Motovario HA Helical Inline Gearmotors (HA51-HA63, 0.09-5.5 kW)

Motovario HA helical inline gearmotors in HA50/HA60 frame sizes (HA51-HA63), with die-cast aluminium alloy housings in 1, 2 and 3 reduction stages and a fitted IEC motor, covering every unit, ratio and motor combination in the current H Series performance tables.

Key features

Die-cast aluminium alloy housing, sizes HA51, HA52, HA53, HA61, HA62, HA63
1, 2 or 3 helical reduction stages, ratios 1.33 to 353.98
Fitted IEC motors 63-112 frame (2, 4, 6 poles), 0.09 to 5.5 kW
Output speeds 2.3-2182.5 rpm, output torque up to 622 Nm
Lubricated for life with mineral oil (LAND OIL GEAR POWER 220), no oil plugs, maintenance-free
Foot or flange versions, output flanges FA-FC, mounting positions B3-V3 selected at order

Specifications

Brand	Motovario (Italy)
Series	HA (aluminium alloy) helical inline
Sizes	HA51, HA52, HA53, HA61, HA62, HA63
Reduction stages	1 (HAx1), 2 (HAx2), 3 (HAx3)
Housing	Die-cast aluminium alloy, RAL 5010 blue
Average efficiency	0.97 / 0.96 / 0.94 (1 / 2 / 3 stages)
Motor supply	50 Hz IEC motors, B5 or compact B10 flange
Mounting positions	B3, B5, B8, B6, B7, V5, V1, V6, V3
Code format	HA<size> <ratio i> <motor size><poles>
Source	Motovario H Series Technical Catalogue IEC STD, p. 77-176

HA51 10,83 63A6		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 79.4 rpm \| Output torque M2: 11 Nm
HA53 88,02 63A6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 84 Nm
HA53 111,61 63A6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 7.7 rpm \| Output torque M2: 106 Nm
HA53 138,71 63A6		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 132 Nm
HA63 138,71 63A6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 132 Nm
HA53 163,05 63A6		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 155 Nm
HA63 163,05 63A6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 155 Nm
HA53 200,27 63A6		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 190 Nm
HA63 200,27 63A6		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 190 Nm
HA53 235,41 63A6		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 223 Nm
HA63 235,41 63A6		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 223 Nm
HA53 284,81 63A6		Unit: HA53 \| Ratio i: 284.81 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 270 Nm
HA63 284,81 63A6		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 270 Nm
HA53 353,98 63A6		Unit: HA53 \| Ratio i: 353.98 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 2.4 rpm \| Output torque M2: 336 Nm
HA63 353,98 63A6		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 2.4 rpm \| Output torque M2: 336 Nm
HA51 10,83 63A4		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 123.7 rpm \| Output torque M2: 9 Nm
HA51 10,83 63B6		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 79.4 rpm \| Output torque M2: 14 Nm
HA53 111,61 63A4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 90 Nm
HA53 74,88 63B6		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 11.5 rpm \| Output torque M2: 95 Nm
HA53 88,02 63B6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 111 Nm
HA53 138,71 63A4		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 9.7 rpm \| Output torque M2: 112 Nm
HA53 163,05 63A4		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 131 Nm
HA63 163,05 63A4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 131 Nm
HA53 111,61 63B6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 7.7 rpm \| Output torque M2: 141 Nm
HA63 111,61 63B6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 7.7 rpm \| Output torque M2: 141 Nm
HA53 200,27 63A4		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 6.7 rpm \| Output torque M2: 161 Nm
HA63 200,27 63A4		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 6.7 rpm \| Output torque M2: 161 Nm
HA53 138,71 63B6		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 175 Nm
HA63 138,71 63B6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 175 Nm
HA53 235,41 63A4		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 5.7 rpm \| Output torque M2: 189 Nm
HA63 235,41 63A4		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 5.7 rpm \| Output torque M2: 189 Nm
HA53 163,05 63B6		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 206 Nm
HA63 163,05 63B6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 206 Nm
HA53 284,81 63A4		Unit: HA53 \| Ratio i: 284.81 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 229 Nm
HA63 284,81 63A4		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 229 Nm
HA53 200,27 63B6		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 253 Nm
HA63 200,27 63B6		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 253 Nm
HA53 353,98 63A4		Unit: HA53 \| Ratio i: 353.98 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 285 Nm
HA63 353,98 63A4		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 285 Nm
HA53 235,41 63B6		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 298 Nm
HA63 235,41 63B6		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 298 Nm
HA53 284,81 63B6		Unit: HA53 \| Ratio i: 284.81 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 360 Nm
HA63 284,81 63B6		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 360 Nm
HA63 353,98 63B6		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 2.4 rpm \| Output torque M2: 448 Nm
HA51 7,88 63C6		Unit: HA51 \| Ratio i: 7.88 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 102.9 rpm \| Output torque M2: 14 Nm
HA51 10,83 63C6		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 74.8 rpm \| Output torque M2: 19 Nm
HA53 49,80 63C6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 16.3 rpm \| Output torque M2: 84 Nm
HA53 60,25 63C6		Unit: HA53 \| Ratio i: 60.25 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 13.4 rpm \| Output torque M2: 101 Nm
HA53 74,88 63C6		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 10.8 rpm \| Output torque M2: 126 Nm
HA53 88,02 63C6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 9.2 rpm \| Output torque M2: 148 Nm
HA63 88,02 63C6		Unit: HA63 \| Ratio i: 88.02 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 9.2 rpm \| Output torque M2: 148 Nm
HA53 111,61 63C6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 7.3 rpm \| Output torque M2: 187 Nm
HA63 111,61 63C6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 7.3 rpm \| Output torque M2: 187 Nm
HA53 138,71 63C6		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.8 rpm \| Output torque M2: 233 Nm
HA63 138,71 63C6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.8 rpm \| Output torque M2: 233 Nm
HA53 163,05 63C6		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.0 rpm \| Output torque M2: 274 Nm
HA63 163,05 63C6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.0 rpm \| Output torque M2: 274 Nm
HA53 200,27 63C6		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 4.0 rpm \| Output torque M2: 336 Nm
HA63 200,27 63C6		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 4.0 rpm \| Output torque M2: 336 Nm
HA63 235,41 63C6		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 3.4 rpm \| Output torque M2: 395 Nm
HA63 284,81 63C6		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 2.8 rpm \| Output torque M2: 478 Nm
HA63 353,98 63C6		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 2.3 rpm \| Output torque M2: 594 Nm
HA51 10,83 63A2		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 258.5 rpm \| Output torque M2: 6 Nm
HA51 10,83 63B4		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 122.8 rpm \| Output torque M2: 14 Nm
HA51 7,88 71A6		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 114.3 rpm \| Output torque M2: 15 Nm
HA51 10,83 71A6		Unit: HA51 \| Ratio i: 10.83 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 83.1 rpm \| Output torque M2: 20 Nm
HA53 111,61 63A2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 62 Nm
HA53 138,71 63A2		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 77 Nm
HA53 49,80 71A6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 18.1 rpm \| Output torque M2: 90 Nm
HA53 74,88 63B4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 17.8 rpm \| Output torque M2: 91 Nm
HA53 163,05 63A2		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 91 Nm
HA63 163,05 63A2		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 91 Nm
HA53 88,02 63B4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 15.1 rpm \| Output torque M2: 107 Nm
HA53 60,25 71A6		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 14.9 rpm \| Output torque M2: 109 Nm
HA53 200,27 63A2		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 112 Nm
HA63 200,27 63A2		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 112 Nm
HA53 74,88 71A6		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 136 Nm
HA63 74,88 71A6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 136 Nm
HA53 111,61 63B4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 136 Nm
HA53 235,41 63A2		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 131 Nm
HA63 111,61 63B4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 136 Nm
HA63 235,41 63A2		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 131 Nm
HA53 88,02 71A6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 160 Nm
HA63 88,02 71A6		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 160 Nm
HA53 284,81 63A2		Unit: HA53 \| Ratio i: 284.81 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 159 Nm
HA63 284,81 63A2		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 159 Nm
HA53 138,71 63B4		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 169 Nm
HA63 138,71 63B4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 169 Nm
HA53 163,05 63B4		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 198 Nm
HA63 163,05 63B4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 198 Nm
HA53 111,61 71A6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 202 Nm
HA63 111,61 71A6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 202 Nm
HA53 353,98 63A2		Unit: HA53 \| Ratio i: 353.98 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 197 Nm
HA63 353,98 63A2		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 197 Nm
HA53 200,27 63B4		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 243 Nm
HA63 200,27 63B4		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 243 Nm
HA53 138,71 71A6		Unit: HA53 \| Ratio i: 138.71 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 252 Nm
HA63 138,71 71A6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 252 Nm
HA53 235,41 63B4		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 286 Nm
HA63 235,41 63B4		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 286 Nm
HA53 163,05 71A6		Unit: HA53 \| Ratio i: 163.05 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 296 Nm
HA63 163,05 71A6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 296 Nm
HA53 284,81 63B4		Unit: HA53 \| Ratio i: 284.81 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 346 Nm
HA63 284,81 63B4		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 346 Nm
HA53 200,27 71A6		Unit: HA53 \| Ratio i: 200.27 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 4.5 rpm \| Output torque M2: 363 Nm
HA63 200,27 71A6		Unit: HA63 \| Ratio i: 200.27 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 4.5 rpm \| Output torque M2: 363 Nm
HA63 235,41 71A6		Unit: HA63 \| Ratio i: 235.41 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 427 Nm
HA63 353,98 63B4		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 430 Nm
HA63 284,81 71A6		Unit: HA63 \| Ratio i: 284.81 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 3.2 rpm \| Output torque M2: 516 Nm
HA51 7,88 63C4		Unit: HA51 \| Ratio i: 7.88 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 168.9 rpm \| Output torque M2: 12 Nm
HA51 10,83 63C4		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 122.8 rpm \| Output torque M2: 17 Nm
HA53 60,25 63C4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 22.1 rpm \| Output torque M2: 89 Nm
HA53 74,88 63C4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 17.8 rpm \| Output torque M2: 111 Nm
HA53 88,02 63C4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 15.1 rpm \| Output torque M2: 131 Nm
HA63 88,02 63C4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 15.1 rpm \| Output torque M2: 131 Nm
HA53 111,61 63C4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 166 Nm
HA63 111,61 63C4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 166 Nm
HA53 138,71 63C4		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 206 Nm
HA63 138,71 63C4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 206 Nm
HA53 163,05 63C4		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 242 Nm
HA63 163,05 63C4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 242 Nm
HA53 200,27 63C4		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 297 Nm
HA63 200,27 63C4		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 297 Nm
HA53 235,41 63C4		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 350 Nm
HA63 235,41 63C4		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 350 Nm
HA63 284,81 63C4		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 423 Nm
HA63 353,98 63C4		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 526 Nm
HA51 10,83 63B2		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 258.5 rpm \| Output torque M2: 9 Nm
HA51 7,88 63D4		Unit: HA51 \| Ratio i: 7.88 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 167.6 rpm \| Output torque M2: 14 Nm
HA51 7,88 71A4		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 167.6 rpm \| Output torque M2: 14 Nm
HA51 5,45 71B6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 165.0 rpm \| Output torque M2: 14 Nm
HA51 10,83 63D4		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 121.8 rpm \| Output torque M2: 19 Nm
HA51 10,83 71A4		Unit: HA51 \| Ratio i: 10.83 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 121.8 rpm \| Output torque M2: 19 Nm
HA51 7,88 71B6		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 114.3 rpm \| Output torque M2: 20 Nm
HA51 10,83 71B6		Unit: HA51 \| Ratio i: 10.83 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 83.1 rpm \| Output torque M2: 28 Nm
HA53 74,88 63B2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 58 Nm
HA53 88,02 63B2		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 68 Nm
HA53 49,80 63D4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 26.5 rpm \| Output torque M2: 85 Nm
HA53 49,80 71A4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 26.5 rpm \| Output torque M2: 85 Nm
HA53 111,61 63B2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 86 Nm
HA53 60,25 63D4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 21.9 rpm \| Output torque M2: 102 Nm
HA53 60,25 71A4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 21.9 rpm \| Output torque M2: 102 Nm
HA53 138,71 63B2		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 107 Nm
HA63 138,71 63B2		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 107 Nm
HA53 49,80 71B6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 18.1 rpm \| Output torque M2: 125 Nm
HA53 74,88 63D4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
HA53 74,88 71A4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
HA63 74,88 63D4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
HA63 74,88 71A4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
HA53 163,05 63B2		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 126 Nm
HA63 163,05 63B2		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 126 Nm
HA53 88,02 63D4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
HA53 88,02 71A4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
HA63 88,02 63D4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
HA63 88,02 71A4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
HA53 60,25 71B6		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 14.9 rpm \| Output torque M2: 152 Nm
HA63 60,25 71B6		Unit: HA63 \| Ratio i: 60.25 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 14.9 rpm \| Output torque M2: 152 Nm
HA53 200,27 63B2		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 155 Nm
HA63 200,27 63B2		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 155 Nm
HA53 74,88 71B6		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 189 Nm
HA63 74,88 71B6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 189 Nm
HA53 235,41 63B2		Unit: HA53 \| Ratio i: 235.41 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 182 Nm
HA63 235,41 63B2		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 182 Nm
HA53 111,61 63D4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
HA53 111,61 71A4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
HA63 111,61 63D4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
HA63 111,61 71A4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
HA53 88,02 71B6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 222 Nm
HA63 88,02 71B6		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 222 Nm
HA53 284,81 63B2		Unit: HA53 \| Ratio i: 284.81 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 220 Nm
HA63 284,81 63B2		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 220 Nm
HA53 138,71 63D4		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
HA53 138,71 71A4		Unit: HA53 \| Ratio i: 138.71 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
HA63 138,71 63D4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
HA63 138,71 71A4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
HA53 111,61 71B6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 281 Nm
HA53 163,05 63D4		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
HA53 163,05 71A4		Unit: HA53 \| Ratio i: 163.05 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
HA63 111,61 71B6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 281 Nm
HA63 163,05 63D4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
HA63 163,05 71A4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
HA63 353,98 63B2		Unit: HA63 \| Ratio i: 353.98 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 274 Nm
HA53 200,27 63D4		Unit: HA53 \| Ratio i: 200.27 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
HA53 200,27 71A4		Unit: HA53 \| Ratio i: 200.27 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
HA63 200,27 63D4		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
HA63 200,27 71A4		Unit: HA63 \| Ratio i: 200.27 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
HA53 138,71 71B6		Unit: HA53 \| Ratio i: 138.71 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 349 Nm
HA63 138,71 71B6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 349 Nm
HA63 235,41 63D4		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 400 Nm
HA63 235,41 71A4		Unit: HA63 \| Ratio i: 235.41 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 400 Nm
HA53 163,05 71B6		Unit: HA53 \| Ratio i: 163.05 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 411 Nm
HA63 163,05 71B6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 411 Nm
HA63 284,81 63D4		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 4.6 rpm \| Output torque M2: 484 Nm
HA63 284,81 71A4		Unit: HA63 \| Ratio i: 284.81 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 4.6 rpm \| Output torque M2: 484 Nm
HA63 200,27 71B6		Unit: HA63 \| Ratio i: 200.27 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 4.5 rpm \| Output torque M2: 504 Nm
HA63 353,98 71A4		Unit: HA63 \| Ratio i: 353.98 \| Motor: 71A4 \| Power P1: 0.25 kW \| Output speed n2: 3.9 rpm \| Output torque M2: 572 Nm
HA63 235,41 71B6		Unit: HA63 \| Ratio i: 235.41 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 593 Nm
HA51 7,88 63C2		Unit: HA51 \| Ratio i: 7.88 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 354.3 rpm \| Output torque M2: 9 Nm
HA51 7,88 71A2		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 354.3 rpm \| Output torque M2: 9 Nm
HA51 2,94 71C6		Unit: HA51 \| Ratio i: 2.94 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 298.9 rpm \| Output torque M2: 12 Nm
HA51 2,94 80A6		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 298.9 rpm \| Output torque M2: 12 Nm
HA51 10,83 63C2		Unit: HA51 \| Ratio i: 10.83 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 257.5 rpm \| Output torque M2: 13 Nm
HA51 10,83 71A2		Unit: HA51 \| Ratio i: 10.83 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 257.5 rpm \| Output torque M2: 13 Nm
HA51 5,45 71B4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 253.0 rpm \| Output torque M2: 14 Nm
HA51 4,75 71C6		Unit: HA51 \| Ratio i: 4.75 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 185.3 rpm \| Output torque M2: 19 Nm
HA51 4,75 80A6		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 185.3 rpm \| Output torque M2: 19 Nm
HA51 7,88 71B4		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 175.2 rpm \| Output torque M2: 20 Nm
HA51 5,45 71C6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 161.3 rpm \| Output torque M2: 21 Nm
HA51 5,45 80A6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 161.3 rpm \| Output torque M2: 21 Nm
HA51 10,83 71B4		Unit: HA51 \| Ratio i: 10.83 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 127.4 rpm \| Output torque M2: 27 Nm
HA61 7,75 80A6		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 121.3 rpm \| Output torque M2: 29 Nm
HA51 7,88 71C6		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71C6 \| Power P1: 0.37 kW \| Output speed n2: 111.7 rpm \| Output torque M2: 31 Nm
HA61 10,67 80A6		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 88.1 rpm \| Output torque M2: 39 Nm
HA53 49,80 63C2		Unit: HA53 \| Ratio i: 49.80 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 56.0 rpm \| Output torque M2: 57 Nm
HA53 49,80 71A2		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 56.0 rpm \| Output torque M2: 57 Nm
HA53 60,25 63C2		Unit: HA53 \| Ratio i: 60.25 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 46.3 rpm \| Output torque M2: 69 Nm
HA53 60,25 71A2		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 46.3 rpm \| Output torque M2: 69 Nm
HA53 74,88 63C2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 37.3 rpm \| Output torque M2: 86 Nm
HA53 74,88 71A2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 37.3 rpm \| Output torque M2: 86 Nm
HA52 25,43 80A6		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 37.0 rpm \| Output torque M2: 93 Nm
HA53 88,02 63C2		Unit: HA53 \| Ratio i: 88.02 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
HA53 88,02 71A2		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
HA63 88,02 63C2		Unit: HA63 \| Ratio i: 88.02 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
HA63 88,02 71A2		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
HA52 29,89 80A6		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 31.4 rpm \| Output torque M2: 109 Nm
HA53 49,80 71B4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 27.7 rpm \| Output torque M2: 120 Nm
HA52 36,17 80A6		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 26.0 rpm \| Output torque M2: 132 Nm
HA62 36,17 80A6		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 26.0 rpm \| Output torque M2: 132 Nm
HA53 111,61 63C2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
HA53 111,61 71A2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
HA63 111,61 63C2		Unit: HA63 \| Ratio i: 111.61 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
HA63 111,61 71A2		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
HA53 60,25 71B4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 22.9 rpm \| Output torque M2: 145 Nm
HA63 60,25 71B4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 22.9 rpm \| Output torque M2: 145 Nm
HA52 44,95 80A6		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 20.9 rpm \| Output torque M2: 164 Nm
HA62 44,95 80A6		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 20.9 rpm \| Output torque M2: 164 Nm
HA53 138,71 63C2		Unit: HA53 \| Ratio i: 138.71 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
HA53 138,71 71A2		Unit: HA53 \| Ratio i: 138.71 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
HA63 138,71 63C2		Unit: HA63 \| Ratio i: 138.71 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
HA63 138,71 71A2		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
HA53 74,88 71B4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 18.4 rpm \| Output torque M2: 180 Nm
HA63 74,88 71B4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 18.4 rpm \| Output torque M2: 180 Nm
HA53 49,80 71C6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
HA53 49,80 80A6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
HA63 49,80 71C6		Unit: HA63 \| Ratio i: 49.80 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
HA63 49,80 80A6		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
HA53 163,05 63C2		Unit: HA53 \| Ratio i: 163.05 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
HA53 163,05 71A2		Unit: HA53 \| Ratio i: 163.05 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
HA63 163,05 63C2		Unit: HA63 \| Ratio i: 163.05 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
HA63 163,05 71A2		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
HA53 88,02 71B4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 15.7 rpm \| Output torque M2: 212 Nm
HA63 88,02 71B4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 15.7 rpm \| Output torque M2: 212 Nm
HA53 60,25 71C6		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
HA53 60,25 80A6		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
HA63 60,25 71C6		Unit: HA63 \| Ratio i: 60.25 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
HA63 60,25 80A6		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
HA63 200,27 63C2		Unit: HA63 \| Ratio i: 200.27 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 13.9 rpm \| Output torque M2: 230 Nm
HA63 200,27 71A2		Unit: HA63 \| Ratio i: 200.27 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 13.9 rpm \| Output torque M2: 230 Nm
HA53 111,61 71B4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 12.4 rpm \| Output torque M2: 269 Nm
HA63 111,61 71B4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 12.4 rpm \| Output torque M2: 269 Nm
HA63 235,41 63C2		Unit: HA63 \| Ratio i: 235.41 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 270 Nm
HA63 235,41 71A2		Unit: HA63 \| Ratio i: 235.41 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 270 Nm
HA53 74,88 71C6		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
HA53 74,88 80A6		Unit: HA53 \| Ratio i: 74.88 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
HA63 74,88 71C6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
HA63 74,88 80A6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
HA53 88,02 71C6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
HA53 88,02 80A6		Unit: HA53 \| Ratio i: 88.02 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
HA63 88,02 71C6		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
HA63 88,02 80A6		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
HA53 138,71 71B4		Unit: HA53 \| Ratio i: 138.71 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 334 Nm
HA63 138,71 71B4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 334 Nm
HA63 284,81 63C2		Unit: HA63 \| Ratio i: 284.81 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 327 Nm
HA63 284,81 71A2		Unit: HA63 \| Ratio i: 284.81 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 327 Nm
HA53 163,05 71B4		Unit: HA53 \| Ratio i: 163.05 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 8.5 rpm \| Output torque M2: 392 Nm
HA63 163,05 71B4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 8.5 rpm \| Output torque M2: 392 Nm
HA53 111,61 71C6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
HA53 111,61 80A6		Unit: HA53 \| Ratio i: 111.61 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
HA63 111,61 71C6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
HA63 111,61 80A6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
HA63 200,27 71B4		Unit: HA63 \| Ratio i: 200.27 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 6.9 rpm \| Output torque M2: 482 Nm
HA63 138,71 71C6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 6.3 rpm \| Output torque M2: 529 Nm
HA63 138,71 80A6		Unit: HA63 \| Ratio i: 138.71 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 6.3 rpm \| Output torque M2: 529 Nm
HA63 235,41 71B4		Unit: HA63 \| Ratio i: 235.41 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 5.9 rpm \| Output torque M2: 567 Nm
HA63 163,05 71C6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 5.4 rpm \| Output torque M2: 622 Nm
HA63 163,05 80A6		Unit: HA63 \| Ratio i: 163.05 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 5.4 rpm \| Output torque M2: 622 Nm
HA51 5,45 71B2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 515.2 rpm \| Output torque M2: 10 Nm
HA51 2,94 71C4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 465.3 rpm \| Output torque M2: 11 Nm
HA51 2,94 80A4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 465.3 rpm \| Output torque M2: 11 Nm
HA51 7,88 71B2		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 356.8 rpm \| Output torque M2: 14 Nm
HA51 2,94 80B6		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 315.8 rpm \| Output torque M2: 16 Nm
HA51 4,75 71C4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 288.4 rpm \| Output torque M2: 18 Nm
HA51 4,75 80A4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 288.4 rpm \| Output torque M2: 18 Nm
HA51 5,45 71C4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 251.2 rpm \| Output torque M2: 20 Nm
HA51 5,45 80A4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 251.2 rpm \| Output torque M2: 20 Nm
HA51 4,75 80B6		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 195.8 rpm \| Output torque M2: 26 Nm
HA61 7,75 80A4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 28 Nm
HA51 7,88 71C4		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71C4 \| Power P1: 0.55 kW \| Output speed n2: 174.0 rpm \| Output torque M2: 29 Nm
HA51 5,45 80B6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 170.5 rpm \| Output torque M2: 30 Nm
HA61 10,67 80A4		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 39 Nm
HA61 7,75 80B6		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 43 Nm
HA61 10,67 80B6		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 87.2 rpm \| Output torque M2: 59 Nm
HA52 20,46 80A4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 74 Nm
HA52 14,50 80B6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 79 Nm
HA53 49,80 71B2		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 56.4 rpm \| Output torque M2: 84 Nm
HA52 25,43 80A4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 92 Nm
HA52 16,91 80B6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 93 Nm
HA52 29,89 80A4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 108 Nm
HA53 60,25 71B2		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 102 Nm
HA63 60,25 71B2		Unit: HA63 \| Ratio i: 60.25 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 102 Nm
HA52 20,46 80B6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 112 Nm
HA52 36,17 80A4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 130 Nm
HA62 36,17 80A4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 130 Nm
HA53 74,88 71B2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 127 Nm
HA63 74,88 71B2		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 127 Nm
HA52 25,43 80B6		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 139 Nm
HA62 25,43 80B6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 139 Nm
HA53 88,02 71B2		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 31.9 rpm \| Output torque M2: 149 Nm
HA63 88,02 71B2		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 31.9 rpm \| Output torque M2: 149 Nm
HA52 29,89 80B6		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 164 Nm
HA52 44,95 80A4		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 162 Nm
HA62 29,89 80B6		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 164 Nm
HA62 44,95 80A4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 162 Nm
HA53 49,80 71C4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
HA53 49,80 80A4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
HA63 49,80 71C4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
HA63 49,80 80A4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
HA52 36,17 80B6		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 25.7 rpm \| Output torque M2: 198 Nm
HA62 36,17 80B6		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 25.7 rpm \| Output torque M2: 198 Nm
HA53 111,61 71B2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 25.2 rpm \| Output torque M2: 189 Nm
HA63 111,61 71B2		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 25.2 rpm \| Output torque M2: 189 Nm
HA53 60,25 71C4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
HA53 60,25 80A4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
HA63 60,25 71C4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
HA63 60,25 80A4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
HA52 44,95 80B6		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 20.7 rpm \| Output torque M2: 246 Nm
HA62 44,95 80B6		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 20.7 rpm \| Output torque M2: 246 Nm
HA63 138,71 71B2		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 20.3 rpm \| Output torque M2: 235 Nm
HA53 49,80 80B6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 267 Nm
HA63 49,80 80B6		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 267 Nm
HA53 74,88 71C4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
HA53 74,88 80A4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
HA63 74,88 71C4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
HA63 74,88 80A4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
HA53 163,05 71B2		Unit: HA53 \| Ratio i: 163.05 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 276 Nm
HA63 163,05 71B2		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 276 Nm
HA53 88,02 71C4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
HA53 88,02 80A4		Unit: HA53 \| Ratio i: 88.02 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
HA63 88,02 71C4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
