IDEC TW Series 22 mm Square Pushbuttons (Flush, Extended)

IDEC TW Series 22 mm Square Pushbuttons (Flush, Extended)

TW Series φ22 pushbuttons with square flush or square extended buttons and black resin square ring, momentary or alternate action.

Key features

  • Square resin ring (black)
  • Button colours B, G, R, Y, S, W
  • φ22.3 mm panel cut-out, heavy-duty one-piece construction
  • Finger-protected SS terminals accept ring tongue terminals without removing screws
  • Front protection IP65 (IEC 60529); main models UL/CSA listed and EN compliant
  • HW-G contact blocks rated 600 V / 10 A (AC-15 A600, DC-13 P600); up to 2 tiers (4 blocks)

Specifications

Series IDEC TW Series (φ22)
Mounting hole φ22.3 mm (IEC 60947-5-1)
Panel thickness 1 to 6 mm
Contact block HW-G, 600 V / 10 A (AC-15 A600, DC-13 P600)
Operating temperature -25 to +50 °C (no freezing)
Insulation resistance 100 MΩ min. (500 V DC megger)
Terminals M3.5 screw, finger-protected SS terminals
Source IDEC TW Series φ22 Control Units catalogue, p. 8
ABQW110B Operator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Black
ABQW110G Operator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Green
ABQW110R Operator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Red
ABQW110Y Operator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Yellow
ABQW110S Operator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Blue
ABQW110W Operator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: White
ABQW101B Operator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Black
ABQW101G Operator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Green
ABQW101R Operator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Red
ABQW101Y Operator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Yellow
ABQW101S Operator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Blue
ABQW101W Operator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: White
ABQW111B Operator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Black
ABQW111G Operator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Green
ABQW111R Operator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Red
ABQW111Y Operator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
ABQW111S Operator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
ABQW111W Operator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: White
ABQW120B Operator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Black
ABQW120G Operator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Green
ABQW120R Operator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Red
ABQW120Y Operator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Yellow
ABQW120S Operator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Blue
ABQW120W Operator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: White
ABQW102B Operator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Black
ABQW102G Operator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Green
ABQW102R Operator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Red
ABQW102Y Operator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Yellow
ABQW102S Operator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Blue
ABQW102W Operator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: White
ABQW122B Operator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Black
ABQW122G Operator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Green
ABQW122R Operator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Red
ABQW122Y Operator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
ABQW122S Operator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
ABQW122W Operator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: White
AOQW110B Operator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Black
AOQW110G Operator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Green
AOQW110R Operator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Red
AOQW110Y Operator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Yellow
AOQW110S Operator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Blue
AOQW110W Operator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: White
AOQW101B Operator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Black
AOQW101G Operator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Green
AOQW101R Operator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Red
AOQW101Y Operator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Yellow
AOQW101S Operator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Blue
AOQW101W Operator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: White
AOQW111B Operator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Black
AOQW111G Operator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Green
AOQW111R Operator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Red
AOQW111Y Operator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
AOQW111S Operator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
AOQW111W Operator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: White
AOQW120B Operator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Black
AOQW120G Operator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Green
AOQW120R Operator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Red
AOQW120Y Operator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Yellow
AOQW120S Operator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Blue
AOQW120W Operator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: White
AOQW102B Operator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Black
AOQW102G Operator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Green
AOQW102R Operator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Red
AOQW102Y Operator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Yellow
AOQW102S Operator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Blue
AOQW102W Operator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: White
AOQW122B Operator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Black
AOQW122G Operator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Green
AOQW122R Operator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Red
AOQW122Y Operator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
AOQW122S Operator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
AOQW122W Operator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: White
ABQW210B Operator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Black
ABQW210G Operator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Green
ABQW210R Operator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Red
ABQW210Y Operator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Yellow
ABQW210S Operator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Blue
ABQW210W Operator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: White
ABQW201B Operator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Black
ABQW201G Operator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Green
ABQW201R Operator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Red
ABQW201Y Operator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Yellow
ABQW201S Operator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Blue
ABQW201W Operator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: White
ABQW211B Operator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Black
ABQW211G Operator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Green
ABQW211R Operator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Red
ABQW211Y Operator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
ABQW211S Operator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
ABQW211W Operator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: White
ABQW220B Operator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Black
ABQW220G Operator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Green
ABQW220R Operator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Red
ABQW220Y Operator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Yellow
ABQW220S Operator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Blue
ABQW220W Operator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: White
ABQW202B Operator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Black
ABQW202G Operator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Green
ABQW202R Operator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Red
ABQW202Y Operator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Yellow
ABQW202S Operator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Blue
ABQW202W Operator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: White
ABQW222B Operator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Black
ABQW222G Operator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Green
ABQW222R Operator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Red
ABQW222Y Operator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
ABQW222S Operator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
ABQW222W Operator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: White
AOQW210B Operator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Black
AOQW210G Operator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Green
AOQW210R Operator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Red
AOQW210Y Operator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Yellow
AOQW210S Operator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Blue
AOQW210W Operator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: White
AOQW201B Operator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Black
AOQW201G Operator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Green
AOQW201R Operator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Red
AOQW201Y Operator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Yellow
AOQW201S Operator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Blue
AOQW201W Operator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: White
AOQW211B Operator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Black
AOQW211G Operator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Green
AOQW211R Operator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Red
AOQW211Y Operator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
AOQW211S Operator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
AOQW211W Operator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: White
AOQW220B Operator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Black
AOQW220G Operator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Green
AOQW220R Operator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Red
AOQW220Y Operator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Yellow
AOQW220S Operator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Blue
AOQW220W Operator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: White
AOQW202B Operator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Black
AOQW202G Operator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Green
AOQW202R Operator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Red
AOQW202Y Operator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Yellow
AOQW202S Operator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Blue
AOQW202W Operator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: White
AOQW222B Operator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Black
AOQW222G Operator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Green
AOQW222R Operator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Red
AOQW222Y Operator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
AOQW222S Operator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
AOQW222W Operator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: White
PushbuttonsIDEC
144 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

