Mitsubishi Electric - SRTD-NF Pneumatic Timer (Off delay, DC operated, 0.1 to 60s)

Mitsubishi Electric - SRTD-NF Pneumatic Timer (Off delay, DC operated, 0.1 to 60s)

Mitsubishi Electric MS-T/N series SRTD-NF pneumatic timer for control equipment timer elements where highly accurate time setting is not required.

Key features

  • Off delay type, dc operated, time range 0.1 to 60 seconds
  • Output contacts are 1a1b timed plus 2a2b instantaneous, all high reliability twin contacts, and every contact can be used at a different voltage so sequence circuits can be combined freely
  • A large knob rotation angle in the short time region makes time setting easy and a manual check button allows sequence checking by hand
  • IEC 35mm rail mounting is fitted as standard, and a terminal cover version with CAN terminals is available by adding CX to the model name
  • Operating coil designations follow same as the srd-k100 auxiliary relay, dc24v to dc220v
  • Rated insulation voltage 660V, allowable voltage range 85 to 110 percent of rated voltage at 40 degrees C hot

Specifications

Type Pneumatic timer
Time Delay Method Off delay
Operation DC operated
Operating Coil Reference Same as the SRD-K100 auxiliary relay, DC24V to DC220V
Rated Insulation Voltage 660V
Time Range 0.1 to 60 seconds
Output Contact 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts
Contact Rating AC-15 Class AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A
Contact Rating DC24V 1A timed and 3A instantaneous
Voltage Variation Error Plus or minus 20 percent over 85 to 110 percent of rated voltage
Allowable Voltage Range 85 to 110 percent of rated voltage at 40 degrees C hot
Mounting IEC 35mm rail mounting fitted as standard
SRTD-NF DC24V SRTD-NF pneumatic timer, off delay, DC24V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC24V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC24V SRTD-NFCX pneumatic timer, off delay, DC24V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC24V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NF DC48V SRTD-NF pneumatic timer, off delay, DC48V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC48V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC48V SRTD-NFCX pneumatic timer, off delay, DC48V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC48V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NF DC100V SRTD-NF pneumatic timer, off delay, DC100V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC100V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC100V SRTD-NFCX pneumatic timer, off delay, DC100V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC100V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NF DC110V SRTD-NF pneumatic timer, off delay, DC110V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC110V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC110V SRTD-NFCX pneumatic timer, off delay, DC110V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC110V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NF DC125V SRTD-NF pneumatic timer, off delay, DC125V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC125V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC125V SRTD-NFCX pneumatic timer, off delay, DC125V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC125V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NF DC200V SRTD-NF pneumatic timer, off delay, DC200V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC200V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC200V SRTD-NFCX pneumatic timer, off delay, DC200V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC200V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NF DC220V SRTD-NF pneumatic timer, off delay, DC220V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: Standard | Operating Coil Designation: DC220V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
SRTD-NFCX DC220V SRTD-NFCX pneumatic timer, off delay, DC220V coil | Type: Pneumatic timer | Time Delay Method: Off delay | Operation: DC operated | Terminal Cover: CAN terminal cover fitted | Operating Coil Designation: DC220V | Operating Coil Reference: Same as the SRD-K100 auxiliary relay, DC24V to DC220V | Rated Insulation Voltage: 660V | Time Range: 0.1 to 60 seconds | Output Contact: 2a2b instantaneous contacts plus 1a1b timed contacts, all twin contacts | Contact Rating AC-15 Class: AC110V 5A timed and 6A instantaneous, AC220V 3A and 3A, AC440V 1A and 1.5A, AC550V 1A and 1.2A | Contact Rating DC24V: 1A timed and 3A instantaneous | Voltage Variation Error: Plus or minus 20 percent over 85 to 110 percent of rated voltage | Allowable Voltage Range: 85 to 110 percent of rated voltage at 40 degrees C hot | Mounting: IEC 35mm rail mounting fitted as standard
TimersMitsubishi Electric
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - SRTD-NF Pneumatic Timer (Off delay, DC operated, 0.1 to 60s)

Brand Mitsubishi Electric·Timers

Available part numbers (14)

SRTD-NF DC24V, SRTD-NFCX DC24V, SRTD-NF DC48V, SRTD-NFCX DC48V, SRTD-NF DC100V, SRTD-NFCX DC100V, SRTD-NF DC110V, SRTD-NFCX DC110V, SRTD-NF DC125V, SRTD-NFCX DC125V + 4 more — see full table ↓