HA63 88,02 80A4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
HA53 60,25 80B6		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 15.4 rpm \| Output torque M2: 323 Nm
HA63 60,25 80B6		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 15.4 rpm \| Output torque M2: 323 Nm
HA63 200,27 71B2		Unit: HA63 \| Ratio i: 200.27 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 340 Nm
HA63 74,88 80B6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 12.4 rpm \| Output torque M2: 402 Nm
HA53 111,61 71C4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
HA53 111,61 80A4		Unit: HA53 \| Ratio i: 111.61 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
HA63 111,61 71C4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
HA63 111,61 80A4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
HA63 235,41 71B2		Unit: HA63 \| Ratio i: 235.41 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 399 Nm
HA63 88,02 80B6		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 10.6 rpm \| Output torque M2: 472 Nm
HA63 138,71 71C4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 500 Nm
HA63 138,71 80A4		Unit: HA63 \| Ratio i: 138.71 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 500 Nm
HA63 163,05 71C4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 8.4 rpm \| Output torque M2: 588 Nm
HA63 163,05 80A4		Unit: HA63 \| Ratio i: 163.05 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 8.4 rpm \| Output torque M2: 588 Nm
HA63 111,61 80B6		Unit: HA63 \| Ratio i: 111.61 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 8.3 rpm \| Output torque M2: 598 Nm
HA51 1,45 80C6		Unit: HA51 \| Ratio i: 1.45 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 635.2 rpm \| Output torque M2: 11 Nm
HA51 1,45 90S6		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 635.2 rpm \| Output torque M2: 11 Nm
HA51 4,75 71C2		Unit: HA51 \| Ratio i: 4.75 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 589.5 rpm \| Output torque M2: 11 Nm
HA51 4,75 80A2		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 589.5 rpm \| Output torque M2: 11 Nm
HA51 5,45 71C2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 513.3 rpm \| Output torque M2: 13 Nm
HA51 5,45 80A2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 513.3 rpm \| Output torque M2: 13 Nm
HA51 2,94 80B4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 475.5 rpm \| Output torque M2: 15 Nm
HA61 7,75 80A2		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 366.5 rpm \| Output torque M2: 18 Nm
HA51 7,88 71C2		Unit: HA51 \| Ratio i: 7.88 \| Motor: 71C2 (brake TBS only) \| Power P1: 0.75 kW \| Output speed n2: 355.6 rpm \| Output torque M2: 19 Nm
HA51 2,94 80C6		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 312.5 rpm \| Output torque M2: 22 Nm
HA51 2,94 90S6		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 312.5 rpm \| Output torque M2: 22 Nm
HA51 4,75 80B4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 24 Nm
HA61 10,67 80A2		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 266.3 rpm \| Output torque M2: 25 Nm
HA51 5,45 80B4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 262.2 rpm \| Output torque M2: 27 Nm
HA61 4,38 80C6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 209.8 rpm \| Output torque M2: 33 Nm
HA61 4,38 90S6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 209.8 rpm \| Output torque M2: 33 Nm
HA51 4,75 80C6		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 193.7 rpm \| Output torque M2: 36 Nm
HA51 4,75 90S6		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 193.7 rpm \| Output torque M2: 36 Nm
HA61 7,75 80B4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 184.5 rpm \| Output torque M2: 38 Nm
HA51 5,45 80C6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 168.7 rpm \| Output torque M2: 42 Nm
HA51 5,45 90S6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 168.7 rpm \| Output torque M2: 42 Nm
HA61 10,67 80B4		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 53 Nm
HA61 7,75 80C6		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 118.7 rpm \| Output torque M2: 59 Nm
HA61 7,75 90S6		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 118.7 rpm \| Output torque M2: 59 Nm
HA52 25,43 80A2		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 60 Nm
HA52 14,50 80B4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 80B4 (brake TBS only) \| Power P1: 0.75 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 71 Nm
HA52 29,89 80A2		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 71 Nm
HA61 10,67 80C6		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 86.3 rpm \| Output torque M2: 81 Nm
HA61 10,67 90S6		Unit: HA61 \| Ratio i: 10.67 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 86.3 rpm \| Output torque M2: 81 Nm
HA52 16,91 80B4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 83 Nm
HA52 11,67 80C6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 78.9 rpm \| Output torque M2: 88 Nm
HA52 11,67 90S6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 78.9 rpm \| Output torque M2: 88 Nm
HA52 36,17 80A2		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 85 Nm
HA52 20,46 80B4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 100 Nm
HA52 14,50 80C6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 63.4 rpm \| Output torque M2: 109 Nm
HA52 14,50 90S6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 63.4 rpm \| Output torque M2: 109 Nm
HA52 44,95 80A2		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 106 Nm
HA62 44,95 80A2		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 106 Nm
HA53 49,80 71C2		Unit: HA53 \| Ratio i: 49.80 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
HA53 49,80 80A2		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
HA63 49,80 71C2		Unit: HA63 \| Ratio i: 49.80 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
HA63 49,80 80A2		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
HA52 25,43 80B4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 125 Nm
HA62 25,43 80B4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 125 Nm
HA52 16,91 80C6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 54.4 rpm \| Output torque M2: 128 Nm
HA52 16,91 90S6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 54.4 rpm \| Output torque M2: 128 Nm
HA52 29,89 80B4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 147 Nm
HA62 29,89 80B4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 147 Nm
HA53 60,25 71C2		Unit: HA53 \| Ratio i: 60.25 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
HA53 60,25 80A2		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
HA63 60,25 71C2		Unit: HA63 \| Ratio i: 60.25 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
HA63 60,25 80A2		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
HA52 20,46 80C6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
HA52 20,46 90S6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
HA62 20,46 80C6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
HA62 20,46 90S6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
HA52 36,17 80B4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 178 Nm
HA62 36,17 80B4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 178 Nm
HA53 74,88 71C2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
HA53 74,88 80A2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
HA63 74,88 71C2		Unit: HA63 \| Ratio i: 74.88 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
HA63 74,88 80A2		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
HA52 25,43 80C6		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
HA52 25,43 90S6		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
HA62 25,43 80C6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
HA62 25,43 90S6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
HA53 88,02 71C2		Unit: HA53 \| Ratio i: 88.02 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
HA53 88,02 80A2		Unit: HA53 \| Ratio i: 88.02 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
HA63 88,02 71C2		Unit: HA63 \| Ratio i: 88.02 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
HA63 88,02 80A2		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
HA52 44,95 80B4		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 221 Nm
HA62 44,95 80B4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 221 Nm
HA52 29,89 80C6		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
HA52 29,89 90S6		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
HA62 29,89 80C6		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
HA62 29,89 90S6		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
HA53 49,80 80B4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 239 Nm
HA63 49,80 80B4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 239 Nm
HA52 36,17 80C6		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
HA52 36,17 90S6		Unit: HA52 \| Ratio i: 36.17 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
HA62 36,17 80C6		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
HA62 36,17 90S6		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
HA53 111,61 71C2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
HA53 111,61 80A2		Unit: HA53 \| Ratio i: 111.61 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
HA63 111,61 71C2		Unit: HA63 \| Ratio i: 111.61 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
HA63 111,61 80A2		Unit: HA63 \| Ratio i: 111.61 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
HA53 60,25 80B4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 290 Nm
HA63 60,25 80B4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 290 Nm
HA52 44,95 80C6		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
HA52 44,95 90S6		Unit: HA52 \| Ratio i: 44.95 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
HA62 44,95 80C6		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
HA62 44,95 90S6		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
HA63 138,71 71C2		Unit: HA63 \| Ratio i: 138.71 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 322 Nm
HA63 138,71 80A2		Unit: HA63 \| Ratio i: 138.71 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 322 Nm
HA53 74,88 80B4		Unit: HA53 \| Ratio i: 74.88 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 360 Nm
HA63 74,88 80B4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 360 Nm
HA53 49,80 80C6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
HA53 49,80 90S6		Unit: HA53 \| Ratio i: 49.80 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
HA63 49,80 80C6		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
HA63 49,80 90S6		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
HA63 88,02 80B4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 15.9 rpm \| Output torque M2: 423 Nm
HA63 60,25 80C6		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 15.3 rpm \| Output torque M2: 445 Nm
HA63 60,25 90S6		Unit: HA63 \| Ratio i: 60.25 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 15.3 rpm \| Output torque M2: 445 Nm
HA63 111,61 80B4		Unit: HA63 \| Ratio i: 111.61 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 12.5 rpm \| Output torque M2: 537 Nm
HA63 74,88 80C6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 553 Nm
HA63 74,88 90S6		Unit: HA63 \| Ratio i: 74.88 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 553 Nm
HA51 2,94 80C4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 475.5 rpm \| Output torque M2: 18 Nm
HA51 4,75 80C4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 29 Nm
HA51 5,45 80C4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 33 Nm
HA61 7,75 80C4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 47 Nm
HA61 10,67 80C4		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 65 Nm
HA52 11,67 80C4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 70 Nm
HA52 14,50 80C4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 87 Nm
HA52 16,91 80C4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 102 Nm
HA52 20,46 80C4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 123 Nm
HA62 20,46 80C4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 123 Nm
HA52 25,43 80C4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 153 Nm
HA62 25,43 80C4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 153 Nm
HA52 29,89 80C4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 180 Nm
HA62 29,89 80C4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 180 Nm
HA52 36,17 80C4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 218 Nm
HA62 36,17 80C4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 218 Nm
HA52 44,95 80C4		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 271 Nm
HA62 44,95 80C4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 271 Nm
HA53 49,80 80C4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 294 Nm
HA63 49,80 80C4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 294 Nm
HA53 60,25 80C4		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 355 Nm
HA63 60,25 80C4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 355 Nm
HA63 74,88 80C4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 442 Nm
HA63 88,02 80C4		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 15.9 rpm \| Output torque M2: 519 Nm
HA51 1,45 80D4		Unit: HA51 \| Ratio i: 1.45 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 966.7 rpm \| Output torque M2: 11 Nm
HA51 1,45 90S4		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 966.7 rpm \| Output torque M2: 11 Nm
HA51 2,94 80B2		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 964.5 rpm \| Output torque M2: 10 Nm
HA51 1,45 90L6		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 649.0 rpm \| Output torque M2: 16 Nm
HA51 4,75 80B2		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 595.8 rpm \| Output torque M2: 17 Nm
HA51 5,45 80B2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 520.7 rpm \| Output torque M2: 19 Nm
HA51 2,94 80D4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 478.9 rpm \| Output torque M2: 21 Nm
HA51 2,94 90S4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 478.9 rpm \| Output torque M2: 21 Nm
HA61 2,50 90L6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 28 Nm
HA61 2,50 100LR6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 28 Nm
HA61 7,75 80B2		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 366.5 rpm \| Output torque M2: 27 Nm
HA61 4,38 80D4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 321.6 rpm \| Output torque M2: 32 Nm
HA61 4,38 90S4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 321.6 rpm \| Output torque M2: 32 Nm
HA51 2,94 90L6		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 315.8 rpm \| Output torque M2: 33 Nm
HA51 4,75 80D4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 35 Nm
HA51 4,75 90S4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 35 Nm
HA61 10,67 80B2		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 266.3 rpm \| Output torque M2: 37 Nm
HA51 5,45 80D4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 40 Nm
HA51 5,45 90S4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 40 Nm
HA61 4,38 90L6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 49 Nm
HA61 4,38 100LR6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 49 Nm
HA51 4,75 90L6		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 195.8 rpm \| Output torque M2: 53 Nm
HA61 7,75 80D4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 181.9 rpm \| Output torque M2: 56 Nm
HA61 7,75 90S4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 181.9 rpm \| Output torque M2: 56 Nm
HA51 5,45 90L6		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 172.3 rpm \| Output torque M2: 60 Nm
HA52 16,91 80B2		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 167.9 rpm \| Output torque M2: 58 Nm
HA52 6,22 90L6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 68 Nm
HA52 6,22 100LR6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 68 Nm
HA52 20,46 80B2		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 138.8 rpm \| Output torque M2: 70 Nm
HA61 10,67 80D4		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 78 Nm
HA61 10,67 90S4		Unit: HA61 \| Ratio i: 10.67 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 78 Nm
HA52 7,73 90L6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 85 Nm
HA52 7,73 100LR6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 85 Nm
HA52 11,67 80D4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 84 Nm
HA52 11,67 90S4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 84 Nm
HA61 7,75 90L6		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 86 Nm
HA52 25,43 80B2		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 111.7 rpm \| Output torque M2: 87 Nm
HA62 25,43 80B2		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 111.7 rpm \| Output torque M2: 87 Nm
HA52 14,50 80D4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 97.2 rpm \| Output torque M2: 104 Nm
HA52 14,50 90S4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 97.2 rpm \| Output torque M2: 104 Nm
HA52 9,64 90L6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 106 Nm
HA52 9,64 100LR6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 106 Nm
HA52 29,89 80B2		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 94.7 rpm \| Output torque M2: 103 Nm
HA62 29,89 80B2		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 94.7 rpm \| Output torque M2: 103 Nm
HA52 16,91 80D4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 122 Nm
HA52 16,91 90S4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 122 Nm
HA52 11,67 90L6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
HA52 11,67 100LR6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
HA62 11,67 90L6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
HA62 11,67 100LR6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
HA52 36,17 80B2		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 78.5 rpm \| Output torque M2: 124 Nm
HA62 36,17 80B2		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 78.5 rpm \| Output torque M2: 124 Nm
HA52 20,46 80D4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
HA52 20,46 90S4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
HA62 20,46 80D4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
HA62 20,46 90S4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
HA52 14,50 90L6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
HA52 14,50 100LR6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
HA62 14,50 90L6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
HA62 14,50 100LR6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
HA52 44,95 80B2		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 63.0 rpm \| Output torque M2: 155 Nm
HA62 44,95 80B2		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 63.0 rpm \| Output torque M2: 155 Nm
HA53 49,80 80B2		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 56.8 rpm \| Output torque M2: 168 Nm
HA63 49,80 80B2		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 56.8 rpm \| Output torque M2: 168 Nm
HA52 25,43 80D4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
HA52 25,43 90S4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
HA62 25,43 80D4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
HA62 25,43 90S4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
HA52 16,91 90L6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
HA52 16,91 100LR6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
HA62 16,91 90L6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
HA62 16,91 100LR6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
HA53 60,25 80B2		Unit: HA53 \| Ratio i: 60.25 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 47.0 rpm \| Output torque M2: 203 Nm
HA63 60,25 80B2		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 47.0 rpm \| Output torque M2: 203 Nm
HA52 29,89 80D4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
HA52 29,89 90S4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
HA62 29,89 80D4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
HA62 29,89 90S4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
HA52 20,46 90L6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
HA52 20,46 100LR6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
HA62 20,46 90L6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
HA62 20,46 100LR6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
HA52 36,17 80D4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
HA52 36,17 90S4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
HA62 36,17 80D4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
HA62 36,17 90S4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
HA53 74,88 80B2		Unit: HA53 \| Ratio i: 74.88 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 37.8 rpm \| Output torque M2: 252 Nm
HA63 74,88 80B2		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 37.8 rpm \| Output torque M2: 252 Nm
HA52 25,43 90L6		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
HA52 25,43 100LR6		Unit: HA52 \| Ratio i: 25.43 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
HA62 25,43 90L6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
HA62 25,43 100LR6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
HA63 88,02 80B2		Unit: HA63 \| Ratio i: 88.02 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 32.2 rpm \| Output torque M2: 296 Nm
HA52 29,89 90L6		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 327 Nm
HA52 44,95 80D4		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
HA52 44,95 90S4		Unit: HA52 \| Ratio i: 44.95 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
HA62 29,89 90L6		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 327 Nm
HA62 44,95 80D4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
HA62 44,95 90S4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
HA53 49,80 80D4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
HA53 49,80 90S4		Unit: HA53 \| Ratio i: 49.80 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
HA63 49,80 80D4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
HA63 49,80 90S4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
HA52 36,17 90L6		Unit: HA52 \| Ratio i: 36.17 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 26.0 rpm \| Output torque M2: 392 Nm
HA62 36,17 90L6		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 25.7 rpm \| Output torque M2: 396 Nm
HA63 60,25 80D4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 425 Nm
HA63 60,25 90S4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 425 Nm
HA62 44,95 90L6		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 20.7 rpm \| Output torque M2: 492 Nm
HA63 49,80 90L6		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 534 Nm
HA63 74,88 80D4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 528 Nm
HA63 74,88 90S4		Unit: HA63 \| Ratio i: 74.88 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 528 Nm
HA51 1,45 90L4		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 980.5 rpm \| Output torque M2: 14 Nm
HA51 1,45 90LA4		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 980.5 rpm \| Output torque M2: 14 Nm
HA51 2,94 80C2		Unit: HA51 \| Ratio i: 2.94 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 954.3 rpm \| Output torque M2: 14 Nm
HA51 2,94 90S2		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 954.3 rpm \| Output torque M2: 14 Nm
HA61 4,38 80C2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 640.9 rpm \| Output torque M2: 21 Nm
HA61 4,38 90S2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 640.9 rpm \| Output torque M2: 21 Nm
HA51 4,75 80C2		Unit: HA51 \| Ratio i: 4.75 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 591.6 rpm \| Output torque M2: 23 Nm
HA51 4,75 90S2		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 591.6 rpm \| Output torque M2: 23 Nm
HA61 2,50 90L4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 560.0 rpm \| Output torque M2: 25 Nm
HA61 2,50 90LA4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 560.0 rpm \| Output torque M2: 25 Nm
HA51 5,45 80C2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 515.2 rpm \| Output torque M2: 26 Nm
HA51 5,45 90S2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 515.2 rpm \| Output torque M2: 26 Nm
HA51 2,94 90L4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 482.3 rpm \| Output torque M2: 29 Nm
HA51 2,94 90LA4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 482.3 rpm \| Output torque M2: 29 Nm
HA61 2,50 100L6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 38 Nm
HA61 2,50 100LA6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 38 Nm
HA61 7,75 80C2		Unit: HA61 \| Ratio i: 7.75 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 362.6 rpm \| Output torque M2: 37 Nm
HA61 7,75 90S2		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 362.6 rpm \| Output torque M2: 37 Nm
HA61 4,38 90L4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 319.3 rpm \| Output torque M2: 44 Nm
HA61 4,38 90LA4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 319.3 rpm \| Output torque M2: 44 Nm
HA51 4,75 90L4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 47 Nm
HA51 4,75 90LA4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 47 Nm
HA61 10,67 80C2		Unit: HA61 \| Ratio i: 10.67 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 263.4 rpm \| Output torque M2: 51 Nm
HA61 10,67 90S2		Unit: HA61 \| Ratio i: 10.67 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 263.4 rpm \| Output torque M2: 51 Nm
HA51 5,45 90L4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 54 Nm
HA51 5,45 90LA4		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 54 Nm
HA52 11,67 80C2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 240.9 rpm \| Output torque M2: 55 Nm
HA52 11,67 90S2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 240.9 rpm \| Output torque M2: 55 Nm
HA52 6,22 90L4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 225.0 rpm \| Output torque M2: 61 Nm
HA52 6,22 90LA4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 225.0 rpm \| Output torque M2: 61 Nm
HA61 4,38 100L6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 66 Nm
HA61 4,38 100LA6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 66 Nm
HA52 14,50 80C2		Unit: HA52 \| Ratio i: 14.50 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 193.8 rpm \| Output torque M2: 68 Nm
HA52 14,50 90S2		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 193.8 rpm \| Output torque M2: 68 Nm
HA52 7,73 90L4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 181.0 rpm \| Output torque M2: 76 Nm
HA52 7,73 90LA4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 181.0 rpm \| Output torque M2: 76 Nm
HA52 5,14 100L6		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 77 Nm
HA52 5,14 100LA6		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 77 Nm
HA61 7,75 90L4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 77 Nm
HA61 7,75 90LA4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 77 Nm
HA52 16,91 80C2		Unit: HA52 \| Ratio i: 16.91 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 166.2 rpm \| Output torque M2: 80 Nm
HA52 16,91 90S2		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 166.2 rpm \| Output torque M2: 80 Nm
HA52 6,22 100L6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 93 Nm
HA52 6,22 100LA6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 93 Nm
HA52 9,64 90L4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 95 Nm
HA52 9,64 90LA4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 95 Nm
HA52 20,46 80C2		Unit: HA52 \| Ratio i: 20.46 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
HA52 20,46 90S2		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
HA62 20,46 80C2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
HA62 20,46 90S2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
HA52 7,73 100L6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
HA52 7,73 100LA6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
HA62 7,73 100L6		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
HA62 7,73 100LA6		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
HA52 11,67 90L4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
HA52 11,67 90LA4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
HA62 11,67 90L4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
HA62 11,67 90LA4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
HA52 25,43 80C2		Unit: HA52 \| Ratio i: 25.43 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
HA52 25,43 90S2		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
HA62 25,43 80C2		Unit: HA62 \| Ratio i: 25.43 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
HA62 25,43 90S2		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
HA52 14,50 90L4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
HA52 14,50 90LA4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
HA62 14,50 90L4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
HA62 14,50 90LA4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
HA52 9,64 100L6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
HA52 9,64 100LA6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
HA62 9,64 100L6		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
HA62 9,64 100LA6		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
HA52 29,89 80C2		Unit: HA52 \| Ratio i: 29.89 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
HA52 29,89 90S2		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
HA62 29,89 80C2		Unit: HA62 \| Ratio i: 29.89 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
HA62 29,89 90S2		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
HA52 16,91 90L4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
HA52 16,91 90LA4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
HA62 16,91 90L4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
HA62 16,91 90LA4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
HA52 11,67 100L6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
HA52 11,67 100LA6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
HA62 11,67 100L6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
HA62 11,67 100LA6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
HA52 36,17 80C2		Unit: HA52 \| Ratio i: 36.17 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
HA52 36,17 90S2		Unit: HA52 \| Ratio i: 36.17 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
HA62 36,17 80C2		Unit: HA62 \| Ratio i: 36.17 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
HA62 36,17 90S2		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
HA52 20,46 90L4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
HA52 20,46 90LA4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
HA62 20,46 90L4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
HA62 20,46 90LA4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
HA52 14,50 100L6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
HA52 14,50 100LA6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
HA62 14,50 100L6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
HA62 14,50 100LA6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
HA52 44,95 80C2		Unit: HA52 \| Ratio i: 44.95 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
HA52 44,95 90S2		Unit: HA52 \| Ratio i: 44.95 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
HA62 44,95 80C2		Unit: HA62 \| Ratio i: 44.95 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
HA62 44,95 90S2		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
HA63 49,80 80C2		Unit: HA63 \| Ratio i: 49.80 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 56.4 rpm \| Output torque M2: 230 Nm
HA63 49,80 90S2		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 56.4 rpm \| Output torque M2: 230 Nm
HA52 25,43 90L4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
HA52 25,43 90LA4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
HA62 25,43 90L4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
HA62 25,43 90LA4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
HA52 16,91 100L6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
HA52 16,91 100LA6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
HA62 16,91 100L6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
HA62 16,91 100LA6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
HA52 29,89 90L4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
HA52 29,89 90LA4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
HA62 29,89 90L4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
HA62 29,89 90LA4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
HA63 60,25 80C2		Unit: HA63 \| Ratio i: 60.25 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 279 Nm
HA63 60,25 90S2		Unit: HA63 \| Ratio i: 60.25 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 279 Nm
HA52 20,46 100L6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
HA52 20,46 100LA6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
HA62 20,46 100L6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
HA62 20,46 100LA6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
