    Samwon ACT Ecoflex Pod Clamps CCL / ECL / LCL

    Samwon ACT Ecoflex Pod Clamps CCL / ECL / LCL

    Die-cast aluminum clamps that fix Ecoflex pods at both ends: CCL for compact pods, ECL for standard pods and LCL for long-stroke and heavy pods.

    Key features

    • CCL: clamp for compact pods (2 to 7 pods)
    • ECL: clamp for standard pods (2 to 8 pods)
    • LCL: clamp for long-stroke and heavy-weight pods (4, 6, 8 pods)
    • Mount clamps with M4 bolts

    Specifications

    Material Die-cast aluminum
    Mounting Bolt M4
    CCL-2 Type: Compact clamp | No. of Pods: 2 | A: 47.0 mm | B: 38.1 mm | C: 29.1 mm
    CCL-3 Type: Compact clamp | No. of Pods: 3 | A: 61.0 mm | B: 52.1 mm | C: 43.1 mm
    CCL-4 Type: Compact clamp | No. of Pods: 4 | A: 74.9 mm | B: 66.0 mm | C: 57.0 mm
    CCL-5 Type: Compact clamp | No. of Pods: 5 | A: 88.9 mm | B: 80.0 mm | C: 71.0 mm
    CCL-6 Type: Compact clamp | No. of Pods: 6 | A: 102.9 mm | B: 94.0 mm | C: 85.1 mm
    CCL-7 Type: Compact clamp | No. of Pods: 7 | A: 116.9 mm | B: 108.0 mm | C: 99.1 mm
    ECL-2 Type: Standard clamp | No. of Pods: 2 | A: 57.2 mm | B: 47.7 mm | C: 38.2 mm
    ECL-3 Type: Standard clamp | No. of Pods: 3 | A: 76.3 mm | B: 66.8 mm | C: 57.3 mm
    ECL-4 Type: Standard clamp | No. of Pods: 4 | A: 95.4 mm | B: 85.9 mm | C: 76.4 mm
    ECL-5 Type: Standard clamp | No. of Pods: 5 | A: 114.5 mm | B: 105.0 mm | C: 95.5 mm
    ECL-6 Type: Standard clamp | No. of Pods: 6 | A: 133.6 mm | B: 124.1 mm | C: 114.6 mm
    ECL-7 Type: Standard clamp | No. of Pods: 7 | A: 152.7 mm | B: 143.2 mm | C: 133.7 mm
    ECL-8 Type: Standard clamp | No. of Pods: 8 | A: 171.8 mm | B: 162.3 mm | C: 152.8 mm
    LCL-4 Type: Long-stroke clamp | No. of Pods: 4 | A: 95.4 mm | B: 85.9 mm | C: 76.4 mm
    LCL-6 Type: Long-stroke clamp | No. of Pods: 6 | A: 133.6 mm | B: 124.1 mm | C: 114.6 mm
    LCL-8 Type: Long-stroke clamp | No. of Pods: 8 | A: 171.7 mm | B: 162.2 mm | C: 152.7 mm
    Cable AccessoriesSamwon ACT
    16 product codes available in this family
    Sourced direct from KoreaExport-ready supplyCompetitive pricing
    RFQ List 0 Email about this

    Need a different model, or a part not listed here? Send us your parts list →

    Samwon ACT Ecoflex Pod Clamps CCL / ECL / LCL

    Brand Samwon ACT·Cable Accessories

    Available part numbers (16)

    CCL-2, CCL-3, CCL-4, CCL-5, CCL-6, CCL-7, ECL-2, ECL-3, ECL-4, ECL-5 + 6 more — see full table ↓

    How to order

    Send the Samwon ACT part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

    RFQ List 0 →
    View full details
    Product codes & specifications
    0 selected
    RFQ List (0)
    Product codeSpec
    CCL-2Type: Compact clamp | No. of Pods: 2 | A: 47.0 mm | B: 38.1 mm | C: 29.1 mm
    CCL-3Type: Compact clamp | No. of Pods: 3 | A: 61.0 mm | B: 52.1 mm | C: 43.1 mm
    CCL-4Type: Compact clamp | No. of Pods: 4 | A: 74.9 mm | B: 66.0 mm | C: 57.0 mm
    CCL-5Type: Compact clamp | No. of Pods: 5 | A: 88.9 mm | B: 80.0 mm | C: 71.0 mm
    CCL-6Type: Compact clamp | No. of Pods: 6 | A: 102.9 mm | B: 94.0 mm | C: 85.1 mm
    CCL-7Type: Compact clamp | No. of Pods: 7 | A: 116.9 mm | B: 108.0 mm | C: 99.1 mm
    ECL-2Type: Standard clamp | No. of Pods: 2 | A: 57.2 mm | B: 47.7 mm | C: 38.2 mm
    ECL-3Type: Standard clamp | No. of Pods: 3 | A: 76.3 mm | B: 66.8 mm | C: 57.3 mm
    ECL-4Type: Standard clamp | No. of Pods: 4 | A: 95.4 mm | B: 85.9 mm | C: 76.4 mm
    ECL-5Type: Standard clamp | No. of Pods: 5 | A: 114.5 mm | B: 105.0 mm | C: 95.5 mm
    ECL-6Type: Standard clamp | No. of Pods: 6 | A: 133.6 mm | B: 124.1 mm | C: 114.6 mm
    ECL-7Type: Standard clamp | No. of Pods: 7 | A: 152.7 mm | B: 143.2 mm | C: 133.7 mm
    ECL-8Type: Standard clamp | No. of Pods: 8 | A: 171.8 mm | B: 162.3 mm | C: 152.8 mm
    LCL-4Type: Long-stroke clamp | No. of Pods: 4 | A: 95.4 mm | B: 85.9 mm | C: 76.4 mm
    LCL-6Type: Long-stroke clamp | No. of Pods: 6 | A: 133.6 mm | B: 124.1 mm | C: 114.6 mm
    LCL-8Type: Long-stroke clamp | No. of Pods: 8 | A: 171.7 mm | B: 162.2 mm | C: 152.7 mm
