Mitsubishi Electric MELSERVO-J4 MR-J4W2-B 2-Axis Servo Amplifier (SSCNET III/H)

Mitsubishi MELSERVO-J4 2-axis integrated servo amplifier with SSCNET III/H interface for space-saving multi-axis control. 3-phase/1-phase 200V and DC48V/24V models, 0.03-1kW per axis, HG rotary servo motor compatible.

Specifications

Axes	2-axis integrated
Interface	SSCNET III/H
Protection	Open IP20

MR-J4W2-22B		MR-J4W2-22B, 2-axis 0.2+0.2kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.2+0.2kW \| Power Supply: 3-phase/1-phase AC200-240V \| Rated Output Current per Axis: 1.5A (output AC170V) \| Cooling: Natural air \| Protection: Open IP20 \| Mass: 1.5kg \| Compatible Servo Motor: HG-KR053/13/23, HG-MR053/13/23
MR-J4W2-44B		MR-J4W2-44B, 2-axis 0.4+0.4kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.4+0.4kW \| Power Supply: 3-phase/1-phase AC200-240V \| Rated Output Current per Axis: 2.8A (output AC170V) \| Cooling: Forced air \| Protection: Open IP20 \| Mass: 1.5kg \| Compatible Servo Motor: HG-KR053/13/23/43, HG-MR053/13/23/43
MR-J4W2-77B		MR-J4W2-77B, 2-axis 0.75+0.75kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.75+0.75kW \| Power Supply: 3-phase/1-phase AC200-240V \| Rated Output Current per Axis: 5.8A (output AC170V) \| Cooling: Forced air \| Protection: Open IP20 \| Mass: 2.0kg \| Compatible Servo Motor: HG-KR43/73, HG-MR43/73, HG-SR51/52, HG-JR53/73, HG-UR72
MR-J4W2-1010B		MR-J4W2-1010B, 2-axis 1+1kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 1+1kW \| Power Supply: 3-phase AC200-240V \| Rated Output Current per Axis: 6.0A (output AC170V) \| Cooling: Forced air \| Protection: Open IP20 \| Mass: 2.0kg \| Compatible Servo Motor: HG-KR43/73, HG-MR43/73, HG-SR51/81/52/102, HG-JR53/73/103, HG-UR72
MR-J4W2-0303B6		MR-J4W2-0303B6, 2-axis 0.03+0.03kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.03+0.03kW \| Power Supply: DC48V/24V \| Rated Output Current per Axis: 2.4A (output AC13V) \| Cooling: Natural air \| Protection: Open IP20 \| Mass: 0.3kg \| Compatible Servo Motor: HG-AK0136/0236/0336 \| Note: DIN rail (35mm) mountable; full-closed control not supported

Servo AmplifiersMitsubishi Electric

5 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric MELSERVO-J4 MR-J4W2-B 2-Axis Servo Amplifier (SSCNET III/H)

Brand Mitsubishi Electric·Servo Amplifiers

Available part numbers (5)

MR-J4W2-22B, MR-J4W2-44B, MR-J4W2-77B, MR-J4W2-1010B, MR-J4W2-0303B6

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	MR-J4W2-22B	MR-J4W2-22B, 2-axis 0.2+0.2kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.2+0.2kW \| Power Supply: 3-phase/1-phase AC200-240V \| Rated Output Current per Axis: 1.5A (output AC170V) \| Cooling: Natural air \| Protection: Open IP20 \| Mass: 1.5kg \| Compatible Servo Motor: HG-KR053/13/23, HG-MR053/13/23
	MR-J4W2-44B	MR-J4W2-44B, 2-axis 0.4+0.4kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.4+0.4kW \| Power Supply: 3-phase/1-phase AC200-240V \| Rated Output Current per Axis: 2.8A (output AC170V) \| Cooling: Forced air \| Protection: Open IP20 \| Mass: 1.5kg \| Compatible Servo Motor: HG-KR053/13/23/43, HG-MR053/13/23/43
	MR-J4W2-77B	MR-J4W2-77B, 2-axis 0.75+0.75kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.75+0.75kW \| Power Supply: 3-phase/1-phase AC200-240V \| Rated Output Current per Axis: 5.8A (output AC170V) \| Cooling: Forced air \| Protection: Open IP20 \| Mass: 2.0kg \| Compatible Servo Motor: HG-KR43/73, HG-MR43/73, HG-SR51/52, HG-JR53/73, HG-UR72
	MR-J4W2-1010B	MR-J4W2-1010B, 2-axis 1+1kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 1+1kW \| Power Supply: 3-phase AC200-240V \| Rated Output Current per Axis: 6.0A (output AC170V) \| Cooling: Forced air \| Protection: Open IP20 \| Mass: 2.0kg \| Compatible Servo Motor: HG-KR43/73, HG-MR43/73, HG-SR51/81/52/102, HG-JR53/73/103, HG-UR72
	MR-J4W2-0303B6	MR-J4W2-0303B6, 2-axis 0.03+0.03kW, SSCNET III/H \| Axes: 2-axis integrated \| Interface: SSCNET III/H \| Rated Output per Axis: 0.03+0.03kW \| Power Supply: DC48V/24V \| Rated Output Current per Axis: 2.4A (output AC13V) \| Cooling: Natural air \| Protection: Open IP20 \| Mass: 0.3kg \| Compatible Servo Motor: HG-AK0136/0236/0336 \| Note: DIN rail (35mm) mountable; full-closed control not supported
