IDEC CW Series Accessories & Spare Parts

Dust covers, nameplate, replacement buttons and lenses, contact blocks, LED illumination units, keys and nuts for CW Series units.

Key features

CW9Z-D11/D12 dust covers give IP66/67, UL Type 4X front
YW-E contact blocks in 1- and 2-tier versions
φ22.3 mm panel cut-out per IEC 60947-5-1 with flush silhouette bezel
Black or metallic-colour bezel options
NC contacts with direct opening action; contact rating up to 10 A
Finger-protected IP20 terminals; IP66/67 and UL Type 4X front with dust cover

Specifications

For use with	CW Series
Series	IDEC CW Series (φ22)
Mounting hole	φ22.3 mm
Ordering	Order by the order part number shown
Pack suffix	PN02 / PN05 / PN10 = pack of 2 / 5 / 10
Product category	Accessory / maintenance part
Brand	IDEC
Source	IDEC CW Series φ22 Flush Silhouette Switches catalogue, p. 17-18

CW9Z-D11		Item: Dust cover, flush unit (IP66/67) \| Voltage: - \| Colour: - \| Pack: 1 pc
CW9Z-D12		Item: Dust cover, extended unit (IP66/67) \| Voltage: - \| Colour: - \| Pack: 1 pc
CWAM		Item: Nameplate CWAM, black resin (for HWNP) \| Voltage: - \| Colour: - \| Pack: 1 pc
CW9Z-B11BPN05		Item: Button, flush, alternate pushbutton \| Voltage: - \| Colour: Black \| Pack: Pack of 5
CW9Z-B11GPN05		Item: Button, flush, alternate pushbutton \| Voltage: - \| Colour: Green \| Pack: Pack of 5
CW9Z-B11RPN05		Item: Button, flush, alternate pushbutton \| Voltage: - \| Colour: Red \| Pack: Pack of 5
CW9Z-B11YPN05		Item: Button, flush, alternate pushbutton \| Voltage: - \| Colour: Yellow \| Pack: Pack of 5
CW9Z-B11SPN05		Item: Button, flush, alternate pushbutton \| Voltage: - \| Colour: Blue \| Pack: Pack of 5
CW9Z-B11WPN05		Item: Button, flush, alternate pushbutton \| Voltage: - \| Colour: White \| Pack: Pack of 5
CW9Z-B12BPN05		Item: Button, extended, alternate pushbutton \| Voltage: - \| Colour: Black \| Pack: Pack of 5
CW9Z-B12GPN05		Item: Button, extended, alternate pushbutton \| Voltage: - \| Colour: Green \| Pack: Pack of 5
CW9Z-B12RPN05		Item: Button, extended, alternate pushbutton \| Voltage: - \| Colour: Red \| Pack: Pack of 5
CW9Z-B12YPN05		Item: Button, extended, alternate pushbutton \| Voltage: - \| Colour: Yellow \| Pack: Pack of 5
CW9Z-B12SPN05		Item: Button, extended, alternate pushbutton \| Voltage: - \| Colour: Blue \| Pack: Pack of 5
CW9Z-B12WPN05		Item: Button, extended, alternate pushbutton \| Voltage: - \| Colour: White \| Pack: Pack of 5
CW9Z-L11RPN05		Item: Lens, flush (illum. PB / pilot light) \| Voltage: - \| Colour: Red \| Pack: Pack of 5
CW9Z-L11GPN05		Item: Lens, flush (illum. PB / pilot light) \| Voltage: - \| Colour: Green \| Pack: Pack of 5
CW9Z-L11YPN05		Item: Lens, flush (illum. PB / pilot light) \| Voltage: - \| Colour: Yellow \| Pack: Pack of 5
