• Omron S8JX-P Switch Mode Power Supply (300/600 W, Front-mount, No Fan)
1 1

Omron S8JX-P Switch Mode Power Supply (300/600 W, Front-mount, No Fan)

Omron S8JX-P Switch Mode Power Supply (300/600 W, Front-mount, No Fan)

S8JX-P Series with EMI Class B and Power Factor Correction is newly added to S8JX Series. 300 W and 600 W models.

Key features

  • Input: 100 to 240 VAC free voltage (80 to 370 VDC)
  • Output: 5/12/24/48 VDC
  • Compliant with EC Directives and safety standards (UL, EN)

Specifications

Input Voltage 100 to 240 VAC free (80 to 370 VDC)
Built-in Fan No
Mounting Front-mounting (bracket provided)
EMI Class B
Power Factor Correction Yes
S8JX-P30005N S8JX-P 300 W, 5 VDC / 60 A, Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 5 VDC | Output Current: 60 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P30012N S8JX-P 300 W, 12 VDC / 27 A, Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 12 VDC | Output Current: 27 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P30024N S8JX-P 300 W, 24 VDC / 14 A peak / 16.5 A (200 VAC), Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 24 VDC | Output Current: 14 A peak / 16.5 A (200 VAC) | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P30048N S8JX-P 300 W, 48 VDC / 7 A, Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 48 VDC | Output Current: 7 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60005N S8JX-P 600 W, 5 VDC / 120 A, Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 5 VDC | Output Current: 120 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60012N S8JX-P 600 W, 12 VDC / 53 A, Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 12 VDC | Output Current: 53 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60024N S8JX-P 600 W, 24 VDC / 27 A peak / 31 A (200 VAC), Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 24 VDC | Output Current: 27 A peak / 31 A (200 VAC) | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60048N S8JX-P 600 W, 48 VDC / 13 A, Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 48 VDC | Output Current: 13 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
Power SuppliesOmron
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron S8JX-P Switch Mode Power Supply (300/600 W, Front-mount, No Fan)

Brand Omron·Power Supplies

Available part numbers (8)

S8JX-P30005N, S8JX-P30012N, S8JX-P30024N, S8JX-P30048N, S8JX-P60005N, S8JX-P60012N, S8JX-P60024N, S8JX-P60048N

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S8JX-P30005NS8JX-P 300 W, 5 VDC / 60 A, Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 5 VDC | Output Current: 60 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P30012NS8JX-P 300 W, 12 VDC / 27 A, Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 12 VDC | Output Current: 27 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P30024NS8JX-P 300 W, 24 VDC / 14 A peak / 16.5 A (200 VAC), Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 24 VDC | Output Current: 14 A peak / 16.5 A (200 VAC) | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P30048NS8JX-P 300 W, 48 VDC / 7 A, Front-mounting, No Fan | Power Rating: 300 W | Output Voltage: 48 VDC | Output Current: 7 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60005NS8JX-P 600 W, 5 VDC / 120 A, Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 5 VDC | Output Current: 120 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60012NS8JX-P 600 W, 12 VDC / 53 A, Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 12 VDC | Output Current: 53 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60024NS8JX-P 600 W, 24 VDC / 27 A peak / 31 A (200 VAC), Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 24 VDC | Output Current: 27 A peak / 31 A (200 VAC) | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
S8JX-P60048NS8JX-P 600 W, 48 VDC / 13 A, Front-mounting, No Fan | Power Rating: 600 W | Output Voltage: 48 VDC | Output Current: 13 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: No | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes
