PATLITE NBM-D88NN Network Interface Converter, 8 Inputs / 8 Outputs

Ethernet interface converter with 8 digital inputs and 8 digital outputs that links contact signals with network commands, e-mail and SNMP traps. 8 inputs and 8 outputs (NPN).

Key features

Digital input condition setup: duration, AND and count conditions trigger outputs or network actions
Can send RSH commands, PNS socket commands, SNMP traps and e-mails on input conditions
Supports HTTP, NTP, Socket (PHN/PNS), SMTP, SNMP v1/v2c, DHCP, DNS, POP3 and RSH

Specifications

Rated Voltage	24V DC
AC Adapter	Not included (optional ADP-001)
Power Consumption	14 W
Mass	1.15 kg
Supported Transistors	NPN
Network	Ethernet 10BASE-T/100BASE-TX, RJ-45
Ambient Temperature	0 to +40°C
Ingress Protection	IP20
Use	Indoor
Approvals	CE, UL, FCC

NBM-D88NN

Inputs/Outputs: 8 / 8

Interface ConvertersPATLITE

1 product code available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

PATLITE NBM-D88NN Network Interface Converter, 8 Inputs / 8 Outputs

Brand PATLITE·Interface Converters

Available part numbers (1)

NBM-D88NN

How to order

Send the PATLITE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
