Mitsubishi Electric FREQROL-E700 Single-Phase 100V VFD (Standard FM terminal, 0.1–0.75kW)

Mitsubishi Electric FREQROL-E700 Single-Phase 100V VFD (Standard FM terminal, 0.1–0.75kW)

Mitsubishi FREQROL-E700 single-phase 100V input compact VFD, 0.1–0.75kW, voltage-doubler 3-phase 200-230V output.

Key features

  • Advanced magnetic flux vector control, 200%/0.5Hz starting torque
  • EMC directive not applicable

Specifications

Overload Current 150% 60s, 200% 3s (inverse-time)
Output Voltage 3-Phase 200-230V (Voltage-doubler)
Input Single-phase 100-115V 50/60Hz
Input Voltage Range 90-132V
Frequency Tolerance ±5%
Control Method V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation
Max Frequency 400 Hz
PWM Carrier Frequency 0.7–14.5 kHz (Soft-PWM selectable)
Cooling Self-cooled
Protection Structure IP20 (enclosed)
Communication RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1)
Safety Function —
FR-E710W-0.1K FR-E710W-0.1K Standard FM terminal, 0.1kW | Applied Motor: 0.1 kW | Rated Capacity: 0.3 kVA | Rated Current: 0.8 A (0.8 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 150% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 0.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: None (no brake resistor connection) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 0.6 kg | Spec Type: Standard FM terminal
FR-E710W-0.2K FR-E710W-0.2K Standard FM terminal, 0.2kW | Applied Motor: 0.2 kW | Rated Capacity: 0.6 kVA | Rated Current: 1.5 A (1.4 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 150% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 0.9 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: None (no brake resistor connection) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 0.7 kg | Spec Type: Standard FM terminal
FR-E710W-0.4K FR-E710W-0.4K Standard FM terminal, 0.4kW | Applied Motor: 0.4 kW | Rated Capacity: 1.2 kVA | Rated Current: 3.0 A (2.5 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 100% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 1.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 0.9 kg | Spec Type: Standard FM terminal
FR-E710W-0.75K FR-E710W-0.75K Standard FM terminal, 0.75kW | Applied Motor: 0.75 kW | Rated Capacity: 2.0 kVA | Rated Current: 5.0 A (4.1 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 100% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 2.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 1.5 kg | Spec Type: Standard FM terminal
Inverters (VFD)Mitsubishi Electric
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric FREQROL-E700 Single-Phase 100V VFD (Standard FM terminal, 0.1–0.75kW)

Brand Mitsubishi Electric·Inverters (VFD)

Available part numbers (4)

FR-E710W-0.1K, FR-E710W-0.2K, FR-E710W-0.4K, FR-E710W-0.75K

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FR-E710W-0.1KFR-E710W-0.1K Standard FM terminal, 0.1kW | Applied Motor: 0.1 kW | Rated Capacity: 0.3 kVA | Rated Current: 0.8 A (0.8 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 150% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 0.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: None (no brake resistor connection) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 0.6 kg | Spec Type: Standard FM terminal
FR-E710W-0.2KFR-E710W-0.2K Standard FM terminal, 0.2kW | Applied Motor: 0.2 kW | Rated Capacity: 0.6 kVA | Rated Current: 1.5 A (1.4 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 150% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 0.9 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: None (no brake resistor connection) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 0.7 kg | Spec Type: Standard FM terminal
FR-E710W-0.4KFR-E710W-0.4K Standard FM terminal, 0.4kW | Applied Motor: 0.4 kW | Rated Capacity: 1.2 kVA | Rated Current: 3.0 A (2.5 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 100% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 1.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 0.9 kg | Spec Type: Standard FM terminal
FR-E710W-0.75KFR-E710W-0.75K Standard FM terminal, 0.75kW | Applied Motor: 0.75 kW | Rated Capacity: 2.0 kVA | Rated Current: 5.0 A (4.1 A at 2kHz+ low-noise PWM) | Overload Current: 150% 60s, 200% 3s (inverse-time) | Output Voltage: 3-Phase 200-230V (Voltage-doubler) | Regenerative Torque: 100% | Input: Single-phase 100-115V 50/60Hz | Input Voltage Range: 90-132V | Frequency Tolerance: ±5% | Power Supply Capacity: 2.5 kVA | Control Method: V/F, General-purpose magnetic flux vector, Advanced magnetic flux vector, Optimum excitation | Max Frequency: 400 Hz | PWM Carrier Frequency: 0.7–14.5 kHz (Soft-PWM selectable) | Brake Transistor: Built-in (0.4K and above) | Cooling: Self-cooled | Protection Structure: IP20 (enclosed) | Communication: RS-485 (PU connector, EIA-485), USB Mini-B (Ver 1.1) | Safety Function: — | Standards: UL, cUL, CE (EMC directive not applicable for E710W) | Mass: 1.5 kg | Spec Type: Standard FM terminal
