IDEC TWS Series 25 mm Illuminated Selector Switches (Incandescent)

TWS Series φ25 illuminated selector switches with incandescent lamp, 90° 2-position and 45° 3-position.

Key features

Specify illumination colour code in the part number
Rated voltages AC/DC6V to AC200/220V
φ25 mm heavy-duty series with finger-protected SS terminals; no terminal cover needed
HW-G contact blocks rated 600 V / 10 A (AC-15 A600, DC-13 P600)
Up to 2 tiers (4 blocks) of contacts per operator
UL/CSA listed and EN compliant (some models excluded)

Specifications

Operator	Illuminated handle
Series	IDEC TWS Series (φ25)
Panel thickness	0.8 to 6 mm
Contact block	HW-G, 600 V / 10 A (AC-15 A600, DC-13 P600)
Operating temperature	-25 to +50 °C (no freezing)
Insulation resistance	100 MΩ min. (500 V DC megger)
Protection	IP65 (A-prefix), IP40 (U-prefix square units)
Source	IDEC TWS Series φ25 Control Units catalogue, p. 22

ASLS26611NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS26611NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS26611NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS26611NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS26611NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS28811NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS28811NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS28811NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS28811NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS28811NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS23311NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS23311NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS23311NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS23311NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS23311NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS21611NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS21611NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS21611NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS21611NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS21611NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS22611NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS22611NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS22611NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS22611NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS22611NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS26620NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS26620NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS26620NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS26620NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS26620NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS28820NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS28820NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS28820NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS28820NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS28820NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS23320NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS23320NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS23320NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS23320NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS23320NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS21620NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS21620NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS21620NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS21620NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS21620NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS22620NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS22620NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS22620NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS22620NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS22620NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS26622NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS26622NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS26622NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS26622NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS26622NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS28822NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS28822NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS28822NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS28822NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS28822NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS23322NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS23322NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS23322NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS23322NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS23322NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS21622NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS21622NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS21622NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS21622NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS21622NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS22622NR		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS22622NG		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS22622NA		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS22622NW		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS22622NS		Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS36620NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS36620NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS36620NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS36620NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS36620NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS38820NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS38820NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS38820NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS38820NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS38820NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS33320NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS33320NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS33320NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS33320NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS33320NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS31620NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS31620NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS31620NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS31620NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS31620NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS32620NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS32620NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS32620NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS32620NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS32620NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS36602NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
ASLS36602NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
ASLS36602NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS36602NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
ASLS36602NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS38802NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
ASLS38802NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
ASLS38802NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS38802NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
ASLS38802NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS33302NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
ASLS33302NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
ASLS33302NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS33302NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
ASLS33302NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS31602NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
ASLS31602NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
ASLS31602NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS31602NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
ASLS31602NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS32602NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
ASLS32602NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
ASLS32602NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS32602NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
ASLS32602NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS36622NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS36622NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS36622NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS36622NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS36622NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS38822NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS38822NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS38822NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS38822NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS38822NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS33322NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS33322NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS33322NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS33322NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS33322NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS31622NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS31622NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS31622NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS31622NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS31622NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS32622NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS32622NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS32622NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS32622NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS32622NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS36640NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
ASLS36640NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
ASLS36640NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS36640NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
ASLS36640NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS38840NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
ASLS38840NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
ASLS38840NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS38840NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
ASLS38840NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS33340NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
ASLS33340NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
ASLS33340NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS33340NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
ASLS33340NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS31640NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
ASLS31640NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
ASLS31640NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
ASLS31640NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
ASLS31640NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
ASLS32640NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
ASLS32640NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
ASLS32640NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS32640NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
ASLS32640NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS36604NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
ASLS36604NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
ASLS36604NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS36604NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
ASLS36604NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS38804NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
ASLS38804NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
ASLS38804NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS38804NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
ASLS38804NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS33304NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
ASLS33304NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
ASLS33304NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS33304NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
ASLS33304NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS31604NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
ASLS31604NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
ASLS31604NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS31604NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
ASLS31604NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS32604NR		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
ASLS32604NG		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
ASLS32604NA		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS32604NW		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