HA52 36,17 90L4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
HA52 36,17 90LA4		Unit: HA52 \| Ratio i: 36.17 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
HA62 36,17 90L4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
HA62 36,17 90LA4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
HA63 74,88 80C2		Unit: HA63 \| Ratio i: 74.88 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 346 Nm
HA63 74,88 90S2		Unit: HA63 \| Ratio i: 74.88 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 346 Nm
HA62 25,43 100L6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 380 Nm
HA62 25,43 100LA6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 380 Nm
HA62 44,95 90L4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 442 Nm
HA62 44,95 90LA4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 442 Nm
HA63 49,80 90L4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 479 Nm
HA63 49,80 90LA4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 479 Nm
HA63 60,25 90L4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 579 Nm
HA63 60,25 90LA4		Unit: HA63 \| Ratio i: 60.25 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 579 Nm
HA51 1,45 90LB4		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 966.7 rpm \| Output torque M2: 18 Nm
HA61 1,33 100LB6		Unit: HA61 \| Ratio i: 1.33 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 25 Nm
HA61 2,50 90LB4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 560.0 rpm \| Output torque M2: 31 Nm
HA51 2,94 90LB4		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 475.5 rpm \| Output torque M2: 36 Nm
HA61 2,50 100LB6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 47 Nm
HA61 4,38 90LB4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 319.3 rpm \| Output torque M2: 54 Nm
HA51 4,75 90LB4		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 58 Nm
HA52 5,14 90LB4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 272.2 rpm \| Output torque M2: 62 Nm
HA52 6,22 90LB4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 225.0 rpm \| Output torque M2: 75 Nm
HA61 4,38 100LB6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 82 Nm
HA52 7,73 90LB4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 181.0 rpm \| Output torque M2: 94 Nm
HA52 5,14 100LB6		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 95 Nm
HA61 7,75 90LB4		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 95 Nm
HA52 6,22 100LB6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 115 Nm
HA62 6,22 100LB6		Unit: HA62 \| Ratio i: 6.22 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 115 Nm
HA52 9,64 90LB4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 117 Nm
HA62 9,64 90LB4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 117 Nm
HA52 7,73 100LB6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 142 Nm
HA62 7,73 100LB6		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 142 Nm
HA52 11,67 90LB4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 141 Nm
HA62 11,67 90LB4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 141 Nm
HA52 14,50 90LB4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 176 Nm
HA62 14,50 90LB4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 176 Nm
HA52 9,64 100LB6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 178 Nm
HA62 9,64 100LB6		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 178 Nm
HA52 16,91 90LB4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 205 Nm
HA62 16,91 90LB4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 205 Nm
HA52 11,67 100LB6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 215 Nm
HA62 11,67 100LB6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 215 Nm
HA52 20,46 90LB4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 248 Nm
HA62 20,46 90LB4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 248 Nm
HA52 14,50 100LB6		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 267 Nm
HA62 14,50 100LB6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 267 Nm
HA52 25,43 90LB4		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 308 Nm
HA62 25,43 90LB4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 308 Nm
HA52 16,91 100LB6		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 312 Nm
HA62 16,91 100LB6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 312 Nm
HA52 29,89 90LB4		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 362 Nm
HA62 29,89 90LB4		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 362 Nm
HA52 20,46 100LB6		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 377 Nm
HA62 20,46 100LB6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 377 Nm
HA62 36,17 90LB4		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 438 Nm
HA62 25,43 100LB6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 468 Nm
HA62 44,95 90LB4		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 545 Nm
HA63 49,80 90LB4		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 591 Nm
HA51 1,45 90L2		Unit: HA51 \| Ratio i: 1.45 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 1988.6 rpm \| Output torque M2: 10 Nm
HA61 2,50 90L2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 1152.0 rpm \| Output torque M2: 17 Nm
HA51 2,94 90L2		Unit: HA51 \| Ratio i: 2.94 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 978.1 rpm \| Output torque M2: 20 Nm
HA61 1,33 112M6		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 30 Nm
HA61 1,33 112MA6		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 30 Nm
HA61 4,38 90L2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 656.8 rpm \| Output torque M2: 30 Nm
HA51 4,75 90L2		Unit: HA51 \| Ratio i: 4.75 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 602.1 rpm \| Output torque M2: 33 Nm
HA61 2,50 100LA4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 36 Nm
HA61 2,50 112MR4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 36 Nm
HA51 5,45 90L2		Unit: HA51 \| Ratio i: 5.45 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 528.0 rpm \| Output torque M2: 37 Nm
HA61 2,50 112M6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 55 Nm
HA61 2,50 112MA6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 55 Nm
HA61 7,75 90L2		Unit: HA61 \| Ratio i: 7.75 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 371.6 rpm \| Output torque M2: 53 Nm
HA52 7,73 90L2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 369.8 rpm \| Output torque M2: 53 Nm
HA61 4,38 100LA4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 63 Nm
HA61 4,38 112MR4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 63 Nm
HA52 9,64 90L2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 296.6 rpm \| Output torque M2: 66 Nm
HA52 5,14 100LA4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 73 Nm
HA52 5,14 112MR4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 73 Nm
HA52 11,67 90L2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 246.9 rpm \| Output torque M2: 79 Nm
HA52 6,22 100LA4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 88 Nm
HA52 6,22 112MR4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 88 Nm
HA61 4,38 112M6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 97 Nm
HA61 4,38 112MA6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 97 Nm
HA52 14,50 90L2		Unit: HA52 \| Ratio i: 14.50 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 197.2 rpm \| Output torque M2: 99 Nm
HA62 14,50 90L2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 197.2 rpm \| Output torque M2: 99 Nm
HA52 7,73 100LA4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
HA52 7,73 112MR4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
HA62 7,73 100LA4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
HA62 7,73 112MR4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
HA52 5,14 112M6		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
HA52 5,14 112MA6		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
HA62 5,14 112M6		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
HA62 5,14 112MA6		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
HA52 16,91 90L2		Unit: HA52 \| Ratio i: 16.91 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 169.1 rpm \| Output torque M2: 115 Nm
HA62 16,91 90L2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 169.1 rpm \| Output torque M2: 115 Nm
HA52 6,22 112M6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
HA52 6,22 112MA6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
HA62 6,22 112M6		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
HA62 6,22 112MA6		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
HA52 9,64 100LA4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
HA52 9,64 112MR4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
HA62 9,64 100LA4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
HA62 9,64 112MR4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
HA52 20,46 90L2		Unit: HA52 \| Ratio i: 20.46 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 139.8 rpm \| Output torque M2: 139 Nm
HA62 20,46 90L2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 139.8 rpm \| Output torque M2: 139 Nm
HA52 11,67 100LA4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
HA52 11,67 112MR4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
HA62 11,67 100LA4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
HA62 11,67 112MR4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
HA52 7,73 112M6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
HA52 7,73 112MA6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
HA62 7,73 112M6		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
HA62 7,73 112MA6		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
HA52 25,43 90L2		Unit: HA52 \| Ratio i: 25.43 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 112.5 rpm \| Output torque M2: 173 Nm
HA62 25,43 90L2		Unit: HA62 \| Ratio i: 25.43 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 112.5 rpm \| Output torque M2: 173 Nm
HA52 14,50 100LA4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
HA52 14,50 112MR4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
HA62 14,50 100LA4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
HA62 14,50 112MR4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
HA52 9,64 112M6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
HA52 9,64 112MA6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
HA62 9,64 112M6		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
HA62 9,64 112MA6		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
HA52 29,89 90L2		Unit: HA52 \| Ratio i: 29.89 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 95.7 rpm \| Output torque M2: 203 Nm
HA62 29,89 90L2		Unit: HA62 \| Ratio i: 29.89 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 95.7 rpm \| Output torque M2: 203 Nm
HA52 16,91 100LA4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
HA52 16,91 112MR4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
HA62 16,91 100LA4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
HA62 16,91 112MR4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
HA52 11,67 112M6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
HA52 11,67 112MA6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
HA62 11,67 112M6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
HA62 11,67 112MA6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
HA62 36,17 90L2		Unit: HA62 \| Ratio i: 36.17 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 79.1 rpm \| Output torque M2: 246 Nm
HA52 20,46 100LA4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
HA52 20,46 112MR4		Unit: HA52 \| Ratio i: 20.46 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
HA62 20,46 100LA4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
HA62 20,46 112MR4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
HA62 14,50 112M6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 318 Nm
HA62 14,50 112MA6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 318 Nm
HA62 44,95 90L2		Unit: HA62 \| Ratio i: 44.95 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 63.6 rpm \| Output torque M2: 306 Nm
HA63 49,80 90L2		Unit: HA63 \| Ratio i: 49.80 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 57.4 rpm \| Output torque M2: 332 Nm
HA62 25,43 100LA4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 361 Nm
HA62 25,43 112MR4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 361 Nm
HA62 16,91 112M6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 370 Nm
HA62 16,91 112MA6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 370 Nm
HA62 20,46 112M6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 448 Nm
HA62 20,46 112MA6		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 448 Nm
HA62 25,43 112M6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 557 Nm
HA62 25,43 112MA6		Unit: HA62 \| Ratio i: 25.43 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 557 Nm
HA61 2,50 100L2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 1160.0 rpm \| Output torque M2: 23 Nm
HA61 2,50 100LA2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 1160.0 rpm \| Output torque M2: 23 Nm
HA61 1,33 100LB4		Unit: HA61 \| Ratio i: 1.33 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 1072.5 rpm \| Output torque M2: 26 Nm
HA61 1,33 112MS4		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 1072.5 rpm \| Output torque M2: 26 Nm
HA61 1,33 112MB6		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 40 Nm
HA61 4,38 100L2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 661.4 rpm \| Output torque M2: 41 Nm
HA61 4,38 100LA2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 661.4 rpm \| Output torque M2: 41 Nm
HA61 2,50 100LB4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 49 Nm
HA61 2,50 112MS4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 49 Nm
HA52 5,14 100L2		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 48 Nm
HA52 5,14 100LA2		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 48 Nm
HA52 6,22 100L2		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 58 Nm
HA52 6,22 100LA2		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 58 Nm
HA61 2,50 112MB6		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 75 Nm
HA52 7,73 100L2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 72 Nm
HA52 7,73 100LA2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 72 Nm
HA62 7,73 100LA2		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LA2 (brake TBS only) \| Power P1: 3.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 72 Nm
HA61 4,38 100LB4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 86 Nm
HA61 4,38 112MS4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 86 Nm
HA52 9,64 100L2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
HA52 9,64 100LA2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
HA62 9,64 100L2		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
HA62 9,64 100LA2		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
HA52 5,14 100LB4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
HA52 5,14 112MS4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
HA62 5,14 100LB4		Unit: HA62 \| Ratio i: 5.14 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
HA62 5,14 112MS4		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
HA52 11,67 100L2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
HA52 11,67 100LA2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
HA62 11,67 100L2		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
HA62 11,67 100LA2		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
HA52 6,22 100LB4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
HA52 6,22 112MS4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
HA62 6,22 100LB4		Unit: HA62 \| Ratio i: 6.22 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
HA62 6,22 112MS4		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
HA61 4,38 112MB6		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 132 Nm
HA52 14,50 100L2		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
HA52 14,50 100LA2		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
HA62 14,50 100L2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
HA62 14,50 100LA2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
HA52 7,73 100LB4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
HA52 7,73 112MS4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
HA62 7,73 100LB4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
HA62 7,73 112MS4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
HA52 5,14 112MB6		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 154 Nm
HA62 5,14 112MB6		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 154 Nm
HA52 16,91 100L2		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
HA52 16,91 100LA2		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
HA62 16,91 100L2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
HA62 16,91 100LA2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
HA52 6,22 112MB6		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 186 Nm
HA62 6,22 112MB6		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 186 Nm
HA52 9,64 100LB4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
HA52 9,64 112MS4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
HA62 9,64 100LB4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
HA62 9,64 112MS4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
HA52 20,46 100L2		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
HA52 20,46 100LA2		Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
HA62 20,46 100L2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
HA62 20,46 100LA2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
HA52 11,67 100LB4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
HA52 11,67 112MS4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
HA62 11,67 100LB4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
HA62 11,67 112MS4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
HA52 7,73 112MB6		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 231 Nm
HA62 7,73 112MB6		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 231 Nm
HA62 25,43 100L2		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 112.9 rpm \| Output torque M2: 235 Nm
HA62 25,43 100LA2		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 112.9 rpm \| Output torque M2: 235 Nm
HA52 14,50 100LB4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
HA52 14,50 112MS4		Unit: HA52 \| Ratio i: 14.50 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
HA62 14,50 100LB4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
HA62 14,50 112MS4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
HA52 9,64 112MB6		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 288 Nm
HA62 9,64 112MB6		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 288 Nm
HA52 16,91 100LB4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
HA52 16,91 112MS4		Unit: HA52 \| Ratio i: 16.91 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
HA62 16,91 100LB4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
HA62 16,91 112MS4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
HA52 11,67 112MB6		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 348 Nm
HA62 11,67 112MB6		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 348 Nm
HA62 20,46 100LB4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 396 Nm
HA62 20,46 112MS4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 396 Nm
HA62 14,50 112MB6		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 433 Nm
HA62 25,43 100LB4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 493 Nm
HA62 25,43 112MS4		Unit: HA62 \| Ratio i: 25.43 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 493 Nm
HA62 16,91 112MB6		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 505 Nm
HA61 2,50 100LB2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1148.0 rpm \| Output torque M2: 31 Nm
HA61 2,50 112M2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1148.0 rpm \| Output torque M2: 31 Nm
HA61 2,50 112MA2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1148.0 rpm \| Output torque M2: 31 Nm
HA61 1,33 112M4		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1087.5 rpm \| Output torque M2: 34 Nm
HA61 1,33 112MA4		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1087.5 rpm \| Output torque M2: 34 Nm
HA61 4,38 100LB2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 654.6 rpm \| Output torque M2: 55 Nm
HA61 4,38 112M2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 654.6 rpm \| Output torque M2: 55 Nm
HA61 4,38 112MA2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 654.6 rpm \| Output torque M2: 55 Nm
HA61 2,50 112M4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 580.0 rpm \| Output torque M2: 64 Nm
HA61 2,50 112MA4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 580.0 rpm \| Output torque M2: 64 Nm
HA52 5,14 100LB2		Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 63 Nm
HA52 5,14 112M2		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 63 Nm
HA52 5,14 112MA2		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 63 Nm
HA52 6,22 100LB2		Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
HA52 6,22 112M2		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
HA52 6,22 112MA2		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
HA62 6,22 100LB2		Unit: HA62 \| Ratio i: 6.22 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
HA62 6,22 112M2		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
HA62 6,22 112MA2		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
HA52 7,73 100LB2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
HA52 7,73 112M2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
HA52 7,73 112MA2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
HA62 7,73 100LB2		Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
HA62 7,73 112M2		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
HA62 7,73 112MA2		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
HA61 4,38 112M4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 328.4 rpm \| Output torque M2: 113 Nm
HA61 4,38 112MA4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 328.4 rpm \| Output torque M2: 113 Nm
HA52 9,64 100LB2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
HA52 9,64 112M2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
HA52 9,64 112MA2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
HA62 9,64 100LB2		Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
HA62 9,64 112M2		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
HA62 9,64 112MA2		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
HA52 5,14 112M4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
HA52 5,14 112MA4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
HA62 5,14 112M4		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
HA62 5,14 112MA4		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
HA52 11,67 100LB2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
HA52 11,67 112M2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
HA52 11,67 112MA2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
HA62 11,67 100LB2		Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
HA62 11,67 112M2		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
HA62 11,67 112MA2		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
HA52 6,22 112M4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
HA52 6,22 112MA4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
HA62 6,22 112M4		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
HA62 6,22 112MA4		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
HA62 14,50 100LB2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 179 Nm
HA62 14,50 112M2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 179 Nm
HA62 14,50 112MA2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 179 Nm
HA52 7,73 112M4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
HA52 7,73 112MA4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
HA62 7,73 112M4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
HA62 7,73 112MA4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
HA62 16,91 100LB2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 209 Nm
HA62 16,91 112M2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 209 Nm
HA62 16,91 112MA2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 209 Nm
HA52 9,64 112M4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
HA52 9,64 112MA4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
HA62 9,64 112M4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
HA62 9,64 112MA4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
HA62 20,46 100LB2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 252 Nm
HA62 20,46 112M2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 252 Nm
HA62 20,46 112MA2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 252 Nm
HA52 11,67 112M4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
HA52 11,67 112MA4		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
HA62 11,67 112M4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
HA62 11,67 112MA4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
HA62 14,50 112M4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 99.3 rpm \| Output torque M2: 369 Nm
HA62 14,50 112MA4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 99.3 rpm \| Output torque M2: 369 Nm
HA62 16,91 112M4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 85.1 rpm \| Output torque M2: 431 Nm
HA62 16,91 112MA4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 85.1 rpm \| Output torque M2: 431 Nm
HA62 20,46 112M4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 70.4 rpm \| Output torque M2: 521 Nm
HA62 20,46 112MA4		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 70.4 rpm \| Output torque M2: 521 Nm
HA61 1,33 112MB4		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 1072.5 rpm \| Output torque M2: 41 Nm
HA61 2,50 112MB4		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 78 Nm
HA61 4,38 112MB4		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 326.1 rpm \| Output torque M2: 136 Nm
HA52 5,14 112MB4		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 158 Nm
HA62 5,14 112MB4		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 158 Nm
HA52 6,22 112MB4		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 191 Nm
HA62 6,22 112MB4		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 191 Nm
HA52 7,73 112MB4		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 184.9 rpm \| Output torque M2: 238 Nm
HA62 7,73 112MB4		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 184.9 rpm \| Output torque M2: 238 Nm
HA52 9,64 112MB4		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 148.3 rpm \| Output torque M2: 297 Nm
HA62 9,64 112MB4		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 148.3 rpm \| Output torque M2: 297 Nm
HA62 11,67 112MB4		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 122.6 rpm \| Output torque M2: 359 Nm
HA62 14,50 112MB4		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 98.6 rpm \| Output torque M2: 446 Nm
HA62 16,91 112MB4		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 84.6 rpm \| Output torque M2: 520 Nm
HA61 1,33 112MB2		Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 2182.5 rpm \| Output torque M2: 23 Nm
HA61 2,50 112MB2		Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 1164.0 rpm \| Output torque M2: 42 Nm
HA61 4,38 112MB2		Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 663.7 rpm \| Output torque M2: 74 Nm
HA52 5,14 112MB2		Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 565.8 rpm \| Output torque M2: 86 Nm
HA62 5,14 112MB2		Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 565.8 rpm \| Output torque M2: 86 Nm
HA52 6,22 112MB2		Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 467.7 rpm \| Output torque M2: 104 Nm
HA62 6,22 112MB2		Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 467.7 rpm \| Output torque M2: 104 Nm
HA52 7,73 112MB2		Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 376.3 rpm \| Output torque M2: 129 Nm
HA62 7,73 112MB2		Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 376.3 rpm \| Output torque M2: 129 Nm
HA52 9,64 112MB2		Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 301.8 rpm \| Output torque M2: 161 Nm
HA62 9,64 112MB2		Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 301.8 rpm \| Output torque M2: 161 Nm
HA52 11,67 112MB2		Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 249.4 rpm \| Output torque M2: 195 Nm
HA62 11,67 112MB2		Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 249.4 rpm \| Output torque M2: 195 Nm
HA62 14,50 112MB2		Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 200.7 rpm \| Output torque M2: 242 Nm
HA62 16,91 112MB2		Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 172.1 rpm \| Output torque M2: 283 Nm
HA62 20,46 112MB2		Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 142.2 rpm \| Output torque M2: 342 Nm
HA51 1.45 90LL4		Legacy code (older catalogue edition) \| Unit: HA51 \| Ratio i: 1.45 \| Motor: 90LL4
HA51 2.94 90LL4		Legacy code (older catalogue edition) \| Unit: HA51 \| Ratio i: 2.94 \| Motor: 90LL4
HA51 4.75 90LL4		Legacy code (older catalogue edition) \| Unit: HA51 \| Ratio i: 4.75 \| Motor: 90LL4
HA52 49.78 80A6		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80A6
HA52 61.87 80A6		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80A6
HA52 49.78 80A4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80A4
HA52 61.87 80A4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80A4
HA52 49.78 80B6		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80B6
HA52 61.87 80B6		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80B6
HA52 49.78 80B4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80B4
HA52 61.87 80B4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80B4
HA52 49.78 80C4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80C4
HA52 9.64 90S4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 9.64 \| Motor: 90S4
HA52 7.73 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 7.73 \| Motor: 90LL4
HA52 9.64 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 9.64 \| Motor: 90LL4
HA52 11.67 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 11.67 \| Motor: 90LL4
HA52 14.50 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 14.50 \| Motor: 90LL4
HA52 16.91 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 16.91 \| Motor: 90LL4
HA52 20.46 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 20.46 \| Motor: 90LL4
HA52 25.43 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 25.43 \| Motor: 90LL4
HA52 29.89 90LL4		Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 29.89 \| Motor: 90LL4
HA53 235.41 71A4		Legacy code (older catalogue edition) \| Unit: HA53 \| Ratio i: 235.41 \| Motor: 71A4
HA61 4.38 80B4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 4.38 \| Motor: 80B4
HA61 4.38 80C4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 4.38 \| Motor: 80C4
HA61 10.67 90L4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 10.67 \| Motor: 90L4
HA61 2.50 90LL4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 2.50 \| Motor: 90LL4
HA61 4.38 90LL4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 4.38 \| Motor: 90LL4
HA61 7.75 90LL4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 7.75 \| Motor: 90LL4
HA61 1.33 100LA4		Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 1.33 \| Motor: 100LA4
HA62 49.78 80B6		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 80B6
HA62 61.87 80B6		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 80B6
HA62 49.78 80B4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 80B4
HA62 61.87 80B4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 80B4
HA62 49.78 90S6		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 90S6
HA62 61.87 90S6		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 90S6
HA62 49.78 80C4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 80C4
HA62 61.87 80C4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 80C4
HA62 49.78 90S4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 90S4
HA62 61.87 90S4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 90S4
HA62 20.46 90LL4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 20.46 \| Motor: 90LL4
HA62 25.43 90LL4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 25.43 \| Motor: 90LL4
HA62 29.89 90LL4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 29.89 \| Motor: 90LL4
HA62 36.17 90LL4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 36.17 \| Motor: 90LL4
HA62 44.95 90LL4		Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 44.95 \| Motor: 90LL4
HA53		Legacy code (older catalogue edition) \| Unit: HA53
HA63		Legacy code (older catalogue edition) \| Unit: HA63
HA51		Legacy code (older catalogue edition) \| Unit: HA51
HA52		Legacy code (older catalogue edition) \| Unit: HA52
HA61		Legacy code (older catalogue edition) \| Unit: HA61
HA62		Legacy code (older catalogue edition) \| Unit: HA62

