• Omron S8BA-LF Integrated Battery DC-DC UPS, 24VDC Input/Output, DIN Rail Mount
1 1

Omron S8BA-LF Integrated Battery DC-DC UPS, 24VDC Input/Output, DIN Rail Mount

Omron S8BA-LF Integrated Battery DC-DC UPS, 24VDC Input/Output, DIN Rail Mount

S8BA-LF Integrated battery type DC-DC UPS.

Key features

  • DIN rail mount
  • Ideal countermeasure for momentary power losses in IPC and controllers
S8BA-24D24D120LF UPS LF integrated 24V 5A/120W | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 5 A / 120 W | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-24D24D240LF UPS LF integrated 24V 10A/240W | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 10 A / 240 W | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-24D24D360LF UPS LF integrated 24V 15A/360W | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 15 A / 360 W | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-24D24D480LF UPS LF integrated 24V 20A/480W (UL: 16.7A/400W) | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 20 A / 480 W (UL: 16.7 A/400 W) | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-B120L Replacement Battery Pack 14.4V 1600mAh for S8BA-LF | Type: Replacement Battery Pack | Rated Voltage: 14.4 VDC | Rated Capacity: 1600 mAh | Weight: 0.3 kg | Compatible: S8BA-24D24D120LF(1pc) / 240LF(2pc) / 360LF(3pc) / 480LF(4pc)
S8BW-C01 Communication Cable RS-232C RJ45/Dsub9Pin 2m | Type: Communication Cable | Interface: RS-232C | Connectors: RJ45/Dsub9Pin | Length: 2 m | Compatible: S8BA series
S8BW-C02 Communication Cable CONTACT port RJ45/Discrete wire 2m | Type: Communication Cable | Interface: CONTACT port | Connectors: RJ45/Discrete wire | Length: 2 m | Compatible: S8BA series
UPSOmron
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron S8BA-LF Integrated Battery DC-DC UPS, 24VDC Input/Output, DIN Rail Mount

Brand Omron·UPS

Available part numbers (7)

S8BA-24D24D120LF, S8BA-24D24D240LF, S8BA-24D24D360LF, S8BA-24D24D480LF, S8BA-B120L, S8BW-C01, S8BW-C02

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S8BA-24D24D120LFUPS LF integrated 24V 5A/120W | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 5 A / 120 W | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-24D24D240LFUPS LF integrated 24V 10A/240W | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 10 A / 240 W | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-24D24D360LFUPS LF integrated 24V 15A/360W | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 15 A / 360 W | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-24D24D480LFUPS LF integrated 24V 20A/480W (UL: 16.7A/400W) | Type: UPS Main Unit | Input: 24 VDC | Output: 24 VDC / 20 A / 480 W (UL: 16.7 A/400 W) | Battery: Integrated | Mount: DIN rail | Series: S8BA-LF
S8BA-B120LReplacement Battery Pack 14.4V 1600mAh for S8BA-LF | Type: Replacement Battery Pack | Rated Voltage: 14.4 VDC | Rated Capacity: 1600 mAh | Weight: 0.3 kg | Compatible: S8BA-24D24D120LF(1pc) / 240LF(2pc) / 360LF(3pc) / 480LF(4pc)
S8BW-C01Communication Cable RS-232C RJ45/Dsub9Pin 2m | Type: Communication Cable | Interface: RS-232C | Connectors: RJ45/Dsub9Pin | Length: 2 m | Compatible: S8BA series
S8BW-C02Communication Cable CONTACT port RJ45/Discrete wire 2m | Type: Communication Cable | Interface: CONTACT port | Connectors: RJ45/Discrete wire | Length: 2 m | Compatible: S8BA series

Need a different model, or a part not listed here? Send us your parts list →