ASLS32604NS		Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS216611NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS216611NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS216611NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS216611NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS216611NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS218811NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS218811NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS218811NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS218811NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS218811NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS213311NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS213311NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS213311NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS213311NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS213311NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS211611NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS211611NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS211611NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS211611NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS211611NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS212611NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS212611NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS212611NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS212611NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS212611NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS216620NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS216620NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS216620NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS216620NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS216620NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS218820NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS218820NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS218820NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS218820NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS218820NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS213320NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS213320NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS213320NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS213320NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS213320NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS211620NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS211620NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS211620NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS211620NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS211620NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS212620NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS212620NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS212620NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS212620NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS212620NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS216622NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS216622NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS216622NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS216622NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS216622NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS218822NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS218822NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS218822NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS218822NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS218822NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS213322NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS213322NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS213322NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS213322NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS213322NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS211622NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS211622NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS211622NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS211622NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS211622NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS212622NR		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS212622NG		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS212622NA		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS212622NW		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS212622NS		Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS316620NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS316620NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS316620NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS316620NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS316620NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS318820NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS318820NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS318820NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS318820NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS318820NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS313320NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS313320NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS313320NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS313320NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS313320NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS311620NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS311620NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS311620NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS311620NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS311620NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS312620NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS312620NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS312620NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS312620NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS312620NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS316602NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
ASLS316602NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
ASLS316602NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS316602NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
ASLS316602NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS318802NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
ASLS318802NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
ASLS318802NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS318802NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
ASLS318802NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS313302NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
ASLS313302NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
ASLS313302NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS313302NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
ASLS313302NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS311602NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
ASLS311602NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
ASLS311602NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS311602NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
ASLS311602NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS312602NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
ASLS312602NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
ASLS312602NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS312602NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
ASLS312602NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS316622NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS316622NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS316622NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS316622NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS316622NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS318822NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS318822NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS318822NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS318822NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS318822NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS313322NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS313322NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS313322NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS313322NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS313322NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS311622NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS311622NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS311622NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS311622NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS311622NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS312622NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS312622NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS312622NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS312622NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS312622NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS316640NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
ASLS316640NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
ASLS316640NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS316640NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
ASLS316640NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS318840NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
ASLS318840NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
ASLS318840NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS318840NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
ASLS318840NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS313340NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
ASLS313340NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
ASLS313340NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS313340NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
ASLS313340NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS311640NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
ASLS311640NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
ASLS311640NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
ASLS311640NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
ASLS311640NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
ASLS312640NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
ASLS312640NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
ASLS312640NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS312640NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
ASLS312640NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS316604NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
ASLS316604NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
ASLS316604NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS316604NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
ASLS316604NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS318804NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
ASLS318804NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
ASLS318804NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS318804NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
ASLS318804NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS313304NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
ASLS313304NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
ASLS313304NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS313304NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
ASLS313304NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS311604NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
ASLS311604NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
ASLS311604NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS311604NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
ASLS311604NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS312604NR		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
ASLS312604NG		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
ASLS312604NA		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS312604NW		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
ASLS312604NS		Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS226611NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS226611NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS226611NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS226611NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS226611NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS228811NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS228811NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS228811NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS228811NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS228811NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS223311NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS223311NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS223311NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS223311NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS223311NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS221611NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS221611NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS221611NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS221611NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS221611NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS222611NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
ASLS222611NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
ASLS222611NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
ASLS222611NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
ASLS222611NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
ASLS226620NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS226620NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS226620NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS226620NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS226620NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS228820NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS228820NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS228820NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS228820NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS228820NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS223320NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS223320NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS223320NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS223320NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS223320NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS221620NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS221620NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS221620NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS221620NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS221620NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS222620NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS222620NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS222620NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS222620NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS222620NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS226622NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS226622NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS226622NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS226622NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS226622NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS228822NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS228822NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS228822NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS228822NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS228822NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS223322NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS223322NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS223322NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS223322NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS223322NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS221622NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS221622NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS221622NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS221622NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS221622NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS222622NR		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS222622NG		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS222622NA		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS222622NW		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS222622NS		Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS326620NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS326620NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS326620NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS326620NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS326620NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS328820NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS328820NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS328820NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS328820NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS328820NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS323320NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS323320NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS323320NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS323320NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS323320NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS321620NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS321620NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS321620NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS321620NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS321620NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS322620NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS322620NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS322620NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS322620NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS322620NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS326602NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
