IDEC φ30 Series Selector Pushbuttons (Ring / Lever Operated)

IDEC φ30 Series Selector Pushbuttons (Ring / Lever Operated)

φ30 Series ABN selector pushbuttons combining a pushbutton with ring- or lever-operated 90° 2-position selection.

Key features

  • Operation types A, B, C, D, E, F, G, H, I per catalogue
  • Button colours B, G, R, Y
  • φ30 mm mounting heavy-duty control units
  • Front protection IP65 (IEC 60529); main models UL/CSA listed and EN compliant
  • BS/BST single-contact blocks rated 600 V / 10 A (AC-15 A600, DC-13 P600)
  • Up to 2 tiers (4 blocks) of contacts per operator

Specifications

Positions 90° 2-position
Series IDEC φ30 Series
Panel thickness 0.8 to 7.5 mm
Contact block BS/BST, 600 V / 10 A (AC-15 A600, DC-13 P600)
Operating temperature -25 to +50 °C (no freezing)
Insulation resistance 100 MΩ min. (500 V DC megger)
Dielectric strength AC 2500 V, 1 min (live to dead metal)
Protection IP65 (IEC 60529)
Source IDEC φ30 Series Control Units catalogue, p. 39
ABN6111B Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Black | Operation type: A
ABN6111G Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Green | Operation type: A
ABN6111R Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Red | Operation type: A
ABN6111Y Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow | Operation type: A
ABN6411B Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Black | Operation type: I
ABN6411G Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Green | Operation type: I
ABN6411R Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Red | Operation type: I
ABN6411Y Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow | Operation type: I
ABN9111B Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Black | Operation type: G
ABN9111G Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Green | Operation type: G
ABN9111R Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Red | Operation type: G
ABN9111Y Operator: Ring operated | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow | Operation type: G
ABN7120B Operator: Ring operated | Contacts: 2a (2NO) | Colour: Black | Operation type: D
ABN7120G Operator: Ring operated | Contacts: 2a (2NO) | Colour: Green | Operation type: D
ABN7120R Operator: Ring operated | Contacts: 2a (2NO) | Colour: Red | Operation type: D
ABN7120Y Operator: Ring operated | Contacts: 2a (2NO) | Colour: Yellow | Operation type: D
ABN6122B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: B
ABN6122G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: B
ABN6122R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: B
ABN6122Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: B
ABN6222B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: C
ABN6222G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: C
ABN6222R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: C
ABN6222Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: C
ABN6422B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: I
ABN6422G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: I
ABN6422R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: I
ABN6422Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: I
ABN7122B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: D
ABN7122G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: D
ABN7122R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: D
ABN7122Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: D
ABN7222B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: E
ABN7222G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: E
ABN7222R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: E
ABN7222Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: E
ABN7322B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: F
ABN7322G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: F
ABN7322R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: F
ABN7322Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: F
ABN9122B Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: H
ABN9122G Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: H
ABN9122R Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: H
ABN9122Y Operator: Ring operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: H
ABN6L111B Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Black | Operation type: A
ABN6L111G Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Green | Operation type: A
ABN6L111R Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Red | Operation type: A
ABN6L111Y Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow | Operation type: A
ABN6L411B Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Black | Operation type: I
ABN6L411G Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Green | Operation type: I
ABN6L411R Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Red | Operation type: I
ABN6L411Y Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow | Operation type: I
ABN9L111B Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Black | Operation type: G
ABN9L111G Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Green | Operation type: G
ABN9L111R Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Red | Operation type: G
ABN9L111Y Operator: Lever operated | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow | Operation type: G
ABN6L122B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: B
ABN6L122G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: B
ABN6L122R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: B
ABN6L122Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: B
ABN6L222B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: C
ABN6L222G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: C
ABN6L222R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: C
ABN6L222Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: C
ABN6L422B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: I
ABN6L422G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: I
ABN6L422R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: I
ABN6L422Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: I
ABN7L122B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: D
ABN7L122G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: D
ABN7L122R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: D
ABN7L122Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: D
ABN7L222B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: E
ABN7L222G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: E
ABN7L222R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: E
ABN7L222Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: E
ABN7L322B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: F
ABN7L322G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: F
ABN7L322R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: F
ABN7L322Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: F
ABN9L122B Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Black | Operation type: H
ABN9L122G Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Green | Operation type: H
ABN9L122R Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Red | Operation type: H
ABN9L122Y Operator: Lever operated | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow | Operation type: H
Selector SwitchesIDEC
84 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

IDEC φ30 Series Selector Pushbuttons (Ring / Lever Operated)

Brand IDEC·Selector Switches

Available part numbers (84)

ABN6111B, ABN6111G, ABN6111R, ABN6111Y, ABN6411B, ABN6411G, ABN6411R, ABN6411Y, ABN9111B, ABN9111G + 74 more — see full table ↓

How to order

Send the IDEC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
