PATLITE LR7 Signal Tower, Φ70 mm, Pre-assembled Models

PATLITE LR7 Signal Tower, Φ70 mm, Pre-assembled Models

Pre-assembled Φ70 mm LED signal tower with 1 to 5 tiers, available with or without flashing/buzzer function.

Key features

  • Pre-assembled tower; LED units, buzzer unit and body can also be ordered separately to change the number of tiers
  • Tool-free assembly: attach LED units one at a time to the body unit
  • Continuous lighting, 60 flashes/min flashing and 4 buzzer sounds with DIP-switch selection
  • Direct mount, pole mount with L-bracket, circular bracket or folding bracket versions
  • Compatible with the WD wireless data acquisition system

Specifications

Size Φ70 mm
Buzzer Sound Level 90 dB
Use Indoor
Mounting Direction Upright
Light Source LED
Flash Rate 60 flashes/min
Alarm Sounds 4 patterns (DIP switch)
Supported Transistors NPN/PNP (100-240V AC type: NPN)
Ingress Protection IP65 (LJ type IP54)
LR7-102WJNW-R Tiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red | Lens: Colored | Power Consumption: 1.3 W | Mass: 0.31 kg
LR7-102WJNW-Y Tiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Amber | Lens: Colored | Power Consumption: 1.3 W | Mass: 0.31 kg
LR7-102WJNW-G Tiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Green | Lens: Colored | Power Consumption: 1.3 W | Mass: 0.31 kg
LR7-202WJNW-RY Tiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.37 kg
LR7-202WJNW-RG Tiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Green | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.37 kg
LR7-302WJNW-RYG Tiers: 3 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber, Green | Lens: Colored | Power Consumption: 3.9 W | Mass: 0.435 kg
LR7-402WJNW-RYGB Tiers: 4 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue | Lens: Colored | Power Consumption: 5.2 W | Mass: 0.5 kg
LR7-502WJNW-RYGBC Tiers: 5 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue, White | Lens: Colored | Power Consumption: 6.5 W | Mass: 0.57 kg
LR7-102WJBW-R Tiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.38 kg
LR7-102WJBW-Y Tiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Amber | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.38 kg
LR7-102WJBW-G Tiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Green | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.38 kg
LR7-202WJBW-RY Tiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber | Lens: Colored | Power Consumption: 3.9 W | Mass: 0.44 kg
LR7-202WJBW-RG Tiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Green | Lens: Colored | Power Consumption: 3.9 W | Mass: 0.44 kg
LR7-302WJBW-RYG Tiers: 3 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber, Green | Lens: Colored | Power Consumption: 5.2 W | Mass: 0.505 kg
LR7-402WJBW-RYGB Tiers: 4 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue | Lens: Colored | Power Consumption: 6.5 W | Mass: 0.57 kg
LR7-502WJBW-RYGBC Tiers: 5 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue, White | Lens: Colored | Power Consumption: 7.8 W | Mass: 0.635 kg
Signal TowersPATLITE
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

PATLITE LR7 Signal Tower, Φ70 mm, Pre-assembled Models

Brand PATLITE·Signal Towers

Available part numbers (16)

LR7-102WJNW-R, LR7-102WJNW-Y, LR7-102WJNW-G, LR7-202WJNW-RY, LR7-202WJNW-RG, LR7-302WJNW-RYG, LR7-402WJNW-RYGB, LR7-502WJNW-RYGBC, LR7-102WJBW-R, LR7-102WJBW-Y + 6 more — see full table ↓

How to order

Send the PATLITE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
LR7-102WJNW-RTiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red | Lens: Colored | Power Consumption: 1.3 W | Mass: 0.31 kg
LR7-102WJNW-YTiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Amber | Lens: Colored | Power Consumption: 1.3 W | Mass: 0.31 kg
LR7-102WJNW-GTiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Green | Lens: Colored | Power Consumption: 1.3 W | Mass: 0.31 kg
LR7-202WJNW-RYTiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.37 kg
LR7-202WJNW-RGTiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Green | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.37 kg
LR7-302WJNW-RYGTiers: 3 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber, Green | Lens: Colored | Power Consumption: 3.9 W | Mass: 0.435 kg
LR7-402WJNW-RYGBTiers: 4 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue | Lens: Colored | Power Consumption: 5.2 W | Mass: 0.5 kg
LR7-502WJNW-RYGBCTiers: 5 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: No | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue, White | Lens: Colored | Power Consumption: 6.5 W | Mass: 0.57 kg
LR7-102WJBW-RTiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.38 kg
LR7-102WJBW-YTiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Amber | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.38 kg
LR7-102WJBW-GTiers: 1 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Green | Lens: Colored | Power Consumption: 2.6 W | Mass: 0.38 kg
LR7-202WJBW-RYTiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber | Lens: Colored | Power Consumption: 3.9 W | Mass: 0.44 kg
LR7-202WJBW-RGTiers: 2 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Green | Lens: Colored | Power Consumption: 3.9 W | Mass: 0.44 kg
LR7-302WJBW-RYGTiers: 3 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber, Green | Lens: Colored | Power Consumption: 5.2 W | Mass: 0.505 kg
LR7-402WJBW-RYGBTiers: 4 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue | Lens: Colored | Power Consumption: 6.5 W | Mass: 0.57 kg
LR7-502WJBW-RYGBCTiers: 5 | Rated Voltage: 24V DC | Mounting/Wiring: Direct mount / cable | Flashing/Buzzer: Yes | Body Color: Off-white | Luminous Color: Red, Amber, Green, Blue, White | Lens: Colored | Power Consumption: 7.8 W | Mass: 0.635 kg