ASLS326602NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
ASLS326602NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS326602NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
ASLS326602NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS328802NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
ASLS328802NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
ASLS328802NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS328802NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
ASLS328802NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS323302NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
ASLS323302NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
ASLS323302NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS323302NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
ASLS323302NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS321602NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
ASLS321602NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
ASLS321602NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS321602NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
ASLS321602NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS322602NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
ASLS322602NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
ASLS322602NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS322602NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
ASLS322602NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS326622NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS326622NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS326622NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS326622NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS326622NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS328822NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS328822NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS328822NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS328822NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS328822NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS323322NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS323322NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS323322NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS323322NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS323322NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS321622NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS321622NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS321622NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS321622NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS321622NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS322622NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS322622NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS322622NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS322622NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS322622NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS326640NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
ASLS326640NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
ASLS326640NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS326640NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
ASLS326640NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS328840NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
ASLS328840NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
ASLS328840NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS328840NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
ASLS328840NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS323340NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
ASLS323340NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
ASLS323340NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS323340NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
ASLS323340NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS321640NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
ASLS321640NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
ASLS321640NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
ASLS321640NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
ASLS321640NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
ASLS322640NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
ASLS322640NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
ASLS322640NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS322640NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
ASLS322640NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS326604NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
ASLS326604NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
ASLS326604NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS326604NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
ASLS326604NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS328804NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
ASLS328804NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
ASLS328804NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS328804NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
ASLS328804NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS323304NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
ASLS323304NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
ASLS323304NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS323304NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
ASLS323304NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS321604NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
ASLS321604NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
ASLS321604NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS321604NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
ASLS321604NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS322604NR		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
ASLS322604NG		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
ASLS322604NA		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS322604NW		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
ASLS322604NS		Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS336620NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
ASLS336620NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
ASLS336620NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS336620NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
ASLS336620NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS338820NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
ASLS338820NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
ASLS338820NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS338820NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
ASLS338820NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS333320NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
ASLS333320NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
ASLS333320NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS333320NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
ASLS333320NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS331620NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
ASLS331620NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
ASLS331620NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS331620NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
ASLS331620NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS332620NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
ASLS332620NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
ASLS332620NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
ASLS332620NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
ASLS332620NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
ASLS336602NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
ASLS336602NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
ASLS336602NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS336602NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
ASLS336602NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS338802NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
ASLS338802NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
ASLS338802NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS338802NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
ASLS338802NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS333302NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
ASLS333302NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
ASLS333302NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS333302NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
ASLS333302NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS331602NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
ASLS331602NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
ASLS331602NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS331602NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
ASLS331602NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS332602NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
ASLS332602NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
ASLS332602NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
ASLS332602NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
ASLS332602NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
ASLS336622NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS336622NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS336622NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS336622NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS336622NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS338822NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS338822NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS338822NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS338822NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS338822NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS333322NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS333322NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS333322NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS333322NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS333322NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS331622NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS331622NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS331622NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS331622NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS331622NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS332622NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
ASLS332622NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
ASLS332622NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
ASLS332622NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
ASLS332622NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
ASLS336640NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
ASLS336640NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
ASLS336640NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS336640NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
ASLS336640NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS338840NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
ASLS338840NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
ASLS338840NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS338840NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
ASLS338840NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS333340NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
ASLS333340NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
ASLS333340NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS333340NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
ASLS333340NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS331640NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
ASLS331640NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
ASLS331640NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
ASLS331640NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
ASLS331640NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
ASLS332640NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
ASLS332640NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
ASLS332640NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
ASLS332640NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
ASLS332640NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
ASLS336604NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
ASLS336604NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
ASLS336604NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS336604NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
ASLS336604NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS338804NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
ASLS338804NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
ASLS338804NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS338804NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
ASLS338804NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS333304NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
ASLS333304NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
ASLS333304NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS333304NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
ASLS333304NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS331604NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
ASLS331604NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
ASLS331604NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS331604NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
ASLS331604NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
ASLS332604NR		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
ASLS332604NG		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
ASLS332604NA		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
ASLS332604NW		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
ASLS332604NS		Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue

