Mitsubishi Electric GM-LJPB Parallel Shaft Geared Motor with Brake (11-22kW, Leg Mount, SF1.4)

Mitsubishi Electric GM-LJPB Parallel Shaft Geared Motor with Brake (11-22kW, Leg Mount, SF1.4)

Mitsubishi Electric GM-LJPB parallel shaft geared motor with built-in brake, 11 to 22kW, leg-mounted horizontal, service factor 1.4.

Key features

  • Reduction ratios 1/3 to 1/60, output speeds 30 to 600 r/min at 60Hz
  • Integrated electromagnetic brake for load holding on inclined conveyors and hoist-type drives
  • Oil-lubricated, 3-phase, 4-pole
  • Flange mount (F-type) and vertical/horizontal orientations available on request
  • Brake unavailable on 22kW 1/45 and 30kW and above
  • Ships without oil; fill with recommended lubricant

Specifications

Series GM-LJP
Type Parallel Shaft
Service Factor 1.4
Mount Leg (horizontal)
Brake Built-in electromagnetic
Poles 4P
Phase 3-phase
Lubrication Oil (ships without oil; fill recommended lubricant)
Availability Made-to-order
GM-LJPB 11kW 1/3 GM-LJPB 11kW 1/3, leg (horizontal), gear size SM, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/3 | Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SM | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/5 GM-LJPB 11kW 1/5, leg (horizontal), gear size SM, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/5 | Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SM | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/10 GM-LJPB 11kW 1/10, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/15 GM-LJPB 11kW 1/15, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/20 GM-LJPB 11kW 1/20, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/30 GM-LJPB 11kW 1/30, leg (horizontal), gear size M, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/45 GM-LJPB 11kW 1/45, leg (horizontal), gear size TN, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/45 | Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/60 GM-LJPB 11kW 1/60, leg (horizontal), gear size TP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/60 | Output Speed: 30 r/min (60Hz) / 25 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/3 GM-LJPB 15kW 1/3, leg (horizontal), gear size SN, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/3 | Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/5 GM-LJPB 15kW 1/5, leg (horizontal), gear size SN, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/5 | Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/10 GM-LJPB 15kW 1/10, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/15 GM-LJPB 15kW 1/15, leg (horizontal), gear size M, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/20 GM-LJPB 15kW 1/20, leg (horizontal), gear size M, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/30 GM-LJPB 15kW 1/30, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/45 GM-LJPB 15kW 1/45, leg (horizontal), gear size TP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/45 | Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/3 GM-LJPB 22kW 1/3, leg (horizontal), gear size SP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/3 | Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/5 GM-LJPB 22kW 1/5, leg (horizontal), gear size SP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/5 | Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/10 GM-LJPB 22kW 1/10, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/15 GM-LJPB 22kW 1/15, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/20 GM-LJPB 22kW 1/20, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/30 GM-LJPB 22kW 1/30, leg (horizontal), gear size P, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
Geared MotorsMitsubishi Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GM-LJPB Parallel Shaft Geared Motor with Brake (11-22kW, Leg Mount, SF1.4)

Brand Mitsubishi Electric·Geared Motors

Available part numbers (21)

GM-LJPB 11kW 1/3, GM-LJPB 11kW 1/5, GM-LJPB 11kW 1/10, GM-LJPB 11kW 1/15, GM-LJPB 11kW 1/20, GM-LJPB 11kW 1/30, GM-LJPB 11kW 1/45, GM-LJPB 11kW 1/60, GM-LJPB 15kW 1/3, GM-LJPB 15kW 1/5 + 11 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GM-LJPB 11kW 1/3GM-LJPB 11kW 1/3, leg (horizontal), gear size SM, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/3 | Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SM | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/5GM-LJPB 11kW 1/5, leg (horizontal), gear size SM, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/5 | Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SM | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/10GM-LJPB 11kW 1/10, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/15GM-LJPB 11kW 1/15, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/20GM-LJPB 11kW 1/20, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/30GM-LJPB 11kW 1/30, leg (horizontal), gear size M, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/45GM-LJPB 11kW 1/45, leg (horizontal), gear size TN, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/45 | Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 11kW 1/60GM-LJPB 11kW 1/60, leg (horizontal), gear size TP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 11kW | Reduction Ratio: 1/60 | Output Speed: 30 r/min (60Hz) / 25 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/3GM-LJPB 15kW 1/3, leg (horizontal), gear size SN, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/3 | Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/5GM-LJPB 15kW 1/5, leg (horizontal), gear size SN, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/5 | Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/10GM-LJPB 15kW 1/10, leg (horizontal), gear size L, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/15GM-LJPB 15kW 1/15, leg (horizontal), gear size M, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/20GM-LJPB 15kW 1/20, leg (horizontal), gear size M, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/30GM-LJPB 15kW 1/30, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 15kW 1/45GM-LJPB 15kW 1/45, leg (horizontal), gear size TP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 15kW | Reduction Ratio: 1/45 | Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/3GM-LJPB 22kW 1/3, leg (horizontal), gear size SP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/3 | Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/5GM-LJPB 22kW 1/5, leg (horizontal), gear size SP, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/5 | Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: SP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/10GM-LJPB 22kW 1/10, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/15GM-LJPB 22kW 1/15, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/20GM-LJPB 22kW 1/20, leg (horizontal), gear size N, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPB 22kW 1/30GM-LJPB 22kW 1/30, leg (horizontal), gear size P, brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Leg (horizontal) | Brake: Built-in electromagnetic | Output: 22kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
