Mitsubishi Electric FREQROL-E700 3-Phase 400V VFD (CC-Link communication, 0.4–15kW)

Mitsubishi Electric FREQROL-E700 3-Phase 400V VFD (CC-Link communication, 0.4–15kW)

Mitsubishi FREQROL-E700 3-phase 400V compact VFD, 0.4–15kW.

Key features

  • CC-Link communication
  • Advanced magnetic flux vector control with 200%/0.5Hz starting torque (≤3.7K)
  • UL/cUL/CE compliant

Specifications

Overload Current 150% 60s, 200% 3s (inverse-time)
Output Voltage 3-Phase 380-480V
Input 3-phase 380-480V 50/60Hz
Input Voltage Range 325-528V
Frequency Tolerance ±5%
Control Method V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation
Max Frequency 400 Hz
PWM Carrier Frequency 0.7–14.5 kHz (Soft-PWM selectable)
Brake Transistor Built-in (0.4K and above)
Protection Structure IP00 (open type)
Communication CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF)
Safety Function S1/S2 dual-channel input
FR-E740-0.4KNC FR-E740-0.4KNC CC-Link communication, 0.4kW | Applied Motor: 0.4 kW | Rated Capacity: 1.2 kVA | Rated Current: 1.6 A (1.4 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 100% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 1.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.4 kg | Spec Type: CC-Link communication
FR-E740-0.75KNC FR-E740-0.75KNC CC-Link communication, 0.75kW | Applied Motor: 0.75 kW | Rated Capacity: 2.0 kVA | Rated Current: 2.6 A (2.2 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 100% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 2.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.4 kg | Spec Type: CC-Link communication
FR-E740-1.5KNC FR-E740-1.5KNC CC-Link communication, 1.5kW | Applied Motor: 1.5 kW | Rated Capacity: 3.0 kVA | Rated Current: 4.0 A (3.8 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 50% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 4.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.9 kg | Spec Type: CC-Link communication
FR-E740-2.2KNC FR-E740-2.2KNC CC-Link communication, 2.2kW | Applied Motor: 2.2 kW | Rated Capacity: 4.6 kVA | Rated Current: 6.0 A (5.4 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 5.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.9 kg | Spec Type: CC-Link communication
FR-E740-3.7KNC FR-E740-3.7KNC CC-Link communication, 3.7kW | Applied Motor: 3.7 kW | Rated Capacity: 7.2 kVA | Rated Current: 9.5 A (8.7 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 9.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.9 kg | Spec Type: CC-Link communication
FR-E740-5.5KNC FR-E740-5.5KNC CC-Link communication, 5.5kW | Applied Motor: 5.5 kW | Rated Capacity: 9.1 kVA | Rated Current: 12 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 12 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 3.2 kg | Spec Type: CC-Link communication
FR-E740-7.5KNC FR-E740-7.5KNC CC-Link communication, 7.5kW | Applied Motor: 7.5 kW | Rated Capacity: 13.0 kVA | Rated Current: 17 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 17 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 3.2 kg | Spec Type: CC-Link communication
FR-E740-11KNC FR-E740-11KNC CC-Link communication, 11kW | Applied Motor: 11 kW | Rated Capacity: 17.5 kVA | Rated Current: 23 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 20 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 6.0 kg | Spec Type: CC-Link communication
FR-E740-15KNC FR-E740-15KNC CC-Link communication, 15kW | Applied Motor: 15 kW | Rated Capacity: 23.0 kVA | Rated Current: 30 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 28 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 6.0 kg | Spec Type: CC-Link communication
Inverters (VFD)Mitsubishi Electric
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric FREQROL-E700 3-Phase 400V VFD (CC-Link communication, 0.4–15kW)

Brand Mitsubishi Electric·Inverters (VFD)

Available part numbers (9)

FR-E740-0.4KNC, FR-E740-0.75KNC, FR-E740-1.5KNC, FR-E740-2.2KNC, FR-E740-3.7KNC, FR-E740-5.5KNC, FR-E740-7.5KNC, FR-E740-11KNC, FR-E740-15KNC

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FR-E740-0.4KNCFR-E740-0.4KNC CC-Link communication, 0.4kW | Applied Motor: 0.4 kW | Rated Capacity: 1.2 kVA | Rated Current: 1.6 A (1.4 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 100% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 1.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.4 kg | Spec Type: CC-Link communication
FR-E740-0.75KNCFR-E740-0.75KNC CC-Link communication, 0.75kW | Applied Motor: 0.75 kW | Rated Capacity: 2.0 kVA | Rated Current: 2.6 A (2.2 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 100% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 2.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.4 kg | Spec Type: CC-Link communication
FR-E740-1.5KNCFR-E740-1.5KNC CC-Link communication, 1.5kW | Applied Motor: 1.5 kW | Rated Capacity: 3.0 kVA | Rated Current: 4.0 A (3.8 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 50% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 4.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.9 kg | Spec Type: CC-Link communication
FR-E740-2.2KNCFR-E740-2.2KNC CC-Link communication, 2.2kW | Applied Motor: 2.2 kW | Rated Capacity: 4.6 kVA | Rated Current: 6.0 A (5.4 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 5.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.9 kg | Spec Type: CC-Link communication
FR-E740-3.7KNCFR-E740-3.7KNC CC-Link communication, 3.7kW | Applied Motor: 3.7 kW | Rated Capacity: 7.2 kVA | Rated Current: 9.5 A (8.7 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 9.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 1.9 kg | Spec Type: CC-Link communication
FR-E740-5.5KNCFR-E740-5.5KNC CC-Link communication, 5.5kW | Applied Motor: 5.5 kW | Rated Capacity: 9.1 kVA | Rated Current: 12 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 12 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 3.2 kg | Spec Type: CC-Link communication
FR-E740-7.5KNCFR-E740-7.5KNC CC-Link communication, 7.5kW | Applied Motor: 7.5 kW | Rated Capacity: 13.0 kVA | Rated Current: 17 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 17 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 3.2 kg | Spec Type: CC-Link communication
FR-E740-11KNCFR-E740-11KNC CC-Link communication, 11kW | Applied Motor: 11 kW | Rated Capacity: 17.5 kVA | Rated Current: 23 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 20 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 6.0 kg | Spec Type: CC-Link communication
FR-E740-15KNCFR-E740-15KNC CC-Link communication, 15kW | Applied Motor: 15 kW | Rated Capacity: 23.0 kVA | Rated Current: 30 A | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 380-480V | Regenerative Torque: 20% | Input: 3-phase 380-480V 50/60Hz | Input Voltage Range: 325-528V | Frequency Tolerance: ±5% | Power Supply Capacity: 28 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Forced air | Protection Structure: IP00 (open type) | Communication: CC-Link (2-port A6CON-L5P / 35505-6000-B0M GF) | Safety Function: S1/S2 dual-channel input | Standards: UL, cUL, CE | Mass: 6.0 kg | Spec Type: CC-Link communication