Selector SwitchesIDEC

725 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

IDEC TWS Series 25 mm Illuminated Selector Switches (Incandescent)

Brand IDEC·Selector Switches

Available part numbers (725)

ASLS26611NR, ASLS26611NG, ASLS26611NA, ASLS26611NW, ASLS26611NS, ASLS28811NR, ASLS28811NG, ASLS28811NA, ASLS28811NW, ASLS28811NS + 715 more — see full table ↓

How to order

Send the IDEC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	ASLS26611NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS26611NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS26611NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS26611NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS26611NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS28811NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS28811NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS28811NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS28811NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS28811NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS23311NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS23311NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS23311NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS23311NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS23311NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS21611NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS21611NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS21611NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS21611NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS21611NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS22611NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS22611NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS22611NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS22611NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS22611NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS26620NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS26620NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS26620NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS26620NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS26620NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS28820NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS28820NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS28820NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS28820NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS28820NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS23320NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS23320NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS23320NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS23320NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS23320NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS21620NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS21620NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS21620NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS21620NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS21620NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS22620NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS22620NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS22620NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS22620NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS22620NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS26622NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS26622NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS26622NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS26622NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS26622NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS28822NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS28822NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS28822NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS28822NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS28822NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS23322NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS23322NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS23322NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS23322NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS23322NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS21622NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS21622NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS21622NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS21622NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS21622NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS22622NR	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS22622NG	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS22622NA	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS22622NW	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS22622NS	Positions: 90° 2-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS36620NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS36620NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS36620NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS36620NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS36620NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS38820NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS38820NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS38820NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS38820NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS38820NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS33320NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS33320NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS33320NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS33320NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS33320NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS31620NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS31620NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS31620NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS31620NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS31620NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS32620NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS32620NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS32620NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS32620NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS32620NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS36602NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS36602NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS36602NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS36602NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
	ASLS36602NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS38802NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS38802NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS38802NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS38802NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
	ASLS38802NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS33302NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS33302NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS33302NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS33302NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
	ASLS33302NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS31602NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS31602NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS31602NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS31602NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
	ASLS31602NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS32602NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS32602NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS32602NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS32602NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
	ASLS32602NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS36622NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS36622NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS36622NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS36622NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS36622NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS38822NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS38822NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS38822NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS38822NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS38822NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS33322NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS33322NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS33322NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS33322NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS33322NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS31622NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS31622NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS31622NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS31622NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS31622NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS32622NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS32622NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS32622NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS32622NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS32622NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS36640NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS36640NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS36640NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS36640NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
	ASLS36640NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS38840NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS38840NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS38840NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS38840NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
	ASLS38840NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS33340NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS33340NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS33340NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS33340NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
	ASLS33340NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS31640NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
	ASLS31640NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
	ASLS31640NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS31640NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
	ASLS31640NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS32640NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS32640NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS32640NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS32640NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
	ASLS32640NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS36604NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS36604NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS36604NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS36604NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
	ASLS36604NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS38804NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS38804NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS38804NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS38804NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
	ASLS38804NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS33304NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS33304NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS33304NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS33304NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
	ASLS33304NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS31604NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS31604NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS31604NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS31604NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
	ASLS31604NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS32604NR	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS32604NG	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS32604NA	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS32604NW	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
	ASLS32604NS	Positions: 45° 3-position \| Operation: Maintained \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS216611NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS216611NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS216611NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS216611NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS216611NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS218811NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS218811NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS218811NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS218811NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS218811NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS213311NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS213311NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS213311NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS213311NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS213311NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS211611NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS211611NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS211611NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS211611NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS211611NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS212611NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS212611NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS212611NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS212611NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS212611NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS216620NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS216620NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS216620NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS216620NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS216620NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS218820NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS218820NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS218820NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS218820NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS218820NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS213320NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS213320NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS213320NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS213320NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS213320NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS211620NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS211620NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS211620NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS211620NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS211620NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS212620NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS212620NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS212620NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS212620NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS212620NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS216622NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS216622NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS216622NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS216622NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS216622NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS218822NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS218822NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS218822NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS218822NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS218822NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS213322NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS213322NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS213322NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS213322NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS213322NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS211622NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS211622NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS211622NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS211622NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS211622NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS212622NR	