Mitsubishi Electric FREQROL FR-CC2-H-P Parallel Converter Unit (400V, for FR-A842-P parallel inverters)

Mitsubishi FREQROL FR-CC2-H-P parallel converter unit for FR-A842-P parallel-operation inverters, three-phase 400V, used in 2-unit or 3-unit parallel up to 1350kW.

Key features

DC 430-780V output, built-in DC reactor, IP00

Specifications

Type	Parallel converter unit (for FR-A842-P parallel inverters)
Overload Rating	150% 60s / 200% 3s
DC Output Voltage	DC 430-780V
Input	3-phase 380-500V 50/60Hz
DC Reactor	Built-in
Cooling	Forced-air cooling
Protection	IP00 (open chassis)

FR-CC2-H400K-P		FR-CC2-H400K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H400K-P \| 2-unit Parallel Motor: 630 kW \| 3-unit Parallel Motor: 945 kW \| 2-unit Input Current: 1232 A \| 3-unit Input Current: 1848 A \| 2-unit Power Supply Capacity: 939 kVA \| 3-unit Power Supply Capacity: 1409 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
FR-CC2-H450K-P		FR-CC2-H450K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H450K-P \| 2-unit Parallel Motor: 710 kW \| 3-unit Parallel Motor: 1065 kW \| 2-unit Input Current: 1386 A \| 3-unit Input Current: 2078 A \| 2-unit Power Supply Capacity: 1056 kVA \| 3-unit Power Supply Capacity: 1584 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
FR-CC2-H500K-P		FR-CC2-H500K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H500K-P \| 2-unit Parallel Motor: 800 kW \| 3-unit Parallel Motor: 1200 kW \| 2-unit Input Current: 1539 A \| 3-unit Input Current: 2309 A \| 2-unit Power Supply Capacity: 1173 kVA \| 3-unit Power Supply Capacity: 1759 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
FR-CC2-H560K-P		FR-CC2-H560K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H560K-P \| 2-unit Parallel Motor: 900 kW \| 3-unit Parallel Motor: 1350 kW \| 2-unit Input Current: 1750 A \| 3-unit Input Current: 2626 A \| 2-unit Power Supply Capacity: 1334 kVA \| 3-unit Power Supply Capacity: 2002 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)

Converter UnitsMitsubishi Electric

4 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric FREQROL FR-CC2-H-P Parallel Converter Unit (400V, for FR-A842-P parallel inverters)

Brand Mitsubishi Electric·Converter Units

Available part numbers (4)

FR-CC2-H400K-P, FR-CC2-H450K-P, FR-CC2-H500K-P, FR-CC2-H560K-P

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	FR-CC2-H400K-P	FR-CC2-H400K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H400K-P \| 2-unit Parallel Motor: 630 kW \| 3-unit Parallel Motor: 945 kW \| 2-unit Input Current: 1232 A \| 3-unit Input Current: 1848 A \| 2-unit Power Supply Capacity: 939 kVA \| 3-unit Power Supply Capacity: 1409 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
	FR-CC2-H450K-P	FR-CC2-H450K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H450K-P \| 2-unit Parallel Motor: 710 kW \| 3-unit Parallel Motor: 1065 kW \| 2-unit Input Current: 1386 A \| 3-unit Input Current: 2078 A \| 2-unit Power Supply Capacity: 1056 kVA \| 3-unit Power Supply Capacity: 1584 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
	FR-CC2-H500K-P	FR-CC2-H500K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H500K-P \| 2-unit Parallel Motor: 800 kW \| 3-unit Parallel Motor: 1200 kW \| 2-unit Input Current: 1539 A \| 3-unit Input Current: 2309 A \| 2-unit Power Supply Capacity: 1173 kVA \| 3-unit Power Supply Capacity: 1759 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
	FR-CC2-H560K-P	FR-CC2-H560K-P parallel converter unit, 2/3-unit parallel, for FR-A842-P \| Type: Parallel converter unit (for FR-A842-P parallel inverters) \| Base Unit: FR-CC2-H560K-P \| 2-unit Parallel Motor: 900 kW \| 3-unit Parallel Motor: 1350 kW \| 2-unit Input Current: 1750 A \| 3-unit Input Current: 2626 A \| 2-unit Power Supply Capacity: 1334 kVA \| 3-unit Power Supply Capacity: 2002 kVA \| Overload Rating: 150% 60s / 200% 3s \| DC Output Voltage: DC 430-780V \| Input: 3-phase 380-500V 50/60Hz \| DC Reactor: Built-in \| Cooling: Forced-air cooling \| Protection: IP00 (open chassis)