IDEC TW Series 22 mm Square Pushbuttons (Flush, Extended)

Brand IDEC·Pushbuttons

Available part numbers (144)

ABQW110B, ABQW110G, ABQW110R, ABQW110Y, ABQW110S, ABQW110W, ABQW101B, ABQW101G, ABQW101R, ABQW101Y + 134 more — see full table ↓

How to order

Send the IDEC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ABQW110BOperator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Black
ABQW110GOperator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Green
ABQW110ROperator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Red
ABQW110YOperator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Yellow
ABQW110SOperator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: Blue
ABQW110WOperator: Square flush | Action: Momentary | Contacts: 1a (1NO) | Colour: White
ABQW101BOperator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Black
ABQW101GOperator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Green
ABQW101ROperator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Red
ABQW101YOperator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Yellow
ABQW101SOperator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: Blue
ABQW101WOperator: Square flush | Action: Momentary | Contacts: 1b (1NC) | Colour: White
ABQW111BOperator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Black
ABQW111GOperator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Green
ABQW111ROperator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Red
ABQW111YOperator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
ABQW111SOperator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
ABQW111WOperator: Square flush | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: White
ABQW120BOperator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Black
ABQW120GOperator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Green
ABQW120ROperator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Red
ABQW120YOperator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Yellow
ABQW120SOperator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: Blue
ABQW120WOperator: Square flush | Action: Momentary | Contacts: 2a (2NO) | Colour: White
ABQW102BOperator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Black
ABQW102GOperator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Green
ABQW102ROperator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Red
ABQW102YOperator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Yellow
ABQW102SOperator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: Blue
ABQW102WOperator: Square flush | Action: Momentary | Contacts: 2b (2NC) | Colour: White
ABQW122BOperator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Black
ABQW122GOperator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Green
ABQW122ROperator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Red
ABQW122YOperator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
ABQW122SOperator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
ABQW122WOperator: Square flush | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: White
AOQW110BOperator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Black
AOQW110GOperator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Green
AOQW110ROperator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Red
AOQW110YOperator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Yellow
AOQW110SOperator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: Blue
AOQW110WOperator: Square flush | Action: Alternate | Contacts: 1a (1NO) | Colour: White
AOQW101BOperator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Black
AOQW101GOperator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Green
AOQW101ROperator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Red
AOQW101YOperator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Yellow
AOQW101SOperator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: Blue
AOQW101WOperator: Square flush | Action: Alternate | Contacts: 1b (1NC) | Colour: White
AOQW111BOperator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Black
AOQW111GOperator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Green
AOQW111ROperator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Red
AOQW111YOperator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
AOQW111SOperator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
AOQW111WOperator: Square flush | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: White
AOQW120BOperator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Black
AOQW120GOperator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Green
AOQW120ROperator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Red
AOQW120YOperator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Yellow
AOQW120SOperator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: Blue
AOQW120WOperator: Square flush | Action: Alternate | Contacts: 2a (2NO) | Colour: White
AOQW102BOperator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Black
AOQW102GOperator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Green
AOQW102ROperator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Red
AOQW102YOperator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Yellow
AOQW102SOperator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: Blue
AOQW102WOperator: Square flush | Action: Alternate | Contacts: 2b (2NC) | Colour: White
AOQW122BOperator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Black
AOQW122GOperator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Green
AOQW122ROperator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Red
AOQW122YOperator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
AOQW122SOperator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