CW9Z-L11APN05		Item: Lens, flush (illum. PB / pilot light) \| Voltage: - \| Colour: Amber \| Pack: Pack of 5
CW9Z-L11CPN05		Item: Lens, flush (illum. PB / pilot light) \| Voltage: - \| Colour: Clear \| Pack: Pack of 5
CW9Z-L11SPN05		Item: Lens, flush (illum. PB / pilot light) \| Voltage: - \| Colour: Blue \| Pack: Pack of 5
CW9Z-L12RPN05		Item: Lens, extended (illum. pushbutton) \| Voltage: - \| Colour: Red \| Pack: Pack of 5
CW9Z-L12GPN05		Item: Lens, extended (illum. pushbutton) \| Voltage: - \| Colour: Green \| Pack: Pack of 5
CW9Z-L12YPN05		Item: Lens, extended (illum. pushbutton) \| Voltage: - \| Colour: Yellow \| Pack: Pack of 5
CW9Z-L12APN05		Item: Lens, extended (illum. pushbutton) \| Voltage: - \| Colour: Amber \| Pack: Pack of 5
CW9Z-L12CPN05		Item: Lens, extended (illum. pushbutton) \| Voltage: - \| Colour: Clear \| Pack: Pack of 5
CW9Z-L12SPN05		Item: Lens, extended (illum. pushbutton) \| Voltage: - \| Colour: Blue \| Pack: Pack of 5
CW9Z-L15RPN05		Item: Lens, extended (pilot light) \| Voltage: - \| Colour: Red \| Pack: Pack of 5
CW9Z-L15GPN05		Item: Lens, extended (pilot light) \| Voltage: - \| Colour: Green \| Pack: Pack of 5
CW9Z-L15YPN05		Item: Lens, extended (pilot light) \| Voltage: - \| Colour: Yellow \| Pack: Pack of 5
CW9Z-L15APN05		Item: Lens, extended (pilot light) \| Voltage: - \| Colour: Amber \| Pack: Pack of 5
CW9Z-L15CPN05		Item: Lens, extended (pilot light) \| Voltage: - \| Colour: Clear \| Pack: Pack of 5
CW9Z-L15SPN05		Item: Lens, extended (pilot light) \| Voltage: - \| Colour: Blue \| Pack: Pack of 5
YW-E10R		Item: Contact block, 1a (NO) \| Voltage: - \| Colour: - \| Pack: 1 pc
YW-E01		Item: Contact block, 1b (NC) \| Voltage: - \| Colour: - \| Pack: 1 pc
YW-EW2R0		Item: 2-tier contact block, 2a (2NO) \| Voltage: - \| Colour: - \| Pack: 1 pc
YW-EW02		Item: 2-tier contact block, 2b (2NC) \| Voltage: - \| Colour: - \| Pack: 1 pc
YW-EW1R1		Item: 2-tier contact block, 1a1b (NO+NC) \| Voltage: - \| Colour: - \| Pack: 1 pc
CW-DBPN05		Item: Dummy block (black polyamide) \| Voltage: - \| Colour: - \| Pack: Pack of 5
CW9Z-LNPN05		Item: Locking nut (black polyamide) \| Voltage: - \| Colour: - \| Pack: Pack of 5
CW9Z-WMPN10		Item: Rubber washer (nitrile) \| Voltage: - \| Colour: - \| Pack: Pack of 10
LA9Z-SK-0HPN02		Item: Spare key No. 0H, standard reversible \| Voltage: - \| Colour: - \| Pack: Pack of 2
LA9Z-SK-1HPN02		Item: Spare key No. 1H, reversible \| Voltage: - \| Colour: - \| Pack: Pack of 2
LA9Z-SK-2HPN02		Item: Spare key No. 2H, reversible \| Voltage: - \| Colour: - \| Pack: Pack of 2
LA9Z-SK-3HPN02		Item: Spare key No. 3H, single-direction \| Voltage: - \| Colour: - \| Pack: Pack of 2
LA9Z-SK-4HPN02		Item: Spare key No. 4H, single-direction \| Voltage: - \| Colour: - \| Pack: Pack of 2
LA9Z-SK-5HPN02		Item: Spare key No. 5H, single-direction \| Voltage: - \| Colour: - \| Pack: Pack of 2