Helical Gear ReducersMotovario

1114 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Motovario HA Helical Inline Gearmotors (HA51-HA63, 0.09-5.5 kW)

Brand Motovario·Helical Gear Reducers

Available part numbers (1114)

HA51 10,83 63A6, HA53 88,02 63A6, HA53 111,61 63A6, HA53 138,71 63A6, HA63 138,71 63A6, HA53 163,05 63A6, HA63 163,05 63A6, HA53 200,27 63A6, HA63 200,27 63A6, HA53 235,41 63A6 + 1104 more — see full table ↓

How to order

Send the Motovario part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	HA51 10,83 63A6	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 79.4 rpm \| Output torque M2: 11 Nm
	HA53 88,02 63A6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 84 Nm
	HA53 111,61 63A6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 7.7 rpm \| Output torque M2: 106 Nm
	HA53 138,71 63A6	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 132 Nm
	HA63 138,71 63A6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 132 Nm
	HA53 163,05 63A6	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 155 Nm
	HA63 163,05 63A6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 155 Nm
	HA53 200,27 63A6	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 190 Nm
	HA63 200,27 63A6	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 190 Nm
	HA53 235,41 63A6	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 223 Nm
	HA63 235,41 63A6	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 223 Nm
	HA53 284,81 63A6	Unit: HA53 \| Ratio i: 284.81 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 270 Nm
	HA63 284,81 63A6	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 270 Nm
	HA53 353,98 63A6	Unit: HA53 \| Ratio i: 353.98 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 2.4 rpm \| Output torque M2: 336 Nm
	HA63 353,98 63A6	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63A6 \| Power P1: 0.09 kW \| Output speed n2: 2.4 rpm \| Output torque M2: 336 Nm
	HA51 10,83 63A4	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 123.7 rpm \| Output torque M2: 9 Nm
	HA51 10,83 63B6	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 79.4 rpm \| Output torque M2: 14 Nm
	HA53 111,61 63A4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 90 Nm
	HA53 74,88 63B6	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 11.5 rpm \| Output torque M2: 95 Nm
	HA53 88,02 63B6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 111 Nm
	HA53 138,71 63A4	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 9.7 rpm \| Output torque M2: 112 Nm
	HA53 163,05 63A4	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 131 Nm
	HA63 163,05 63A4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 131 Nm
	HA53 111,61 63B6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 7.7 rpm \| Output torque M2: 141 Nm
	HA63 111,61 63B6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 7.7 rpm \| Output torque M2: 141 Nm
	HA53 200,27 63A4	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 6.7 rpm \| Output torque M2: 161 Nm
	HA63 200,27 63A4	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 6.7 rpm \| Output torque M2: 161 Nm
	HA53 138,71 63B6	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 175 Nm
	HA63 138,71 63B6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 6.2 rpm \| Output torque M2: 175 Nm
	HA53 235,41 63A4	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 5.7 rpm \| Output torque M2: 189 Nm
	HA63 235,41 63A4	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 5.7 rpm \| Output torque M2: 189 Nm
	HA53 163,05 63B6	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 206 Nm
	HA63 163,05 63B6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 5.3 rpm \| Output torque M2: 206 Nm
	HA53 284,81 63A4	Unit: HA53 \| Ratio i: 284.81 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 229 Nm
	HA63 284,81 63A4	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 229 Nm
	HA53 200,27 63B6	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 253 Nm
	HA63 200,27 63B6	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 4.3 rpm \| Output torque M2: 253 Nm
	HA53 353,98 63A4	Unit: HA53 \| Ratio i: 353.98 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 285 Nm
	HA63 353,98 63A4	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63A4 \| Power P1: 0.12 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 285 Nm
	HA53 235,41 63B6	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 298 Nm
	HA63 235,41 63B6	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.7 rpm \| Output torque M2: 298 Nm
	HA53 284,81 63B6	Unit: HA53 \| Ratio i: 284.81 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 360 Nm
	HA63 284,81 63B6	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 3.0 rpm \| Output torque M2: 360 Nm
	HA63 353,98 63B6	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63B6 \| Power P1: 0.12 kW \| Output speed n2: 2.4 rpm \| Output torque M2: 448 Nm
	HA51 7,88 63C6	Unit: HA51 \| Ratio i: 7.88 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 102.9 rpm \| Output torque M2: 14 Nm
	HA51 10,83 63C6	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 74.8 rpm \| Output torque M2: 19 Nm
	HA53 49,80 63C6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 16.3 rpm \| Output torque M2: 84 Nm
	HA53 60,25 63C6	Unit: HA53 \| Ratio i: 60.25 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 13.4 rpm \| Output torque M2: 101 Nm
	HA53 74,88 63C6	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 10.8 rpm \| Output torque M2: 126 Nm
	HA53 88,02 63C6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 9.2 rpm \| Output torque M2: 148 Nm
	HA63 88,02 63C6	Unit: HA63 \| Ratio i: 88.02 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 9.2 rpm \| Output torque M2: 148 Nm
	HA53 111,61 63C6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 7.3 rpm \| Output torque M2: 187 Nm
	HA63 111,61 63C6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 7.3 rpm \| Output torque M2: 187 Nm
	HA53 138,71 63C6	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.8 rpm \| Output torque M2: 233 Nm
	HA63 138,71 63C6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.8 rpm \| Output torque M2: 233 Nm
	HA53 163,05 63C6	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.0 rpm \| Output torque M2: 274 Nm
	HA63 163,05 63C6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 5.0 rpm \| Output torque M2: 274 Nm
	HA53 200,27 63C6	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 4.0 rpm \| Output torque M2: 336 Nm
	HA63 200,27 63C6	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 4.0 rpm \| Output torque M2: 336 Nm
	HA63 235,41 63C6	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 3.4 rpm \| Output torque M2: 395 Nm
	HA63 284,81 63C6	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 2.8 rpm \| Output torque M2: 478 Nm
	HA63 353,98 63C6	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63C6 \| Power P1: 0.15 kW \| Output speed n2: 2.3 rpm \| Output torque M2: 594 Nm
	HA51 10,83 63A2	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 258.5 rpm \| Output torque M2: 6 Nm
	HA51 10,83 63B4	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 122.8 rpm \| Output torque M2: 14 Nm
	HA51 7,88 71A6	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 114.3 rpm \| Output torque M2: 15 Nm
	HA51 10,83 71A6	Unit: HA51 \| Ratio i: 10.83 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 83.1 rpm \| Output torque M2: 20 Nm
	HA53 111,61 63A2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 62 Nm
	HA53 138,71 63A2	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 77 Nm
	HA53 49,80 71A6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 18.1 rpm \| Output torque M2: 90 Nm
	HA53 74,88 63B4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 17.8 rpm \| Output torque M2: 91 Nm
	HA53 163,05 63A2	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 91 Nm
	HA63 163,05 63A2	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 91 Nm
	HA53 88,02 63B4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 15.1 rpm \| Output torque M2: 107 Nm
	HA53 60,25 71A6	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 14.9 rpm \| Output torque M2: 109 Nm
	HA53 200,27 63A2	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 112 Nm
	HA63 200,27 63A2	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 112 Nm
	HA53 74,88 71A6	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 136 Nm
	HA63 74,88 71A6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 136 Nm
	HA53 111,61 63B4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 136 Nm
	HA53 235,41 63A2	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 131 Nm
	HA63 111,61 63B4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 136 Nm
	HA63 235,41 63A2	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 131 Nm
	HA53 88,02 71A6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 160 Nm
	HA63 88,02 71A6	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 160 Nm
	HA53 284,81 63A2	Unit: HA53 \| Ratio i: 284.81 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 159 Nm
	HA63 284,81 63A2	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 159 Nm
	HA53 138,71 63B4	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 169 Nm
	HA63 138,71 63B4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 169 Nm
	HA53 163,05 63B4	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 198 Nm
	HA63 163,05 63B4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 198 Nm
	HA53 111,61 71A6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 202 Nm
	HA63 111,61 71A6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 202 Nm
	HA53 353,98 63A2	Unit: HA53 \| Ratio i: 353.98 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 197 Nm
	HA63 353,98 63A2	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63A2 \| Power P1: 0.18 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 197 Nm
	HA53 200,27 63B4	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 243 Nm
	HA63 200,27 63B4	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 243 Nm
	HA53 138,71 71A6	Unit: HA53 \| Ratio i: 138.71 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 252 Nm
	HA63 138,71 71A6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 252 Nm
	HA53 235,41 63B4	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 286 Nm
	HA63 235,41 63B4	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 286 Nm
	HA53 163,05 71A6	Unit: HA53 \| Ratio i: 163.05 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 296 Nm
	HA63 163,05 71A6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 296 Nm
	HA53 284,81 63B4	Unit: HA53 \| Ratio i: 284.81 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 346 Nm
	HA63 284,81 63B4	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 346 Nm
	HA53 200,27 71A6	Unit: HA53 \| Ratio i: 200.27 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 4.5 rpm \| Output torque M2: 363 Nm
	HA63 200,27 71A6	Unit: HA63 \| Ratio i: 200.27 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 4.5 rpm \| Output torque M2: 363 Nm
	HA63 235,41 71A6	Unit: HA63 \| Ratio i: 235.41 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 427 Nm
	HA63 353,98 63B4	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63B4 \| Power P1: 0.18 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 430 Nm
	HA63 284,81 71A6	Unit: HA63 \| Ratio i: 284.81 \| Motor: 71A6 \| Power P1: 0.18 kW \| Output speed n2: 3.2 rpm \| Output torque M2: 516 Nm
	HA51 7,88 63C4	Unit: HA51 \| Ratio i: 7.88 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 168.9 rpm \| Output torque M2: 12 Nm
	HA51 10,83 63C4	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 122.8 rpm \| Output torque M2: 17 Nm
	HA53 60,25 63C4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 22.1 rpm \| Output torque M2: 89 Nm
	HA53 74,88 63C4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 17.8 rpm \| Output torque M2: 111 Nm
	HA53 88,02 63C4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 15.1 rpm \| Output torque M2: 131 Nm
	HA63 88,02 63C4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 15.1 rpm \| Output torque M2: 131 Nm
	HA53 111,61 63C4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 166 Nm
	HA63 111,61 63C4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 166 Nm
	HA53 138,71 63C4	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 206 Nm
	HA63 138,71 63C4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 9.6 rpm \| Output torque M2: 206 Nm
	HA53 163,05 63C4	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 242 Nm
	HA63 163,05 63C4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 8.2 rpm \| Output torque M2: 242 Nm
	HA53 200,27 63C4	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 297 Nm
	HA63 200,27 63C4	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 297 Nm
	HA53 235,41 63C4	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 350 Nm
	HA63 235,41 63C4	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 350 Nm
	HA63 284,81 63C4	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 4.7 rpm \| Output torque M2: 423 Nm
	HA63 353,98 63C4	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63C4 \| Power P1: 0.22 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 526 Nm
	HA51 10,83 63B2	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 258.5 rpm \| Output torque M2: 9 Nm
	HA51 7,88 63D4	Unit: HA51 \| Ratio i: 7.88 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 167.6 rpm \| Output torque M2: 14 Nm
	HA51 7,88 71A4	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 167.6 rpm \| Output torque M2: 14 Nm
	HA51 5,45 71B6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 165.0 rpm \| Output torque M2: 14 Nm
	HA51 10,83 63D4	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 121.8 rpm \| Output torque M2: 19 Nm
	HA51 10,83 71A4	Unit: HA51 \| Ratio i: 10.83 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 121.8 rpm \| Output torque M2: 19 Nm
	HA51 7,88 71B6	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 114.3 rpm \| Output torque M2: 20 Nm
	HA51 10,83 71B6	Unit: HA51 \| Ratio i: 10.83 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 83.1 rpm \| Output torque M2: 28 Nm
	HA53 74,88 63B2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 58 Nm
	HA53 88,02 63B2	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 68 Nm
	HA53 49,80 63D4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 26.5 rpm \| Output torque M2: 85 Nm
	HA53 49,80 71A4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 26.5 rpm \| Output torque M2: 85 Nm
	HA53 111,61 63B2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 86 Nm
	HA53 60,25 63D4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 21.9 rpm \| Output torque M2: 102 Nm
	HA53 60,25 71A4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 21.9 rpm \| Output torque M2: 102 Nm
	HA53 138,71 63B2	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 107 Nm
	HA63 138,71 63B2	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 107 Nm
	HA53 49,80 71B6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 18.1 rpm \| Output torque M2: 125 Nm
	HA53 74,88 63D4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
	HA53 74,88 71A4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
	HA63 74,88 63D4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
	HA63 74,88 71A4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 17.6 rpm \| Output torque M2: 127 Nm
	HA53 163,05 63B2	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 126 Nm
	HA63 163,05 63B2	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 126 Nm
	HA53 88,02 63D4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
	HA53 88,02 71A4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
	HA63 88,02 63D4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
	HA63 88,02 71A4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 15.0 rpm \| Output torque M2: 150 Nm
	HA53 60,25 71B6	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 14.9 rpm \| Output torque M2: 152 Nm
	HA63 60,25 71B6	Unit: HA63 \| Ratio i: 60.25 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 14.9 rpm \| Output torque M2: 152 Nm
	HA53 200,27 63B2	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 155 Nm
	HA63 200,27 63B2	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 155 Nm
	HA53 74,88 71B6	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 189 Nm
	HA63 74,88 71B6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 12.0 rpm \| Output torque M2: 189 Nm
	HA53 235,41 63B2	Unit: HA53 \| Ratio i: 235.41 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 182 Nm
	HA63 235,41 63B2	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 182 Nm
	HA53 111,61 63D4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
	HA53 111,61 71A4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
	HA63 111,61 63D4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
	HA63 111,61 71A4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 190 Nm
	HA53 88,02 71B6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 222 Nm
	HA63 88,02 71B6	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 10.2 rpm \| Output torque M2: 222 Nm
	HA53 284,81 63B2	Unit: HA53 \| Ratio i: 284.81 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 220 Nm
	HA63 284,81 63B2	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 220 Nm
	HA53 138,71 63D4	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
	HA53 138,71 71A4	Unit: HA53 \| Ratio i: 138.71 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
	HA63 138,71 63D4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
	HA63 138,71 71A4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 9.5 rpm \| Output torque M2: 236 Nm
	HA53 111,61 71B6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 281 Nm
	HA53 163,05 63D4	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
	HA53 163,05 71A4	Unit: HA53 \| Ratio i: 163.05 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
	HA63 111,61 71B6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 281 Nm
	HA63 163,05 63D4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
	HA63 163,05 71A4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 8.1 rpm \| Output torque M2: 277 Nm
	HA63 353,98 63B2	Unit: HA63 \| Ratio i: 353.98 \| Motor: 63B2 \| Power P1: 0.25 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 274 Nm
	HA53 200,27 63D4	Unit: HA53 \| Ratio i: 200.27 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
	HA53 200,27 71A4	Unit: HA53 \| Ratio i: 200.27 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
	HA63 200,27 63D4	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
	HA63 200,27 71A4	Unit: HA63 \| Ratio i: 200.27 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 6.6 rpm \| Output torque M2: 340 Nm
	HA53 138,71 71B6	Unit: HA53 \| Ratio i: 138.71 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 349 Nm
	HA63 138,71 71B6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 6.5 rpm \| Output torque M2: 349 Nm
	HA63 235,41 63D4	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 400 Nm
	HA63 235,41 71A4	Unit: HA63 \| Ratio i: 235.41 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 5.6 rpm \| Output torque M2: 400 Nm
	HA53 163,05 71B6	Unit: HA53 \| Ratio i: 163.05 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 411 Nm
	HA63 163,05 71B6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 5.5 rpm \| Output torque M2: 411 Nm
	HA63 284,81 63D4	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63D4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 4.6 rpm \| Output torque M2: 484 Nm
	HA63 284,81 71A4	Unit: HA63 \| Ratio i: 284.81 \| Motor: 71A4 (frame printed 63D/71A) \| Power P1: 0.25 kW \| Output speed n2: 4.6 rpm \| Output torque M2: 484 Nm
	HA63 200,27 71B6	Unit: HA63 \| Ratio i: 200.27 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 4.5 rpm \| Output torque M2: 504 Nm
	HA63 353,98 71A4	Unit: HA63 \| Ratio i: 353.98 \| Motor: 71A4 \| Power P1: 0.25 kW \| Output speed n2: 3.9 rpm \| Output torque M2: 572 Nm
	HA63 235,41 71B6	Unit: HA63 \| Ratio i: 235.41 \| Motor: 71B6 \| Power P1: 0.25 kW \| Output speed n2: 3.8 rpm \| Output torque M2: 593 Nm
	HA51 7,88 63C2	Unit: HA51 \| Ratio i: 7.88 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 354.3 rpm \| Output torque M2: 9 Nm
	HA51 7,88 71A2	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 354.3 rpm \| Output torque M2: 9 Nm
	HA51 2,94 71C6	Unit: HA51 \| Ratio i: 2.94 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 298.9 rpm \| Output torque M2: 12 Nm
	HA51 2,94 80A6	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 298.9 rpm \| Output torque M2: 12 Nm
	HA51 10,83 63C2	Unit: HA51 \| Ratio i: 10.83 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 257.5 rpm \| Output torque M2: 13 Nm
	HA51 10,83 71A2	Unit: HA51 \| Ratio i: 10.83 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 257.5 rpm \| Output torque M2: 13 Nm
	HA51 5,45 71B4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 253.0 rpm \| Output torque M2: 14 Nm
	HA51 4,75 71C6	Unit: HA51 \| Ratio i: 4.75 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 185.3 rpm \| Output torque M2: 19 Nm
	HA51 4,75 80A6	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 185.3 rpm \| Output torque M2: 19 Nm
	HA51 7,88 71B4	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 175.2 rpm \| Output torque M2: 20 Nm
	HA51 5,45 71C6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 161.3 rpm \| Output torque M2: 21 Nm
	HA51 5,45 80A6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 161.3 rpm \| Output torque M2: 21 Nm
	HA51 10,83 71B4	Unit: HA51 \| Ratio i: 10.83 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 127.4 rpm \| Output torque M2: 27 Nm
	HA61 7,75 80A6	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 121.3 rpm \| Output torque M2: 29 Nm
	HA51 7,88 71C6	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71C6 \| Power P1: 0.37 kW \| Output speed n2: 111.7 rpm \| Output torque M2: 31 Nm
	HA61 10,67 80A6	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 88.1 rpm \| Output torque M2: 39 Nm
	HA53 49,80 63C2	Unit: HA53 \| Ratio i: 49.80 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 56.0 rpm \| Output torque M2: 57 Nm
	HA53 49,80 71A2	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 56.0 rpm \| Output torque M2: 57 Nm
	HA53 60,25 63C2	Unit: HA53 \| Ratio i: 60.25 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 46.3 rpm \| Output torque M2: 69 Nm
	HA53 60,25 71A2	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 46.3 rpm \| Output torque M2: 69 Nm
	HA53 74,88 63C2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 37.3 rpm \| Output torque M2: 86 Nm
	HA53 74,88 71A2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 37.3 rpm \| Output torque M2: 86 Nm
	HA52 25,43 80A6	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 37.0 rpm \| Output torque M2: 93 Nm
	HA53 88,02 63C2	Unit: HA53 \| Ratio i: 88.02 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
	HA53 88,02 71A2	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
	HA63 88,02 63C2	Unit: HA63 \| Ratio i: 88.02 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
	HA63 88,02 71A2	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 31.7 rpm \| Output torque M2: 101 Nm
	HA52 29,89 80A6	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 31.4 rpm \| Output torque M2: 109 Nm
	HA53 49,80 71B4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 27.7 rpm \| Output torque M2: 120 Nm
	HA52 36,17 80A6	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 26.0 rpm \| Output torque M2: 132 Nm
	HA62 36,17 80A6	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 26.0 rpm \| Output torque M2: 132 Nm
	HA53 111,61 63C2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
	HA53 111,61 71A2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
	HA63 111,61 63C2	Unit: HA63 \| Ratio i: 111.61 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
	HA63 111,61 71A2	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 25.0 rpm \| Output torque M2: 128 Nm
	HA53 60,25 71B4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 22.9 rpm \| Output torque M2: 145 Nm
	HA63 60,25 71B4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 22.9 rpm \| Output torque M2: 145 Nm
	HA52 44,95 80A6	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 20.9 rpm \| Output torque M2: 164 Nm
	HA62 44,95 80A6	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80A6 \| Power P1: 0.37 kW \| Output speed n2: 20.9 rpm \| Output torque M2: 164 Nm
	HA53 138,71 63C2	Unit: HA53 \| Ratio i: 138.71 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
	HA53 138,71 71A2	Unit: HA53 \| Ratio i: 138.71 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
	HA63 138,71 63C2	Unit: HA63 \| Ratio i: 138.71 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
	HA63 138,71 71A2	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 20.1 rpm \| Output torque M2: 159 Nm
	HA53 74,88 71B4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 18.4 rpm \| Output torque M2: 180 Nm
	HA63 74,88 71B4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 18.4 rpm \| Output torque M2: 180 Nm
	HA53 49,80 71C6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
	HA53 49,80 80A6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
	HA63 49,80 71C6	Unit: HA63 \| Ratio i: 49.80 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
	HA63 49,80 80A6	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 17.7 rpm \| Output torque M2: 190 Nm
	HA53 163,05 63C2	Unit: HA53 \| Ratio i: 163.05 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
	HA53 163,05 71A2	Unit: HA53 \| Ratio i: 163.05 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
	HA63 163,05 63C2	Unit: HA63 \| Ratio i: 163.05 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
	HA63 163,05 71A2	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 17.1 rpm \| Output torque M2: 187 Nm
	HA53 88,02 71B4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 15.7 rpm \| Output torque M2: 212 Nm
	HA63 88,02 71B4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 15.7 rpm \| Output torque M2: 212 Nm
	HA53 60,25 71C6	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
	HA53 60,25 80A6	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
	HA63 60,25 71C6	Unit: HA63 \| Ratio i: 60.25 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
	HA63 60,25 80A6	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 14.6 rpm \| Output torque M2: 230 Nm
	HA63 200,27 63C2	Unit: HA63 \| Ratio i: 200.27 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 13.9 rpm \| Output torque M2: 230 Nm
	HA63 200,27 71A2	Unit: HA63 \| Ratio i: 200.27 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 13.9 rpm \| Output torque M2: 230 Nm
	HA53 111,61 71B4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 12.4 rpm \| Output torque M2: 269 Nm
	HA63 111,61 71B4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 12.4 rpm \| Output torque M2: 269 Nm
