Mitsubishi Electric GV-SB 1.5kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, with Brake)

Mitsubishi Electric GV-SB 1.5kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, with Brake)

Mitsubishi Electric GV-SB 1.5kW 400V class S-PM sensorless servo geared motor, parallel shaft type with leg mounting, with brake.

Key features

  • Combines an S-PM permanent magnet motor with Mitsubishi PM sensorless vector control for high-accuracy speed regulation under load fluctuation without an encoder
  • Motor rated speed 3000r/min, 17 reduction ratios 1/5-1/450, permissible output shaft torque 22-1230Nm
  • Requires dedicated drive unit FR-D740-2.2K-G (3-phase 380-480V 50/60Hz input; direct commercial power connection is not possible). 4P motor, TEFC enclosure, indoor IP44, grease lubrication, insulation class 130(B), continuous rating
  • Semi-standard options: outdoor type, tropical treatment, one-touch manual release brake

Specifications

Voltage Class 400V (drive input 3-phase 380-480V 50/60Hz)
Output 1.5kW
Motor Rated Voltage 375V
Motor Rated Current 2.8A
Poles 4P
Motor Rated Frequency 100Hz
Motor Speed 3000r/min
Drive Unit FR-D740-2.2K-G
Power Supply Capacity 5.5kVA
Mount Leg
Brake Built-in spring brake
Shaft Solid shaft
GV-SB 1.5kW 1/5 400V GV-SB 1.5kW ratio 1/5 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/5 | Actual Ratio: 1/4.87 | Output Shaft Speed: 600r/min | Permissible Output Torque: 22Nm | Permissible Overhang Load: 980N | Permissible Thrust Load: 50N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/10 400V GV-SB 1.5kW ratio 1/10 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/10 | Actual Ratio: 1/10.00 | Output Shaft Speed: 300r/min | Permissible Output Torque: 45Nm | Permissible Overhang Load: 980N | Permissible Thrust Load: 83N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/15 400V GV-SB 1.5kW ratio 1/15 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/15 | Actual Ratio: 1/14.54 | Output Shaft Speed: 200r/min | Permissible Output Torque: 66Nm | Permissible Overhang Load: 980N | Permissible Thrust Load: 83N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/20 400V GV-SB 1.5kW ratio 1/20 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/20 | Actual Ratio: 1/19.44 | Output Shaft Speed: 150r/min | Permissible Output Torque: 88Nm | Permissible Overhang Load: 1470N | Permissible Thrust Load: 167N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/25 400V GV-SB 1.5kW ratio 1/25 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/25 | Actual Ratio: 1/22.95 | Output Shaft Speed: 120r/min | Permissible Output Torque: 104Nm | Permissible Overhang Load: 1470N | Permissible Thrust Load: 167N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/30 400V GV-SB 1.5kW ratio 1/30 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/30 | Actual Ratio: 1/30.60 | Output Shaft Speed: 100r/min | Permissible Output Torque: 139Nm | Permissible Overhang Load: 1570N | Permissible Thrust Load: 250N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/40 400V GV-SB 1.5kW ratio 1/40 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/40 | Actual Ratio: 1/37.15 | Output Shaft Speed: 75r/min | Permissible Output Torque: 163Nm | Permissible Overhang Load: 1760N | Permissible Thrust Load: 333N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/50 400V GV-SB 1.5kW ratio 1/50 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/50 | Actual Ratio: 1/45.86 | Output Shaft Speed: 60r/min | Permissible Output Torque: 201Nm | Permissible Overhang Load: 1960N | Permissible Thrust Load: 417N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/60 400V GV-SB 1.5kW ratio 1/60 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/60 | Actual Ratio: 1/55.82 | Output Shaft Speed: 50r/min | Permissible Output Torque: 245Nm | Permissible Overhang Load: 2160N | Permissible Thrust Load: 500N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/80 400V GV-SB 1.5kW ratio 1/80 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/80 | Actual Ratio: 1/76.12 | Output Shaft Speed: 37.5r/min | Permissible Output Torque: 334Nm | Permissible Overhang Load: 2650N | Permissible Thrust Load: 500N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/100 400V GV-SB 1.5kW ratio 1/100 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/100 | Actual Ratio: 1/95.11 | Output Shaft Speed: 30r/min | Permissible Output Torque: 418Nm | Permissible Overhang Load: 2740N | Permissible Thrust Load: 500N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/120 400V GV-SB 1.5kW ratio 1/120 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/120 | Actual Ratio: 1/113.20 | Output Shaft Speed: 25r/min | Permissible Output Torque: 497Nm | Permissible Overhang Load: 3920N | Permissible Thrust Load: 700N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/160 400V GV-SB 1.5kW ratio 1/160 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/160 | Actual Ratio: 1/157.42 | Output Shaft Speed: 18.8r/min | Permissible Output Torque: 692Nm | Permissible Overhang Load: 3920N | Permissible Thrust Load: 700N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/200 400V GV-SB 1.5kW ratio 1/200 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/200 | Actual Ratio: 1/174.91 | Output Shaft Speed: 15r/min | Permissible Output Torque: 768Nm | Permissible Overhang Load: 3920N | Permissible Thrust Load: 700N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/270 400V GV-SB 1.5kW ratio 1/270 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/270 | Actual Ratio: 1/271.09 | Output Shaft Speed: 11.1r/min | Permissible Output Torque: 1165Nm | Permissible Overhang Load: 6660N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/360 400V GV-SB 1.5kW ratio 1/360 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/360 | Actual Ratio: 1/376.83 | Output Shaft Speed: 8.3r/min | Permissible Output Torque: 1230Nm (torque-limited) | Permissible Overhang Load: 6960N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
GV-SB 1.5kW 1/450 400V GV-SB 1.5kW ratio 1/450 400V class, leg mount, with brake | Voltage Class: 400V (drive input 3-phase 380-480V 50/60Hz) | Output: 1.5kW | Nominal Ratio: 1/450 | Actual Ratio: 1/432.59 | Output Shaft Speed: 6.7r/min | Permissible Output Torque: 1230Nm (torque-limited) | Permissible Overhang Load: 6960N | Permissible Thrust Load: 1200N | Motor Rated Voltage: 375V | Motor Rated Current: 2.8A | Poles: 4P | Motor Rated Frequency: 100Hz | Motor Speed: 3000r/min | Drive Unit: FR-D740-2.2K-G | Power Supply Capacity: 5.5kVA | Mount: Leg | Brake: Built-in spring brake | Shaft: Solid shaft | Enclosure: TEFC | Protection: IP44 (indoor) | Insulation: 130(B) | Lubrication: Grease
Sensorless Servo Geared MotorsMitsubishi Electric
17 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric GV-SB 1.5kW 400V Class S-PM Sensorless Servo Geared Motor (Parallel Shaft, Leg Mount, with Brake)

Brand Mitsubishi Electric·Sensorless Servo Geared Motors

Available part numbers (17)

GV-SB 1.5kW 1/5 400V, GV-SB 1.5kW 1/10 400V, GV-SB 1.5kW 1/15 400V, GV-SB 1.5kW 1/20 400V, GV-SB 1.5kW 1/25 400V, GV-SB 1.5kW 1/30 400V, GV-SB 1.5kW 1/40 400V, GV-SB 1.5kW 1/50 400V, GV-SB 1.5kW 1/60 400V, GV-SB 1.5kW 1/80 400V + 7 more — see full table ↓
