Mitsubishi Electric FREQROL FR-A842-E Three-Phase 400V with Built-in Ethernet (315-500kW ND, requires FR-CC2 converter)

Mitsubishi FREQROL FR-A842-E separate-converter high-performance inverter (VFD), Three-Phase 400V, ND 315-500kW built-in ethernet (ethernet/ip, modbus/tcp).

Key features

DC bus input (requires FR-CC2 converter unit), SLD/LD/ND/HD rating, IP00

Specifications

Rating Modes	SLD/LD/ND/HD selectable
Input	DC 430-780V (separate converter type, requires FR-CC2)
Network Interface	Built-in Ethernet (EtherNet/IP, Modbus/TCP)
Output Terminal	FM (pulse) / CA (0-10V analog), Pr.54 selectable
Cooling	Forced-air cooling
Protection	IP00 (open chassis)

FR-A842-315K-E		FR-A842-E three-phase 400v separate-converter inverter, ND 315kW (07700) \| Applied Motor (ND): 315 kW \| Max Applied Motor (SLD): 400 kW \| Rated Output Current (ND): 610 A \| Rated Capacity (ND): 465 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 07700 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 163 kg
FR-A842-355K-E		FR-A842-E three-phase 400v separate-converter inverter, ND 355kW (08660) \| Applied Motor (ND): 355 kW \| Max Applied Motor (SLD): 450 kW \| Rated Output Current (ND): 683 A \| Rated Capacity (ND): 521 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 08660 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 163 kg
FR-A842-400K-E		FR-A842-E three-phase 400v separate-converter inverter, ND 400kW (09620) \| Applied Motor (ND): 400 kW \| Max Applied Motor (SLD): 500 kW \| Rated Output Current (ND): 770 A \| Rated Capacity (ND): 587 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 09620 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 243 kg
FR-A842-450K-E		FR-A842-E three-phase 400v separate-converter inverter, ND 450kW (10940) \| Applied Motor (ND): 450 kW \| Max Applied Motor (SLD): 560 kW \| Rated Output Current (ND): 866 A \| Rated Capacity (ND): 660 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 10940 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 243 kg
FR-A842-500K-E		FR-A842-E three-phase 400v separate-converter inverter, ND 500kW (12120) \| Applied Motor (ND): 500 kW \| Max Applied Motor (SLD): 630 kW \| Rated Output Current (ND): 962 A \| Rated Capacity (ND): 733 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 12120 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 243 kg

Inverters (VFD)Mitsubishi Electric

5 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric FREQROL FR-A842-E Three-Phase 400V with Built-in Ethernet (315-500kW ND, requires FR-CC2 converter)

Brand Mitsubishi Electric·Inverters (VFD)

Available part numbers (5)

FR-A842-315K-E, FR-A842-355K-E, FR-A842-400K-E, FR-A842-450K-E, FR-A842-500K-E

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	FR-A842-315K-E	FR-A842-E three-phase 400v separate-converter inverter, ND 315kW (07700) \| Applied Motor (ND): 315 kW \| Max Applied Motor (SLD): 400 kW \| Rated Output Current (ND): 610 A \| Rated Capacity (ND): 465 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 07700 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 163 kg
	FR-A842-355K-E	FR-A842-E three-phase 400v separate-converter inverter, ND 355kW (08660) \| Applied Motor (ND): 355 kW \| Max Applied Motor (SLD): 450 kW \| Rated Output Current (ND): 683 A \| Rated Capacity (ND): 521 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 08660 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 163 kg
	FR-A842-400K-E	FR-A842-E three-phase 400v separate-converter inverter, ND 400kW (09620) \| Applied Motor (ND): 400 kW \| Max Applied Motor (SLD): 500 kW \| Rated Output Current (ND): 770 A \| Rated Capacity (ND): 587 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 09620 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 243 kg
	FR-A842-450K-E	FR-A842-E three-phase 400v separate-converter inverter, ND 450kW (10940) \| Applied Motor (ND): 450 kW \| Max Applied Motor (SLD): 560 kW \| Rated Output Current (ND): 866 A \| Rated Capacity (ND): 660 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 10940 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 243 kg
	FR-A842-500K-E	FR-A842-E three-phase 400v separate-converter inverter, ND 500kW (12120) \| Applied Motor (ND): 500 kW \| Max Applied Motor (SLD): 630 kW \| Rated Output Current (ND): 962 A \| Rated Capacity (ND): 733 kVA \| Rating Modes: SLD/LD/ND/HD selectable \| Inverter Rating Code: 12120 \| Input: DC 430-780V (separate converter type, requires FR-CC2) \| Network Interface: Built-in Ethernet (EtherNet/IP, Modbus/TCP) \| Output Terminal: FM (pulse) / CA (0-10V analog), Pr.54 selectable \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis) \| Weight: 243 kg
