LS Electric G7L Communication Expansion Modules (Discontinued)

LS Electric G7L Communication Expansion Modules (Discontinued)

Discontinued LS Electric G7L Cnet, Fnet, Rnet, Profibus-DP and DeviceNet communication expansion modules for GLOFA-GM7U/GM7 and MASTER-K120S/K80S block PLCs.

Key features

  • Cnet RS-232C (modem capable) or RS-422/485 serial link, 1,200-57,600 bps
  • Fnet and Rnet master modules at 1 Mbps, up to 64 stations
  • Profibus-DP slave up to 12 Mbps, 127 stations
  • DeviceNet slave at 125/250/500 kbps
  • One communication module per system

Specifications

Max. modules 1 communication module
Configuration GMWIN / KGLWIN parameters
Cnet protocols Dedicated, MODBUS ASCII/RTU, user
Power Supplied from main unit
Status Discontinued; spare-parts supply
Source LS Electric A016_GLOFA_GM_181227.pdf, p. 24, 56; A020_MASTER_K_____1910.pdf, p. 15, 55
G7L-CUEB Network: Cnet | Role: Computer link | Interface: RS-232C, 1 channel
G7L-CUEC Network: Cnet | Role: Computer link | Interface: RS-422/485, 1 channel
G7L-FUEA Network: Fnet | Role: Master | Interface: Twisted pair, 1 Mbps
G7L-RUEA Network: Rnet (Smart I/O) | Role: Master | Interface: Twisted pair, 1 Mbps
G7L-PBEA Network: Profibus-DP | Role: Slave | Interface: RS-485
G7L-DBEA Network: DeviceNet | Role: Slave | Interface: CAN, 5-wire
PLC Communication ModulesLS Electric
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric G7L Communication Expansion Modules (Discontinued)

Brand LS Electric·PLC Communication Modules

Available part numbers (6)

G7L-CUEB, G7L-CUEC, G7L-FUEA, G7L-RUEA, G7L-PBEA, G7L-DBEA

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
G7L-CUEBNetwork: Cnet | Role: Computer link | Interface: RS-232C, 1 channel
G7L-CUECNetwork: Cnet | Role: Computer link | Interface: RS-422/485, 1 channel
G7L-FUEANetwork: Fnet | Role: Master | Interface: Twisted pair, 1 Mbps
G7L-RUEANetwork: Rnet (Smart I/O) | Role: Master | Interface: Twisted pair, 1 Mbps
G7L-PBEANetwork: Profibus-DP | Role: Slave | Interface: RS-485
G7L-DBEANetwork: DeviceNet | Role: Slave | Interface: CAN, 5-wire