LA9Z-SK-6HPN02		Item: Spare key No. 6H, single-direction \| Voltage: - \| Colour: - \| Pack: Pack of 2
CW-EAQ2R		Item: LED illumination unit \| Voltage: AC/DC6V \| Colour: Red \| Pack: -
CW-EAQ2G		Item: LED illumination unit \| Voltage: AC/DC6V \| Colour: Green \| Pack: -
CW-EAQ2A		Item: LED illumination unit \| Voltage: AC/DC6V \| Colour: Amber \| Pack: -
CW-EAQ2S		Item: LED illumination unit \| Voltage: AC/DC6V \| Colour: Blue \| Pack: -
CW-EAQ2PW		Item: LED illumination unit \| Voltage: AC/DC6V \| Colour: Pure white \| Pack: -
CW-EAQ3R		Item: LED illumination unit \| Voltage: AC/DC12V \| Colour: Red \| Pack: -
CW-EAQ3G		Item: LED illumination unit \| Voltage: AC/DC12V \| Colour: Green \| Pack: -
CW-EAQ3A		Item: LED illumination unit \| Voltage: AC/DC12V \| Colour: Amber \| Pack: -
CW-EAQ3S		Item: LED illumination unit \| Voltage: AC/DC12V \| Colour: Blue \| Pack: -
CW-EAQ3PW		Item: LED illumination unit \| Voltage: AC/DC12V \| Colour: Pure white \| Pack: -
CW-EAQ4R		Item: LED illumination unit \| Voltage: AC/DC24V \| Colour: Red \| Pack: -
CW-EAQ4G		Item: LED illumination unit \| Voltage: AC/DC24V \| Colour: Green \| Pack: -
CW-EAQ4A		Item: LED illumination unit \| Voltage: AC/DC24V \| Colour: Amber \| Pack: -
CW-EAQ4S		Item: LED illumination unit \| Voltage: AC/DC24V \| Colour: Blue \| Pack: -
CW-EAQ4PW		Item: LED illumination unit \| Voltage: AC/DC24V \| Colour: Pure white \| Pack: -
CW-EAQHR		Item: LED illumination unit \| Voltage: AC100/120V \| Colour: Red \| Pack: -
CW-EAQHG		Item: LED illumination unit \| Voltage: AC100/120V \| Colour: Green \| Pack: -
CW-EAQHA		Item: LED illumination unit \| Voltage: AC100/120V \| Colour: Amber \| Pack: -
CW-EAQHS		Item: LED illumination unit \| Voltage: AC100/120V \| Colour: Blue \| Pack: -
CW-EAQHPW		Item: LED illumination unit \| Voltage: AC100/120V \| Colour: Pure white \| Pack: -
CW-EAQMR		Item: LED illumination unit \| Voltage: AC200/220V \| Colour: Red \| Pack: -
CW-EAQMG		Item: LED illumination unit \| Voltage: AC200/220V \| Colour: Green \| Pack: -
CW-EAQMA		Item: LED illumination unit \| Voltage: AC200/220V \| Colour: Amber \| Pack: -
CW-EAQMS		Item: LED illumination unit \| Voltage: AC200/220V \| Colour: Blue \| Pack: -
CW-EAQMPW		Item: LED illumination unit \| Voltage: AC200/220V \| Colour: Pure white \| Pack: -
CW-EAQM4R		Item: LED illumination unit \| Voltage: AC230/240V \| Colour: Red \| Pack: -
CW-EAQM4G		Item: LED illumination unit \| Voltage: AC230/240V \| Colour: Green \| Pack: -
CW-EAQM4A		Item: LED illumination unit \| Voltage: AC230/240V \| Colour: Amber \| Pack: -
CW-EAQM4S		Item: LED illumination unit \| Voltage: AC230/240V \| Colour: Blue \| Pack: -
CW-EAQM4PW		Item: LED illumination unit \| Voltage: AC230/240V \| Colour: Pure white \| Pack: -
