Mitsubishi Electric - SRT-NF Pneumatic Timer (Off delay, AC operated, 0.1 to 60s)

Mitsubishi Electric - SRT-NF Pneumatic Timer (Off delay, AC operated, 0.1 to 60s)

Mitsubishi Electric MS-T/N series SRT-NF pneumatic timer for control equipment timer elements where highly accurate time setting is not required.

Key features

  • Off delay type, ac operated, time range 0.1 to 60 seconds
  • Output contacts are 1a1b timed plus 2a2b instantaneous, all high reliability twin contacts, and every contact can be used at a different voltage so sequence circuits can be combined freely
  • A large knob rotation angle in the short time region makes time setting easy and a manual check button allows sequence checking by hand
  • IEC 35mm rail mounting is fitted as standard, and a terminal cover version with CAN terminals is available by adding CX to the model name
  • Operating coil designations follow same as the sr-k100 auxiliary relay, ac12v to ac500v
  • Rated insulation voltage 660V, allowable voltage range 85 to 110 percent of rated voltage at 40 degrees C hot

Specifications

Type Pneumatic timer
Time Delay Method Off delay
Operation AC operated
Operating Coil Reference Same as the SR-K100 auxiliary relay, AC12V to AC500V
Rated Insulation Voltage 660V
Time Range 0.1 to 60 seconds
Output Contact 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts
Contact Rating AC-15 Class AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A
Contact Rating DC24V 1A timed and 3A instantaneous
Voltage Variation Error Plus or minus 20 percent over 85 to 110 percent of rated voltage
Allowable Voltage Range 85 to 110 percent of rated voltage at 40 degrees C hot
Mounting IEC 35mm rail mounting fitted as standard
SRT-NF AC12V SRT-NF pneumatic timer, off delay, AC12V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC12V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC12V SRT-NFCX pneumatic timer, off delay, AC12V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC12V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC24V SRT-NF pneumatic timer, off delay, AC24V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC24V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC24V SRT-NFCX pneumatic timer, off delay, AC24V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC24V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC48V SRT-NF pneumatic timer, off delay, AC48V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC48V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC48V SRT-NFCX pneumatic timer, off delay, AC48V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC48V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC100V SRT-NF pneumatic timer, off delay, AC100V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC100V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC100V SRT-NFCX pneumatic timer, off delay, AC100V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC100V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC120V SRT-NF pneumatic timer, off delay, AC120V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC120V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC120V SRT-NFCX pneumatic timer, off delay, AC120V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC120V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC127V SRT-NF pneumatic timer, off delay, AC127V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC127V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC127V SRT-NFCX pneumatic timer, off delay, AC127V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC127V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC200V SRT-NF pneumatic timer, off delay, AC200V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC200V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC200V SRT-NFCX pneumatic timer, off delay, AC200V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC200V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC220V SRT-NF pneumatic timer, off delay, AC220V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC220V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC220V SRT-NFCX pneumatic timer, off delay, AC220V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC220V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC230V SRT-NF pneumatic timer, off delay, AC230V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC230V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC230V SRT-NFCX pneumatic timer, off delay, AC230V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC230V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC260V SRT-NF pneumatic timer, off delay, AC260V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC260V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC260V SRT-NFCX pneumatic timer, off delay, AC260V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC260V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC380V SRT-NF pneumatic timer, off delay, AC380V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC380V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC380V SRT-NFCX pneumatic timer, off delay, AC380V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC380V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC400V SRT-NF pneumatic timer, off delay, AC400V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC400V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC400V SRT-NFCX pneumatic timer, off delay, AC400V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC400V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC440V SRT-NF pneumatic timer, off delay, AC440V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC440V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC440V SRT-NFCX pneumatic timer, off delay, AC440V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC440V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC500V SRT-NF pneumatic timer, off delay, AC500V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC500V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC500V SRT-NFCX pneumatic timer, off delay, AC500V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC500V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
TimersMitsubishi Electric
28 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - SRT-NF Pneumatic Timer (Off delay, AC operated, 0.1 to 60s)

Brand Mitsubishi Electric·Timers

Available part numbers (28)

SRT-NF AC12V, SRT-NFCX AC12V, SRT-NF AC24V, SRT-NFCX AC24V, SRT-NF AC48V, SRT-NFCX AC48V, SRT-NF AC100V, SRT-NFCX AC100V, SRT-NF AC120V, SRT-NFCX AC120V + 18 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SRT-NF AC12VSRT-NF pneumatic timer, off delay, AC12V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC12V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC12VSRT-NFCX pneumatic timer, off delay, AC12V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC12V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC24VSRT-NF pneumatic timer, off delay, AC24V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC24V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC24VSRT-NFCX pneumatic timer, off delay, AC24V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC24V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC48VSRT-NF pneumatic timer, off delay, AC48V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC48V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC48VSRT-NFCX pneumatic timer, off delay, AC48V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC48V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC100VSRT-NF pneumatic timer, off delay, AC100V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC100V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC100VSRT-NFCX pneumatic timer, off delay, AC100V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC100V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC120VSRT-NF pneumatic timer, off delay, AC120V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC120V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC120VSRT-NFCX pneumatic timer, off delay, AC120V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC120V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC127VSRT-NF pneumatic timer, off delay, AC127V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC127V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC127VSRT-NFCX pneumatic timer, off delay, AC127V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC127V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC200VSRT-NF pneumatic timer, off delay, AC200V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC200V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC200VSRT-NFCX pneumatic timer, off delay, AC200V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC200V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC220VSRT-NF pneumatic timer, off delay, AC220V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC220V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC220VSRT-NFCX pneumatic timer, off delay, AC220V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC220V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC230VSRT-NF pneumatic timer, off delay, AC230V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC230V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC230VSRT-NFCX pneumatic timer, off delay, AC230V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC230V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC260VSRT-NF pneumatic timer, off delay, AC260V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC260V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC260VSRT-NFCX pneumatic timer, off delay, AC260V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC260V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC380VSRT-NF pneumatic timer, off delay, AC380V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC380V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC380VSRT-NFCX pneumatic timer, off delay, AC380V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC380V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC400VSRT-NF pneumatic timer, off delay, AC400V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC400V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC400VSRT-NFCX pneumatic timer, off delay, AC400V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC400V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC440VSRT-NF pneumatic timer, off delay, AC440V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC440V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC440VSRT-NFCX pneumatic timer, off delay, AC440V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC440V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NF AC500VSRT-NF pneumatic timer, off delay, AC500V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: Standard | Operating Coil Designation: AC500V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRT-NFCX AC500VSRT-NFCX pneumatic timer, off delay, AC500V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: AC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: AC500V | Operating Coil Reference: Same as the SR-K100 auxiliary relay, AC12V to AC500V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard

Need a different model, or a part not listed here? Send us your parts list →