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS212622NG	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS212622NA	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS212622NW	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS212622NS	Positions: 90° 2-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS316620NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS316620NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS316620NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS316620NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS316620NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS318820NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS318820NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS318820NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS318820NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS318820NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS313320NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS313320NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS313320NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS313320NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS313320NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS311620NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS311620NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS311620NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS311620NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS311620NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS312620NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS312620NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS312620NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS312620NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS312620NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS316602NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS316602NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS316602NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS316602NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
	ASLS316602NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS318802NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS318802NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS318802NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS318802NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
	ASLS318802NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS313302NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS313302NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS313302NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS313302NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
	ASLS313302NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS311602NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS311602NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS311602NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS311602NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
	ASLS311602NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS312602NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS312602NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS312602NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS312602NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
	ASLS312602NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS316622NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS316622NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS316622NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS316622NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS316622NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS318822NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS318822NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS318822NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS318822NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS318822NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS313322NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS313322NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS313322NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS313322NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS313322NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS311622NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS311622NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS311622NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS311622NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS311622NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS312622NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS312622NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS312622NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS312622NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS312622NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS316640NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS316640NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS316640NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS316640NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
	ASLS316640NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS318840NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS318840NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS318840NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS318840NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
	ASLS318840NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS313340NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS313340NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS313340NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS313340NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
	ASLS313340NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS311640NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
	ASLS311640NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
	ASLS311640NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS311640NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
	ASLS311640NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS312640NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS312640NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS312640NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS312640NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
	ASLS312640NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS316604NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS316604NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS316604NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS316604NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
	ASLS316604NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS318804NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS318804NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS318804NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS318804NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
	ASLS318804NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS313304NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS313304NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS313304NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS313304NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
	ASLS313304NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS311604NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS311604NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS311604NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS311604NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
	ASLS311604NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS312604NR	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS312604NG	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS312604NA	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS312604NW	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
	ASLS312604NS	Positions: 45° 3-position \| Operation: Spring return from right \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS226611NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS226611NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS226611NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS226611NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS226611NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS228811NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS228811NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS228811NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS228811NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS228811NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS223311NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS223311NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS223311NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS223311NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS223311NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS221611NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS221611NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS221611NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS221611NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS221611NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS222611NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Red
	ASLS222611NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Green
	ASLS222611NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Amber
	ASLS222611NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: White
	ASLS222611NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 1a-1b (1NO+1NC) \| Colour: Blue
	ASLS226620NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS226620NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS226620NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS226620NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS226620NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS228820NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS228820NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS228820NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS228820NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS228820NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS223320NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS223320NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS223320NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS223320NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS223320NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS221620NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS221620NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS221620NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS221620NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS221620NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS222620NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS222620NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS222620NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS222620NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS222620NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS226622NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS226622NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS226622NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS226622NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS226622NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS228822NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS228822NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS228822NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS228822NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS228822NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS223322NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS223322NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS223322NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS223322NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS223322NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS221622NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS221622NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS221622NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS221622NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS221622NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS222622NR	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS222622NG	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS222622NA	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS222622NW	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS222622NS	Positions: 90° 2-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS326620NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS326620NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS326620NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS326620NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS326620NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS328820NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS328820NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS328820NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS328820NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS328820NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS323320NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS323320NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS323320NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS323320NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS323320NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS321620NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS321620NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS321620NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS321620NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS321620NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS322620NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS322620NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS322620NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS322620NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS322620NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS326602NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS326602NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS326602NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS326602NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
