Mitsubishi Electric GM-LJPV Parallel Shaft Geared Motor (11-37kW, Vertical Mount, SF1.4)

Mitsubishi Electric GM-LJPV Parallel Shaft Geared Motor (11-37kW, Vertical Mount, SF1.4)

Mitsubishi Electric GM-LJPV large-capacity parallel shaft geared motor, vertical mount, 11 to 37kW, service factor 1.4.

Key features

  • Reduction ratios 1/10 to 1/60, output speeds 30 to 180 r/min at 60Hz
  • Oil-lubricated heavy-duty gearbox configured for vertical-shaft installations such as agitators and mixers. 3-phase, 4-pole; gear frame sizes L through TP
  • Flange mount (F-type) and vertical/horizontal orientations available on request
  • Ships without oil; fill with recommended lubricant before operation

Specifications

Series GM-LJP
Type Parallel Shaft
Service Factor 1.4
Mount Vertical
Brake None
Phase 3-phase
Lubrication Oil (ships without oil; fill recommended lubricant)
Availability Made-to-order
GM-LJPV 11kW 1/10 GM-LJPV 11kW 1/10, vertical, gear size L, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 11kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 11kW 1/15 GM-LJPV 11kW 1/15, vertical, gear size L, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 11kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 11kW 1/20 GM-LJPV 11kW 1/20, vertical, gear size L, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 11kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 11kW 1/30 GM-LJPV 11kW 1/30, vertical, gear size M, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 11kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 11kW 1/45 GM-LJPV 11kW 1/45, vertical, gear size TN, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 11kW | Reduction Ratio: 1/45 | Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TN | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 11kW 1/60 GM-LJPV 11kW 1/60, vertical, gear size TP, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 11kW | Reduction Ratio: 1/60 | Output Speed: 30 r/min (60Hz) / 25 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 15kW 1/10 GM-LJPV 15kW 1/10, vertical, gear size L, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 15kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: L | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 15kW 1/15 GM-LJPV 15kW 1/15, vertical, gear size M, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 15kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 15kW 1/20 GM-LJPV 15kW 1/20, vertical, gear size M, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 15kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: M | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 15kW 1/30 GM-LJPV 15kW 1/30, vertical, gear size N, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 15kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 15kW 1/45 GM-LJPV 15kW 1/45, vertical, gear size TP, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 15kW | Reduction Ratio: 1/45 | Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: TP | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 22kW 1/10 GM-LJPV 22kW 1/10, vertical, gear size N, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 22kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 22kW 1/15 GM-LJPV 22kW 1/15, vertical, gear size N, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 22kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 22kW 1/20 GM-LJPV 22kW 1/20, vertical, gear size N, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 22kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: N | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 22kW 1/30 GM-LJPV 22kW 1/30, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 22kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 22kW 1/45 GM-LJPV 22kW 1/45, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 22kW | Reduction Ratio: 1/45 | Output Speed: consult (6-pole variant) | Poles: 6P (this ratio produced as 6-pole only) | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 30kW 1/10 GM-LJPV 30kW 1/10, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 30kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 30kW 1/15 GM-LJPV 30kW 1/15, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 30kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 30kW 1/20 GM-LJPV 30kW 1/20, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 30kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 30kW 1/30 GM-LJPV 30kW 1/30, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 30kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 37kW 1/10 GM-LJPV 37kW 1/10, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 37kW | Reduction Ratio: 1/10 | Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 37kW 1/15 GM-LJPV 37kW 1/15, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 37kW | Reduction Ratio: 1/15 | Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 37kW 1/20 GM-LJPV 37kW 1/20, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 37kW | Reduction Ratio: 1/20 | Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
GM-LJPV 37kW 1/30 GM-LJPV 37kW 1/30, vertical, gear size P, no brake | Series: GM-LJP | Type: Parallel Shaft | Service Factor: 1.4 | Mount: Vertical | Brake: None | Output: 37kW | Reduction Ratio: 1/30 | Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) | Poles: 4P | Phase: 3-phase | Gear Size: P | Lubrication: Oil (ships without oil; fill recommended lubricant) | Availability: Made-to-order
Geared MotorsMitsubishi Electric
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GM-LJPV Parallel Shaft Geared Motor (11-37kW, Vertical Mount, SF1.4)

Brand Mitsubishi Electric·Geared Motors

Available part numbers (24)

GM-LJPV 11kW 1/10, GM-LJPV 11kW 1/15, GM-LJPV 11kW 1/20, GM-LJPV 11kW 1/30, GM-LJPV 11kW 1/45, GM-LJPV 11kW 1/60, GM-LJPV 15kW 1/10, GM-LJPV 15kW 1/15, GM-LJPV 15kW 1/20, GM-LJPV 15kW 1/30 + 14 more — see full table ↓
