PATLITE CLK / CLK-A LED Work Light with Tempered Glass Lens

PATLITE CLK / CLK-A LED Work Light with Tempered Glass Lens

Robust LED work light with tempered glass lens and aluminum or stainless steel body, with M12 connector, daisy-link or cable wiring.

Key features

  • IP66G, IP67G and IP69K protection
  • Aluminum (AG) or stainless steel (SG) body
  • M12 connector, daisy-link (CL) or 0.5 m cable versions
  • Daylight or natural white (300 mm)

Specifications

Rated Voltage 24V DC
Lens Tempered glass
Use Indoor
Mounting Direction All directions
Ambient Temperature -40 to +60°C
Ingress Protection IP66G, IP67G, IP69K
Approvals CE, RoHS10, UL (AG type only)
CLK2C-24AG-CD+FL005 Illuminated Length: 200mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 8.4 W | Mass: 0.526 kg
CLK3C-24AG-CD Illuminated Length: 300mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3C-24AG-CN Illuminated Length: 300mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Natural white | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3C-24SG-CD Illuminated Length: 300mm | Body Material: Stainless steel | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 1.490 kg
CLK3C-24SG-CN Illuminated Length: 300mm | Body Material: Stainless steel | Wiring: M12 connector | Luminous Color: Natural white | Power Consumption: 12.5 W | Mass: 1.490 kg
CLK3CL-24AG-CD Illuminated Length: 300mm | Body Material: Aluminum | Wiring: M12 connector Daisy link | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3CL-24SG-CD Illuminated Length: 300mm | Body Material: Stainless steel | Wiring: M12 connector Daisy link | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 1.490 kg
CLK6C-24AG-CD Illuminated Length: 600mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 25 W | Mass: 1.222 kg
CLK6CL-24AG-CD Illuminated Length: 600mm | Body Material: Aluminum | Wiring: M12 connector Daisy link | Luminous Color: Daylight | Power Consumption: 25 W | Mass: 1.222 kg
CLK2S-24AAG-CD Illuminated Length: 200mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Daylight | Power Consumption: 8.4 W | Mass: 0.526 kg
CLK3S-24AAG-CD Illuminated Length: 300mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3S-24AAG-CN Illuminated Length: 300mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Natural white | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK6S-24AAG-CD Illuminated Length: 600mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Daylight | Power Consumption: 25 W | Mass: 1.222 kg
LED Work LightsPATLITE
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

PATLITE CLK / CLK-A LED Work Light with Tempered Glass Lens

Brand PATLITE·LED Work Lights

Available part numbers (13)

CLK2C-24AG-CD+FL005, CLK3C-24AG-CD, CLK3C-24AG-CN, CLK3C-24SG-CD, CLK3C-24SG-CN, CLK3CL-24AG-CD, CLK3CL-24SG-CD, CLK6C-24AG-CD, CLK6CL-24AG-CD, CLK2S-24AAG-CD + 3 more — see full table ↓

How to order

Send the PATLITE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CLK2C-24AG-CD+FL005Illuminated Length: 200mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 8.4 W | Mass: 0.526 kg
CLK3C-24AG-CDIlluminated Length: 300mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3C-24AG-CNIlluminated Length: 300mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Natural white | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3C-24SG-CDIlluminated Length: 300mm | Body Material: Stainless steel | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 1.490 kg
CLK3C-24SG-CNIlluminated Length: 300mm | Body Material: Stainless steel | Wiring: M12 connector | Luminous Color: Natural white | Power Consumption: 12.5 W | Mass: 1.490 kg
CLK3CL-24AG-CDIlluminated Length: 300mm | Body Material: Aluminum | Wiring: M12 connector Daisy link | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3CL-24SG-CDIlluminated Length: 300mm | Body Material: Stainless steel | Wiring: M12 connector Daisy link | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 1.490 kg
CLK6C-24AG-CDIlluminated Length: 600mm | Body Material: Aluminum | Wiring: M12 connector | Luminous Color: Daylight | Power Consumption: 25 W | Mass: 1.222 kg
CLK6CL-24AG-CDIlluminated Length: 600mm | Body Material: Aluminum | Wiring: M12 connector Daisy link | Luminous Color: Daylight | Power Consumption: 25 W | Mass: 1.222 kg
CLK2S-24AAG-CDIlluminated Length: 200mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Daylight | Power Consumption: 8.4 W | Mass: 0.526 kg
CLK3S-24AAG-CDIlluminated Length: 300mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Daylight | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK3S-24AAG-CNIlluminated Length: 300mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Natural white | Power Consumption: 12.5 W | Mass: 0.676 kg
CLK6S-24AAG-CDIlluminated Length: 600mm | Body Material: Aluminum | Wiring: 0.5m cable | Luminous Color: Daylight | Power Consumption: 25 W | Mass: 1.222 kg