	ASLS326602NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS328802NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS328802NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS328802NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS328802NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
	ASLS328802NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS323302NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS323302NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS323302NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS323302NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
	ASLS323302NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS321602NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS321602NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS321602NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS321602NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
	ASLS321602NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS322602NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS322602NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS322602NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS322602NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
	ASLS322602NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS326622NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS326622NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS326622NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS326622NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS326622NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS328822NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS328822NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS328822NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS328822NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS328822NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS323322NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS323322NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS323322NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS323322NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS323322NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS321622NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS321622NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS321622NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS321622NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS321622NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS322622NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS322622NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS322622NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS322622NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS322622NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS326640NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS326640NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS326640NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS326640NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
	ASLS326640NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS328840NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS328840NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS328840NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS328840NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
	ASLS328840NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS323340NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS323340NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS323340NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS323340NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
	ASLS323340NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS321640NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
	ASLS321640NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
	ASLS321640NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS321640NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
	ASLS321640NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS322640NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS322640NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS322640NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS322640NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
	ASLS322640NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS326604NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS326604NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS326604NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS326604NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
	ASLS326604NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS328804NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS328804NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS328804NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS328804NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
	ASLS328804NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS323304NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS323304NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS323304NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS323304NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
	ASLS323304NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS321604NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS321604NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS321604NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS321604NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
	ASLS321604NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS322604NR	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS322604NG	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS322604NA	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS322604NW	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
	ASLS322604NS	Positions: 45° 3-position \| Operation: Spring return from left \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS336620NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS336620NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS336620NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS336620NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: White
	ASLS336620NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS338820NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS338820NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS338820NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS338820NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: White
	ASLS338820NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS333320NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS333320NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS333320NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS333320NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: White
	ASLS333320NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS331620NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS331620NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS331620NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS331620NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: White
	ASLS331620NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS332620NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Red
	ASLS332620NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Green
	ASLS332620NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Amber
	ASLS332620NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: White
	ASLS332620NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a (2NO) \| Colour: Blue
	ASLS336602NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS336602NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS336602NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS336602NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: White
	ASLS336602NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS338802NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS338802NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS338802NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS338802NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: White
	ASLS338802NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS333302NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS333302NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS333302NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS333302NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: White
	ASLS333302NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS331602NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS331602NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS331602NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS331602NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: White
	ASLS331602NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS332602NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Red
	ASLS332602NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Green
	ASLS332602NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Amber
	ASLS332602NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: White
	ASLS332602NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2b (2NC) \| Colour: Blue
	ASLS336622NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS336622NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS336622NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS336622NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS336622NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS338822NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS338822NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS338822NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS338822NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS338822NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS333322NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS333322NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS333322NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS333322NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS333322NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS331622NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS331622NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS331622NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS331622NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS331622NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS332622NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Red
	ASLS332622NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Green
	ASLS332622NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Amber
	ASLS332622NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: White
	ASLS332622NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 2a-2b (2NO+2NC) \| Colour: Blue
	ASLS336640NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS336640NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS336640NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS336640NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: White
	ASLS336640NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS338840NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS338840NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS338840NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS338840NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: White
	ASLS338840NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS333340NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS333340NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS333340NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS333340NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: White
	ASLS333340NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS331640NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Red
	ASLS331640NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Green
	ASLS331640NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS331640NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: White
	ASLS331640NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: - \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS332640NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Red
	ASLS332640NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Green
	ASLS332640NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Amber
	ASLS332640NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: White
	ASLS332640NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4a (4NO) \| Colour: Blue
	ASLS336604NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS336604NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS336604NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS336604NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: White
	ASLS336604NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC6V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS338804NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS338804NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS338804NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS338804NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: White
	ASLS338804NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC12V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS333304NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS333304NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS333304NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS333304NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: White
	ASLS333304NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC/DC24V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS331604NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS331604NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS331604NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS331604NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: White
	ASLS331604NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC100/110V \| Contacts: 4b (4NC) \| Colour: Blue
	ASLS332604NR	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Red
	ASLS332604NG	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Green
	ASLS332604NA	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Amber
	ASLS332604NW	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: White
	ASLS332604NS	Positions: 45° 3-position \| Operation: Spring return both sides \| Voltage: AC200/220V \| Contacts: 4b (4NC) \| Colour: Blue

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Relays & Switches →

Item added to your cart

IDEC TWS Series 25 mm Illuminated Selector Switches (Incandescent)