AOQW122WOperator: Square flush | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: White
ABQW210BOperator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Black
ABQW210GOperator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Green
ABQW210ROperator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Red
ABQW210YOperator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Yellow
ABQW210SOperator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: Blue
ABQW210WOperator: Square extended | Action: Momentary | Contacts: 1a (1NO) | Colour: White
ABQW201BOperator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Black
ABQW201GOperator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Green
ABQW201ROperator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Red
ABQW201YOperator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Yellow
ABQW201SOperator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: Blue
ABQW201WOperator: Square extended | Action: Momentary | Contacts: 1b (1NC) | Colour: White
ABQW211BOperator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Black
ABQW211GOperator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Green
ABQW211ROperator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Red
ABQW211YOperator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
ABQW211SOperator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
ABQW211WOperator: Square extended | Action: Momentary | Contacts: 1a-1b (1NO+1NC) | Colour: White
ABQW220BOperator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Black
ABQW220GOperator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Green
ABQW220ROperator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Red
ABQW220YOperator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Yellow
ABQW220SOperator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: Blue
ABQW220WOperator: Square extended | Action: Momentary | Contacts: 2a (2NO) | Colour: White
ABQW202BOperator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Black
ABQW202GOperator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Green
ABQW202ROperator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Red
ABQW202YOperator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Yellow
ABQW202SOperator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: Blue
ABQW202WOperator: Square extended | Action: Momentary | Contacts: 2b (2NC) | Colour: White
ABQW222BOperator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Black
ABQW222GOperator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Green
ABQW222ROperator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Red
ABQW222YOperator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
ABQW222SOperator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
ABQW222WOperator: Square extended | Action: Momentary | Contacts: 2a-2b (2NO+2NC) | Colour: White
AOQW210BOperator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Black
AOQW210GOperator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Green
AOQW210ROperator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Red
AOQW210YOperator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Yellow
AOQW210SOperator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: Blue
AOQW210WOperator: Square extended | Action: Alternate | Contacts: 1a (1NO) | Colour: White
AOQW201BOperator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Black
AOQW201GOperator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Green
AOQW201ROperator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Red
AOQW201YOperator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Yellow
AOQW201SOperator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: Blue
AOQW201WOperator: Square extended | Action: Alternate | Contacts: 1b (1NC) | Colour: White
AOQW211BOperator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Black
AOQW211GOperator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Green
AOQW211ROperator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Red
AOQW211YOperator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Yellow
AOQW211SOperator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: Blue
AOQW211WOperator: Square extended | Action: Alternate | Contacts: 1a-1b (1NO+1NC) | Colour: White
AOQW220BOperator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Black
AOQW220GOperator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Green
AOQW220ROperator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Red
AOQW220YOperator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Yellow
AOQW220SOperator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: Blue
AOQW220WOperator: Square extended | Action: Alternate | Contacts: 2a (2NO) | Colour: White
AOQW202BOperator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Black
AOQW202GOperator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Green
AOQW202ROperator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Red
AOQW202YOperator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Yellow
AOQW202SOperator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: Blue
AOQW202WOperator: Square extended | Action: Alternate | Contacts: 2b (2NC) | Colour: White
AOQW222BOperator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Black
AOQW222GOperator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Green
AOQW222ROperator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Red
AOQW222YOperator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Yellow
AOQW222SOperator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: Blue
AOQW222WOperator: Square extended | Action: Alternate | Contacts: 2a-2b (2NO+2NC) | Colour: White

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Relays & Switches →