	HA63 235,41 63C2	Unit: HA63 \| Ratio i: 235.41 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 270 Nm
	HA63 235,41 71A2	Unit: HA63 \| Ratio i: 235.41 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 270 Nm
	HA53 74,88 71C6	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
	HA53 74,88 80A6	Unit: HA53 \| Ratio i: 74.88 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
	HA63 74,88 71C6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
	HA63 74,88 80A6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 11.8 rpm \| Output torque M2: 285 Nm
	HA53 88,02 71C6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
	HA53 88,02 80A6	Unit: HA53 \| Ratio i: 88.02 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
	HA63 88,02 71C6	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
	HA63 88,02 80A6	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 10.0 rpm \| Output torque M2: 336 Nm
	HA53 138,71 71B4	Unit: HA53 \| Ratio i: 138.71 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 334 Nm
	HA63 138,71 71B4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 334 Nm
	HA63 284,81 63C2	Unit: HA63 \| Ratio i: 284.81 \| Motor: 63C2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 327 Nm
	HA63 284,81 71A2	Unit: HA63 \| Ratio i: 284.81 \| Motor: 71A2 (frame printed 63C/71A) \| Power P1: 0.37 kW \| Output speed n2: 9.8 rpm \| Output torque M2: 327 Nm
	HA53 163,05 71B4	Unit: HA53 \| Ratio i: 163.05 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 8.5 rpm \| Output torque M2: 392 Nm
	HA63 163,05 71B4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 8.5 rpm \| Output torque M2: 392 Nm
	HA53 111,61 71C6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
	HA53 111,61 80A6	Unit: HA53 \| Ratio i: 111.61 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
	HA63 111,61 71C6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
	HA63 111,61 80A6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 7.9 rpm \| Output torque M2: 425 Nm
	HA63 200,27 71B4	Unit: HA63 \| Ratio i: 200.27 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 6.9 rpm \| Output torque M2: 482 Nm
	HA63 138,71 71C6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 6.3 rpm \| Output torque M2: 529 Nm
	HA63 138,71 80A6	Unit: HA63 \| Ratio i: 138.71 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 6.3 rpm \| Output torque M2: 529 Nm
	HA63 235,41 71B4	Unit: HA63 \| Ratio i: 235.41 \| Motor: 71B4 \| Power P1: 0.37 kW \| Output speed n2: 5.9 rpm \| Output torque M2: 567 Nm
	HA63 163,05 71C6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71C6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 5.4 rpm \| Output torque M2: 622 Nm
	HA63 163,05 80A6	Unit: HA63 \| Ratio i: 163.05 \| Motor: 80A6 (frame printed 71C/80A) \| Power P1: 0.37 kW \| Output speed n2: 5.4 rpm \| Output torque M2: 622 Nm
	HA51 5,45 71B2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 515.2 rpm \| Output torque M2: 10 Nm
	HA51 2,94 71C4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 465.3 rpm \| Output torque M2: 11 Nm
	HA51 2,94 80A4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 465.3 rpm \| Output torque M2: 11 Nm
	HA51 7,88 71B2	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 356.8 rpm \| Output torque M2: 14 Nm
	HA51 2,94 80B6	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 315.8 rpm \| Output torque M2: 16 Nm
	HA51 4,75 71C4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 288.4 rpm \| Output torque M2: 18 Nm
	HA51 4,75 80A4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 288.4 rpm \| Output torque M2: 18 Nm
	HA51 5,45 71C4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 251.2 rpm \| Output torque M2: 20 Nm
	HA51 5,45 80A4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 251.2 rpm \| Output torque M2: 20 Nm
	HA51 4,75 80B6	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 195.8 rpm \| Output torque M2: 26 Nm
	HA61 7,75 80A4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 28 Nm
	HA51 7,88 71C4	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71C4 \| Power P1: 0.55 kW \| Output speed n2: 174.0 rpm \| Output torque M2: 29 Nm
	HA51 5,45 80B6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 170.5 rpm \| Output torque M2: 30 Nm
	HA61 10,67 80A4	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 39 Nm
	HA61 7,75 80B6	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 43 Nm
	HA61 10,67 80B6	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 87.2 rpm \| Output torque M2: 59 Nm
	HA52 20,46 80A4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 74 Nm
	HA52 14,50 80B6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 79 Nm
	HA53 49,80 71B2	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 56.4 rpm \| Output torque M2: 84 Nm
	HA52 25,43 80A4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 92 Nm
	HA52 16,91 80B6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 93 Nm
	HA52 29,89 80A4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 108 Nm
	HA53 60,25 71B2	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 102 Nm
	HA63 60,25 71B2	Unit: HA63 \| Ratio i: 60.25 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 102 Nm
	HA52 20,46 80B6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 112 Nm
	HA52 36,17 80A4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 130 Nm
	HA62 36,17 80A4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 130 Nm
	HA53 74,88 71B2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 127 Nm
	HA63 74,88 71B2	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 127 Nm
	HA52 25,43 80B6	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 139 Nm
	HA62 25,43 80B6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 139 Nm
	HA53 88,02 71B2	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 31.9 rpm \| Output torque M2: 149 Nm
	HA63 88,02 71B2	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 31.9 rpm \| Output torque M2: 149 Nm
	HA52 29,89 80B6	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 164 Nm
	HA52 44,95 80A4	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 162 Nm
	HA62 29,89 80B6	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 164 Nm
	HA62 44,95 80A4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80A4 \| Power P1: 0.55 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 162 Nm
	HA53 49,80 71C4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
	HA53 49,80 80A4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
	HA63 49,80 71C4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
	HA63 49,80 80A4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 27.5 rpm \| Output torque M2: 179 Nm
	HA52 36,17 80B6	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 25.7 rpm \| Output torque M2: 198 Nm
	HA62 36,17 80B6	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 25.7 rpm \| Output torque M2: 198 Nm
	HA53 111,61 71B2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 25.2 rpm \| Output torque M2: 189 Nm
	HA63 111,61 71B2	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 25.2 rpm \| Output torque M2: 189 Nm
	HA53 60,25 71C4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
	HA53 60,25 80A4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
	HA63 60,25 71C4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
	HA63 60,25 80A4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 22.7 rpm \| Output torque M2: 217 Nm
	HA52 44,95 80B6	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 20.7 rpm \| Output torque M2: 246 Nm
	HA62 44,95 80B6	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 20.7 rpm \| Output torque M2: 246 Nm
	HA63 138,71 71B2	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 20.3 rpm \| Output torque M2: 235 Nm
	HA53 49,80 80B6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 267 Nm
	HA63 49,80 80B6	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 267 Nm
	HA53 74,88 71C4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
	HA53 74,88 80A4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
	HA63 74,88 71C4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
	HA63 74,88 80A4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 18.3 rpm \| Output torque M2: 270 Nm
	HA53 163,05 71B2	Unit: HA53 \| Ratio i: 163.05 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 276 Nm
	HA63 163,05 71B2	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 17.2 rpm \| Output torque M2: 276 Nm
	HA53 88,02 71C4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
	HA53 88,02 80A4	Unit: HA53 \| Ratio i: 88.02 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
	HA63 88,02 71C4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
	HA63 88,02 80A4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 15.6 rpm \| Output torque M2: 317 Nm
	HA53 60,25 80B6	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 15.4 rpm \| Output torque M2: 323 Nm
	HA63 60,25 80B6	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 15.4 rpm \| Output torque M2: 323 Nm
	HA63 200,27 71B2	Unit: HA63 \| Ratio i: 200.27 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 14.0 rpm \| Output torque M2: 340 Nm
	HA63 74,88 80B6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 12.4 rpm \| Output torque M2: 402 Nm
	HA53 111,61 71C4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
	HA53 111,61 80A4	Unit: HA53 \| Ratio i: 111.61 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
	HA63 111,61 71C4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
	HA63 111,61 80A4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 402 Nm
	HA63 235,41 71B2	Unit: HA63 \| Ratio i: 235.41 \| Motor: 71B2 \| Power P1: 0.55 kW \| Output speed n2: 11.9 rpm \| Output torque M2: 399 Nm
	HA63 88,02 80B6	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 10.6 rpm \| Output torque M2: 472 Nm
	HA63 138,71 71C4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 500 Nm
	HA63 138,71 80A4	Unit: HA63 \| Ratio i: 138.71 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 9.9 rpm \| Output torque M2: 500 Nm
	HA63 163,05 71C4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 71C4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 8.4 rpm \| Output torque M2: 588 Nm
	HA63 163,05 80A4	Unit: HA63 \| Ratio i: 163.05 \| Motor: 80A4 (frame printed 71C/80A) \| Power P1: 0.55 kW \| Output speed n2: 8.4 rpm \| Output torque M2: 588 Nm
	HA63 111,61 80B6	Unit: HA63 \| Ratio i: 111.61 \| Motor: 80B6 \| Power P1: 0.55 kW \| Output speed n2: 8.3 rpm \| Output torque M2: 598 Nm
	HA51 1,45 80C6	Unit: HA51 \| Ratio i: 1.45 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 635.2 rpm \| Output torque M2: 11 Nm
	HA51 1,45 90S6	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 635.2 rpm \| Output torque M2: 11 Nm
	HA51 4,75 71C2	Unit: HA51 \| Ratio i: 4.75 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 589.5 rpm \| Output torque M2: 11 Nm
	HA51 4,75 80A2	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 589.5 rpm \| Output torque M2: 11 Nm
	HA51 5,45 71C2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 513.3 rpm \| Output torque M2: 13 Nm
	HA51 5,45 80A2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 513.3 rpm \| Output torque M2: 13 Nm
	HA51 2,94 80B4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 475.5 rpm \| Output torque M2: 15 Nm
	HA61 7,75 80A2	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 366.5 rpm \| Output torque M2: 18 Nm
	HA51 7,88 71C2	Unit: HA51 \| Ratio i: 7.88 \| Motor: 71C2 (brake TBS only) \| Power P1: 0.75 kW \| Output speed n2: 355.6 rpm \| Output torque M2: 19 Nm
	HA51 2,94 80C6	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 312.5 rpm \| Output torque M2: 22 Nm
	HA51 2,94 90S6	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 312.5 rpm \| Output torque M2: 22 Nm
	HA51 4,75 80B4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 24 Nm
	HA61 10,67 80A2	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 266.3 rpm \| Output torque M2: 25 Nm
	HA51 5,45 80B4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 262.2 rpm \| Output torque M2: 27 Nm
	HA61 4,38 80C6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 209.8 rpm \| Output torque M2: 33 Nm
	HA61 4,38 90S6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 209.8 rpm \| Output torque M2: 33 Nm
	HA51 4,75 80C6	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 193.7 rpm \| Output torque M2: 36 Nm
	HA51 4,75 90S6	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 193.7 rpm \| Output torque M2: 36 Nm
	HA61 7,75 80B4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 184.5 rpm \| Output torque M2: 38 Nm
	HA51 5,45 80C6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 168.7 rpm \| Output torque M2: 42 Nm
	HA51 5,45 90S6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 168.7 rpm \| Output torque M2: 42 Nm
	HA61 10,67 80B4	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 53 Nm
	HA61 7,75 80C6	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 118.7 rpm \| Output torque M2: 59 Nm
	HA61 7,75 90S6	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 118.7 rpm \| Output torque M2: 59 Nm
	HA52 25,43 80A2	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 60 Nm
	HA52 14,50 80B4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 80B4 (brake TBS only) \| Power P1: 0.75 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 71 Nm
	HA52 29,89 80A2	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 71 Nm
	HA61 10,67 80C6	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 86.3 rpm \| Output torque M2: 81 Nm
	HA61 10,67 90S6	Unit: HA61 \| Ratio i: 10.67 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 86.3 rpm \| Output torque M2: 81 Nm
	HA52 16,91 80B4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 83 Nm
	HA52 11,67 80C6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 78.9 rpm \| Output torque M2: 88 Nm
	HA52 11,67 90S6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 78.9 rpm \| Output torque M2: 88 Nm
	HA52 36,17 80A2	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 85 Nm
	HA52 20,46 80B4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 100 Nm
	HA52 14,50 80C6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 63.4 rpm \| Output torque M2: 109 Nm
	HA52 14,50 90S6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 63.4 rpm \| Output torque M2: 109 Nm
	HA52 44,95 80A2	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 106 Nm
	HA62 44,95 80A2	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80A2 \| Power P1: 0.75 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 106 Nm
	HA53 49,80 71C2	Unit: HA53 \| Ratio i: 49.80 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
	HA53 49,80 80A2	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
	HA63 49,80 71C2	Unit: HA63 \| Ratio i: 49.80 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
	HA63 49,80 80A2	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 56.2 rpm \| Output torque M2: 116 Nm
	HA52 25,43 80B4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 125 Nm
	HA62 25,43 80B4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 125 Nm
	HA52 16,91 80C6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 54.4 rpm \| Output torque M2: 128 Nm
	HA52 16,91 90S6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 54.4 rpm \| Output torque M2: 128 Nm
	HA52 29,89 80B4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 147 Nm
	HA62 29,89 80B4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 147 Nm
	HA53 60,25 71C2	Unit: HA53 \| Ratio i: 60.25 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
	HA53 60,25 80A2	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
	HA63 60,25 71C2	Unit: HA63 \| Ratio i: 60.25 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
	HA63 60,25 80A2	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 46.5 rpm \| Output torque M2: 140 Nm
	HA52 20,46 80C6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
	HA52 20,46 90S6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
	HA62 20,46 80C6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
	HA62 20,46 90S6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 45.0 rpm \| Output torque M2: 154 Nm
	HA52 36,17 80B4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 178 Nm
	HA62 36,17 80B4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 178 Nm
	HA53 74,88 71C2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
	HA53 74,88 80A2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
	HA63 74,88 71C2	Unit: HA63 \| Ratio i: 74.88 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
	HA63 74,88 80A2	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 37.4 rpm \| Output torque M2: 174 Nm
	HA52 25,43 80C6	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
	HA52 25,43 90S6	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
	HA62 25,43 80C6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
	HA62 25,43 90S6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 36.2 rpm \| Output torque M2: 192 Nm
	HA53 88,02 71C2	Unit: HA53 \| Ratio i: 88.02 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
	HA53 88,02 80A2	Unit: HA53 \| Ratio i: 88.02 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
	HA63 88,02 71C2	Unit: HA63 \| Ratio i: 88.02 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
	HA63 88,02 80A2	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 31.8 rpm \| Output torque M2: 204 Nm
	HA52 44,95 80B4	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 221 Nm
	HA62 44,95 80B4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 221 Nm
	HA52 29,89 80C6	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
	HA52 29,89 90S6	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
	HA62 29,89 80C6	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
	HA62 29,89 90S6	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 30.8 rpm \| Output torque M2: 226 Nm
	HA53 49,80 80B4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 239 Nm
	HA63 49,80 80B4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 239 Nm
	HA52 36,17 80C6	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
	HA52 36,17 90S6	Unit: HA52 \| Ratio i: 36.17 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
	HA62 36,17 80C6	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
	HA62 36,17 90S6	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 25.4 rpm \| Output torque M2: 273 Nm
	HA53 111,61 71C2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
	HA53 111,61 80A2	Unit: HA53 \| Ratio i: 111.61 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
	HA63 111,61 71C2	Unit: HA63 \| Ratio i: 111.61 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
	HA63 111,61 80A2	Unit: HA63 \| Ratio i: 111.61 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 25.1 rpm \| Output torque M2: 259 Nm
	HA53 60,25 80B4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 290 Nm
	HA63 60,25 80B4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 290 Nm
	HA52 44,95 80C6	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
	HA52 44,95 90S6	Unit: HA52 \| Ratio i: 44.95 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
	HA62 44,95 80C6	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
	HA62 44,95 90S6	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 20.5 rpm \| Output torque M2: 339 Nm
	HA63 138,71 71C2	Unit: HA63 \| Ratio i: 138.71 \| Motor: 71C2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 322 Nm
	HA63 138,71 80A2	Unit: HA63 \| Ratio i: 138.71 \| Motor: 80A2 (frame printed 71C/80A) \| Power P1: 0.75 kW \| Output speed n2: 20.2 rpm \| Output torque M2: 322 Nm
	HA53 74,88 80B4	Unit: HA53 \| Ratio i: 74.88 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 360 Nm
	HA63 74,88 80B4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 360 Nm
	HA53 49,80 80C6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
	HA53 49,80 90S6	Unit: HA53 \| Ratio i: 49.80 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
	HA63 49,80 80C6	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
	HA63 49,80 90S6	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 18.5 rpm \| Output torque M2: 368 Nm
	HA63 88,02 80B4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 15.9 rpm \| Output torque M2: 423 Nm
	HA63 60,25 80C6	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 15.3 rpm \| Output torque M2: 445 Nm
	HA63 60,25 90S6	Unit: HA63 \| Ratio i: 60.25 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 15.3 rpm \| Output torque M2: 445 Nm
	HA63 111,61 80B4	Unit: HA63 \| Ratio i: 111.61 \| Motor: 80B4 \| Power P1: 0.75 kW \| Output speed n2: 12.5 rpm \| Output torque M2: 537 Nm
	HA63 74,88 80C6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80C6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 553 Nm
	HA63 74,88 90S6	Unit: HA63 \| Ratio i: 74.88 \| Motor: 90S6 (frame printed 80C/90S) \| Power P1: 0.75 kW \| Output speed n2: 12.3 rpm \| Output torque M2: 553 Nm
	HA51 2,94 80C4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 475.5 rpm \| Output torque M2: 18 Nm
	HA51 4,75 80C4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 29 Nm
	HA51 5,45 80C4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 33 Nm
	HA61 7,75 80C4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 47 Nm
	HA61 10,67 80C4	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 65 Nm
	HA52 11,67 80C4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 70 Nm
	HA52 14,50 80C4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 87 Nm
	HA52 16,91 80C4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 102 Nm
	HA52 20,46 80C4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 123 Nm
	HA62 20,46 80C4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 123 Nm
	HA52 25,43 80C4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 153 Nm
	HA62 25,43 80C4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 153 Nm
	HA52 29,89 80C4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 180 Nm
	HA62 29,89 80C4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 180 Nm
	HA52 36,17 80C4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 218 Nm
	HA62 36,17 80C4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 218 Nm
	HA52 44,95 80C4	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 271 Nm
	HA62 44,95 80C4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 271 Nm
	HA53 49,80 80C4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 294 Nm
	HA63 49,80 80C4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 294 Nm
	HA53 60,25 80C4	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 355 Nm
	HA63 60,25 80C4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 355 Nm
	HA63 74,88 80C4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 442 Nm
	HA63 88,02 80C4	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80C4 (brake TBS only) \| Power P1: 0.92 kW \| Output speed n2: 15.9 rpm \| Output torque M2: 519 Nm
	HA51 1,45 80D4	Unit: HA51 \| Ratio i: 1.45 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 966.7 rpm \| Output torque M2: 11 Nm
	HA51 1,45 90S4	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 966.7 rpm \| Output torque M2: 11 Nm
	HA51 2,94 80B2	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 964.5 rpm \| Output torque M2: 10 Nm
	HA51 1,45 90L6	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 649.0 rpm \| Output torque M2: 16 Nm
	HA51 4,75 80B2	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 595.8 rpm \| Output torque M2: 17 Nm
	HA51 5,45 80B2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 520.7 rpm \| Output torque M2: 19 Nm
	HA51 2,94 80D4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 478.9 rpm \| Output torque M2: 21 Nm
	HA51 2,94 90S4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 478.9 rpm \| Output torque M2: 21 Nm
	HA61 2,50 90L6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 28 Nm
	HA61 2,50 100LR6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 28 Nm
	HA61 7,75 80B2	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 366.5 rpm \| Output torque M2: 27 Nm
	HA61 4,38 80D4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 321.6 rpm \| Output torque M2: 32 Nm
	HA61 4,38 90S4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 321.6 rpm \| Output torque M2: 32 Nm
	HA51 2,94 90L6	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 315.8 rpm \| Output torque M2: 33 Nm
	HA51 4,75 80D4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 35 Nm
	HA51 4,75 90S4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 35 Nm
	HA61 10,67 80B2	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 266.3 rpm \| Output torque M2: 37 Nm
	HA51 5,45 80D4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 40 Nm
	HA51 5,45 90S4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 40 Nm
	HA61 4,38 90L6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 49 Nm
	HA61 4,38 100LR6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 49 Nm
	HA51 4,75 90L6	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 195.8 rpm \| Output torque M2: 53 Nm
	HA61 7,75 80D4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 181.9 rpm \| Output torque M2: 56 Nm
	HA61 7,75 90S4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 181.9 rpm \| Output torque M2: 56 Nm
	HA51 5,45 90L6	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 172.3 rpm \| Output torque M2: 60 Nm
	HA52 16,91 80B2	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 167.9 rpm \| Output torque M2: 58 Nm
	HA52 6,22 90L6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 68 Nm
	HA52 6,22 100LR6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 68 Nm
	HA52 20,46 80B2	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 138.8 rpm \| Output torque M2: 70 Nm
	HA61 10,67 80D4	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 78 Nm
	HA61 10,67 90S4	Unit: HA61 \| Ratio i: 10.67 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 131.3 rpm \| Output torque M2: 78 Nm
	HA52 7,73 90L6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 85 Nm
	HA52 7,73 100LR6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 85 Nm
	HA52 11,67 80D4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 84 Nm
	HA52 11,67 90S4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 84 Nm
	HA61 7,75 90L6	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 86 Nm
	HA52 25,43 80B2	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 111.7 rpm \| Output torque M2: 87 Nm
	HA62 25,43 80B2	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 111.7 rpm \| Output torque M2: 87 Nm
	HA52 14,50 80D4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 97.2 rpm \| Output torque M2: 104 Nm
	HA52 14,50 90S4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 97.2 rpm \| Output torque M2: 104 Nm
	HA52 9,64 90L6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 106 Nm
	HA52 9,64 100LR6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 106 Nm
	HA52 29,89 80B2	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 94.7 rpm \| Output torque M2: 103 Nm
