rpm | Output Torque: 6 kgf·cm
KWC-1500-KB3640S1 KWC-3640 BLDC worm gearhead KB3640S1, 1/1500, DC 12V | Gear Ratio: 1/1500 | Output Speed: 3 rpm | Output Torque: 6 kgf·cm
DCGGM
19 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KWC-3640-S1 BLDC Worm Geared Motor (DC 12V, 1/25–1/1500)

Brand GGM·DC

Available part numbers (19)

KWC-0025-KB3640S1, KWC-0030-KB3640S1, KWC-0050-KB3640S1, KWC-0060-KB3640S1, KWC-0075-KB3640S1, KWC-0100-KB3640S1, KWC-0125-KB3640S1, KWC-0150-KB3640S1, KWC-0200-KB3640S1, KWC-0250-KB3640S1 + 9 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KWC-0025-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/25, DC 12V | Gear Ratio: 1/25 | Output Speed: 180 rpm | Output Torque: 0.8 kgf·cm
KWC-0030-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/30, DC 12V | Gear Ratio: 1/30 | Output Speed: 150 rpm | Output Torque: 1.0 kgf·cm
KWC-0050-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/50, DC 12V | Gear Ratio: 1/50 | Output Speed: 90 rpm | Output Torque: 1.6 kgf·cm
KWC-0060-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/60, DC 12V | Gear Ratio: 1/60 | Output Speed: 75 rpm | Output Torque: 1.7 kgf·cm
KWC-0075-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/75, DC 12V | Gear Ratio: 1/75 | Output Speed: 60 rpm | Output Torque: 2.2 kgf·cm
KWC-0100-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/100, DC 12V | Gear Ratio: 1/100 | Output Speed: 45 rpm | Output Torque: 2.9 kgf·cm
KWC-0125-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/125, DC 12V | Gear Ratio: 1/125 | Output Speed: 36 rpm | Output Torque: 3.6 kgf·cm
KWC-0150-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/150, DC 12V | Gear Ratio: 1/150 | Output Speed: 30 rpm | Output Torque: 4.4 kgf·cm
KWC-0200-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/200, DC 12V | Gear Ratio: 1/200 | Output Speed: 22.5 rpm | Output Torque: 5.2 kgf·cm
KWC-0250-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/250, DC 12V | Gear Ratio: 1/250 | Output Speed: 18 rpm | Output Torque: 6 kgf·cm
KWC-0300-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/300, DC 12V | Gear Ratio: 1/300 | Output Speed: 15 rpm | Output Torque: 6 kgf·cm
KWC-0375-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/375, DC 12V | Gear Ratio: 1/375 | Output Speed: 12 rpm | Output Torque: 6 kgf·cm
KWC-0500-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/500, DC 12V | Gear Ratio: 1/500 | Output Speed: 9 rpm | Output Torque: 6 kgf·cm
KWC-0600-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/600, DC 12V | Gear Ratio: 1/600 | Output Speed: 7.5 rpm | Output Torque: 6 kgf·cm
KWC-0750-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/750, DC 12V | Gear Ratio: 1/750 | Output Speed: 6 rpm | Output Torque: 6 kgf·cm
KWC-0900-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/900, DC 12V | Gear Ratio: 1/900 | Output Speed: 5 rpm | Output Torque: 6 kgf·cm
KWC-1050-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/1050, DC 12V | Gear Ratio: 1/1050 | Output Speed: 4.2 rpm | Output Torque: 6 kgf·cm
KWC-1350-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/1350, DC 12V | Gear Ratio: 1/1350 | Output Speed: 3.3 rpm | Output Torque: 6 kgf·cm
KWC-1500-KB3640S1KWC-3640 BLDC worm gearhead KB3640S1, 1/1500, DC 12V | Gear Ratio: 1/1500 | Output Speed: 3 rpm | Output Torque: 6 kgf·cm
