Omron SDV-F Voltage Sensor Single-function (FL/FM/FH, Overvoltage or Undervoltage, 24~240V Control)

SDV Voltage Sensor Single-function.

Key features

Overvoltage or Undervoltage detection (switch selectable)
AC and DC input

Specifications

Type	Voltage Sensor
Input	DC or AC
Detection	Overvoltage or Undervoltage
Series	SDV

SDV-FL2		Single-func FL 24VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 24 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FL3		Single-func FL 48VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 48 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FL4		Single-func FL 100/110VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 100/110 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FL5		Single-func FL 125VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 125 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FL6		Single-func FL 100/110VAC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 100/110 VAC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FL7		Single-func FL 200/220VAC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 200/220 VAC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FM2		Single-func FM 24VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 24 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FM3		Single-func FM 48VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 48 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FM4		Single-func FM 100/110VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 100/110 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FM5		Single-func FM 125VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 125 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FM6		Single-func FM 100/110VAC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 100/110 VAC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FM7		Single-func FM 200/220VAC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 200/220 VAC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH2		Single-func FH 24VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 24 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH3		Single-func FH 48VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 48 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH4		Single-func FH 100/110VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 100/110 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH5		Single-func FH 125VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 125 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH51		Single-func FH 200/220VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 200/220 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH6		Single-func FH 100/110VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 100/110 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH61		Single-func FH 120VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 120 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH7		Single-func FH 200/220VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 200/220 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
SDV-FH71		Single-func FH 240VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 240 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV

Monitoring RelaysOmron

21 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Omron SDV-F Voltage Sensor Single-function (FL/FM/FH, Overvoltage or Undervoltage, 24~240V Control)

Brand Omron·Monitoring Relays

Available part numbers (21)

SDV-FL2, SDV-FL3, SDV-FL4, SDV-FL5, SDV-FL6, SDV-FL7, SDV-FM2, SDV-FM3, SDV-FM4, SDV-FM5 + 11 more — see full table ↓

How to order

Send the Omron part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	SDV-FL2	Single-func FL 24VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 24 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FL3	Single-func FL 48VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 48 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FL4	Single-func FL 100/110VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 100/110 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FL5	Single-func FL 125VDC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 125 VDC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FL6	Single-func FL 100/110VAC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 100/110 VAC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FL7	Single-func FL 200/220VAC 4~240mV \| Type: Voltage Sensor \| Model: Single-function FL \| Control: 200/220 VAC \| Input: DC or AC \| Input Range: 4~240 mV \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FM2	Single-func FM 24VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 24 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FM3	Single-func FM 48VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 48 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FM4	Single-func FM 100/110VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 100/110 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FM5	Single-func FM 125VDC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 125 VDC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FM6	Single-func FM 100/110VAC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 100/110 VAC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FM7	Single-func FM 200/220VAC 0.2~12V \| Type: Voltage Sensor \| Model: Single-function FM \| Control: 200/220 VAC \| Input: DC or AC \| Input Range: 0.2~12 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH2	Single-func FH 24VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 24 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH3	Single-func FH 48VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 48 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH4	Single-func FH 100/110VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 100/110 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH5	Single-func FH 125VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 125 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH51	Single-func FH 200/220VDC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 200/220 VDC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH6	Single-func FH 100/110VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 100/110 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH61	Single-func FH 120VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 120 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH7	Single-func FH 200/220VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 200/220 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
	SDV-FH71	Single-func FH 240VAC 10~300V \| Type: Voltage Sensor \| Model: Single-function FH \| Control: 240 VAC \| Input: DC or AC \| Input Range: 10~300 V \| Detection: Overvoltage or Undervoltage \| Series: SDV