	HA62 29,89 80B2	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 94.7 rpm \| Output torque M2: 103 Nm
	HA52 16,91 80D4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 122 Nm
	HA52 16,91 90S4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 122 Nm
	HA52 11,67 90L6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
	HA52 11,67 100LR6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
	HA62 11,67 90L6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
	HA62 11,67 100LR6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 128 Nm
	HA52 36,17 80B2	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 78.5 rpm \| Output torque M2: 124 Nm
	HA62 36,17 80B2	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 78.5 rpm \| Output torque M2: 124 Nm
	HA52 20,46 80D4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
	HA52 20,46 90S4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
	HA62 20,46 80D4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
	HA62 20,46 90S4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 147 Nm
	HA52 14,50 90L6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
	HA52 14,50 100LR6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
	HA62 14,50 90L6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
	HA62 14,50 100LR6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 159 Nm
	HA52 44,95 80B2	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 63.0 rpm \| Output torque M2: 155 Nm
	HA62 44,95 80B2	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 63.0 rpm \| Output torque M2: 155 Nm
	HA53 49,80 80B2	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 56.8 rpm \| Output torque M2: 168 Nm
	HA63 49,80 80B2	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 56.8 rpm \| Output torque M2: 168 Nm
	HA52 25,43 80D4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
	HA52 25,43 90S4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
	HA62 25,43 80D4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
	HA62 25,43 90S4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 183 Nm
	HA52 16,91 90L6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
	HA52 16,91 100LR6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
	HA62 16,91 90L6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
	HA62 16,91 100LR6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 185 Nm
	HA53 60,25 80B2	Unit: HA53 \| Ratio i: 60.25 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 47.0 rpm \| Output torque M2: 203 Nm
	HA63 60,25 80B2	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 47.0 rpm \| Output torque M2: 203 Nm
	HA52 29,89 80D4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
	HA52 29,89 90S4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
	HA62 29,89 80D4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
	HA62 29,89 90S4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 215 Nm
	HA52 20,46 90L6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
	HA52 20,46 100LR6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
	HA62 20,46 90L6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
	HA62 20,46 100LR6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 224 Nm
	HA52 36,17 80D4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
	HA52 36,17 90S4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
	HA62 36,17 80D4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
	HA62 36,17 90S4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 261 Nm
	HA53 74,88 80B2	Unit: HA53 \| Ratio i: 74.88 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 37.8 rpm \| Output torque M2: 252 Nm
	HA63 74,88 80B2	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 37.8 rpm \| Output torque M2: 252 Nm
	HA52 25,43 90L6	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
	HA52 25,43 100LR6	Unit: HA52 \| Ratio i: 25.43 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
	HA62 25,43 90L6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90L6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
	HA62 25,43 100LR6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LR6 (frame printed 90L/100LR) \| Power P1: 1.10 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 279 Nm
	HA63 88,02 80B2	Unit: HA63 \| Ratio i: 88.02 \| Motor: 80B2 \| Power P1: 1.10 kW \| Output speed n2: 32.2 rpm \| Output torque M2: 296 Nm
	HA52 29,89 90L6	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 327 Nm
	HA52 44,95 80D4	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
	HA52 44,95 90S4	Unit: HA52 \| Ratio i: 44.95 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
	HA62 29,89 90L6	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 327 Nm
	HA62 44,95 80D4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
	HA62 44,95 90S4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 324 Nm
	HA53 49,80 80D4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
	HA53 49,80 90S4	Unit: HA53 \| Ratio i: 49.80 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
	HA63 49,80 80D4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
	HA63 49,80 90S4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 351 Nm
	HA52 36,17 90L6	Unit: HA52 \| Ratio i: 36.17 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 26.0 rpm \| Output torque M2: 392 Nm
	HA62 36,17 90L6	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 25.7 rpm \| Output torque M2: 396 Nm
	HA63 60,25 80D4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 425 Nm
	HA63 60,25 90S4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 425 Nm
	HA62 44,95 90L6	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 20.7 rpm \| Output torque M2: 492 Nm
	HA63 49,80 90L6	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90L6 \| Power P1: 1.10 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 534 Nm
	HA63 74,88 80D4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80D4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 528 Nm
	HA63 74,88 90S4	Unit: HA63 \| Ratio i: 74.88 \| Motor: 90S4 (frame printed 80D/90S) \| Power P1: 1.10 kW \| Output speed n2: 18.7 rpm \| Output torque M2: 528 Nm
	HA51 1,45 90L4	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 980.5 rpm \| Output torque M2: 14 Nm
	HA51 1,45 90LA4	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 980.5 rpm \| Output torque M2: 14 Nm
	HA51 2,94 80C2	Unit: HA51 \| Ratio i: 2.94 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 954.3 rpm \| Output torque M2: 14 Nm
	HA51 2,94 90S2	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 954.3 rpm \| Output torque M2: 14 Nm
	HA61 4,38 80C2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 640.9 rpm \| Output torque M2: 21 Nm
	HA61 4,38 90S2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 640.9 rpm \| Output torque M2: 21 Nm
	HA51 4,75 80C2	Unit: HA51 \| Ratio i: 4.75 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 591.6 rpm \| Output torque M2: 23 Nm
	HA51 4,75 90S2	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 591.6 rpm \| Output torque M2: 23 Nm
	HA61 2,50 90L4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 560.0 rpm \| Output torque M2: 25 Nm
	HA61 2,50 90LA4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 560.0 rpm \| Output torque M2: 25 Nm
	HA51 5,45 80C2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 515.2 rpm \| Output torque M2: 26 Nm
	HA51 5,45 90S2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 515.2 rpm \| Output torque M2: 26 Nm
	HA51 2,94 90L4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 482.3 rpm \| Output torque M2: 29 Nm
	HA51 2,94 90LA4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 482.3 rpm \| Output torque M2: 29 Nm
	HA61 2,50 100L6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 38 Nm
	HA61 2,50 100LA6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 38 Nm
	HA61 7,75 80C2	Unit: HA61 \| Ratio i: 7.75 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 362.6 rpm \| Output torque M2: 37 Nm
	HA61 7,75 90S2	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 362.6 rpm \| Output torque M2: 37 Nm
	HA61 4,38 90L4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 319.3 rpm \| Output torque M2: 44 Nm
	HA61 4,38 90LA4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 319.3 rpm \| Output torque M2: 44 Nm
	HA51 4,75 90L4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 47 Nm
	HA51 4,75 90LA4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 47 Nm
	HA61 10,67 80C2	Unit: HA61 \| Ratio i: 10.67 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 263.4 rpm \| Output torque M2: 51 Nm
	HA61 10,67 90S2	Unit: HA61 \| Ratio i: 10.67 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 263.4 rpm \| Output torque M2: 51 Nm
	HA51 5,45 90L4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 54 Nm
	HA51 5,45 90LA4	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 256.7 rpm \| Output torque M2: 54 Nm
	HA52 11,67 80C2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 240.9 rpm \| Output torque M2: 55 Nm
	HA52 11,67 90S2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 240.9 rpm \| Output torque M2: 55 Nm
	HA52 6,22 90L4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 225.0 rpm \| Output torque M2: 61 Nm
	HA52 6,22 90LA4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 225.0 rpm \| Output torque M2: 61 Nm
	HA61 4,38 100L6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 66 Nm
	HA61 4,38 100LA6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 66 Nm
	HA52 14,50 80C2	Unit: HA52 \| Ratio i: 14.50 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 193.8 rpm \| Output torque M2: 68 Nm
	HA52 14,50 90S2	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 193.8 rpm \| Output torque M2: 68 Nm
	HA52 7,73 90L4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 181.0 rpm \| Output torque M2: 76 Nm
	HA52 7,73 90LA4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 181.0 rpm \| Output torque M2: 76 Nm
	HA52 5,14 100L6	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 77 Nm
	HA52 5,14 100LA6	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 77 Nm
	HA61 7,75 90L4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 77 Nm
	HA61 7,75 90LA4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 77 Nm
	HA52 16,91 80C2	Unit: HA52 \| Ratio i: 16.91 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 166.2 rpm \| Output torque M2: 80 Nm
	HA52 16,91 90S2	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 166.2 rpm \| Output torque M2: 80 Nm
	HA52 6,22 100L6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 93 Nm
	HA52 6,22 100LA6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 93 Nm
	HA52 9,64 90L4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 95 Nm
	HA52 9,64 90LA4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 95 Nm
	HA52 20,46 80C2	Unit: HA52 \| Ratio i: 20.46 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
	HA52 20,46 90S2	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
	HA62 20,46 80C2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
	HA62 20,46 90S2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 137.3 rpm \| Output torque M2: 97 Nm
	HA52 7,73 100L6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
	HA52 7,73 100LA6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
	HA62 7,73 100L6	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
	HA62 7,73 100LA6	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 115 Nm
	HA52 11,67 90L4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
	HA52 11,67 90LA4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
	HA62 11,67 90L4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
	HA62 11,67 90LA4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 115 Nm
	HA52 25,43 80C2	Unit: HA52 \| Ratio i: 25.43 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
	HA52 25,43 90S2	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
	HA62 25,43 80C2	Unit: HA62 \| Ratio i: 25.43 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
	HA62 25,43 90S2	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 110.5 rpm \| Output torque M2: 120 Nm
	HA52 14,50 90L4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
	HA52 14,50 90LA4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
	HA62 14,50 90L4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
	HA62 14,50 90LA4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 142 Nm
	HA52 9,64 100L6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
	HA52 9,64 100LA6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
	HA62 9,64 100L6	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
	HA62 9,64 100LA6	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 144 Nm
	HA52 29,89 80C2	Unit: HA52 \| Ratio i: 29.89 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
	HA52 29,89 90S2	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
	HA62 29,89 80C2	Unit: HA62 \| Ratio i: 29.89 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
	HA62 29,89 90S2	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 94.0 rpm \| Output torque M2: 141 Nm
	HA52 16,91 90L4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
	HA52 16,91 90LA4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
	HA62 16,91 90L4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
	HA62 16,91 90LA4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 166 Nm
	HA52 11,67 100L6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
	HA52 11,67 100LA6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
	HA62 11,67 100L6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
	HA62 11,67 100LA6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 174 Nm
	HA52 36,17 80C2	Unit: HA52 \| Ratio i: 36.17 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
	HA52 36,17 90S2	Unit: HA52 \| Ratio i: 36.17 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
	HA62 36,17 80C2	Unit: HA62 \| Ratio i: 36.17 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
	HA62 36,17 90S2	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 77.7 rpm \| Output torque M2: 171 Nm
	HA52 20,46 90L4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
	HA52 20,46 90LA4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
	HA62 20,46 90L4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
	HA62 20,46 90LA4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 201 Nm
	HA52 14,50 100L6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
	HA52 14,50 100LA6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
	HA62 14,50 100L6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
	HA62 14,50 100LA6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 217 Nm
	HA52 44,95 80C2	Unit: HA52 \| Ratio i: 44.95 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
	HA52 44,95 90S2	Unit: HA52 \| Ratio i: 44.95 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
	HA62 44,95 80C2	Unit: HA62 \| Ratio i: 44.95 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
	HA62 44,95 90S2	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 62.5 rpm \| Output torque M2: 212 Nm
	HA63 49,80 80C2	Unit: HA63 \| Ratio i: 49.80 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 56.4 rpm \| Output torque M2: 230 Nm
	HA63 49,80 90S2	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 56.4 rpm \| Output torque M2: 230 Nm
	HA52 25,43 90L4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
	HA52 25,43 90LA4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
	HA62 25,43 90L4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
	HA62 25,43 90LA4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 250 Nm
	HA52 16,91 100L6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
	HA52 16,91 100LA6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
	HA62 16,91 100L6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
	HA62 16,91 100LA6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 253 Nm
	HA52 29,89 90L4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
	HA52 29,89 90LA4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
	HA62 29,89 90L4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
	HA62 29,89 90LA4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 294 Nm
	HA63 60,25 80C2	Unit: HA63 \| Ratio i: 60.25 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 279 Nm
	HA63 60,25 90S2	Unit: HA63 \| Ratio i: 60.25 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 46.6 rpm \| Output torque M2: 279 Nm
	HA52 20,46 100L6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
	HA52 20,46 100LA6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
	HA62 20,46 100L6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
	HA62 20,46 100LA6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 306 Nm
	HA52 36,17 90L4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
	HA52 36,17 90LA4	Unit: HA52 \| Ratio i: 36.17 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
	HA62 36,17 90L4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
	HA62 36,17 90LA4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 355 Nm
	HA63 74,88 80C2	Unit: HA63 \| Ratio i: 74.88 \| Motor: 80C2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 346 Nm
	HA63 74,88 90S2	Unit: HA63 \| Ratio i: 74.88 \| Motor: 90S2 (frame printed 80C/90S) \| Power P1: 1.50 kW \| Output speed n2: 37.5 rpm \| Output torque M2: 346 Nm
	HA62 25,43 100L6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100L6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 380 Nm
	HA62 25,43 100LA6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LA6 (frame printed 100L/100LA) \| Power P1: 1.50 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 380 Nm
	HA62 44,95 90L4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 442 Nm
	HA62 44,95 90LA4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 442 Nm
	HA63 49,80 90L4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 479 Nm
	HA63 49,80 90LA4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 479 Nm
	HA63 60,25 90L4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 90L4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 579 Nm
	HA63 60,25 90LA4	Unit: HA63 \| Ratio i: 60.25 \| Motor: 90LA4 (frame printed 90L/90LA) \| Power P1: 1.50 kW \| Output speed n2: 23.2 rpm \| Output torque M2: 579 Nm
	HA51 1,45 90LB4	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 966.7 rpm \| Output torque M2: 18 Nm
	HA61 1,33 100LB6	Unit: HA61 \| Ratio i: 1.33 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 25 Nm
	HA61 2,50 90LB4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 560.0 rpm \| Output torque M2: 31 Nm
	HA51 2,94 90LB4	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 475.5 rpm \| Output torque M2: 36 Nm
	HA61 2,50 100LB6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 47 Nm
	HA61 4,38 90LB4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 319.3 rpm \| Output torque M2: 54 Nm
	HA51 4,75 90LB4	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 294.7 rpm \| Output torque M2: 58 Nm
	HA52 5,14 90LB4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 272.2 rpm \| Output torque M2: 62 Nm
	HA52 6,22 90LB4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 225.0 rpm \| Output torque M2: 75 Nm
	HA61 4,38 100LB6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 82 Nm
	HA52 7,73 90LB4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 181.0 rpm \| Output torque M2: 94 Nm
	HA52 5,14 100LB6	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 95 Nm
	HA61 7,75 90LB4	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 180.6 rpm \| Output torque M2: 95 Nm
	HA52 6,22 100LB6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 115 Nm
	HA62 6,22 100LB6	Unit: HA62 \| Ratio i: 6.22 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 115 Nm
	HA52 9,64 90LB4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 117 Nm
	HA62 9,64 90LB4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 145.2 rpm \| Output torque M2: 117 Nm
	HA52 7,73 100LB6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 142 Nm
	HA62 7,73 100LB6	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 142 Nm
	HA52 11,67 90LB4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 141 Nm
	HA62 11,67 90LB4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 120.0 rpm \| Output torque M2: 141 Nm
	HA52 14,50 90LB4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 176 Nm
	HA62 14,50 90LB4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 96.6 rpm \| Output torque M2: 176 Nm
	HA52 9,64 100LB6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 178 Nm
	HA62 9,64 100LB6	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 178 Nm
	HA52 16,91 90LB4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 205 Nm
	HA62 16,91 90LB4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 82.8 rpm \| Output torque M2: 205 Nm
	HA52 11,67 100LB6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 215 Nm
	HA62 11,67 100LB6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 215 Nm
	HA52 20,46 90LB4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 248 Nm
	HA62 20,46 90LB4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 68.4 rpm \| Output torque M2: 248 Nm
	HA52 14,50 100LB6	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 267 Nm
	HA62 14,50 100LB6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 267 Nm
	HA52 25,43 90LB4	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 308 Nm
	HA62 25,43 90LB4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 55.1 rpm \| Output torque M2: 308 Nm
	HA52 16,91 100LB6	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 312 Nm
	HA62 16,91 100LB6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 312 Nm
	HA52 29,89 90LB4	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 362 Nm
	HA62 29,89 90LB4	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 46.8 rpm \| Output torque M2: 362 Nm
	HA52 20,46 100LB6	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 377 Nm
	HA62 20,46 100LB6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 377 Nm
	HA62 36,17 90LB4	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 38.7 rpm \| Output torque M2: 438 Nm
	HA62 25,43 100LB6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LB6 \| Power P1: 1.85 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 468 Nm
	HA62 44,95 90LB4	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 31.1 rpm \| Output torque M2: 545 Nm
	HA63 49,80 90LB4	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90LB4 (brake TBS only) \| Power P1: 1.85 kW \| Output speed n2: 28.1 rpm \| Output torque M2: 591 Nm
	HA51 1,45 90L2	Unit: HA51 \| Ratio i: 1.45 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 1988.6 rpm \| Output torque M2: 10 Nm
	HA61 2,50 90L2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 1152.0 rpm \| Output torque M2: 17 Nm
	HA51 2,94 90L2	Unit: HA51 \| Ratio i: 2.94 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 978.1 rpm \| Output torque M2: 20 Nm
	HA61 1,33 112M6	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 30 Nm
	HA61 1,33 112MA6	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 30 Nm
	HA61 4,38 90L2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 656.8 rpm \| Output torque M2: 30 Nm
	HA51 4,75 90L2	Unit: HA51 \| Ratio i: 4.75 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 602.1 rpm \| Output torque M2: 33 Nm
	HA61 2,50 100LA4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 36 Nm
	HA61 2,50 112MR4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 36 Nm
	HA51 5,45 90L2	Unit: HA51 \| Ratio i: 5.45 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 528.0 rpm \| Output torque M2: 37 Nm
	HA61 2,50 112M6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 55 Nm
	HA61 2,50 112MA6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 55 Nm
	HA61 7,75 90L2	Unit: HA61 \| Ratio i: 7.75 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 371.6 rpm \| Output torque M2: 53 Nm
	HA52 7,73 90L2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 369.8 rpm \| Output torque M2: 53 Nm
	HA61 4,38 100LA4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 63 Nm
	HA61 4,38 112MR4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 63 Nm
	HA52 9,64 90L2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 296.6 rpm \| Output torque M2: 66 Nm
	HA52 5,14 100LA4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 73 Nm
	HA52 5,14 112MR4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 73 Nm
	HA52 11,67 90L2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 246.9 rpm \| Output torque M2: 79 Nm
	HA52 6,22 100LA4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 88 Nm
	HA52 6,22 112MR4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 88 Nm
	HA61 4,38 112M6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 97 Nm
	HA61 4,38 112MA6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 97 Nm
	HA52 14,50 90L2	Unit: HA52 \| Ratio i: 14.50 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 197.2 rpm \| Output torque M2: 99 Nm
	HA62 14,50 90L2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 197.2 rpm \| Output torque M2: 99 Nm
	HA52 7,73 100LA4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
	HA52 7,73 112MR4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
	HA62 7,73 100LA4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
	HA62 7,73 112MR4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 110 Nm
	HA52 5,14 112M6	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
	HA52 5,14 112MA6	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
	HA62 5,14 112M6	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
	HA62 5,14 112MA6	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 113 Nm
	HA52 16,91 90L2	Unit: HA52 \| Ratio i: 16.91 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 169.1 rpm \| Output torque M2: 115 Nm
	HA62 16,91 90L2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 169.1 rpm \| Output torque M2: 115 Nm
	HA52 6,22 112M6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
	HA52 6,22 112MA6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
	HA62 6,22 112M6	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
	HA62 6,22 112MA6	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 136 Nm
	HA52 9,64 100LA4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
	HA52 9,64 112MR4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
	HA62 9,64 100LA4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
	HA62 9,64 112MR4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 137 Nm
	HA52 20,46 90L2	Unit: HA52 \| Ratio i: 20.46 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 139.8 rpm \| Output torque M2: 139 Nm
	HA62 20,46 90L2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 139.8 rpm \| Output torque M2: 139 Nm
	HA52 11,67 100LA4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
	HA52 11,67 112MR4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
	HA62 11,67 100LA4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
	HA62 11,67 112MR4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 166 Nm
	HA52 7,73 112M6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
	HA52 7,73 112MA6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
	HA62 7,73 112M6	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
	HA62 7,73 112MA6	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 169 Nm
	HA52 25,43 90L2	Unit: HA52 \| Ratio i: 25.43 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 112.5 rpm \| Output torque M2: 173 Nm
	HA62 25,43 90L2	Unit: HA62 \| Ratio i: 25.43 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 112.5 rpm \| Output torque M2: 173 Nm
	HA52 14,50 100LA4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
	HA52 14,50 112MR4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
	HA62 14,50 100LA4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
	HA62 14,50 112MR4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 206 Nm
	HA52 9,64 112M6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
	HA52 9,64 112MA6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
	HA62 9,64 112M6	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
	HA62 9,64 112MA6	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 211 Nm
	HA52 29,89 90L2	Unit: HA52 \| Ratio i: 29.89 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 95.7 rpm \| Output torque M2: 203 Nm
	HA62 29,89 90L2	Unit: HA62 \| Ratio i: 29.89 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 95.7 rpm \| Output torque M2: 203 Nm
	HA52 16,91 100LA4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
	HA52 16,91 112MR4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
	HA62 16,91 100LA4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
	HA62 16,91 112MR4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 240 Nm
	HA52 11,67 112M6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
	HA52 11,67 112MA6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
	HA62 11,67 112M6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
	HA62 11,67 112MA6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 256 Nm
	HA62 36,17 90L2	Unit: HA62 \| Ratio i: 36.17 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 79.1 rpm \| Output torque M2: 246 Nm
	HA52 20,46 100LA4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
	HA52 20,46 112MR4	Unit: HA52 \| Ratio i: 20.46 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
	HA62 20,46 100LA4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
	HA62 20,46 112MR4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 291 Nm
	HA62 14,50 112M6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 318 Nm
	HA62 14,50 112MA6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 318 Nm
	HA62 44,95 90L2	Unit: HA62 \| Ratio i: 44.95 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 63.6 rpm \| Output torque M2: 306 Nm
	HA63 49,80 90L2	Unit: HA63 \| Ratio i: 49.80 \| Motor: 90L2 \| Power P1: 2.20 kW \| Output speed n2: 57.4 rpm \| Output torque M2: 332 Nm
	HA62 25,43 100LA4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LA4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 361 Nm
	HA62 25,43 112MR4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 112MR4 (frame printed 100LA/112MR) \| Power P1: 2.20 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 361 Nm
	HA62 16,91 112M6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 370 Nm
	HA62 16,91 112MA6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 370 Nm
	HA62 20,46 112M6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 448 Nm
	HA62 20,46 112MA6	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 45.5 rpm \| Output torque M2: 448 Nm
	HA62 25,43 112M6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 112M6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 557 Nm
	HA62 25,43 112MA6	Unit: HA62 \| Ratio i: 25.43 \| Motor: 112MA6 (frame printed 112M/112MA) \| Power P1: 2.20 kW \| Output speed n2: 36.6 rpm \| Output torque M2: 557 Nm
	HA61 2,50 100L2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 1160.0 rpm \| Output torque M2: 23 Nm
	HA61 2,50 100LA2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 1160.0 rpm \| Output torque M2: 23 Nm
	HA61 1,33 100LB4	Unit: HA61 \| Ratio i: 1.33 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 1072.5 rpm \| Output torque M2: 26 Nm
	HA61 1,33 112MS4	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 1072.5 rpm \| Output torque M2: 26 Nm
	HA61 1,33 112MB6	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 697.5 rpm \| Output torque M2: 40 Nm
	HA61 4,38 100L2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 661.4 rpm \| Output torque M2: 41 Nm
	HA61 4,38 100LA2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 661.4 rpm \| Output torque M2: 41 Nm
	HA61 2,50 100LB4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 49 Nm
	HA61 2,50 112MS4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 49 Nm
	HA52 5,14 100L2	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 48 Nm
	HA52 5,14 100LA2	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 48 Nm
	HA52 6,22 100L2	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 58 Nm
	HA52 6,22 100LA2	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 58 Nm
	HA61 2,50 112MB6	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 372.0 rpm \| Output torque M2: 75 Nm
	HA52 7,73 100L2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 72 Nm
	HA52 7,73 100LA2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 72 Nm
	HA62 7,73 100LA2	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LA2 (brake TBS only) \| Power P1: 3.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 72 Nm
	HA61 4,38 100LB4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 86 Nm
	HA61 4,38 112MS4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 323.9 rpm \| Output torque M2: 86 Nm
	HA52 9,64 100L2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
	HA52 9,64 100LA2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
	HA62 9,64 100L2	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
	HA62 9,64 100LA2	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 89 Nm
	HA52 5,14 100LB4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
	HA52 5,14 112MS4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
	HA62 5,14 100LB4	Unit: HA62 \| Ratio i: 5.14 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
	HA62 5,14 112MS4	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 276.1 rpm \| Output torque M2: 100 Nm
	HA52 11,67 100L2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
	HA52 11,67 100LA2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
	HA62 11,67 100L2	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
	HA62 11,67 100LA2	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 108 Nm
	HA52 6,22 100LB4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
	HA52 6,22 112MS4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
	HA62 6,22 100LB4	Unit: HA62 \| Ratio i: 6.22 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
	HA62 6,22 112MS4	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 228.2 rpm \| Output torque M2: 121 Nm
	HA61 4,38 112MB6	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 212.1 rpm \| Output torque M2: 132 Nm
	HA52 14,50 100L2	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
	HA52 14,50 100LA2	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
	HA62 14,50 100L2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
	HA62 14,50 100LA2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 134 Nm
	HA52 7,73 100LB4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
	HA52 7,73 112MS4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
	HA62 7,73 100LB4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
	HA62 7,73 112MS4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 183.6 rpm \| Output torque M2: 150 Nm
	HA52 5,14 112MB6	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 154 Nm
	HA62 5,14 112MB6	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 180.8 rpm \| Output torque M2: 154 Nm
	HA52 16,91 100L2	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
	HA52 16,91 100LA2	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
	HA62 16,91 100L2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
	HA62 16,91 100LA2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 156 Nm
	HA52 6,22 112MB6	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 186 Nm
	HA62 6,22 112MB6	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 149.5 rpm \| Output torque M2: 186 Nm
	HA52 9,64 100LB4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
	HA52 9,64 112MS4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
	HA62 9,64 100LB4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
	HA62 9,64 112MS4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 147.3 rpm \| Output torque M2: 187 Nm
	HA52 20,46 100L2	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
	HA52 20,46 100LA2	Unit: HA52 \| Ratio i: 20.46 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
	HA62 20,46 100L2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
	HA62 20,46 100LA2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 189 Nm
	HA52 11,67 100LB4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
	HA52 11,67 112MS4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
	HA62 11,67 100LB4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
	HA62 11,67 112MS4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 121.7 rpm \| Output torque M2: 226 Nm
	HA52 7,73 112MB6	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 231 Nm
	HA62 7,73 112MB6	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 120.3 rpm \| Output torque M2: 231 Nm
	HA62 25,43 100L2	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100L2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 112.9 rpm \| Output torque M2: 235 Nm
	HA62 25,43 100LA2	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LA2 (frame printed 100L/100LA) \| Power P1: 3.00 kW \| Output speed n2: 112.9 rpm \| Output torque M2: 235 Nm
	HA52 14,50 100LB4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
	HA52 14,50 112MS4	Unit: HA52 \| Ratio i: 14.50 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
	HA62 14,50 100LB4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
	HA62 14,50 112MS4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 97.9 rpm \| Output torque M2: 281 Nm
	HA52 9,64 112MB6	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 288 Nm
	HA62 9,64 112MB6	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 96.4 rpm \| Output torque M2: 288 Nm
	HA52 16,91 100LB4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
	HA52 16,91 112MS4	Unit: HA52 \| Ratio i: 16.91 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
	HA62 16,91 100LB4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
	HA62 16,91 112MS4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 84.0 rpm \| Output torque M2: 328 Nm
	HA52 11,67 112MB6	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 348 Nm
	HA62 11,67 112MB6	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 79.7 rpm \| Output torque M2: 348 Nm
	HA62 20,46 100LB4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 396 Nm
	HA62 20,46 112MS4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 69.4 rpm \| Output torque M2: 396 Nm
	HA62 14,50 112MB6	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 64.1 rpm \| Output torque M2: 433 Nm
	HA62 25,43 100LB4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 100LB4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 493 Nm
	HA62 25,43 112MS4	Unit: HA62 \| Ratio i: 25.43 \| Motor: 112MS4 (frame printed 100LB/112MS) \| Power P1: 3.00 kW \| Output speed n2: 55.8 rpm \| Output torque M2: 493 Nm
	HA62 16,91 112MB6	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MB6 \| Power P1: 3.00 kW \| Output speed n2: 55.0 rpm \| Output torque M2: 505 Nm
	HA61 2,50 100LB2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1148.0 rpm \| Output torque M2: 31 Nm
	HA61 2,50 112M2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1148.0 rpm \| Output torque M2: 31 Nm
	HA61 2,50 112MA2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1148.0 rpm \| Output torque M2: 31 Nm
	HA61 1,33 112M4	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1087.5 rpm \| Output torque M2: 34 Nm
	HA61 1,33 112MA4	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 1087.5 rpm \| Output torque M2: 34 Nm
	HA61 4,38 100LB2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 654.6 rpm \| Output torque M2: 55 Nm
	HA61 4,38 112M2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 654.6 rpm \| Output torque M2: 55 Nm
	HA61 4,38 112MA2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 654.6 rpm \| Output torque M2: 55 Nm
	HA61 2,50 112M4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 580.0 rpm \| Output torque M2: 64 Nm
	HA61 2,50 112MA4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 580.0 rpm \| Output torque M2: 64 Nm
	HA52 5,14 100LB2	Unit: HA52 \| Ratio i: 5.14 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 63 Nm
	HA52 5,14 112M2	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 63 Nm
	HA52 5,14 112MA2	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 558.1 rpm \| Output torque M2: 63 Nm
	HA52 6,22 100LB2	Unit: HA52 \| Ratio i: 6.22 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
	HA52 6,22 112M2	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
	HA52 6,22 112MA2	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
	HA62 6,22 100LB2	Unit: HA62 \| Ratio i: 6.22 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
	HA62 6,22 112M2	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
	HA62 6,22 112MA2	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 461.3 rpm \| Output torque M2: 77 Nm
	HA52 7,73 100LB2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
	HA52 7,73 112M2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
	HA52 7,73 112MA2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
	HA62 7,73 100LB2	Unit: HA62 \| Ratio i: 7.73 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
	HA62 7,73 112M2	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
	HA62 7,73 112MA2	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 371.1 rpm \| Output torque M2: 95 Nm
	HA61 4,38 112M4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 328.4 rpm \| Output torque M2: 113 Nm
	HA61 4,38 112MA4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 328.4 rpm \| Output torque M2: 113 Nm
	HA52 9,64 100LB2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
	HA52 9,64 112M2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
	HA52 9,64 112MA2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
	HA62 9,64 100LB2	Unit: HA62 \| Ratio i: 9.64 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
	HA62 9,64 112M2	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
	HA62 9,64 112MA2	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 297.6 rpm \| Output torque M2: 119 Nm
	HA52 5,14 112M4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
	HA52 5,14 112MA4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
	HA62 5,14 112M4	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
	HA62 5,14 112MA4	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 280.0 rpm \| Output torque M2: 131 Nm
	HA52 11,67 100LB2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
	HA52 11,67 112M2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
	HA52 11,67 112MA2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
	HA62 11,67 100LB2	Unit: HA62 \| Ratio i: 11.67 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
	HA62 11,67 112M2	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
	HA62 11,67 112MA2	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 246.0 rpm \| Output torque M2: 144 Nm
	HA52 6,22 112M4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
	HA52 6,22 112MA4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
	HA62 6,22 112M4	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
	HA62 6,22 112MA4	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 231.4 rpm \| Output torque M2: 158 Nm
	HA62 14,50 100LB2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 179 Nm
	HA62 14,50 112M2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 179 Nm
	HA62 14,50 112MA2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 197.9 rpm \| Output torque M2: 179 Nm
	HA52 7,73 112M4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
	HA52 7,73 112MA4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
	HA62 7,73 112M4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
	HA62 7,73 112MA4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 186.2 rpm \| Output torque M2: 197 Nm
	HA62 16,91 100LB2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 209 Nm
	HA62 16,91 112M2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 209 Nm
	HA62 16,91 112MA2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 169.7 rpm \| Output torque M2: 209 Nm
	HA52 9,64 112M4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
	HA52 9,64 112MA4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
	HA62 9,64 112M4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
	HA62 9,64 112MA4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 149.3 rpm \| Output torque M2: 246 Nm
	HA62 20,46 100LB2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 100LB2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 252 Nm
	HA62 20,46 112M2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112M2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 252 Nm
	HA62 20,46 112MA2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MA2 (frame printed 100LB/112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 140.3 rpm \| Output torque M2: 252 Nm
	HA52 11,67 112M4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
	HA52 11,67 112MA4	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
	HA62 11,67 112M4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
	HA62 11,67 112MA4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 123.4 rpm \| Output torque M2: 297 Nm
	HA62 14,50 112M4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 99.3 rpm \| Output torque M2: 369 Nm
	HA62 14,50 112MA4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 99.3 rpm \| Output torque M2: 369 Nm
	HA62 16,91 112M4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 85.1 rpm \| Output torque M2: 431 Nm
	HA62 16,91 112MA4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 85.1 rpm \| Output torque M2: 431 Nm
	HA62 20,46 112M4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112M4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 70.4 rpm \| Output torque M2: 521 Nm
	HA62 20,46 112MA4	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MA4 (frame printed 112M/112MA) \| Power P1: 4.00 kW \| Output speed n2: 70.4 rpm \| Output torque M2: 521 Nm
	HA61 1,33 112MB4	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 1072.5 rpm \| Output torque M2: 41 Nm
	HA61 2,50 112MB4	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 572.0 rpm \| Output torque M2: 78 Nm
	HA61 4,38 112MB4	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 326.1 rpm \| Output torque M2: 136 Nm
	HA52 5,14 112MB4	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 158 Nm
	HA62 5,14 112MB4	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 278.1 rpm \| Output torque M2: 158 Nm
	HA52 6,22 112MB4	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 191 Nm
	HA62 6,22 112MB4	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 229.8 rpm \| Output torque M2: 191 Nm
	HA52 7,73 112MB4	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 184.9 rpm \| Output torque M2: 238 Nm
	HA62 7,73 112MB4	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 184.9 rpm \| Output torque M2: 238 Nm
	HA52 9,64 112MB4	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 148.3 rpm \| Output torque M2: 297 Nm
	HA62 9,64 112MB4	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 148.3 rpm \| Output torque M2: 297 Nm
	HA62 11,67 112MB4	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 122.6 rpm \| Output torque M2: 359 Nm
	HA62 14,50 112MB4	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 98.6 rpm \| Output torque M2: 446 Nm
	HA62 16,91 112MB4	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MB4 (brake TBS only) \| Power P1: 4.80 kW \| Output speed n2: 84.6 rpm \| Output torque M2: 520 Nm
	HA61 1,33 112MB2	Unit: HA61 \| Ratio i: 1.33 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 2182.5 rpm \| Output torque M2: 23 Nm
	HA61 2,50 112MB2	Unit: HA61 \| Ratio i: 2.50 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 1164.0 rpm \| Output torque M2: 42 Nm
	HA61 4,38 112MB2	Unit: HA61 \| Ratio i: 4.38 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 663.7 rpm \| Output torque M2: 74 Nm
	HA52 5,14 112MB2	Unit: HA52 \| Ratio i: 5.14 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 565.8 rpm \| Output torque M2: 86 Nm
	HA62 5,14 112MB2	Unit: HA62 \| Ratio i: 5.14 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 565.8 rpm \| Output torque M2: 86 Nm
	HA52 6,22 112MB2	Unit: HA52 \| Ratio i: 6.22 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 467.7 rpm \| Output torque M2: 104 Nm
	HA62 6,22 112MB2	Unit: HA62 \| Ratio i: 6.22 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 467.7 rpm \| Output torque M2: 104 Nm
	HA52 7,73 112MB2	Unit: HA52 \| Ratio i: 7.73 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 376.3 rpm \| Output torque M2: 129 Nm
	HA62 7,73 112MB2	Unit: HA62 \| Ratio i: 7.73 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 376.3 rpm \| Output torque M2: 129 Nm
	HA52 9,64 112MB2	Unit: HA52 \| Ratio i: 9.64 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 301.8 rpm \| Output torque M2: 161 Nm
	HA62 9,64 112MB2	Unit: HA62 \| Ratio i: 9.64 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 301.8 rpm \| Output torque M2: 161 Nm
	HA52 11,67 112MB2	Unit: HA52 \| Ratio i: 11.67 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 249.4 rpm \| Output torque M2: 195 Nm
	HA62 11,67 112MB2	Unit: HA62 \| Ratio i: 11.67 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 249.4 rpm \| Output torque M2: 195 Nm
	HA62 14,50 112MB2	Unit: HA62 \| Ratio i: 14.50 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 200.7 rpm \| Output torque M2: 242 Nm
	HA62 16,91 112MB2	Unit: HA62 \| Ratio i: 16.91 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 172.1 rpm \| Output torque M2: 283 Nm
	HA62 20,46 112MB2	Unit: HA62 \| Ratio i: 20.46 \| Motor: 112MB2 (brake TBS only) \| Power P1: 5.50 kW \| Output speed n2: 142.2 rpm \| Output torque M2: 342 Nm
	HA51 1.45 90LL4	Legacy code (older catalogue edition) \| Unit: HA51 \| Ratio i: 1.45 \| Motor: 90LL4
	HA51 2.94 90LL4	Legacy code (older catalogue edition) \| Unit: HA51 \| Ratio i: 2.94 \| Motor: 90LL4
	HA51 4.75 90LL4	Legacy code (older catalogue edition) \| Unit: HA51 \| Ratio i: 4.75 \| Motor: 90LL4
	HA52 49.78 80A6	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80A6
	HA52 61.87 80A6	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80A6
	HA52 49.78 80A4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80A4
	HA52 61.87 80A4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80A4
	HA52 49.78 80B6	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80B6
	HA52 61.87 80B6	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80B6
	HA52 49.78 80B4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80B4
	HA52 61.87 80B4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 61.87 \| Motor: 80B4
	HA52 49.78 80C4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 49.78 \| Motor: 80C4
	HA52 9.64 90S4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 9.64 \| Motor: 90S4
	HA52 7.73 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 7.73 \| Motor: 90LL4
	HA52 9.64 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 9.64 \| Motor: 90LL4
	HA52 11.67 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 11.67 \| Motor: 90LL4
	HA52 14.50 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 14.50 \| Motor: 90LL4
	HA52 16.91 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 16.91 \| Motor: 90LL4
	HA52 20.46 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 20.46 \| Motor: 90LL4
	HA52 25.43 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 25.43 \| Motor: 90LL4
	HA52 29.89 90LL4	Legacy code (older catalogue edition) \| Unit: HA52 \| Ratio i: 29.89 \| Motor: 90LL4
	HA53 235.41 71A4	Legacy code (older catalogue edition) \| Unit: HA53 \| Ratio i: 235.41 \| Motor: 71A4
	HA61 4.38 80B4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 4.38 \| Motor: 80B4
	HA61 4.38 80C4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 4.38 \| Motor: 80C4
	HA61 10.67 90L4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 10.67 \| Motor: 90L4
	HA61 2.50 90LL4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 2.50 \| Motor: 90LL4
	HA61 4.38 90LL4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 4.38 \| Motor: 90LL4
	HA61 7.75 90LL4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 7.75 \| Motor: 90LL4
	HA61 1.33 100LA4	Legacy code (older catalogue edition) \| Unit: HA61 \| Ratio i: 1.33 \| Motor: 100LA4
	HA62 49.78 80B6	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 80B6
	HA62 61.87 80B6	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 80B6
	HA62 49.78 80B4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 80B4
	HA62 61.87 80B4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 80B4
	HA62 49.78 90S6	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 90S6
	HA62 61.87 90S6	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 90S6
	HA62 49.78 80C4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 80C4
	HA62 61.87 80C4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 80C4
	HA62 49.78 90S4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 49.78 \| Motor: 90S4
	HA62 61.87 90S4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 61.87 \| Motor: 90S4
	HA62 20.46 90LL4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 20.46 \| Motor: 90LL4
	HA62 25.43 90LL4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 25.43 \| Motor: 90LL4
	HA62 29.89 90LL4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 29.89 \| Motor: 90LL4
	HA62 36.17 90LL4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 36.17 \| Motor: 90LL4
	HA62 44.95 90LL4	Legacy code (older catalogue edition) \| Unit: HA62 \| Ratio i: 44.95 \| Motor: 90LL4
	HA53	Legacy code (older catalogue edition) \| Unit: HA53
	HA63	Legacy code (older catalogue edition) \| Unit: HA63
	HA51	Legacy code (older catalogue edition) \| Unit: HA51
	HA52	Legacy code (older catalogue edition) \| Unit: HA52
	HA61	Legacy code (older catalogue edition) \| Unit: HA61
	HA62	Legacy code (older catalogue edition) \| Unit: HA62

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →

Item added to your cart

Motovario HA Helical Inline Gearmotors (HA51-HA63, 0.09-5.5 kW)
