• Mitsubishi Electric FR-E700EX FR-E720EX Sensorless Servo Drive Unit (3-Phase 200V, for MM-GKR)
1 1

Mitsubishi Electric FR-E700EX FR-E720EX Sensorless Servo Drive Unit (3-Phase 200V, for MM-GKR)

Mitsubishi Electric FR-E700EX FR-E720EX Sensorless Servo Drive Unit (3-Phase 200V, for MM-GKR)

FR-E700EX sensorless servo drive unit FR-E720EX, 3-phase 200V, 0.1-0.75kW, for MM-GKR PM motors.

Key features

  • PM sensorless vector control (no encoder), point-table positioning (7 points), built-in RS-485, IP20 self-cooling

Specifications

Overload 150% 60s / 200% 3s (motor rated current basis, inverse-time)
Control PM sensorless vector (high-freq superposition at low speed)
Carrier 10kHz
Positioning point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg
Communication built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link
Input 3-ph 200-240V 50/60Hz
Enclosure Closed IP20
Cooling Self-cooling
FR-E720EX-0.1K FR-E700EX drive unit FR-E720EX 0.1kW, 3-ph 200V, for MM-GKR13 | Applied Motor: 0.1 kW | Rated Output Current: 0.8 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 0.5 kg | Depth (D): 80.5 mm
FR-E720EX-0.2K FR-E700EX drive unit FR-E720EX 0.2kW, 3-ph 200V, for MM-GKR23 | Applied Motor: 0.2 kW | Rated Output Current: 1.5 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 0.5 kg | Depth (D): 80.5 mm
FR-E720EX-0.4K FR-E700EX drive unit FR-E720EX 0.4kW, 3-ph 200V, for MM-GKR43 | Applied Motor: 0.4 kW | Rated Output Current: 3 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 0.7 kg | Depth (D): 112.5 mm
FR-E720EX-0.75K FR-E700EX drive unit FR-E720EX 0.75kW, 3-ph 200V, for MM-GKR73 | Applied Motor: 0.75 kW | Rated Output Current: 5 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 1.0 kg | Depth (D): 132.5 mm
Inverters (VFD)Mitsubishi Electric
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric FR-E700EX FR-E720EX Sensorless Servo Drive Unit (3-Phase 200V, for MM-GKR)

Brand Mitsubishi Electric·Inverters (VFD)

Available part numbers (4)

FR-E720EX-0.1K, FR-E720EX-0.2K, FR-E720EX-0.4K, FR-E720EX-0.75K

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FR-E720EX-0.1KFR-E700EX drive unit FR-E720EX 0.1kW, 3-ph 200V, for MM-GKR13 | Applied Motor: 0.1 kW | Rated Output Current: 0.8 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 0.5 kg | Depth (D): 80.5 mm
FR-E720EX-0.2KFR-E700EX drive unit FR-E720EX 0.2kW, 3-ph 200V, for MM-GKR23 | Applied Motor: 0.2 kW | Rated Output Current: 1.5 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 0.5 kg | Depth (D): 80.5 mm
FR-E720EX-0.4KFR-E700EX drive unit FR-E720EX 0.4kW, 3-ph 200V, for MM-GKR43 | Applied Motor: 0.4 kW | Rated Output Current: 3 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 0.7 kg | Depth (D): 112.5 mm
FR-E720EX-0.75KFR-E700EX drive unit FR-E720EX 0.75kW, 3-ph 200V, for MM-GKR73 | Applied Motor: 0.75 kW | Rated Output Current: 5 A | Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) | Control: PM sensorless vector (high-freq superposition at low speed) | Carrier: 10kHz | Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg | Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link | Input: 3-ph 200-240V 50/60Hz | Enclosure: Closed IP20 | Cooling: Self-cooling | Mass: 1.0 kg | Depth (D): 132.5 mm
